Empire Comfort Systems DVCT35CBN95N-1 Installation Instructions And Owner's Manual
Direct vent gas fireplace heater fireplace insert models
Hide thumbs
Also See for DVCT35CBN95N-1:
- Homeowner's manual (16 pages) ,
- Homeowner's manual (16 pages) ,
- Installation instructions manual (32 pages)
Table of Contents
Advertisement
INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
WARNING
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death or
property damage.
— Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do
not use any phone in your building.
•
Leave the building immediately.
•
Immediately call your gas supplier
from a neighbor's phone. Follow the
gas supplier's instructions.
•
If you cannot reach your gas supplier,
call the fire department.
— Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
DANGER
A barrier designed to reduce the risk of burns from the
hot viewing glass is provided with this appliance and shall
be installed for the protection of children and other at-risk
individuals.
INSTALLATION INSTRUCTIONS
HOT GLASS
WILL
CAUSE BURNS.
DO NOT TOUCH
UNTIL COOLED.
NEVER
ALLOW CHILDREN
TO TOUCH GLASS.
38102
DIRECT VENT
GAS FIREPLACE HEATER
FIREPLACE
INSERT MODELS
DVCT(30,35)CBN95(N,P)-1
This appliance may be installed into a listed
wood-burning fireplace in an aftermarket,
permanently located, manufactured home
(USA only) or mobile home, where not
prohibited by state or local codes.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certified kit is used.
GLASS
GAS-FIRED
UL FILE NO. MH30033
This fireplace is design
certified in accordance
with American National
Standard/CSA Stan-
dard ANSI Z21.88/CSA
2.33 and by Underwrit-
ers Laboratories as a
Direct-Vent Gas Fire-
place Heater and shall
be installed according
to these instructions.
Page 1
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Empire Comfort Systems DVCT35CBN95N-1
Summary of Contents for Empire Comfort Systems DVCT35CBN95N-1
- Page 1 INSTALLATION INSTRUCTIONS 38102 INSTALLER: DIRECT VENT GAS FIREPLACE HEATER Leave this manual with the appliance. CONSUMER: FIREPLACE Retain this manual for future reference. INSERT MODELS DVCT(30,35)CBN95(N,P)-1 WARNING FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death or property damage.
-
Page 2: Table Of Contents
TABLE OF CONTENTS SECTION PAGE Attention Installer ............................3 Before You Start ............................4 Carton Contents & Hardware Pack ......................5 Specifications ............................. 6 Accessories ..............................7 Venting Accessories ........................... 7 Introduction .............................. 8-9 Fireplace Insert Dimensions ........................10 Minimum Fireplace Opening Dimensions ....................11 Mantel and Trim Clearances ........................11 Gas Supply ............................ -
Page 3: Attention Installer
ATTENTION INSTALLER: Fireplace Installation Checklist Use this checklist in conjunction with the instructions in this manual. Customer: _____________________________________ Date Installed: __________________________________ Lot/Address: ___________________________________ Fireplace Location: ______________________________ _______________________________________________ Installer: _______________________________________ Model: ________________________________________ Dealer Phone #: _________________________________ Serial #: ________________________________________ _______________________________________________ FIREPLACE INSTALLATION COMMENTS ____________________ Verified clearances to combustibles (pg. -
Page 4: Before You Start
BEFORE YOU START Preparation WARNING This fireplace insert and its components are safe when installed Read and follow these safety precautions prior to operating in accordance with this Installation Manual. Report any parts this appliance. Failure to follow these precautions may damaged in shipment to your dealer. -
Page 5: Carton Contents & Hardware Pack
CARTON CONTENTS & HARDWARE PACK Rockwool QUANTITY SUPPLIED INDEX NUMBER DESCRIPTION LOCATION DVCT30 DVCT35 Fireplace Insert In Carton Glass Door Assembly Front of Insert Barrier Screen Assembly Front of Insert Rockwool Embers In Envelope AA Batteries In Envelope AAA Batteries In Envelope Remote In Bag Inside Insert... -
Page 6: Specifications
SPECIFICATIONS DVCT30CBN95(N,P)-1 DVCT35CBN95(N,P)-1 Propane Natural Propane Natural Input BTU/Hr Maximum (Both Burners High) 28,500 30,000 35,000 39,000 Input BTU/Hr Minimum (Both Burners Low) 22,000 19,500 28,500 25,500 Input BTU/Hr Minimum (Only Front Burner Low) 10,000 8,500 11,000 10,000 KWH (Maximum) 8.34 8.78 10.2... -
Page 7: Accessories
ACCESSORIES DVCT30 DVCT35 DVCT30 LINER (REQUIRED) SURROUNDS (REQUIRED) SURROUNDS (REQUIRED) Description DVCT30 DVCT35 Description Model Description Model Porcelain Black DVP30CPKR DVP35CPKR (Black) Number (Black) Number Rustic Brick DVP30CPMB DVP35CPMB 36 x 24 x 1 DS30631BL 40 x 29 x 1 DS35631BL Cottage Brick DVP30CPTB... -
Page 8: Introduction
Confirm orifice • Only surrounds supplied by the manufacturer shall be used size with Empire Comfort Systems. in the installation of this appliance. Canadian High Altitude •... -
Page 9: Introduction
INTRODUCTION (CONT’D) • This appliance comes standard with a 120 VAC cord assembly to accommodate the blower accessory. A junction box may be installed in a bottom back corner of the existing solid fuel masonry or factory built fireplace to connect the cord assembly, or the supplied power cord may be routed out onto the hearth to a nearby outlet. -
Page 10: Fireplace Insert Dimensions
FIREPLACE INSERT DIMENSIONS FLUE INTAKE 4" DIA 3" DIA 2.375” DVCT30 DVCT35 INDEX DIMENSION DESCRIPTION LETTER DIMENSIONS IN INCHES The maximum height of fireplace face The maximum width of fireplace face 30-11/16 34-3/4 The maximum depth of fireplace 17-9/16 18-9/16 The height of the fireplace opening (not shown) 15-3/4 20-3/4... -
Page 11: Minimum Fireplace Opening Dimensions
MINIMUM FIREPLACE OPENING DIMENSIONS DIMENSIONS (in inches) 8” MIN. DIA. FLUE REQUIRED Front Rear Model No. Height A Depth C Width B Width D DVCT30 19-1/2 31-1/4 DVCT35 24-1/2 35-1/4 25-3/4 *Subtract surround depth from dimension C. MANTEL AND TRIM CLEARANCES Combustible Material CEILING 12”... -
Page 12: Gas Supply
GAS SUPPLY If the fireplace where you are installing the insert has no gas line Use the following gas connectors: access hole, drill an access hole of 1.5 inch (37.5 mm) or less — ANSI Z21.24 Appliance Connectors of Corrugated Metal through the lower sides or bottom of the firebox. -
Page 13: Electrical Considerations
GAS SUPPLY (CONT’D) Installing a New Main Gas Shut-Off Valve Checking Manifold Pressures Each appliance must have its own manual gas shut-off valve Both Propane and Natural Gas valves have a built-in pressure located in close proximity. Where none exists, or where its size regulator. -
Page 14: Fireplace Preparation
FIREPLACE PREPARATION Before You Start 8” DIAMETER FLUE (MIN.) Before installing, read these instructions and the Vent Kit Instructions to ensure proper installation. Consult local Building Codes before beginning the Installation. INTERIOR BAFFLES, NOTICE: Cutting the sheet metal parts of an existing fireplace to SMOKE SHIELDS, AND install the fireplace insert is prohibited unless mentioned below. -
Page 15: Venting
VENTING Vent System Installation Precautions NOTICE: The minimum vertical vent rise is 10 feet and the Before installing vent kits, read these instructions and the vent kit maximum vertical vent rise is 40 feet. These dimensions are Instructions. Consult local Building Codes before beginning the measured from the starting collars of the unit to the end of the Installation. -
Page 16: Vertical Termination
VERTICAL TERMINATION Determining Minimum Vent Height Above the Roof. Vertical Applications The Gas Fireplace Insert has been approved for vertical NOTICE: Major U.S. building codes specify minimum chimney installations up to 40 feet in height (starting of collars to end height above the roof top. -
Page 17: Installation
INSTALLATION CAUTION CAUTION The vent cap and vent tubing have sharp edges. Wear Seal off the area between the termination cap and the top gloves when unpacking and installing. of the solid-fuel chimney opening into which the vent cap is installed to avoid downdrafts and/or cold air problems. Connect the Vent Pipe and Install the Fireplace Insert For fireplace vent pipe and insert installation refer to information 1 through 6 below. - Page 18 INSTALLATION (CONT’D) 8. Set insert in front of fireplace opening. 14. Work the insert into the fireplace cavity as you pull forward 9. If necessary, remove the 2 hex screws from the vent slide on the vent slide plate. Do not use excessive force on the plate assembly.
- Page 19 INSTALLATION (CONT’D) 18. Remove barrier screen assembly by lifting the screen 20. Sync Remote. assembly and pulling it toward you. See Figure 16. Push the sync button to the right of the insert. See Figure 18. With the batteries already installed in the transmitter, push the CAUTION ON button.
- Page 20 INSTALLATION (CONT’D) 21. Reinstall door assembly removed in step 19. 22. Adjust damper and air shutter for perfect burn. Allow about 15 minutes for flame to stabilize. See Figures 19-21 and the following two tables. R E W IN G S C R E T A IN S E D 1 /4 C L O...
- Page 21 INSTALLATION (CONT’D) REAR BURNER AIR SHUTTER GUIDELINES 24. Seasonal switch must be in "ON" position. DVCT30 VENT LENGTH Propane Natural 10 ft Open Full Closed 20 ft 1/2 - 3/4 Closed Full Closed 30 ft 1/2 - 3/4 Closed Full Closed 40 ft 1/2 Closed Full Closed...
-
Page 22: Ipi System Electronic System Wiring Diagram
IPI ELECTRONIC SYSTEM WIRING DIAGRAM BLUE PINK BLUE BLACK BLACK SOLENOID VALVE SYNC BUTTON If any of the original wire as supplied with this unit must be WARNING replaced, it must be replaced with equivalent gauge and ELECTRICAL GROUNDING INSTRUCTIONS temperature rated wire. -
Page 23: Intermittent Pilot Lighting Instructions
INTERMITTENT PILOT LIGHTING INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING WARNING If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance is equipped with an ignition device which C. -
Page 24: Safety Information For Users Of Propane
SAFETY INFORMATION FOR USERS OF PROPANE-GAS Propane (Propane-Gas) is a flammable gas which can Propane-Gas may stratify in a closed area, and the odor intensity cause fires and explosions. In its natural state, propane is could vary at different levels. Since it is heavier than air, there odorless and colorless. -
Page 25: Intermittent Control System Troubleshooting
INTERMITTENT CONTROL SYSTEM TROUBLESHOOTING Brief Description of the Components The controls are designed to be used with either Propane or Natural Gas and can be converted by use of an OEM supplied conversion kit. The Intermittent Fireplace Control (IFC) is an automatic gas ignition system based on a single microcontroller core. - Page 26 INTERMITTENT CONTROL SYSTEM TROUBLESHOOTING PROBLEM OBSERVED POSSIBLE CAUSE CORRECTIVE MEASURE What To Do If You Smell Gas • Do not try to light any appliance. Gas odor during setup • Do not touch any electrical switch; • Do not use any phone in your building. Gas Leak •...
-
Page 27: Intermittent Control System Troubleshooting
INTERMITTENT CONTROL SYSTEM TROUBLESHOOTING PROBLEM OBSERVED POSSIBLE CAUSE CORRECTIVE MEASURE Low gas pressure Check gas supply pressure Loose sensor wire Check wire connection Valve not grounded well Check ground connections Clogged or dirty burner ports Clean burner ports Burner lights but does not Move remote away from fireplace Room temperature is higher than stay lit while pilot remains on... -
Page 28: Insert Parts List
INSERT PARTS LIST PART NUMBER INDEX DVCT30 DVCT35 DESCRIPTION NATURAL PROPANE NATURAL PROPANE DVCT30 Firebox R12428 R12428 R12428 R12428 Blower Assembly 37911 37911 38529 38529 Slider Gasket Assembly R12258 R12258 Catalyst R12488 R12488 R12258 R12258 Catalyst R12279 R12279 R12476 R12476 Catalyst R11837 R11837... -
Page 29: Insert Parts View
INSERT PARTS LIST (CONT’D) PART NUMBER INDEX DVCT30 DVCT35 DESCRIPTION NATURAL PROPANE NATURAL PROPANE R11550 R11550 R11550 R11550 Transmitter - Remote R11515 R11515 R11515 R11515 Cord Set R12462 R12462 R12462 R12462 Module - Switch/Blower Wire Harness (2 req’d) R11524 R11524 R11524 R11524 Receiver Wire Harness... -
Page 30: Master Parts Distributor List
This list changes from time to time. For the current list, please click on the Master Parts button at www.empirecomfort.com. Please note: Master Parts Distributors are independent businesses that stock the most commonly ordered Original Equipment repair parts for Heaters, Grills, and Fireplaces manufactured by Empire Comfort Systems Inc. Dey Distributing F. -
Page 31: Important Safety Information
IMPORTANT SAFETY INFORMATION Maintenance Precautions • Young children should be carefully supervised when they are Installation and repair should be done by a qualified service person. in the same room as the fireplace. Toddlers, young children, The fireplace should be inspected before use and at least annually and others may be susceptible to accidental contract burns. -
Page 32: Warranty
WARRANTY Empire Comfort Systems Inc. warranties this hearth product to be free from defects at the time of purchase and for the periods specified below. Hearth products must be installed by a qualified technician and must be maintained and operated safely, in accordance with the instructions in the owner’s manual.
