BPDW8913WR
2.4GHz Digtal Wireless
Car Rearview System
Connection WiFi:
1. Click on the "
" icon.
2. Click on "Wi-Fi", then select the camera to connect too. The initial SSID of the device
is "WIFICAMERA". Then type in the password of the devices
(Default password: 88888888).
WIFICAMERA
Security
Wi-Fi
WP2 PSK
WIFICAMERA
Password
Secured with WP2
Cancel
View the video:
Open the
APP, if the connection between the wifi tool and the mobile device is
successful the app will be highlighted. Then the image would be transmitted from the
camera to the
app. As shown in the figure below, the camera is showning real-time
monitoring in the app. The user would also be able to press
icon to refresh the image
Record
Take a
Connecting
Video
Settings
a Video
Camera
Playback
Notice
* When set WIFI signal to connect the mobile phone, please close the WIFI signal
previously opened.
*
image display time is relate to the CPU memory, software version, working
,
software number of mobile phone.
* when the background is black or the image is still, please exit the APP, and check
whether the wifi connection is normal then click again the APP icon to enter into
.
the software interface.
Packing List
Camera
Emitter
License Plate
License Plate
In-line Wire
Grommet
Nuts & Bolts
Screws (Optional)
Connectors
Specifications
WIFI car rear view
Items
GL8912
Items
Operation Voltage
Power Supply
12V DC
Consumption Current
150mA MAX
Operation Current
Operation Frequency
Video output
0.9
~1 2
. Vp-p 75Ω
Night Vision Range
>3m
Wireless Protocol
Image Sensor
1/4inch CMOS
640×480 pixels
Encryption Mode
Effective Pixels
Video Format
NTSC/PAL
1/60s-12ns(NTSC) sec
Modulation Mode
Electronic Exposure Time
1/50s-12.5ns(PAL) sec
Minimum illumination
<5 Lux
Transmission Distance
Horizontal View Angle
80
O
With No Obstacle
- 10~
Weight
Operation Temperature
+50
O
C
Storage Temperature
- 20~
+60
O
C
Dimensions
Operation Humidity
15%~85%RH
Operation Temperature
Dimensions
370 X 55 X 35MM
Storage Temperature
Weight
140g
Operation Humidity
* All the specifications are subject to minor change without prior notice
Settings:
Press this
icon to enter into the settings menu you can change the default factory SSID
and password of the wifi camera tool, and clicking
will show whether the change is successful,
and clicking
to cancel the new SSID set.
Connect
Notice
* User could press the RESET button of the emitter to renew the default factory
SSID and password.
* When the user changes the SSID and password, the user shall forget the network in the
"Settings" , and then reconnect the new network. Otherwise login error will remain displayed.
The specific steps to clear network memory are as follows. and then follow the above WIFI connection
method to reconnect the new network.
Wi-Fi
WIFICAMERA
Not in range
Installation
Installation instructions for the camera:
Cable Ties
1. In the proper position of rear license plate
drill a hole for mounting screws
WIFI transmitter box
GT4068
12V DC
150mA(MAX)
2400- 2483.5MHz
IEEE 802.11b, IEEE 802.11g,
3. Move the camera orientation to adjust the
IEEE 802.n (1T1R Modes)
display effect
WPA2
：
802.11b
DSSS (CCK, DQPSK,
：
DBPSK)•802.11g/n
OFDM
(BPSK, QPSK, 16QAM, 64QAM)
Installation instructions for the emitter:
≥ 10m
60±5g
71 X 35.5 X 12.3MM
- 10~
+50
O
C
- 20~
+60
O
C
20%~90%RH
Operations for iOS Apple system client
Installation app Software
1. Turn on the iOS device and enter the App Store
2. Search "Sight Wifi" app.
3. Install the Sight Wifi app
Connection WiFi:
1. Click on the "
" icon in the main interface of the iOS device.
2. Click on "Wi-Fi", then select the camera to connect too. The initial SSID of the device
is "WIFICAMERA". Then type in the password of the devices
(Default password: 88888888).
WIFICAMERA
View the video:
Open the
APP, if the connection between the wifi tool and the mobile device is
successful the app will be highlighted. Then the image would be transmitted from the
camera to the
app. As shown in the figure below, the camera is showning real-time
monitoring in the app. The user would also be able to press
WIFICAMERA
Settings
Connecting Camera
2. Use a Screwdriver to ensure that the first
screw is properly screwed into the drill hole.
When the camera is fixed, put the lead-wire of the camera through the car trunk.
Notice
* The positive and negative pole of the emitter box's power cable are connected
to the positive and negative pole of the rear lamp of the car.
* Never reverse the positive and negative pole. Reversing the poles
can damage the emitter box and camera, rendering them unusable.
* The antenna of the emitter box should not be placed near any metal part of the car.
This can negatively effect the emitting distance and image transmission.
4. After adjustment, drill a second hole, then
mount and tighten to finish camera installation
Operations for Android system client
Installation app Software
1. Turn on the Andriod Phone and enter the Google Play Store
2. Search "Sight Wifi" app.
3. Install the "Sight Wifi" app
Notice
* When set WIFI signal to connect the mobile phone, please close the WIFI signal
previously opened.
*
image display time is relate to the CPU memory, software version, working
software number of mobile phone.
* when the background is black
whether the wifi connection is normal. then
the software interface.
Settings:
Press this
icon to enter into the settings
SSID and password of the wifi camera tool, and clicking
is successful, and clicking
Notice
* User could press the RESET button of the emitter to renew the default factory
SSID and password.
icon to refresh the image
* When the user changes the SSID and password, the user shall forget the network in the
"Settings" , and then reconnect the new network. Otherwise login error will remain displayed.
The specific steps to clear network memory are as follows. and then follow the above WIFI connection
method to reconnect the new network.
G
Logo
Red+
rear lamp
Black-
,
or the image is still, please exit the APP, and check
click again the APP icon to enter into
menu.
You can change the default factory
will show whether the change
to cancel the new SSID set.
