Audio Submenu

Figure 29.
The
Audio
PCS or the internal web pages for initial audio configuration (see
Page on page 102 for more audio configuration details and tips).
Audio Mute — Press the navigation buttons to globally mute or unmute audio output.
•
• Audio Format — Press the navigation buttons to select the audio input format. Analog
inputs can only be set to
formats.
Audio Input
Format
None
Analog
LPCM-2Ch
Multi-Ch
LPCM-2Ch Auto Sets the selected input to prioritize digital audio. Analog
Multi-Ch Auto
NOTE: Multi-channel audio does not include microphone inputs or audio
processing when it is sent to the output. It is also unaffected by volume control.
Audio Submenu
submenu allows users to adjust audio settings. Extron recommends using the
or
Analog
Details
Mutes audio for the selected input. Sets No audio EDID.
Sets the selected input to analog. Sets No audio EDID.
Default for inputs 1 and 2.
Sets the selected input to LPCM-2Ch audio.
Sets 2Ch audio EDID.
Sets the selected input to Multi-Ch audio. Sets Multi-Ch
audio EDID.
audio is passed when digital is not present. Sets 2Ch
audio EDID.
Default for inputs 3 through 8.
Sets the selected input to prioritize digital audio. Analog
audio is passed when digital is not present.
Sets Multi-Ch audio EDID.
