- Page 1 FREECURVE U S E R M A N U A L 915 Mhz 2,4 Ghz Classic Elegance Alliance...
- Page 3 FOREWORD CONTENT USER MANUAL Thank you for choosing a Handicare stairlift. This manual is for the Classic and Elegance/ OPTIONS Alliance seat types, and includes instructions for the standard features and optional upgra- IMPORTANT INFORMATION des. FAULT FINDING ATTACHMENTS A. Reminders B.
- Page 4 CLASSIC OPTIONS Autoswivel 915 Mhz/ 868MHz 2.4 GHz Pow. footrest Folding hinge Turn & Go The illustration opposite shows the features [1]LED [6]Seat swivel lever used to operate the Classic seat. The Classic [2]Joystick [7]Footplate can be upgraded with the automatic swivel [3]Emergency [8]Remote control seat, powered footrest, hinged rail and Turn &...
- Page 5 ELEGANCE / ALLIANCE OPTIONS Autoswivel 915 Mhz/ 868MHz 2.4 GHz Pow. footrest Folding hinge Turn & Go ActiveSeat [1]LED The illustration opposite shows the [2]Joystick features used to operate the Elegance/ [3]Emergency stop Alliance seat. The Elegance/Alliance can [4]Key switch be upgraded with the automatic swivel seat, powered footrest, hinged rail,Turn [5]Seat belt...
- Page 6 FOLD DOWN Fold down the armrests and seat. SIT DOWN Sit down on the seat. page 14 > OPTIONAL ACTIVE SEAT 4 USER MANUAL...
- Page 7 UNFOLD FOOTREST Fold down the footplate. page 12 > OPTIONAL POWERED FOOTREST PLACE FEET Place your feet on the footplate. Ensure that both feet are completely on the plate. USER MANUAL 5...
- Page 8 SAFETY FIRST CLICK! Fasten the seat belt securely, ensuring that it clicks into the holder. Put the key in the switch and turn it ninety degrees clockwise. The LED on the armrest lights up faintly. RIDE Move the joystick in the desired direction of travel. The LED lights up. The lift beeps three times, then gradually starts to move.
- Page 9 EMERGENCY STOP In an emergency, press the emergency stop once. The lift stops straight away. To release the lift, press the emergency stop again. SWIVEL CLICK! The lift stops automatically at the end of the rail. You can now swivel the seat manually, making it easier to get on and off.
- Page 10 FOLD FOOTREST Fold up the footplate. page 12 > OPTIONAL POWERED FOOTREST LOOSEN BELT Unfasten the seat belt. 8 USER MANUAL...
- Page 11 STAND UP Stand up from the seat. page 14 > OPTIONAL ACTIVE SEAT FOLD UP CLICK! Fold up the armrests and seat {A}. Push the handle, located to the left or right under the seat, downwards. Swivel the seat until you hear a 'click'. The seat is now in the locked position {B}.
- Page 12 PARK Press and hold the button on the remote control until the lift reaches a charge point. When pushing the remote a green LED will light up. CHARGE There are charge points for recharging the lift's batteries at the top and bottom of the rail (there may be additional charge points).
- Page 13 OPTIONS AUTOSWIVEL page 11 POWERED FOOTREST page 12 FOLDING HINGE page 12 TURN & GO page 13 ACTIVE SEAT page 14 AUTOSWIVEL CLICK! The AUTOMATIC SWIVEL SEAT option lets you swivel the seat automatically to face the direction you are going to walk in. To do this, push and hold the joystick in the upwards direction.
- Page 14 OPTION POWERED FOOTREST The POWERED FOOTPLATE option lets you fold the footplate up and down automatically using the switch on the side of the armrest. The footplate lights up when folded down. FOLDING HINGE With the FOLDING HINGE option, the seat stops just above the hinged rail. Move the joystick up or down to fold or unfold the rail.
- Page 15 FOLDING HINGE [PARK] Do not leave the lift on the hinged rail after use. Use the remote control to move the lift to a charge point and recharge the batteries. The first stopping point is at the hinged rail. Keep moving the lift until it reaches a charge point further up. TURN &...
- Page 16 ACTIVE SEAT CLICK! With the ACTIVE SEAT option, the seat assists you when sitting down and standing up. To stand up, pull the handle, located to the left or right under the seat, upwards. The seat pushes you up. When you sit back down, the seat slowly returns to its normal position and clicks into place.
- Page 17 USER MANUAL 15...
- Page 18 floors,banisters, plinths etc. which are to support or surround the installation have been verified and ensured by the customer, who therefore accepts all relative responsibilities. Neither Handicare nor its authorized dealers may be held responsible for the suitability of the structures which surround and support the installation. All tests, except for the operating test, shall be performed by the customer.
- Page 19 The wallbuttons of this stairlift work radiographic. Handicare does not accept any responsability for the non-functioning of these wallbuttons due to interference by a source outside this stairlift.
- Page 20 To prevent accidents, repairs and preventive maintenance must only be carried out by engineers qualified to do so. 8. The stairlift must not be used in the event of a fire or as a means of escape during a fire. 9.
- Page 21 Technical specifications Supply voltage 230 VAC Frequency 50/60 Hz Current Power 360 watt Fuses 30 A Load (max.) 19.7 stone Speed 0.49 f/s (max.) Ambient temperature 32 - 104 °F Relative humidity 20 - 80 % Service life 15 rides per 24hours 10 rides continuous Noise 56 dB...
- Page 22 FAULTFINDING OBSTACLE page 20 CHAIRPOSITION page 21 EMERGENCY STOP page 21 ARMREST page 22 page 22 BATTERIES RC page 23 POWER page 23 OBSTACLE C A U S E S O L U T I O N Problem: the lift travels in one direction only and the LED flashes when the joystick is operated.
- Page 23 CHAIRPOSITION CLICK! C A U S E S O L U T I O N Problem: the lift does not travel in either direction and the LED flashes when the joystick is operated. Cause: the seat is not locked and is in a swivelled position. Solution: swivel the seat using the handle located to the left or right under the seat.
- Page 24 ARMREST C A U S E S O L U T I O N Problem: the lift does not travel in either direction and the LED on the armrest lights up when the joystick is operated. Cause: an armrest has not been folded down.
- Page 25 BATTERIES RC RED light C A U S E S O L U T I O N Problem: the lift does not travel in either direction and the LED on the remote control shines red when the remote control is operated. Cause: the batteries in the remote control are flat.
- Page 26 ATTACHMENTS REMINDERS page 25 FLOOR page 26 REMINDERS [A]Remove the key from the switch whenever you leave the lift. [B]Never remove the lift plug from the wall socket. [C]The powered footplate has a light, which goes off automatically when the footplate is folded up or when the lift is not at a charge point.
- Page 27 USER MANUAL 25...
- Page 28 OPTION FLOOR Stairlift with powered swivel can swivel automatic on a preferent intermediate landing after tapping. Before the start of the lift, the joystick (not the remote con- trol) is operated in the direction of travel (Tap). The number of operations (taps) indicates the desired floor.
- Page 32 Handicare Monte-escaliers 4 Rue des Piverts ZAC de l’ Aunaie 91610 Ballancourt-sur-Essonne France Tel: +33 (0) 1 69 46 86 10 Fax: +33 (0) 1 69 46 86 19 monte-escaliers@handicare.fr Handicare GmbH Hausberger Straße 16 32457 Porta Westfalica Deutschland Tel: +49 (0) 571 973398-55 Fax: +49 (0) 571 973398-56 data@handicare.com...
