QUICK SETUP GUIDE
9" Dual Screen
Portable DVD
Players
NS-DS9PDVD15
PACKAGE CONTENTS
• AV connecting cable
• 9" DVD player A
(for player A to player B connection)
• 9" DVD player B
• Travel case
• AC adapters (2)
• Headrest mounting straps (2)
• Y-type vehicle power adapter
• Quick Setup Guide
• AV adapter cables
(to connect DVD players A and B to a TV)(2)
FIND YOUR USER GUIDE ONLINE!
Go to www.insigniaproducts.com, enter your model in
the search box, then press ENTER. Next to Features,
click Support & Downloads, then next to User Guide,
click the language you want.
SETTING UP YOUR PLAYER
To connect to a 12V power outlet
• Plug the included Y-type vehicle power adapter into your player(s) and
then into a 12V power outlet.
12V power outlet
DVD
player A
To connect to AC power
• Plug the included AC adapter into your player and then into a power
outlet.
FEATURES
DVD players A and B
USING YOUR DVD PLAYER
Play a DVD or audio CD
Note: Most DVDs and your DVD player have region codes that help
control illegal distribution of DVDs. The region code for your player is 1.
You can only play DVDs with a region code of 1 or ALL. The region code
for a DVD is printed on the DVD or the DVD packaging.
1 Make sure that your player is connected to power.
2 Slide the ON/OFF switch to the ON position.
3 Slide the OPEN switch. The disc tray opens.
4 Place a disc, label side up, in the disc tray, then close the tray.
The disc starts playing automatically.
5 Use the player navigation controls and buttons on the
DVD player to control playback.
For more information about using your Portable DVD player,
see your online User Guide at www.insigniaproducts.com.
Connecting your two DVD players
1 Using the AV connecting cable, connect the AV OUT jack
on player A to the AV IN jack on player B.
2 Plug the Y-type vehicle power adapter into the DC IN jacks
on both players and then into a 12V power outlet.
DVD
3 Turn on the DVD players.
player B
4 Press and hold the INPUT button on player B until A/V IN
appears on the screen.
DVD player A
Before using your new product, please read these instructions to prevent any damage.
#
1
2
3
4
5
6
7
8
9
10 DC IN jack
11 AV IN jack
12 AV OUT jack
13 Headphone jack
14 Volume control
15 Stand
12V
16 Strap slots
vehicle
charger
DVD player B
AV connecting cable
ITEM DESCRIPTION
 OPEN switch
Slide to open the disc tray.
ON/OFF switch Slide to turn your DVD player on or off.
SETUP button Press to open or close the Setup menu.
FUNC. button Press to enter or exit the Function menu.
Navigation Playback Mode: press the () and ()
controls buttons to fast reverse or fast forward the disc.
Menu Mode: Press to navigate and confirm an
entry or selection.
(play/pause) Press to pause or resume playback.
button
(stop) button Press to stop disc playback.
(Player A)
Stop/AV IN button Press to stop disc playback. When player A and
player B are connected to each other, press and
(Player B)
hold this button on player B to switch to AV IN
mode.
Lights blue when your player is powered and
Power indicator
turned on.
Provides audio output when headphones are
Speakers
not connected.
Connect to an AC adapter or 12V car power
outlet.
Connect the DVD player A using the AV
connecting cable.
(Player B)
Connect the DVD player B using the AV
connecting cable, or connect a monitor, TV, or
(Player A/B)
amplifier to this jack using the included AV
cable and an RCA cable (not included).
Plug headphones into this jack.
Note: When headphones are plugged in, the
built-in speakers are muted.
Rotate to increase or decrease the volume.
Pull out to set your player on a desktop or table.
Slide the mounting straps through these slots
when installing the player in a vehicle.
