Salus AKL06P Installation And Wiring Manual

AUX XX
TRANSFORMER
BOILER
POWER IN
L N
120 VAC
Electrical connections
L Line voltage 120VAC
N Neutral
Ground
Night Set Back
Switch live output (0-24VAC)
Fuse 5 Amp Slow blow
AUX Auxiliar, Dry contact
XX Dry contact
Zone1 E/S (ZC/ZR) Zone1 E/S Dry contact
C1 Communication Connections
C2 Communication Connections
For PDF Installation guide go to www.salusna.com
www.salusna.com Technical Helpline 1-650-360-1725
AKL06P Zone Pump Wiring Center
Group 1 thermostats
G1 (1-2)
H N H N H
H N H N H
R W C R
R W C
ZONE1 E/S
24V - T-STAT 1
24V -T-STAT 2
ZC/ZR
PRIORITY
GROUND
PUMP2 PUMP3 PUMP4
PUMP1
L N L N L N L
120 VAC
GROUND
OUTPUT
120VAC TO PUMP Cables will
be supplied by the installer.
Group 2 thermostats
G2 (3-6)
N H N H N H
N H N H N H
W C
R W C R W C R W
24V -T-STAT 4 24V -T-STAT 5 24V -T-STAT 6
24V -T-STAT 3
PRIMARY
PUMP5 PUMP6
PUMP
N L N L N L N
ZC N
Installation and Wiring Guide
Electrical connections for
24VAC thermostats
H/R Hot 24VAC
Switch live output (0-24VAC)
/W
N
N/C Return 24VAC
Night Set Back
C1 C2
N H 1-2 3-6
R G1 G2
C
A NSB 1-2/3-6
COMMS
POWER PRIMARY PRIORITY
ZONE 1
ZONE 2
ZONE 3
ZONE 4
ZONE 5
ZONE 6
MASTER SLAVE
PRIORITY ON OFF
EXERCISE ON OFF
PRIMARY STATUS DURING PRIORITY ON OFF
PURGE ON OFF
These instructions apply to the SALUS model stated above.
Warning
This product must be by a competent person, and installation must
comply with the guidance, standards and regulations applicable to the
country or state where the product is installed. Failure to comply with the
requirements of the relevant guidance, standards and regulations could
lead to injury, death or prosecution.
Warning
Always isolate the AC main supply before installing or working on any
components that require 120 V AC 60Hz supply.
The ground terminals on the AKL06P are for ground connections only.
These terminals provide no earth protection.
Maintaining a policy of continued product development SALUS Controls plc reserves the right to change
Issue Date: Feb 2017
