Owner's Manual
Thank you, and congratulations on your choice of the BOSS
BR-900CD Digital Recording Studio.
Before using this unit, carefully read the sections entitled:
• USING THE UNIT SAFELY (page 2–3)
• IMPORTANT NOTES (page 4–5)
These sections provide important information concerning
the proper operation of the unit.
Additionally, in order to feel assured that you have gained a
good grasp of every feature provided by your new unit,
Owner's manual should be read in its entirety. The manual
should be saved and kept on hand as a convenient reference.

■ Printing Conventions in This Manual

• Text or numerals enclosed in square brackets [ ] indicate buttons.
[PLAY]
PLAY button
[REC]
REC button
• Reference such as (p. **) indicate pages in this manual to which
you can refer.
Copyright © 2005 BOSS CORPORATION
All rights reserved. No part of this publication may be reproduced in any form
without the written permission of BOSS CORPORATION.

Advertisement

Table of Contents
loading

Related Manuals for Roland BR-900CD

Summary of Contents for Roland BR-900CD

  • Page 1: Printing Conventions In This Manual

    Owner’s Manual Thank you, and congratulations on your choice of the BOSS BR-900CD Digital Recording Studio. Before using this unit, carefully read the sections entitled: • USING THE UNIT SAFELY (page 2–3) • IMPORTANT NOTES (page 4–5) These sections provide important information concerning the proper operation of the unit.

  • Page 2: Using The Unit Safely

    • Do not attempt to repair the unit, or replace parts within it (except when this manual provides specific instructions directing you to do so). Refer all servicing to your retailer, the nearest Roland Service Center, or an authorized Roland distributor, as listed on the “Information” sheet.
  • Page 3 • Before using the unit in a foreign country, consult with your retailer, the nearest Roland Service Center, or an authorized Roland distributor, as listed on the “Information” sheet.

  • Page 4: Important Notes

    BOSS FV-300L; sold separately). By connecting any other expression pedals, you risk causing malfunction and/or damage to the unit. • Use a cable from Roland to make the connection. If using some other make of connection cable, please note the following precautions.

  • Page 5: Using Memory Cards

    Handling CD-ROMs • Avoid touching or scratching the shiny underside (encoded surface) of the disc. Damaged or dirty CD-ROM discs may not be read properly. Keep your discs clean using a commercially available CD cleaner. Before Using Memory Cards (CompactFlash) Using Memory Cards •...

  • Page 6: Before Using Cd-R/Rw Discs

    Before Using CD-R/RW Discs Two different types of recordable disc can be used with the BR-900CD—namely, CD-R discs and CD-RW discs. What is a CD-R disc? CD-R (Compact Disc Recordable) is a CD to which data can be written. It is not possible to erase or move the data that has been written.

  • Page 7: Notes When Using Mics

    Failure to properly and fully insert a disc can result in an inability to carry out writing correctly. 5. Press disc tray until it is locked in the BR-900CD. Notes When Using Mics Always be sure to switch the phantom power off except when connecting condenser mics requiring a phantom power supply.

  • Page 8: Table Of Contents

    Inserting Batteries...23 Quick Start ... 25 Connecting Peripheral Devices ...26 Inserting a Memory Card ...27 Turning On / Off the BR-900CD ...28 Turning On the Power ...28 Turning Off the Power...28 Listening to a Demo Song ...29 Selecting a song (Song Select) ...29 Playing back a song ...29...
  • Page 9 Section 1 Recording and Playback.. 47 Recording...48 Selecting the Recording Track ...48 Changing V-Tracks...49 Changing the Position of the Input Sound (Pan)...49 Recording Operations ...50 Repeating Playback (Repeat)...51 Setting the Repeat Portion...51 Setting the Repeat Portion with Accurate Timing...52 Re-recording Only a Mistake (Punch-in/out) ...53 Manually Punching In/Out ...53 Manually punching in and out using [REC] ...53...
  • Page 10 Section 3 Using Effects ... 83 Using the Insert Effects ...84 Effect Patches and Banks ...84 Editing Insert Effect Settings...85 Saving Insert Effects Settings (Write) ...86 Changing How the Insert Effects are Used According to the Mode ...87 Insert Effect Parameter Functions ...88 Algorithm List...88 BANK: GUITAR ...88 1.
  • Page 11 Track EQ Parameter Functions ...112 Parameter List ...112 Fixing the Pitch of Vocals (Pitch Correction) ...113 The Pitch Correction ...113 Makeup of the Pitch Correction ...113 Pitch Correction Patches...113 Precautions for Pitch Correction Usage ...113 Using the Pitch Correction ...114 Setting the Correction Method for Vocal Pitch (Pitch Correction Edit) ...115 Saving the Pitch Correction Settings (Write)...115...
  • Page 12 Connecting a Computer...163 Notes on Using USB ...163 With Windows ... 164 Backing Up the BR-900CD’s Data ...164 Saving BR-900CD Track Data in WAV/AIFF Format (WAV/AIFF Export) ...165 Loading WAV/AIFF Files in BR-900CD Tracks (WAV/AIFF Import)...167 Importing SMFs and Creating Patterns...169 Loading Drum Sounds from WAV/AIFF Files (Tone Load) ...171...
  • Page 13 Copying Difficult Songs (Phrase Trainer)...192 Slowing Down the Speed (Time Stretch) ...192 Canceling the Center Sound (Center Cancel)...192 Initializing the BR-900CD’s Settings ... 194 Initializing All the BR-900CD’s Settings ...194 Initializing the System Settings ...194 Initializing the Effect Settings ...195 Initializing the Rhythm Arrangements/Patterns/ Drum Kits ...195...

  • Page 14: Introduction To The Br-900Cd

    Introduction to the BR-900CD Features Simple operation The BR-900CD is designed to be operated as easily as a cassette tape recorder, even by beginners. The BR-900CD allows anyone to readily enjoy the benefits of digital recording as soon as it’s taken out of the box. So, you’ll surely have listened to the demo songs, if not gone...

  • Page 15: Editing Functions

    BR-900CD and a computer. Two-way power supply allows you to record anywhere You can use the BR-900CD powered by batteries (six size AA dry cells) or with the AC adaptor. And, thanks to its built-in microphone, you can make...

  • Page 16: Memory Cards Supported By Your Br-900Cd

    Your BR-900CD The BR-900CD uses CompactFlash cards as the storage media for recording and playback. The BR-900CD uses 32 MB to 1 GB CompactFlash cards with a 3.3 V power supply. For more on supported memory cards (CompactFlash) for the BR-900CD, refer to “About Memory Cards” (separate sheet).

  • Page 17: Panel Descriptions

    Panel Descriptions Front Panel Input section SENS knob Use this knob to adjust the sensitivity at the input jacks (e.g., GUITAR/BASS, MIC1, MIC2, and LINE). PEAK indicator This indicator shows how strong the input level is at the various input jacks (e.g., GUITAR/BASS, MIC1, and MIC2). This indicator lights at a level -6 dB lower than where sound distortion occurs.
  • Page 18 “TRACK faders.” RHYTHM fader Adjusts the volume of the Rhythm. MASTER fader Controls the overall volume of the BR-900CD. [V-TRACK] Use this button to call up the screen for selecting a V-Track. “What are V-Tracks?” (p. 14) “Changing V-Tracks” (p. 49) REC TRACK (Recording Track) buttons 1–6, 7/8...

  • Page 19: Rhythm Section

    Press this button to confirm a selection or a value being entered. CURSOR buttons Press these buttons to move the cursor within the screen. [CD-R/RW] The BR-900CD uses this drive unit to read from, write to, and play CD-R/RW discs. Rhythm section Here you can make settings for the Rhythm function.

  • Page 20: Headphones Jack

    Panel Descriptions [PAN/EQ] Pressed to access a screen where you can set the pan (left/ right location of the sound) for the playback of each track or for the input sound (p. 42, p. 49). This, also, adjusts the tone (Low, High) for each track (p. 42, p.
  • Page 21 At the factory settings, one second is set to 30 frames (non- drop). This is one type of a specification known as MTC (MIDI Time Code), and when you use the BR-900CD to play in synchronization with another MIDI device, you will need to set both devices to the same MTC type.

  • Page 22: Rear Panel

    MIDI device (rhythm machine or sound module). 10. POWER switch This is the power switch. It turns the power of the BR-900CD on/off. 11. DC IN (AC Adaptor) jack Connect the supplied AC adaptor (PSC-series) to this jack.

  • Page 23: Inserting Batteries

    Panel Descriptions Inserting Batteries 1. Make sure that the power of the BR-900CD is turned off. 2. Remove the battery cover on the rear panel. * When turning the unit upside-down, get a bunch of...
  • Page 24 MEMO...

  • Page 25: Quick Start

    Quick Start...

  • Page 26: Connecting Peripheral Devices

    AC Adaptor (PSC-series) Foot Switch (FS-5U etc.) Expression Pedal (Roland EV-5 etc.) To prevent malfunction and/or damage to speakers or other devices, always turn down the volume, and turn off the power on all devices before making any connections. ●...

  • Page 27: Inserting A Memory Card

    Before inserting the memory card, be sure to first turn off the BR-900CD. If a memory card is inserted when the power is turned on, the data in the memory card may be destroyed, or the memory card may become unusable.

  • Page 28: Turning On / Off The Br-900Cd

    1. Before you turn the power on, make sure of the following points. ❒ Are all external devices connected properly? ❒ Is the volume on the BR-900CD and all other devices completely lowered? ❒ Is the memory card inserted? * The BR-900CD is shipped with a memory card already inserted in the slot.

  • Page 29: Listening To A Demo Song

    4. Press [ENTER]. ■ If you have changed the recording or editing Since the BR-900CD automatically updates the recorded data and operation content if the recording or editing have been changed, you do not need to perform any special operations for saving.

  • Page 30: Changing The Current Position

    Listening to a Demo Song In addition to the procedures given above, you can also change your current position in the song using the procedures given below. Changing the current position Elapsed time display The value given at “TIME” in the display shows the elapsed time into the song using MTC (MIDI time codes) and is expressed as follows: hours-minutes-seconds-frames-sub frames.

  • Page 31: Recording/Playing Back A Song

    Inserting the memory card Before inserting the memory card (CompactFlash), be sure to first turn off the BR-900CD. If a memory card is inserted when the power is turned on, the data in the memory card may be destroyed, or the memory card may become unusable.

  • Page 32: Selecting The Song To Record

    Do not turn off the BR-900CD until the initializing has been completed. Do not remove the memory card or turn off the BR-900CD while the display shows “Keep power on!” Doing so can destroy the data on the memory card and/or render the memory card itself unusable.

  • Page 33: Connecting Instruments

    “Type” appears in the display. fig.00-406d 3. Turn the TIME/VALUE dial to select the desired data type. * The BR-900CD uses a sample rate of 44.1 kHz. It is not possible to change the sample rate. 4. Press [ENTER]. “Are you sure?” appears.

  • Page 34: Press The Input Select Button Of The Instrument That You Want To Record

    MIC1 jack and the internal microphone simultaneously. * Your BR-900CD is shipped with its internal microphone turned off. When not using the internal microphone, be sure to turn it on (see next section).

  • Page 35: Adjusting The Input Sensitivity

    MASTER fader to adjust the volume to the level you desire. Recording/Playing Back a Song (5) Using Insert Effects The BR-900CD comes with five onboard effects processors: an insert effect, loop effects, track EQ, pitch correction and mastering tool kit. Below is an explanation of the operations related to the insert effects.

  • Page 36: Recording Without Insert Effects

    This is convenient when you have created a patch for a specific recorded performance, and would like to store that patch together with the song. fig.00-415 BR-900CD Preset User Patch Patch 3. Press CURSOR [...

  • Page 37: Using The Rhythm

    (6) Using the Rhythm What is the Rhythm? When you record, it is convenient to use the built-in Rhythm. The “Rhythm” is a dedicated Rhythm track that can not only play back Rhythm sounds as a guide during recording, you can also use it to play internal Rhythm patterns and original user-created Rhythm patterns and to play and record these patterns as your own Rhythm part performances.

  • Page 38: Changing Patterns

    Song Arrangements (S) Song arrangements can be written; however, the data for song arrangements are stored along with the song data to the memory card. fig.00-420 BR-900CD Preset Arrangement 3. Press [EXIT] to return to the Play screen. Changing patterns 1.

  • Page 39: Basic Recording

    In addition, Tracks 7/8 are stereo tracks, so they always produce stereo recordings. About the recording (REC) modes Recording on the BR-900CD is separated into three main modes. Use whichever mode is suitable in the course of bringing your song to completion.

  • Page 40: Procedure

    1. Press [REC MODE] repeatedly until “INPUT” is indicated for REC MODE at the left of the screen. fig.00-428d 2. Press [REC]. [REC] flashes in red and the BR-900CD enters the recording standby state. fig.00-429 Flash 3. Press [PLAY].

  • Page 41: Playing Back Recorded Music

    How the Tracks Are Organized The BR-900CD features eight audio tracks that can be used for recording and playback. Tracks 1 through 6 are independent mono tracks. Tracks 7 and 8 are linked as stereo tracks. Tracks 7 and 8 are fixed as left and right tracks, respectively, while fader movements, Loop Effects, and other processes are applied in common to both tracks.

  • Page 42: Adjusting The Sound For Each Track

    Recording/Playing Back a Song 4. Press [PLAY]. The [REC] and REC TRACK button indicators change from flashing in red to being continually lit and recording begins. [PLAY] lights up. Only what you are currently playing is recorded to the new track. The music that is being played back is not recorded.

  • Page 43: Adjusting The Tone (Track Eq)

    Recording/Playing Back a Song Adding width to the sound (Loop Effect) The BR-900CD features chorus, delay, and doubling (any one of these three can be selected at any one time) as loop effects, and includes reverb as well. Effective use of these allows you to add greater breadth to the sound.
  • Page 44 Recording/Playing Back a Song When using CHO/DLY Select from “CHORUS,” “DELAY,” or “DBLN” (doubling). fig.00-438d When using REV Select from “HALL” or “ROOM.” fig.00-439d 4. If you want to change the settings for the selected effect, press CURSOR [ ] to select the parameter, then change the setting’s value with the TIME/VALUE dial.

  • Page 45: Bouncing (Putting Multiple Tracks Together)

    To turn off the power, use the procedure described in “Turning Off the Power” (p. 28). Before you turn off the BR-900CD, make sure to first stop any recording. If the BR-900CD is turned off during playback/ recording where the memory card is being accessed, the recorded data, mixer settings, and effect patch data may be lost.
  • Page 46 MEMO...

  • Page 47: Section 1 Recording And Playback

    Section 1 Recording Playback...

  • Page 48: Recording

    Recording Selecting the Recording Track 1. Press either [1]–[7/8] at REC TRACK to select the recording track. If the button flashes in red, that track is ready for recording. fig.01-101 The status of each track can be determined from the indicator on the button.

  • Page 49: Changing V-Tracks

    V-Tracks for recording or playback. Therefore, by making use of the many V-Tracks, you can use the BR-900CD just as if it were a 64-track multitrack recorder. This allows a wide range of uses, such as recording one take of a guitar solo or vocal, and then recording another take without having to erase the first one.

  • Page 50: Recording Operations

    Recording Operations 1. Press [REC MODE] repeatedly until “INPUT” is indicated for REC MODE at the left of the screen. fig.01-109d 2. Press [REC]. [REC] flashes in red and the BR-900CD enters the recording standby state. fig.01-110 Flash 3. Press [PLAY].

  • Page 51: Repeating Playback (Repeat)

    Repeating Playback (Repeat) By using the “Repeat function” you can repeatedly play back a specified part. Repeating playback allows you to check the mixing balance or perform loop recordings (p. 56) with the punch in/out functions. The position in the song where [REPEAT] is pressed first becomes repeat start point (A), and the position where it is pressed a second time becomes repeat end point (B).

  • Page 52: Setting The Repeat Portion With Accurate Timing

    Repeating Playback (Repeat) Setting the Repeat Portion with Accurate Timing Normally, the repeat start and end points are registered at the exact position where [REPEAT] is pressed. This may make it difficult for you to set the repeat portion exactly as you desire.

  • Page 53: Re-Recording Only A Mistake (Punch-In/Out)

    (p. 78) to delete unneeded data from the memory card. Manually Punching In/Out You can use the button on the BR-900CD or a foot switch to punch in or out. When you are playing an instrument and performing the recording by yourself, it may be difficult to punch in or out using the button on the BR-900CD.

  • Page 54: Manually Punching In And Out Using A Foot Switch

    When you are using a foot switch (BOSS FS-5U, Roland DP-2, etc.) to punch in and out, connect the foot switch to the FOOT SW jack on the BR-900CD and change the function of the FOOT SW jack by following the procedure given below.

  • Page 55: Erasing A Registered Auto Punch In/Out Location

    The indicator lights up, showing that the auto punch in and out have been set. Re-recording Only a Mistake (Punch-in/out) 6. Press [REC] to place the BR-900CD in recording standby and then press [PLAY]. Recording automatically starts at the auto punch-in location, so start playing what you want to record.

  • Page 56: Repeatedly Recording Over The Same Location (Loop Recording)

    Re-recording Only a Mistake (Punch-in/out) Repeatedly Recording Over the Same Location (Loop Recording) The repeat function (p. 51) allows you to play a certain portion of a song (the loop portion) over and over again. If you used auto punch in/out together with the repeat function, the portion will be repeated so the result of the recording can be heard right away.

  • Page 57: Canceling An Operation (Undo/Redo)

    Canceling an Operation (Undo/Redo) Occasionally when the recording you make may not turn out as you wish, or the settings you make for an editing operation are incorrect, and you want to reverse what you have done. At these times, you can use the “Undo function.” The Undo function reverses the action you have just performed and returns you to the status you were in beforehand.

  • Page 58: Putting Multiple Tracks Together (Bounce)

    Putting Multiple Tracks Together (Bounce) Although the BR-900CD allows the simultaneous playback of eight tracks, when you run out of tracks, the BR-900CD also lets you copy the recordings of multiple tracks together onto one track (V-Track). This is called “bounce” (also known as bounce recording or ping-pong recording).

  • Page 59: Bouncing Directly To A Cd-R/Rw Disc (Direct Cd Bounce)

    Bouncing Directly to a CD-R/RW Disc (Direct CD Bounce) With the BR-900CD, you can bounce data directly to a CD-R/ RW disc instead of the audio tracks. This is a convenient way to keep a copy of song sketches after recording them.

  • Page 60: Selecting The Input Source And Bouncing The Recording To A Cd-R/Rw

    Putting Multiple Tracks Together (Bounce) 5. Press [REC]. The CD-R/RW drive’s motor begins spinning. “Now Checking...” appears in the display. The message disappears approximately ten seconds later, indicating that preparations for bouncing have been completed. • In contrast to normal recording, you cannot press [REC] (manual punch in) after first pressing [PLAY].

  • Page 61: Loading Songs Created With The

    Loading Songs Created with the BR-532 When copying song data created with the BR-532 from SmartMedia to a BR-900CD memory card, you can load the data as a BR-900CD song. Reading BR-532 data requires a PC with a SmartMedia reader and CompactFlash writer connected.

  • Page 62: Displaying The Song Information

    Displaying the Song Information Displaying the Remaining Available Recording Time Follow the procedure below to either display the elapsed recording time in the recording standby and recording screens. 1. Press [UTILITY]. 2. Press CURSOR [ ] to move the cursor to “SYS,” and press [ENTER].

  • Page 63: Section 2 Editing

    Section 2 Editing...

  • Page 64: Registering Time (Locator)

    Registering Time (Locator) Using the locator function, you can register any desired time in a song as a “locator point” so that you can jump to that point later with just the press of a button. This function is quite useful during editing. Registering a Locator Point 1.

  • Page 65: Search For The Music's Start And End (Scrub/Preview)

    To enable you to find these points accurately, the BR-900CD is equipped with the Scrub function. When you use the Scrub function during playback (called “scrubbing”), the portion from your before or after the...

  • Page 66: Changing The Scrub Points

    Search for the Music’s Start and End (Scrub/Preview) Changing the Scrub Points Besides switching the scrub point in the Play screen (p. 65), you can also use the following method to switch the scrub point. 1. Press [UTILITY]. 2. Press CURSOR [ ] to move the cursor to “SCR,”...

  • Page 67: Editing The Performance On A Track (Track Editing)

    Editing the Performance on a Track (Track Editing) The BR-900CD allows you to edit your songs by performing editing functions such as copying and moving data recorded on the tracks. About the Measure/Time Specification screen Measures and time are specified in the “S” (Start), “E”...

  • Page 68: Copying By Specifying The Time (Tme/Mes)

    Editing the Performance on a Track (Track Editing) 4. Turn the TIME/VALUE dial to select “AB” and press [ENTER]. fig.02-306d 5. Use CURSOR [ ] and the TIME/VALUE dial to select the track/V-Track to copy from, and track/V- Track to copy to. 6.

  • Page 69: Copying A Complete Track (All)

    fig.02-319d 5. Use CURSOR [ ] and the TIME/VALUE dial to select the track/V-Track to copy from, and track/V- Track to copy to. 6. Press [ENTER]. fig.02-314d 7. Use [CURSOR] and the TIME/VALUE dial to specify the beginning of the portion “S” (Start) of data you want to copy.

  • Page 70: Moving Data (Track Move)

    Editing the Performance on a Track (Track Editing) fig.02-319d 4. Turn the TIME/VALUE dial to select “ALL” and press [ENTER]. fig.02-320d 5. Use CURSOR [ ] and the TIME/VALUE dial to select the track/V-Track to copy from, and track/V- Track to copy to. 6.

  • Page 71: Moving By Specifying The Time (Tme/Mes)

    3. Press CURSOR [ ] to move the cursor to “MOV,” and press [ENTER]. fig.02-324d 4. Turn the TIME/VALUE dial to select “AB” and press [ENTER]. fig.02-325d 5. Use CURSOR [ ] and the TIME/VALUE dial to select the track/V-Track to move from, and track/V- Track to move to.

  • Page 72: Moving A Complete Track (All)

    Editing the Performance on a Track (Track Editing) fig.02-331d 5. Use CURSOR [ ] and the TIME/VALUE dial to select the track/V-Track to move from, and track/V- Track to move to. 6. Press [ENTER]. fig.02-332d 7. Use [CURSOR] and the TIME/VALUE dial to specify the beginning of the portion “S”...

  • Page 73: Erasing Data (Track Erase)

    5. Press CURSOR [ ] and the TIME/VALUE dial to select the track/V-Track to move from, and track/V- Track to move to. 6. Press [ENTER]. fig.02-338d 7. Use [CURSOR] and the TIME/VALUE dial to specify the time of the beginning of the location “T” (To) where you want the data to be moved.

  • Page 74: Erasing By Specifying The Time (Tme/Mes)

    Editing the Performance on a Track (Track Editing) fig.02-341d 4. Turn the TIME/VALUE dial to select “AB” and press [ENTER]. fig.02-342d 5. Use CURSOR [ ] and the TIME/VALUE dial to select the track/V-Track to erase from. 6. When you are ready to execute the erasure, press [ENTER]. The display will ask “Are you sure?,”...

  • Page 75: Erasing A Complete Track (All)

    5. Use CURSOR [ ] and the TIME/VALUE dial to select the track/V-Track to erase from. 6. Press [ENTER]. fig.02-347d 7. Use [CURSOR] and the TIME/VALUE dial to specify the beginning of the portion “S” (Start) of data you want to erase. 8.

  • Page 76: Exchanging Data (Track Exchange)

    Editing the Performance on a Track (Track Editing) Exchanging Data (Track Exchange) Perform the procedure given below to exchange the data between two tracks. Example: exchanging all the data on track 1 with all the data on track 2 fig.02-352 Track 1 Track 2 Track 1...

  • Page 77: Organizing The Songs You've Recorded

    Organizing the Songs You’ve Recorded Copying a Song (Song Copy) Follow the procedure below to copy the currently selected song. 1. Press [UTILITY]. 2. Press CURSOR [ ] to move the cursor to “EDT,” and press [ENTER]. fig.02-401d 3. Press CURSOR [ ] to move the cursor to “CPY,”...

  • Page 78: Saving Memory On The Memory Card (Song Optimize)

    Naming Songs (Song Name) When a new song is created, it is automatically given a name such as “SONG 0001.” With your BR-900CD, you can use “Song Name” to give each song a name, which helps you manage and organize your songs.

  • Page 79: Protecting A Song (Song Protect)

    Saving the Current Settings to the Song (Song Save) The BR-900CD can save the following contents as song data. • Recorded data • Mixer settings (Pan, Track EQ, etc.) • Insert Effect song patches • Mastering Tool Kit song patches •...

  • Page 80: Creating A Master Tape / Disc

    Cassette tape Recorder 2. Put the cassette tape recorder in record mode. 3. Press [PLAY] on the BR-900CD and start the playback of the recorded data. Recording to a Digital Recorder (Digital Connection) 1. Connect the BR-900CD’s DIGITAL OUT connector to the digital recorder's input connector.
  • Page 81 CD player. If you are using this type of DAT recorder, it will not be possible to record the digital output of the BR-900CD on a DAT recorder if “Copy Prtct” is turned “ON.” In this case, you will need to turn off the “Copy Prtct”...
  • Page 82 MEMO...

  • Page 83: Section 3 Using Effects

    Section 3 Using Effects...

  • Page 84: Using The Insert Effects

    * Song patches (S) cannot be selected unless a memory card is inserted. Your BR-900CD is shipped with the user patches (U) and song patches (S) containing the same patches as the preset patches (P). When you create a new song, copies of the patches in the...

  • Page 85: Editing Insert Effect Settings

    Editing Insert Effect Settings If you wish to create a new effect sound, you should first select an existing patch that is closest to the sound you want, and then edit its settings. If you wish to save the effect settings that you edited, save them as a user patch or song patch.

  • Page 86: Saving Insert Effects Settings (Write)

    Using the Insert Effects Saving Insert Effects Settings (Write) Follow the procedure below to enter a name (patch name) for an effect that you’ve modified, and save it as a new effect patch. * You cannot save an effect patch during the recording or playback of a song.

  • Page 87: Changing How The Insert Effects Are Used According To The Mode

    (wet) sound to be recorded and monitored. However, sometimes you want to change the connection order. On the BR-900CD, you can accommodate a wide variety of situations by changing the point to which the insert effects are connected. Follow the procedure below to change where insert effects are connected.

  • Page 88: Insert Effect Parameter Functions

    Insert Effect Parameter Functions Algorithm List The algorithms (the available effects and their connection order) that can be used as an insert effect are shown below. The algorithms that can be selected will differ for each bank. To select the algorithm that you wish to use, first select the effect bank that includes that algorithm, and then refer to the “Effect Patch List”...

  • Page 89: Bass Sim

    3. BASS SIM Simulates the sound of a bass guitar. Obtain the sound of a bass guitar while playing an electric guitar. * You should avoid playing chords when using the Bass Simulator. fig.04-108 –[ BSIM ]–[ COMP/DEF ]–[ NS ]–[ FV ]–[ MOD ]= Bass Simulator Compressor/Defretter - Compressor...

  • Page 90: Cosm Bass Amp

    Insert Effect Parameter Functions 7. COSM BASS AMP This is a multi-effect designed for bass guitar. This features an amp sound that uses a preamp and speaker simulator. fig.04-113 –[ COMP ]–[ PAMP ]–[ SP ]–[ EQ/WAH ] –[ NS ]–[ FV ]–[ MOD ]=[ DLY ]= Compressor Preamp Speaker Simulator...

  • Page 91: 11. Cosm Comp Vcl

    11. COSM COMP VCL This is a multi-effect designed for vocals. The COSM compressor/limiter is perfect for creating a basic sound. fig.04-117 –[ COMP/LIM ]–[ DES ]–[ ENH ] [ EQ ]–[ NS ]–[ FV ]–[ DLY ]= COSM Comp/Limiter De-esser Enhancer 4Band Equalizer...

  • Page 92: Bank: Simul

    Insert Effect Parameter Functions BANK: SIMUL 14. VO+GT AMP This algorithm is for use when simultaneously recording a vocal and electric guitar. For the guitar, you can produce an amp sound using a preamp and speaker simulator. (GUITAR) fig.04-121 –[ COMP ]–[ PAMP ]–[ SP ]–[ NS ]–[ DLY ]– (MIC) fig.04-120 –[ COMP ]–[ EQ ]–[ NS ]–[ DLY ]–...

  • Page 93: Parameter List

    The trademarks listed in this document are trademarks of their respective owners, which are separate companies from BOSS. Those companies are not affiliated with BOSS and have not licensed or authorized BOSS’s BR-900CD. Their marks are used solely to identify the equipment whose sound is simulated by BOSS’s BR-900CD.

  • Page 94: Chorus

    (threshold). You can get the same effect OFF, ON achieved with the compressor by setting the threshold at a low value. The BR-900CD uses COSM technology to model four types of compressor/limiter in which the compressor and limiter functions are 0–100 combined.

  • Page 95: De-Esser

    De-esser Useful for reducing ‘sibilant’ or ‘S’ sounds produced by a vocalist. On/Off This parameter turns the de-esser effect on/off. Sibilant Adjusts the sensitivity relative to the input volume, which controls how the effect is applied. Level Adjusts the volume. Defretter This simulates a fretless bass.

  • Page 96: Equalizer

    Insert Effect Parameter Functions Equalizer A 4-band equalizer. * You can use this effect with the following algorithms when “4BAND EQ” is selected for the 4BAND EQ/WAH “Type” setting. COSM GTR AMP COSM BASS AMP COSM COMP GTR COSM COMP BSS BASS MULTI STEREO MULTI On/Off...

  • Page 97: Noise Suppressor

    ■ When “DIGITAL” is selected Pre Filter This filter decreases digital distortion. When turned off, you can create an intense lo-fi sound incorporating digital distortion. Smpl Rate Modify the sample rate. Modify the number of data bits. If this is turned off, the number of data bits will be unchanged.

  • Page 98: Pitch Shifter

    -50– +50 MS (1, 2, 1+2) SLDN METAL METAL D The sound of the Roland “JC-120,” a favorite of pro musicians around the world. The sound of a conventional built-in tube amp. Allows you to obtain a crunch effect that creates a natural distortion.

  • Page 99: Ring Modulator

    ■ With “COSM BASS AMP” or “COSM COMP BSS” algorithms It produces the vintage sound of an early transistor amp. It produces the sound of a large double-stack vacuum tube amp with ultra-lows and a crisp edge. Volume Adjusts the volume and distortion of the amp. Bass GUITAR AMP: 0–100, BASS AMP:-100–...

  • Page 100: Speaker Simulator

    Insert Effect Parameter Functions Speaker Simulator This simulates the characteristics of various types of speakers. When the output of the BR-900CD is connected directly to a mixer, etc., this can be used to create the sound of your favorite speakers system. On/Off This parameter turns the speaker simulator effect on/off.

  • Page 101: Wah

    The wah effect creates a unique tone by changing the frequency response characteristics of a filter. Touch wah creates an automatic wah by changing the filter in response to the volume of the input. Pedal wah lets you use an Expression pedal or the like to obtain real-time control of the wah effect.

  • Page 102: Mastering

    * The Mastering Tool Kit features 19 pre-programmed “Preset Patches” (P01–P19), 19 rewritable “User Patches” (U01–U19), and 19 “Song Patches,” which are stored individually for each song (S01–S19). fig.01-800 BR-900CD Preset User Patch Patch “Mastering Tool Kit Patch List” (p. 205)

  • Page 103: Editing The Mastering Tool Kit Settings

    The overall volume is adjusted by the MASTER fader. At this time, raise the volume as high as possible without allowing the sound to distort. 7. Press [REC]. [REC] flashes in red and the BR-900CD enters the recording standby state. fig.01-804 Flash 8.

  • Page 104: Saving The Mastering Tool Kit Settings (Write)

    Mastering 5. Press CURSOR [ ] to move the cursor to each effect and turn the TIME/VALUE dial to turn each effect on or off. Blocks that are turned on are shown in uppercase letters, while blocks that are turned off are shown in lowercase letters.

  • Page 105: Mastering Tool Kit Parameter Functions

    Mastering Tool Kit Parameter Functions Algorithm fig.04-204 =[ EQ ]=[ BCUT ]=[ ENH ]=[ IN ]=[ EXP ] [ COMP ]=[ MIX ]=[ LIM ]=[ OUT ] Equalizer Bass Cut Filter Enhancer Input Expander Compressor Mixer Limiter Output Parameter List Equalizer On/Off This parameter turns the equalizer effect on/off.

  • Page 106: Bass Cut Filter

    Mastering Tool Kit Parameter Functions Bass Cut Filter This is a filter that cuts unwanted low range noise, such as pops. On/Off This setting turns the Bass Cut Filter on/off. Freq This sets the frequency containing popping or other undesirable lower-range noises that you want to cut.

  • Page 107: Compressor

    Compressor This compresses the overall output signal when the input volume level exceeds a set value. On/Off This parameter turns the compressor effect on/off. Lo Thres This sets the volume level at which the lower-range compressor goes into effect. Lo Ratio This sets the ratio of suppression of the lower-range output when the input level exceeds the Lo threshold level.

  • Page 108: Using The Loop Effects/Track Eq

    Using the Loop Effects/Track EQ Here is an explanation of how to change the various parameters for the loop effects (chorus/delay/doubling/ reverb). For an explanation of loop effects, refer to “Loop Effect Parameter Functions” (p. 111). Loop effects do not have “patches.” Loop effect settings are saved along with the song data.

  • Page 109: Adjusting How The Loop Effect Is Applied

    Adjusting How the Loop Effect is Applied The following explains how you can alter the volume of the signals sent by each track to the loop effects (the send level), and control the degree to which the loop effects are applied. 1.

  • Page 110: Setting The Track Eq

    Using the Loop Effects/Track EQ Setting the Track EQ This section explains how to edit the Track EQ settings (parameters). For a fuller description of Track EQ, refer to “Track EQ Parameter Functions” (p. 112). Track EQ do not have “patches.” Loop effect settings are saved along with the song data.

  • Page 111: Loop Effect Parameter Functions

    Loop Effect Parameter Functions Parameter List CHORUS/DELAY/DBLN (Doubling) This selects the chorus, delay, or doubling effect. FX Type This sets the type of the effect. CHORUS: A sound with a subtly shifted pitch is added to the direct sound, making the final output sound thicker and broader. DELAY: This creates a thicker sound by applying a delayed sound to the direct sound.

  • Page 112: Track Eq Parameter Functions

    Track EQ Parameter Functions Parameter List This is a two-band equalizer that is independent for each track. If you adjust the equalizer while listening to the sound, you may notice a clicking noise. This is not a malfunction. If the noise is objectionable, make adjustments while the sound is not playing.

  • Page 113: Fixing The Pitch Of Vocals (Pitch Correction)

    Patch. At the time of purchase, a total of 5 pitch correction patches (i.e., preset patches) will be stored in the BR-900CD. In addition, 5 song patches can be set up for use within a specific song.

  • Page 114: Using The Pitch Correction

    Fixing the Pitch of Vocals (Pitch Correction) Using the Pitch Correction Let’s now use the BR-900CD’s pitch correction feature to clean up some mistakes in a solo vocal part. Using this feature, we will be able to correct pitches in real time and in semitone units.

  • Page 115: Setting The Correction Method For Vocal Pitch (Pitch Correction Edit)

    Select this setting for a low-pitched, female voice. HI.FEML (High Female) Select this setting for a high-pitched, female voice. * If the BR-900CD is frequently incorrect when detecting the pitch, either change the type setting. In certain cases, this will reduce the number of incorrect detections.

  • Page 116: Making Detailed Settings For Pitch Correction (Correction Event Map)

    Fixing the Pitch of Vocals (Pitch Correction) 5. Turn the TIME/VALUE dial to select the patch number to which to write the new patch. 6. After you’ve selected the destination, press [ENTER]. After the save has been completed, you are returned to the Pitch Correction patch selection screen.
  • Page 117 6. Use [CURSOR] to move the cursor to “Smth” and specify the correction speed. Smth (Smooth) The value set here is added to the value for the “Smooth” patch parameter (p. 115). When set to 0, the correction proceeds at the rate set in the patch’s “Smooth”...
  • Page 118 MEMO...

  • Page 119: Section 4 Using The Rhythm

    Section 4 Using the Rhythm...

  • Page 120: Using The Rhythm

    Types of patterns Preset patterns (P001–P327) These are internal patterns stored in the BR-900CD that have already been prepared for use. There are 327 patterns categorized by musical genre, such as “rock” and “jazz.” * You cannot change and overwrite Preset pattern data.

  • Page 121: Switching The Rhythm Mode

    Switching the Rhythm Mode The Rhythm mode switches each time [ARRANGE/ PATTERN/OFF] is pressed. [ARRANGE/PATTERN/OFF]: Lit (Arrangement Mode) Performance and programming of arrangements is enabled. Press [PLAY] to start the performance of the arrangement. * You cannot play back or record during programming. [ARRANGE/PATTREN/OFF]: Flashing (Pattern Mode) Performance and programming of patterns is enabled.

  • Page 122: Selecting Patterns

    Using the Rhythm Selecting patterns This selects the pattern to be played with the Rhythm. 1. Press [ARRANGE/PATTERN/OFF] repeatedly until the indicator is flashing. fig.03-203d P: Preset / S: Song Number 2. Select a pattern. Use CURSOR [ ] and the TIME/VALUE dial to select the Preset/Song and number.

  • Page 123: Creating Original Arrangements

    Creating Original Arrangements You can create arrangements (Song arrangements) of up to 999 measures. 1. Make sure performance of the song is stopped, then press [ARRANGE/PATTERN/OFF] repeatedly until the indicator is lit. fig.03-301d 2. Press CURSOR [ ] and the TIME/VALUE dial to select the Arrangement number.

  • Page 124: Inserting A Step

    Creating Original Arrangements Inserting a Step Perform the procedure below to insert a new step into the location of the present step. fig.03-305 Verse Insert Step 1 Step 2 Step 3 Intro Verse Fill Step 1 Step 2 Step 3 Intro Verse Verse...

  • Page 125: Copying Arrangements

    4. Press CURSOR [ ] and turn the TIME/VALUE dial to change the characters. * Press [ENTER] to switch between uppercase and lowercase. 5. Press [EXIT] repeatedly to return to the Play screen. * During updating, “Keep power on!” appears in the upper line of the display, while the lower line shows what is being processed.

  • Page 126: Creating Original Patterns

    Creating Original Patterns When creating a Rhythm arrangement by stringing together Rhythm patterns, there may be times when you do not find anything suitable among the preset Rhythm patterns, or when you want to get a Rhythm pattern that sounds exactly the way you want.
  • Page 127 4. Use [CURSOR] and the TIME/VALUE dial to set the measure, beat, and click from which to start recording of the pattern. Measure This sets the number of measures in the pattern to be recorded. Valid Settings: 1–999 Tempo When recording, this sets the tempo for confirming the pattern.

  • Page 128: Rehearsing Recordings

    “REAL” appears in REC MODE at the left of the screen. The Recording Standby screen appears. fig.03-408d 4. Press CURSOR [ ] repeatedly to move the cursor to “RHR,” and press [ENTER]. The BR-900CD is put into Rehearsal mode. fig.03-409d...

  • Page 129: Deleting Unneeded Drum Sounds

    5. Rehearse the performance by pressing the REC TRACK [1]–[6]. You can switch the UPPER and LOWER drum sounds by pressing [RHYTHM PAD]. * At this point, adjust Fader 1 to confirm the velocity status. 6. When you have finished rehearsing, move the cursor to “STOP”...

  • Page 130: Creating Patterns In Step Recording

    Creating Original Patterns Creating Patterns in Step Recording 1. Press [ARRANGE/PATTERN/OFF] repeatedly until the indicator is flashing. fig.03-415d 2. Press [EDIT]. fig.03-416d 3. Press [CURSOR] to move the cursor to “STEP,” and press [ENTER]. “STEP” appears in REC MODE at the left of the screen. The recording standby screen appears in the display.
  • Page 131 7. Set the velocity (how “hard” the note is played) for the sounds to be input from the current point by adjusting Fader 1. fig.03-423d Velocity 8. Input the drum sounds. There are two ways to input drum sounds. (Method 1) Inputting with the REC TRACK buttons Use REC TRACK [1]–[6] to input the drum sounds.

  • Page 132: Changing The Velocity

    Creating Original Patterns You can press [REC MODE] during Step Recording to switch to Realtime Recording. 9. Set the tempo and Quantize values as needed. 10. Repeat Steps 6–9 as needed. * Press [PLAY] to listen to the recording pattern. 11.

  • Page 133: Copying Patterns

    Copying Patterns 1. Press [ARRANGE/PATTERN/OFF] repeatedly until the indicator is flashing. 2. Press [EDIT]. 3. Press [CURSOR] to move the cursor to “COPY,” and press [ENTER]. The Pattern Copy screen appears. fig.03-429d 4. Turn the TIME/VALUE dial to select the copy- destination arrangement.

  • Page 134: Using The Drum Kits

    Using the Drum Kits A drum kit is a variety of rhythm instrument sounds collected in a single set; the BR-900CD includes nine internal “preset drum kits.” In addition, you can also put together an additional five original “song drum kits.”...

  • Page 135: Creating Original Drum Kits (Tone Load)

    ROCK 2... STD 2 Creating Original Drum Kits (Tone Load) With the BR-900CD, you can create original drum kits not only with the internal drum sounds, but by loading drum sounds from external sources as well. There are four ways to load drum tones.
  • Page 136 Using the Drum Kits 5. Use [CURSOR] and the TIME/VALUE dial to specify the range (start and end points) of drum sounds to be loaded in terms of measures or time locations. * You cannot specify an interval between the start and end points or a length of time in less than 100 ms or excess of 13 seconds.

  • Page 137: Copying Drum Sounds From Other Drum Kits

    Copying drum sounds from other drum kits 1. Press [UTILITY]. 2. Press CURSOR [ ] to move the cursor to “TONE,” and press [ENTER]. fig.03-505d 3. Press CURSOR [ ] to move the cursor to “COPY,” and press [ENTER]. fig.03-519d 4.

  • Page 138: Changing The Position (Pan) Of The Drum Sounds

    Using the Drum Kits Erasing drum sounds 1. Press [UTILITY]. 2. Press CURSOR [ ] to move the cursor to “TONE,” and press [ENTER]. 3. Press CURSOR [ ] to move the cursor to “ERASE,” and press [ENTER]. fig.03-523d 4. Turn the TIME/VALUE dial to specify the erase drum kit, then press [ENTER].

  • Page 139: Using The Cd-R/Rw Drive

    Section 5 Using the CD-R/ RW Drive...

  • Page 140: Creating Audio Cd

    You should, therefore, confirm that the CD player to be used is compatible with CD-R discs. Note that the BR-900CD’s CD-R/RW drive can play commercially produced audio CDs, CD-R discs, and CD-RW discs. When you use the CD-R/RW drive, you must use only the supplied AC adaptor.
  • Page 141 • The range of available write speeds can sometimes be limited by the type of media being used. In such a case, the BR-900CD will allow you to select only the supported speeds. • If you are using CD-R or CD-RW discs intended for high- speed writing, the frequency of write errors may increase if the x2 or x4 speed is selected.

  • Page 142: Viewing The Remaining Time For Recording On Audio Cds

    Playing Back Audio CDs Let’s now listen to the audio CD we have just created using the BR-900CD’s CD-R/RW drive. In addition to CD-R discs, this drive can be used to play back CD-RW discs that cannot be played on standard CD players. Naturally, you will also...

  • Page 143: Enabling Playback On Cd Players (Finalize)

    Players (Finalize) If you intend to play a audio CD that was written using the BR-900CD’s CD-R/RW drive on a standard CD player, the audio CD must be finalized. Audio CD-R/RW discs can be finalized at any time to enable playback on this type of player.
  • Page 144 Creating Audio CD 3. Press CURSOR [ ] to move the cursor to “AUDIO,” and press [ENTER]. The Audio CD menu screen will appear. fig.05_CDaudio 4. Press CURSOR [ ] to move the cursor to “FINAL,” and press [ENTER]. The message “Finalize CD OK?” will appear. fig.05_CDfinalize 5.

  • Page 145: Using The Cd-R/Rw Drive To Exchange Data

    Using the CD-R/RW Drive to Exchange Data The BR-900CD’s built-in CD-R/RW drive can be used to exchange data in the following ways: ● Storing of songs and other data on the memory card to CD-R/RW discs (Backup) ● Reading songs and other backup data back into the memory card (Recover) ●...

  • Page 146: Saving All Of The Songs On A Memory Card To A Cd-R/Rw Disc (All Backup)

    • The range of available write speeds can sometimes be limited by the type of media being used. In such a case, the BR-900CD will allow you to select only the supported speeds. • If you are using CD-R or CD-RW discs intended for high- speed writing, the frequency of write errors may increase if the x2 or x4 speed is selected.

  • Page 147: Loading Saved Songs To A Memory Card (Recover)

    Loading saved songs to a memory card one at a time (Song Recover) 1. Insert a CD-R/RW disc containing backup songs into the BR-900CD’s CD-R/RW drive. The drive’s access indicator will begin to flash. Wait until this indicator stops flashing and turns off before proceeding.

  • Page 148: Copying And Writing Waveform Data

    You can also take audio track data recorded with the BR-900CD and copy it to your computer for editing. Copying waveform data from a...

  • Page 149: Copying Wav/Aiff Files As Drum Sounds (Tone Load)

    For instructions on how to write waveform data to CD- R/RW discs, refer to your computer and CD-R/RW drive owner’s manuals. 2. Place the CD-R/RW disc in the BR-900CD’s CD-R/RW drive. The drive’s access indicator will begin to flash. Wait until this indicator stops flashing and turns off before proceeding.

  • Page 150: Copying Audio Track Waveform Data To Computers (Wav/Aiff Export)

    CD-ROM or CD-R drive. In this case, used CD-R discs. 1. Place a writable CD-R/RW disc (a blank disc) in the BR-900CD’s CD-R/RW drive. The drive’s access indicator will begin to flash. Wait until this indicator stops flashing and turns off before proceeding.

  • Page 151: Using Smf

    Using SMF Playing SMFs using external MIDI instruments (SMF Player) You can use the BR-900CD to read SMFs from CD-R/RW discs and play these files using MIDI instruments connected to the MIDI OUT port. Any SMFs that satisfy the following conditions can be played in this way.

  • Page 152: Loading Drum Patterns From The Cd-R/Rw Drive (Smf Import)

    Channel 10 is generally assigned as the channel used for rhythm performances. Thus, only the data on MIDI Channel 10 in the SMF is isolated and imported by the BR-900CD. Note that the data on other channels is disregarded. 1. Using a PC, burn a CD-R/RW disc containing the SMFs you want to import.

  • Page 153: Erasing Data From A Cd-Rw Disc (Cd-Rw Erase)

    5. Press CURSOR [ ] to move the cursor to “SMF,” and press [ENTER]. The SMF menu screen will appear. fig.05-CDsmf 6. Press CURSOR [ ] to move the cursor to “IMPORT,” and press [ENTER]. The SMF import screen appears. fig.05-CDsmfplay If the SMFs are collected in a folder, then the folder name is displayed.

  • Page 154: Importing Songs From Cds To Audio Tracks

    Importing Songs from CDs to Audio Tracks The BR-900CD allows you to import selected songs from a audio CD to audio tracks. (CD-R/RW Write) Important Notice • The BR-900CD and its CD-R/RW drive are designed to allow you to reproduce material for which you...

  • Page 155: Section 6 Using Midi

    Section 6 Using MIDI...

  • Page 156: Midi Fundamentals

    MIDI IN: This connector accepts the MIDI messages arriving from other MIDI devices. MIDI OUT: All the MIDI messages from the BR-900CD are sent out from this connector. MIDI THRU: This connector re-transmits all the MIDI messages that arrive at the MIDI IN connector.

  • Page 157: Synchronizing With Midi Devices

    Perform the procedure given below to use a MIDI sound module and choose the sounds you desire for the Rhythm. 1. Use a MIDI cable to connect the BR-900CD and your MIDI sound module as shown in the diagram. fig.05-401...

  • Page 158: Synchronizing Playback With A Midi Sequencer

    When synchronizing with a MIDI sequencer, it is possible to synchronize the MIDI sequencer using the BR-900CD (i.e., with the BR-900CD as the master), but it is not possible to synchronize the BR-900CD with the MIDI sequencer (i.e., with the BR-900CD as the slave).

  • Page 159: Setting The Mtc Offset

    MIDI sequencer using the external MIDI clock. 8. Get the MIDI song data ready for playback. When the BR-900CD begins playing, the MIDI sequencer will also begin playing in sync with it. What are drop and non-drop formats? There are two types of format used by NTSC video cassette recorders, non-drop and drop.

  • Page 160: Using Mmc

    MIDI System Exclusive messages to remotely control multiple recording devices from one device. Your BR- 900CD supports the MMC protocol. By using MMC, your BR-900CD can send commands such as PLAY, STOP, and FF to connected MIDI devices to operate them.

  • Page 161: Section 7 Using Usb

    Section 7 Using USB...

  • Page 162: Before Using Usb (Overview)

    SMF Folder SMF File USB Folder WAV/AIFF File ROLAND Folder The structure of the files and folders on the BR-900CD is as follows. BR0 Folder Song data (recording data, song arrangements/patterns/ drum kits, effect song patches, and song information) are saved to each song folder.

  • Page 163: Connecting A Computer

    USB Folder WAV and AIFF files loaded to the BR-900CD’s tracks, and WAV and AIFF files saved on computers (track data converted to WAV and AIFF format) will be saved here (p. 165, p. 167, p. 176, p. 178). Folders and files created on memory cards are displayed on the computer screen.

  • Page 164: With Windows

    With Windows Backing Up the BR-900CD’s Data 1. Connect your computer and the BR-900CD with a USB cable. 2. Confirm that the recorder is stopped, then press [UTILITY]. 3. Press CURSOR [ ] to move the cursor to “USB,” and press [ENTER].

  • Page 165: Saving Br-900Cd Track Data In Wav/Aiff Format (Wav/Aiff Export)

    3. Also erase track data other than that for the tracks you want to export (see p. 73). 4. Export the data. 5. Restore the backed up data to the BR-900CD (see the Step 5 “HINT” on p. 164). Using a high-capacity memory card For more on supported memory cards (CompactFlash) for the BR-900CD, refer to the separate sheet “About Memory...
  • Page 166 Click the “BOSS_BR-900” (or “Removable disk (*:)”) icon. Drag the WAV or AIFF file in the “USB” folder in the “ROLAND” folder to the computer’s folder and drop it in the folder. fig.06-114d When you have finished exporting the data, the Idling screen returns to the display.

  • Page 167: Loading Wav/Aiff Files In Br-900Cd Tracks (Wav/Aiff Import)

    Pattern mode at the time of the import, it takes place in accord with the timing of the Pattern mode. 1. Connect your computer and the BR-900CD with a USB cable. 2. Confirm that the recorder is stopped, then press [UTILITY].
  • Page 168 Once the import is complete, you are returned to the screen for specifying the import-source track/V-Track. At this point, you can safely disconnect the USB cable from the BR-900CD and the computer. 10. Repeat Steps 4–8 as needed. 11. When you have finished importing the WAV or AIFF file(s), press [EXIT] repeatedly to return to the Play screen.

  • Page 169: Importing Smfs And Creating Patterns

    Add the extension “MID” to SMFs you are importing. ● Use file names containing eight alphanumeric characters. 1. Connect your computer and the BR-900CD with a USB cable. 2. Confirm that the recorder is stopped, then press [UTILITY]. 3. Press CURSOR [ ] to move the cursor to “USB,”...
  • Page 170 Channel 10 is generally assigned as the channel used for rhythm performances. Thus, only the data on MIDI Channel 10 in the SMF is isolated and imported by the BR-900CD. Note that the data on other channels is disregarded. 12. Turn the TIME/VALUE dial to select the import- destination song pattern, then press [ENTER].

  • Page 171: Loading Drum Sounds From Wav/Aiff Files (Tone Load)

    7 seconds → Total 13 seconds ● Stereo WAV and AIFF files are loaded as “mono” sounds with the left and right sides mixed. 1. Connect your computer and the BR-900CD with a USB cable. 2. Confirm that the recorder is stopped, then press [UTILITY].
  • Page 172 * WAV and AIFF files in the TONELOAD folder are retained without being deleted even after this procedure is completed. If these files are no longer needed, connect the BR-900CD to your computer via USB and use the computer to delete the files.

  • Page 173: Using The Br-864 / Br-532'S Data

    Using the BR-864 / BR-532’s Data You can use the BR-900CD to play BR-864 (or BR-532) data. * First be sure to back up the BR-864 / BR-532’s “ROLAND” folder to the computer. 1. Initializing the memory card on the BR-900CD (p. 196).
  • Page 174 [ENTER] returns the USB screen to the display. fig.06-106ad 10. When backup of the data is complete, press [EXIT] to return to the Play screen. At this point, you can safely disconnect the USB cable from the BR-900CD and the computer.

  • Page 175: With Macintosh

    With Macintosh Backing Up the BR-900CD’s Data 1. Connect your computer and the BR-900CD with a USB cable. 2. Confirm that the recorder is stopped, then press [UTILITY]. 3. Press CURSOR [ ] to move the cursor to “USB,” and press [ENTER].

  • Page 176: Saving Br-900Cd Track Data In Wav/Aiff Format (Wav/Aiff Export)

    3. Also erase track data other than that for the tracks you want to export (see p. 73). 4. Export the data. 5. Restore the backed up data to the BR-900CD (see the Step 5 “HINT” on p. 175). Using a high-capacity memory card For more on supported memory cards (CompactFlash) for the BR-900CD, refer to the separate sheet “About Memory...
  • Page 177 8. Export the WAV or AIFF file to the computer. Double-click the “BOSS_BR-900” icon. Drag the WAV or AIFF file in the “USB” folder in the “ROLAND” folder to the computer’s folder and drop it in the folder. fig.06-119d When you have finished exporting the data, the Idling screen returns to the display.

  • Page 178: Loading Wav/Aiff Files In Br-900Cd Tracks (Wav/Aiff Import)

    Pattern mode at the time of the import, it takes place in accord with the timing of the Pattern mode. 1. Connect your computer and the BR-900CD with a USB cable. 2. Confirm that the recorder is stopped, then press [UTILITY].

  • Page 179: Importing Smfs And Creating Patterns

    ● Add the extension “MID” to SMFs you are importing. ● Use file names containing eight alphanumeric characters. 1. Connect your computer and the BR-900CD with a USB cable. 2. Confirm that the recorder is stopped, then press [UTILITY]. 3. Press CURSOR [ ] to move the cursor to “USB,”...
  • Page 180 Channel 10 is generally assigned as the channel used for rhythm performances. Thus, only the data on MIDI Channel 10 in the SMF is isolated and imported by the BR-900CD. Note that the data on other channels is disregarded. 12. Turn the TIME/VALUE dial to select the import- destination song pattern, then press [ENTER].

  • Page 181: Loading Drum Sounds From Wav/Aiff Files (Tone Load)

    7 seconds → Total 13 seconds ● Stereo WAV and AIFF files are loaded as “mono” sounds with the left and right sides mixed. 1. Connect your computer and the BR-900CD with a USB cable. 2. Confirm that the recorder is stopped, then press [UTILITY].
  • Page 182 * WAV and AIFF files in the TONELOAD folder are retained without being deleted even after this procedure is completed. If these files are no longer needed, connect the BR-900CD to your computer via USB and use the computer to delete the files.

  • Page 183: Using The Br-864 / Br-532'S Data

    Using the BR-864 / BR-532’s Data You can use the BR-900CD to play BR-864 / BR-532 data. * First be sure to back up the BR-864 / BR-532’s “ROLAND” folder to the computer. 1. Initializing the memory card on the BR-900CD (p. 196).
  • Page 184 MEMO...

  • Page 185: Other Convenient Functions

    Section 8 Other Convenient Functions...

  • Page 186: Adjusting The Display Contrast

    Adjusting the Display Contrast Depending on where the BR-900CD is situated, the display contents may be difficult to read. If this is the case, perform the procedure given below to adjust the contrast (1 to 21). fig.00-309 1. Press [UTILITY].

  • Page 187: Using A Foot Switch Or Expression Pedal

    Using a Foot Switch or Expression Pedal You can connect an optional foot switch (such as the BOSS FS-5U or Roland DP-2) or expression pedal (such as the Roland EV-5 or BOSS FV-300L) to the FOOT SW/EXP PEDAL jack on the rear panel, allowing you to use your foot to control a number of functions.

  • Page 188: Tuning An Instrument (Tuner)

    Explanation of the indications that appear while tuning When the built-in tuner of the BR-900CD is used, the reference pitch is shown in the upper left of the display, and the note name in the right. The lower part will display a tuning guide to indicate the difference between the input sound and the displayed note.

  • Page 189: Tuning

    “A” key at the center of a piano keyboard) from the instrument that serves as the reference pitch during performances (e.g., piano). On the BR-900CD, you can set the reference pitch of the tuner to any value between 435 and 445 * This was set to 440 Hz when the unit was shipped from the factory.

  • Page 190: Mixing The Output From An External Midi Device With The Output From Your Br-900Cd (Audio Sub Mix)

    900CD so you won’t need an external mixer. Also, since you can output the signal from the MIDI device without having to first record it to a track on the BR-900CD, you can use the BR-900CD tracks more effectively. fig.05-501...

  • Page 191: Using Condenser Microphones (Phantom Power)

    MIC 1 or to the GUITAR/BASS jack. • The phantom power setting reverts to “OFF” whenever the BR-900CD is turned on. Remember, therefore, to turn on this power supply whenever it is needed. • No supply of phantom power will be needed from the BR-900CD when using an external microphone pre-amp or a dedicated, external phantom power supply.

  • Page 192: Copying Difficult Songs (Phrase Trainer)

    * The Rhythm does not sound when Phrase Trainer is on. 1. Record the song you want to copy onto tracks 5 and 6. For how to record with the BR-900CD, refer to “(7) Basic Recording” (p. 39). 2. Repeat the portion of the song that you want to copy.
  • Page 193 3. To emphasize the bass sound, press CURSOR [ ] to select “Low Boost,” and turn the TIME/VALUE dial and adjust the value so that the bass sound is more easily heard. fig.05-303d 4. Press CURSOR [ ] to select “C.Adjust,” and turn the TIME/VALUE dial and adjust the value of the sound that you want to remove to decrease its volume.

  • Page 194: Initializing The Br-900Cd's Settings

    Initializing the BR-900CD’s Settings Initializing All the BR-900CD’s Settings The following settings are initialized together at one time. • System Settings • Effects (User Patches/Song Patches) • Rhythm (Arrangements/Patterns/Drum Kits) 1. Press [UTILITY]. 2. Press CURSOR [ ] to move the cursor to “INI,”...

  • Page 195: Initializing The Effect Settings

    To cancel, press [EXIT] (NO) (or [UTILITY]). When [ENTER] is pressed, initialization begins. After the initialization has been completed, you are returned to the Play screen. Initializing the BR-900CD’s Settings Initializing the Rhythm Arrangements/Patterns/Drum Kits This initializes the Rhythm Arrangements, Patterns, and Drum Kits.

  • Page 196: Initializing The Memory Card

    900CD, the demo songs on the card will be lost. Before you insert or remove a memory card, always turn off the BR-900CD first. If a memory card is inserted when the power is turned on, the data in the memory card may be destroyed, or the memory card may become unusable.

  • Page 197: Conserving Battery Power (Power Save)

    Conserving Battery Power (Power Save) Your BR-900CD is equipped with a power save function that limits the current dissipation during use. When the power save function is activated, if no button, or TIME/VALUE dial on the BR-900CD is used for a certain amount of time, the BR-900CD will enter the standby state and turn off the display backlight and button indicators.

  • Page 198: Utility Parameter List

    Utility Parameter List Utilities include the following: • “System parameters” for setting functions affecting the entire BR-900CD • “Sync parameters” for setting synchronized performance functions • “Scrub parameters” for setting scrub functions About the System Parameters This section describes the System parameters.

  • Page 199: About The Scrub Parameters

    Sets the time required to align the song playback and MTC timing when synchronizing an external device using MTC from the BR-900CD. The offset is set as the difference between the “time to which to align the MTC timing” and the “time to which to align the song timing.”...
  • Page 200 MEMO...

  • Page 201: Section 9 Appendices

    Section 9 Appendices...

  • Page 202: Effect Patch List

    Effect Patch List ■ GTR (GUITAR/BASS) Patch Name Algorithm JC Clean COSM GTR AMP HiGainLd COSM GTR AMP Over Drv COSM GTR AMP Phased COSM GTR AMP Crunch COSM GTR AMP MS Strgt COSM GTR AMP St WACK COSM GTR AMP Ambient COSM GTR AMP Voxy!
  • Page 203 ■ MIC Patch Name Algorithm Vo Comp1 COSM COMP VCL Vo Comp2 COSM COMP VCL Kick Cmp COSM COMP VCL SnareCmp COSM COMP VCL BrassCmp COSM COMP VCL VocalFx1 VOCAL MULTI VocalFx2 VOCAL MULTI VocalFx3 VOCAL MULTI VocalFx4 VOCAL MULTI NARRATOR VOCAL MULTI VOX DOUB...
  • Page 204 Effect Patch List ■ SML (SIMUL) Patch Name Algorithm EQ + JC VO+GT AMP DELAY+JC VO+GT AMP CMP+TWIN VO+GT AMP EQ+twin VO+GT AMP CMP+SMAL VO+GT AMP EQ+CRNCH VO+GT AMP EQ+MATCH VO+GT AMP DL+match VO+GT AMP EQ+VO VO+GT AMP COMP+vo VO+GT AMP CMP+BLUS VO+GT AMP CMP+BG...

  • Page 205: Mastering Tool Kit Patch List

    Mastering Tool Kit Patch List ■ MTK (MASTERING TOOL KIT) Patch Name Mix Down PreMastr Live Mix Pop Mix DanceMix JinglMix HardComp SoftComp CleanCmp DanceCmp OrchComp VocalCmp Acoustic RockBand Orchestr LowBoost Brighten DJsVoice PhoneVox Pitch Correction Patch List ■ PCR (PITCH CORRECTION) Patch Name Alto Soprano...

  • Page 206: Arrangement / Pattern List

    Arrangement / Pattern List Preset Arrangement List Each of the preset Arrangement (except Metro4/4) is set so that a three-measure BREAK, followed by V1 (verse) comes after the E (ending). Arrangement Initial Name Tempo ROCK1 ROCK2 ROCK3 ROCK4 ROCK5 ROCK6 HdRck1 HdRck2 HdRck3...

  • Page 207: Preset Pattern List

    Preset Pattern List Initial Pattern Name Tempo (Abbreviation shown in display) ROCK1 ROCK2 ROCK3 ROCK4 ROCK5 ROCK6 Hard Rock 1(HdRc1) Hard Rock 1(HdRc2) Hard Rock 1(HdRc3) Hard Rock 1(HdRc4) Hard Rock 1(HdRc5) HEAVY1 (HEVY1) HEAVY2 (HEVY2) HEAVY3 (HEVY3) HEAVY4 (HEVY4) HEAVY5 (HEVY5) POP1 POP2...

  • Page 208: Parameter List

    Parameter List (*1) If you want to save the settings as the currently selected song data, hold down [STOP] and press [REC]. (*2) Stored in the BR-900CD. (*3) Not Stored. Mixer Parameter (*1) Parameter Name Input Select Recording Mode Chorus / Delay / Doubling...
  • Page 209 Recorder Parameter (*1) Parameter Name Recording Track V-Track Auto Punch On/Off Auto Punch In/Out Locator Repeat * The settable range for Auto Punch In/Out, Locator and Repeat will change slightly depending on the MTC Type (sync parameter). Song Parameter (*1) Parameter Name Song Name Data Type...
  • Page 210 Parameter List CD Parameter Parameter Name Pre Gap Scrub Parameter (*3) Parameter Name Scrub From/To Mode Preview Switch Rhythm Parameter (*1) Parameter Name Arrangement / Pattern / Off Arrangement Pattern Rhythm Pad (*3) Arrangement Parameter Parameter Name Step Tempo Starting Measure Pattern Drum Kit Pattern Parameter...

  • Page 211: Troubleshooting

    If this does not resolve the problem, contact a nearby Roland service center or your dealer. Problems with the Sound No sound ❍ Is the power of the BR-900CD and of the connected equipment turned on? ❍ Are the audio cables connected correctly? ❍ Are any audio cables broken? ❍...
  • Page 212 Synchronization Problems Cannot Synchronize When using MTC to synchronize the BR-900CD with a MIDI sequencer, the BR-900CD must be the master device. ❍ Is the MIDI cable connected correctly? ❍ Is the MIDI cable broken? ❍...

  • Page 213: Error Messages

    Card Read Error! Cause: Memory card data cannot be loaded correctly. Solution 1: Turn off the BR-900CD, properly insert the memory card, then turn the BR-900CD back on. Solution 2: Initialize the card (p. 196). * If the same message appears after you have taken the above steps, it is possible that the memory card is malfunctioning.
  • Page 214 Perform the Song Optimize operation (p. 78). What is an event? The smallest unit of memory used by the BR-900CD to store recorded results on a memory card is the event. A newly created song provides approximately 2,000 events per song.
  • Page 215 Erase unneeded songs (p. 77). Unformatted! Cause: The Memory card is not formatted by DOS. Solution 1: Turn off the BR-900CD, properly insert the memory card, then turn the BR-900CD back on. Solution 2: Initialize the card (p. 196). Unsupported Card!

  • Page 216: Midi Implementation

    Minutes Count xxyyyyyy yyyyyy Hours Count xyyzzzzz * The time code types defined by the MIDI specification correspond to the BR-900CD Sync parameter “MTC Type” as follows. MIDI specification setting 0 = 24 Frames/Sec 1 = 25 Frames/Sec 2 = 30 Frames/Sec (Drop Frame) 3 = 30 Frames/Sec (Non Drop Frame) zzzzz Hours (0–23)

  • Page 217: Midi Implementation

    2. MIDI Machine Control ■MIDI Machine Control Command Reference ●STOP (MCS) Status Byte * If the transport switch [STOP] was pressed, the BR-900CD transmits this message. ●DEFERRED PLAY (MCS) Status Status Byte * If the transport switch [PLAY] was pressed, the BR-900CD transmits this message.
  • Page 218 MIDI Implementation ●LOCATE (MCP) ❍Format 2 - LOCATE [TARGET] Status Data Bytes 7FH, Dev, 06H, 44H, 06H, 01H, hrH, mnH, scH, frH, ffH F7H Byte Description Status of Exclusive Message Universal System Exclusive Message Realtime Header Device ID (7FH) MMC Command Message LOCATE(MCP) Number of Bytes “TARGET”...

  • Page 219: Midi Implementation Chart

    DIGITAL RECORDING STUDIO MIDI Implementation Chart Model BR-900CD Function... Default Basic 1–16 Channel Changed 1–16 Default Mode 3 Mode Messages Altered ************** 31, 33, 34, 36, 38, 41, 42, Note 45, 46, 48–51, 56 True Voice Number : ************** Note ON O 9n V=1–127...

  • Page 220: Specifications

    DA Conversion: Internal Processing: 24 bit (digital mixer section) * AF method (Adaptive Focus method) Adaptive Focus is a unique Roland/BOSS technology that allows the signal noise (S/N) ratios of AD and DA converters to be vastly improved. ● Sample Rate 44.1 kHz...

  • Page 221: Power Supply

    13-7/8 (W) x 8-7/8 (D) x 2-3/4 (H) inches ● Weight 2.2 kg/4 lbs 14 oz (excluding batteries) ● Accessories AC Adaptor (PSC-series) Demo Card (Already inserted when the BR-900CD is shipped) Owner’s Manual Separate sheet (“About Memory Cards” etc.) Roland Service (information sheet) ● Options...

  • Page 222: Index

    Index Symbols ... 69, 72, 75 Numerics ... 159, 199 ... 159, 199 ... 158, 199 ... 158, 199 ... 158, 199 ... 52, 198 AB Qtz ... 99 ... 22, 26 AC Adaptor ... 21 Access indicator ... 89 ACOUSTIC GTR ...
  • Page 223 ... 43–44, 108–109 CHO/DLY ... 44, 108, 111 CHORUS ... 94, 108 Chorus ... 188 Chromatic Tuner ... 98 CLEAN ... 129 Click ... 5, 16, 27, 31 CompactFlash ... 162 Compatible OS ... 94, 107 Compressor ... 7 Condenser mic ...
  • Page 224 Index ... 43, 110 ... 43, 96, 105 Equalizer ... 124–125, 133, 138, 153 ERASE Erasing ... 125 Arrangement ... 153 Data from a CD-RW ... 138 Drum sounds ... 133 Pattern ... 77 Song ... 124 Step ... 74–75 Track ...
  • Page 225 ... 194 Initializing ... 194 ... 195 Effect setting ... 31, 196 Memory card ... 195 Rhythm ... 194 System setting ... 40, 50, INPUT ... 94, 106 Input ... 105 Input Gain ... 35 INPUT LEVEL knob ... 39, 48 INPUT SELECT ...
  • Page 226 Index ... 158 ... 21 MEAS ... 127, 130 Measure ... 20 MEMORY CARD ... 5, 16, 27, 31 Memory Card ... 162 Composition of data ... 62 Remaining memory ... 78 Saving memory ... 98 METAL ... 98 METAL D ...
  • Page 227 ... 123 Pattern Number ... 205 ... 105 PEAK ... 101 Peak ... 35 PEAK indicator ... 98, 101 PEDAL ... 7, 191 Phantom power ... 191, 198 Phantom SW ... 97 Phaser ... 192 [PHRASE TRAINER] ... 192 Phrase Trainer ...
  • Page 228 ... 121 Rhythm Mode ... 127, 131, 134 [RHYTHM PAD] ... 99 Ring Modulator ... 99 RiseTme ... 162 ROLAND Folder ... 44, 108, 111 ROOM ... 195 S EFX ... 29, 79 Saving ... 86 Insert Effects ... 104 Mastering Tool Kit ...
  • Page 229 ... 149 TONE ... 94, 111 Tone ... 135, 149, 171, 181 Tone Load ... 162 TONELOAD Folder ... 93 Top-Hi ... 93 Top-Mid ... 101 TOUCH ... 87, 135 TRACK ... 39, 41, 48 Track ... 140 Track At Once ...

  • Page 230: Track Sheet

    Track Sheet...
  • Page 231 DECLARATION OF CONFORMITY Compliance Information Statement Model Name : BR-900CD Type of Equipment : Digital Recording Studio Responsible Party : Roland Corporation U.S. 5100 S.Eastern Avenue, Los Angeles, CA 90040-2938 Address : (323) 890-3700 Telephone : NOTICE AVIS For the U.K.
  • Page 232 **********...

Table of Contents
