Planet WGS-804HP User Manual

1. Package Contents
Thank you for purchasing PLANET 8-Port 10/100/1000T
Wall Mounted Gigabit Ethernet Switch with 4-Port PoE+,
WGS-804HP. "Wall-mounted PoE Switch" mentioned
in this Guide refers to the WGS-804HP.
Open the box of the Wall-mounted PoE Switch and
carefully unpack it. The box should contain the following
items:
 The Wall-mounted PoE Switch x 1
 User Manual x 1
 DIN-rail Kit x 1
 Wall-mounted kit x 1
 Magnet Kit x 1
 3-pin Terminal Block Connector x 1
 RJ45 Dust-proof Cap x 8
If any item is found missing or damaged, please contact
your local reseller for replacement.
- 1 -
2. Hardware Description
The front panel of the WGS-804HP PoE Ethernet Switch
consists of 8 x Auto-Sensing 10/100/1000Mbps Ethernet
RJ45 Ports. The LED Indicators are also located on the
RJ45 ports of the PoE Ethernet Switch.
Gigabit 802.3at PoE+ Port
Data+ Power
1 2 3 4
PoE Power LNK ACT
Usage (W)
PoE In-Use
120
PoE Power Usage 90
60
30
Power LED
PWR
8-Port Gigabit Ethernet Switch
3-pin Terminal Block
with 4-Port PoE+
1000
LNK ACT
Data
5 6 7 8
DC Plug-in 10/100/1000Base-T RJ45 Port
- 2 -
2.1 Terminal Block Connector Pinouts
To install the 3-pin Terminal Block Connector on the
WGS-804HP, simply follow the following steps:
Step 1: Insert positive DC power wire into V+,
negative DC power wire into V-, and grounding
wire into Ground.
Ground
V
-
V+
Step 2: Tighten the wire-clamp screws for preventing
the wires from loosening and plug into the
wall-mounted switch.
1. The wire gauge should be in the range
from 12 to 24 AWG
2. The device must be grounding
Note
3. The DC power input range is 48V ~ 56V DC
2.2 LED Indicators
 System
LED Color Function
Lights to indicate that the Switch has
PWR Green
power.
- 3 -
 PoE 10/100/1000BASE-T interfaces
(Port-1 to Port-4)
LED Color Function
Lights: To indicate the link through
that port is successfully
established.
LNK/
Green
ACT
Blink: To indicate that the switch is
actively sending or receiving
data over that port.
Lights: To indicate the port is
providing DC in-line power.
PoE Orange
Off: To indicate the connected
device is not a PoE Powered
Device (PD)
 10/100/1000BASE-T interfaces
(Port-5 to Port-8)
LED Color Function
Lights: To indicate the link through
that port is successfully
established.
LNK/
Green
ACT
Blink: To indicate that the switch is
actively sending or receiving
data over that port.
- 4 -
Lights: To indicate that the port is
operating at 1000Mbps.
Off: If LNK/ACT LED is lit, it
indicates that the port is
1000 Green
operating at 10/100Mbps.
If LNK/ACT LED is Off, it
indicates that the port is link-
down.
 PoE Power Usage (Unit: Watt)
LED Color Function
Lights: To indicate the system
30 Green consumes over 30-watt PoE
power budget
Lights: To indicate the system
60 Green consumes over 60-watt PoE
power budget
Lights: To indicate the system
90 Green consumes over 90-watt PoE
power budget
Lights: To indicate the system
120 Green consumes over 120-watt PoE
power budget
- 5 -
2.3 Product Specifications
Model WGS-804HP
Hardware Specifications
Network
8-Port RJ45 for 10/100/1000BASE-T
Connector
4-Port with 802.3af / 802.3at PoE
PoE Inject Port
injector function
MAC Address 8K MAC address table with auto
Table learning function
Data Buffer 64Kbytes
Switch Fabric 16Gbps
Switch
11.9Mpps@64Bytes
Throughput
Back pressure for half duplex. IEEE
Flow Control
802.3x pause frame for full duplex
Power
48~56V DC, 3A (max.)
Requirements
Power
140 watts / 478BTU
Consumption
ESD Protection 6KV DC
EFT Protection 6KV DC
- 6 -
Enclosure IP30 aluminum
Dimensions
148 x 24.2 x 134mm
(W x D x H)
Weight 510g
Power over Ethernet
IEEE 802.3af / 802.3at Power over
PoE Standard
Ethernet PSE
PoE Power
End-span
Supply Type
Power Pin
1/2(+), 3/6(-)
Assignment
IEEE 802.3af Standard
- Per port 48V~56V DC (depending
on the power supply), 15.4 watts
PoE Power (max.)
Output IEEE 802.3at Standard
- Per port 50V~56V DC (depending
on the power supply), 30 watts
(max.)
PoE Power
120 watts
Budget
- 7 -
Standard Conformance
IEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3ab Gigabit Ethernet
Standard
IEEE 802.3x Flow Control
Compliance
IEEE 802.3af Power over Ethernet
IEEE 802.3at Power over Ethernet
Plus
Regulation
FCC Part 15 Class A, CE
Compliance
Environment
Temperature: -10 ~ 60 degrees C
Operating Relative Humidity: 5 ~ 95%
(non-condensing)
Temperature: -20 ~ 70 degrees C
Storage Relative Humidity: 5 ~ 95%
(non-condensing)
- 8 -
