QUICK SETUP GUIDE
RF-TVMLPT02
Thank you for choosing the
Rocketfish RF-TVMLPT02.
The RF-TVMLPT02 TV mount
is designed to support
a TV weighing up to
80 lbs. (36.37 kg).
Package contents
A Wall plate (1)
B Left TV bracket (1)
C Right TV bracket (1)
M4 bag
A
D M4 x 12 mm screws (4)
E M4 x 30 mm screws (4)
F M4/M5 washers (8)
G M4/M5 spacers (4)
M5 bag
H M5 x 12 mm screws (4)
M4 bag
I M5 x 30 mm screws (4)
D E
M6 bag
M4 x 12mm M4 x 30mm
J M6 x 12 mm screws (4)
K M6 x 20 mm screws (4)
L M6 x 35 mm screws (4) M5 bag
H I
M M6 washers (4)
N M6 spacers (4)
M5 x 12mm M5 x 30mm
Hex key bag
M6 bag
O 3⁄ 1 6 in. hex key (1)
J K
Lag bolt bag
M6 x 12mm M6 x 20mm M6 x 35mm
P Concrete anchors (3)
Q Lag bolt washers (3)
R 5⁄ 1 6 in. x 23⁄ 4 in. lag bolts (3)
Tools you will need:
• Phillips screw driver
• Stud finder
• Hammer (Concrete Only)
• Awl
• ½ in. socket wrench
• Pencil
• 3/16 in. wood drill bit
• Level
• 3/8 in. masonry drill bit (Concrete Only)
• Tape measure
• Power drill
1 Attach the TV brackets
Option 1: Attaching to
a at mounting
surface
Attach the left and right TV
brackets (B and C) to the
back of the TV using:
The M4/M5 washers (F) and
the M4 x 12 mm screws (D) or
the M5 x 12 mm screws (H).
Or
The M6 washers (M) and
the M6 x 12 mm screws (J) or
the M6 x 20 mm screws (K).
C
B
Option 2: Attaching to a curved or
irregular mounting surface
Attach the left and right TV brackets (B and C)
F G to the back of the TV using:
The M4/M5 spacers (G), M4/M5 washers (F),
and the M4 x 30 mm screws (E) or M5 x 30 mm
M4/M5
M4/M5 screws (I).
Or
Hex key bag
The M6 spacers (N), M6 washers (M), and
the M6 x 35 mm screws (L).
O
Note: Use the M4 washers (F) between
the spacers and the bracket with the M4
M
N or M5 screws only.
L
M6
M6
Lag bolt bag
P Q
R
in. x 2 in.
C
B
or
or
F
C
B
C
or
G N
F
B
B
or
C
2 Install the wall plate
Option 1: Installing to a wood stud wall
Caution: Avoid potential injuries or property damage! DO NOT over-tighten the lag bolts.
Note: Any material covering the wall must not exceed 5/8 in. (16 mm).
a. Locate the studs. Verify the center of the stud with an awl or thin nail or use an edge-to-edge stud finder.
b. Level the wall plate (A) and mark hole locations.
c. Drill pilot holes as illustrated.
d. Align the wall plate (A) with the pilot holes, then place the lag bolt washers (Q) over the holes. Insert the
lag bolts (R) through the washers, then tighten the lag bolt with a socket wrench only until they are pulled
firmly against the wall plate.
M
D H
J K
b.
A
d.
or
F M
E I
Q
R
L
a.
< 16 mm
5 ⁄8
( in.)
c.
75mm
3 in.
