Troubleshooting

Please read this User Guide carefully before using your universal
wireless rear speaker kit. Check this list for a possible troubleshooting
solution before calling for service.
Problem
No sound
Sound interference
No communication between the sender and
receiver
Solution
• Make sure that the AC adapter is connected to the sender and the power
cord is connected to the AC supply for the receiver.
• Make sure that all the cables are connected correctly. Check to see if the
LEDs illuminate on the front of both the sender and receiver units. If the
LEDs are lit solidly, the communication is working correctly and all speaker
wires and the amplifier operation should be checked. If the LEDs are
flashing, refer to the "No communication between the sender and receiver"
section below.
• Move the sender and receiver slowly to find the best reception position for
your system.
• Shorten the distance between your sender and receiver. The maximum
distance is 100 feet.
• Check to determine if there are any obvious radio frequency interference
sources near your system.
• Make sure that the power cords are connected correctly.
• After the power buttons have been pressed to turn on both the sender and
receiver, the front panel LEDs should light. If they are solidly on, a
communication link has been successfully established between the units. If
they are flashing on one or both units, press and hold the CONNECT button
on either the sender or receiver for two seconds. (The sender's CONNECT
button is on the bottom and the receiver's CONNECT button is on the back
panel.) This will put the unit into the "connection mode" for about 30
seconds. During this period the CONNECT button on the other unit must
also be pressed for two seconds so that it will also enter "connection mode."
The system proceeds with the connection process between the sender and
receiver. While in "connection mode," the LED indicators blink at a faster
rate. When an active link is established between the sender and receiver,
the LED indicators will be solid on and will not blink.
Note: Try pressing the CONNECT buttons again if the LED indicators keep
blinking after 30 seconds.
RF-WHTIB 15
