Aztech MWR638 Easy Start Manual

Easy Start Guide
MWR638
3G Mobile Wi-Fi
This Easy Start Guide is designed to help you immediately
use and configure your Aztech MWR638 3G Mobile Wi-Fi's
basic settings according to your needs.
This Easy Start Guide together with the User Manual which
provides a more advanced guide to this product can be
downloaded from our Aztech Website
( www.aztech.com > Categories > Aztech Datacom >
Mobile Wi-Fi > MWR638 )
Contents
Package Contents........................................................2
Device Overview............................................................3
Setting Up Your Device..................................................4
Internet Connectivity....................................................6
Connecting Wirelessly..................................................6
The Web User Interface.................................................8
Configuring your Wireless Network..............................9
Factory Default Reset...................................................9
Device Tips & Reminders............................................10
1 Package Contents
The following items are included in your package:
• 3G Mobile Wi-Fi • Easy Start Guide
• Battery Pack • Warranty Policy
• USB Cable
2
2 Device Overview
Your Aztech MWR638 converts your SIM Card's 3G / 2G
signal to Wi-Fi signals, giving your wireless devices
constant internet access, anytime and anywhere.
Screen Display
Reset Button
Power Button
Micro USB Port
Screen Display
Icons
Signal Strength
Indicator
/ Network Type
Network/Operator
Information
WiFi Status &
Device User Count
Automatic/Manual
Dial Mode
Internet Status
Data Usage
New SMS
Indicator
Inbox Full Roaming Status
3
Device Label Sticker
Found underneath the
battery pack of your
device, the label sticker
contains the default
SSID (wireless network
name), WiFi Key (wireless
You may opt to write
password), the web user
down the WiFi Key of
interface IP Address and
your Aztech MWR638 for
its login password.
easier reference.
3 Setting up Your Device
A. SIM Card Installation
1. Remove the
bottom cover
BOTTOM
and battery pack
COvER
of your Aztech
MWR638 device.
2. Insert the
standard SIM
BATTERY
PACK
card on your
device's SIM
card slot.
SIM CARD
3. Return the
battery pack
and bottom
cover in place.
4
B. Charging your Device
Connect your Aztech MWR638 to your Desktop / PC
using the USB Cable included in the package.
NOTE : You
may also use
a 5V 1A phone
charger for
your device.
C. Turning ON your Aztech MWR638
Press and hold the power
button until the Screen
Display turns ON.
Note : To turn OFF, press
and hold the power button
until the Screen Display
turns OFF.
D. PIN Lock
If your SIM has an active PIN code, you may have
to log in to the web user interface of your Aztech
MWR638 and correctly enter it first. You may opt to
disable this feature later on.
Note: For more details regarding your SIM Card's
PIN / PUK Code, please contact your service
provider.
5
