OPERATOR'S MANUAL
Reciprocating Saw
R3000
Variable Speed
This new saw has been engineered and manufactured to our high standards for dependability, ease of operation, and operator
safety. When properly cared for, the saw will give you years of rugged, trouble-free performance.
WARNING:
To reduce the risk of injury, the user must read and understand the operator's manual before using this product.
Thank you for buying a RIDGID product.
SAVE THIS MANUAL FOR FUTURE REFERENCE
1
®

Advertisement

Table of Contents
loading

Related Manuals for RIDGID R3000

Summary of Contents for RIDGID R3000

  • Page 1 When properly cared for, the saw will give you years of rugged, trouble-free performance. WARNING: To reduce the risk of injury, the user must read and understand the operator’s manual before using this product. Thank you for buying a RIDGID product. SAVE THIS MANUAL FOR FUTURE REFERENCE ®...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS General Safety Rules ... 3-4 Specific Safety Rules ... 4 Symbols ...5 Specifications ... 6 Unpacking ... 7 Applications ... 7 Features ... 8-9 Operation ... 10-12 Maintenance ... 13 Warranty ... 14 Notes ...15 Customer Service Information ... 16 INTRODUCTION The Reciprocating Saw has many features for making the use of this product more pleasant and enjoyable.

  • Page 3: General Safety Rules

    GENERAL SAFETY RULES WARNING: Read and understand all instructions. Failure to follow all instructions listed below, may result in electric shock, fire and/or serious personal injury. SAVE THESE INSTRUCTIONS Work Area Keep your work area clean and well lit. Cluttered benches and dark areas invite accidents.

  • Page 4: Specific Safety Rules

    GENERAL SAFETY RULES Service Tool service must be performed only by qualified repair personnel. Service or maintenance performed by unqualified personnel could result in a risk of injury. SPECIFIC SAFETY RULES Hold tool by insulated gripping surfaces when performing an operation where the cutting tool may contact hidden wiring or its cord.

  • Page 5: Symbols

    SYMBOLS Important: Some of the following symbols may be used on your tool. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the tool better and safer. SYMBOL NAME Volts Amperes Hertz Watt Minutes Alternating Current...

  • Page 6: Specifications

    SPECIFICATIONS Input ... 120 Volts, 60 Hz, AC Only, 9.0 amperes No load speed ... 0-2800 /min. Stroke Length ... 1 1/8 in. (28.6 mm) Switch ... Variable Speed ELECTRICAL DOUBLE INSULATION Double insulation is a concept in safety in electric power tools, which eliminates the need for the usual three-wire grounded power cord.

  • Page 7: Unpacking

    UNPACKING INSTRUCTIONS When unpacking the tool: Carefully remove the tool and accessories from the box. Make sure that all items listed in the packing list are in- cluded. Inspect the tool carefully to make sure no breakage or damage occurred during shipping. Do not discard the packing material until you have care- fully inspected and satisfactorily operated the tool.

  • Page 8: Features

    By doing this you will get a smoother, faster cut and prolong blade life. Replacement blades for this saw are available from your nearest Ridgid dealer. SWITCH To turn your saw ON, pull switch trigger.
  • Page 9 FEATURES INSULATED GRIPPING SURFACE SWITCH TRIGGER BASE (SHOE) ASSEMBLY INSULATED GRIPPING SURFACE SAW BLADE BLADE CLAMP LOCK / RELEASE LEVER ILLUMINATED PLUG Fig. 1...

  • Page 10: Operation

    OPERATION WARNING: Always wear safety googles or safety glasses dur- ing powertool operation or when blowing dust. If operatin is dusty, also wear a dust mask. WARNING: Exercise caution when using this tool. Careless actions, for even a fraction of a second, can result in serious personal injury.
  • Page 11 OPERATION WARNING: Cutting into electrical wiring in walls can cause metal surfaces of the saw to become electrically live. Do not touch metal parts when cutting into a wall; grasp only the insulated gripping surfaces pro- vided on the tool. Make sure hidden electrical wir- ing, water pipes and mechanical hazards are not in the blade path when cutting into a wall.

  • Page 12: Operation

    OPERATION METAL CUTTING See Figure 7. Metals such as sheet steel, pipe, steel rods, aluminum, brass, and copper may be cut with your saw. Be careful not to twist or bend the saw blade. Do not force. We recommend cutting oil when cutting most soft metals and steel. Cutting oil will also keep blades cool, increase cutting action, and prolong blade life.

  • Page 13: Maintenance

    MAINTENANCE WARNING: When servicing use only identical RIDGID® re- placement parts. Use of any other parts may cre- ate a hazard or cause product damage. WARNING: The tool should never be connected to a power supply when you are assembling parts, making adjustments, cleaning, performing maintenance, or when the tool is not in use.

  • Page 14: Warranty

    THREE YEAR WARRANTY This warranty covers all defects in workmanship or materials in this RIDGID tool for the three year period from the date of purchase. This warranty is specific to this tool. Warranties for other RIDGID products may vary.

  • Page 15: Notes

    NOTES...

  • Page 16: Customer Service Information

    Customer Service Information: For parts or service, contact your nearest RIDGID authorized service center. Be sure to provide all relevant information when you call or visit. For the location of the authorized service center nearest you, please call 1-866-539-1710 or visit us online at www.ridgidwoodworking.com.
