PARTS AND FEATURES

UNIT
c a
DIGITAL DISPLAY ACTION INDICATORS AND CONTROL PANEL
a b
d
POWER
e
LEVEL
X 2
f
PROG
g
STOP/
h
RESET
START
i
d
b
Figure 3
c
1
2
3
4
5
j
6
7
8
9
0
Figure 2
e
a. "X2" indicates cooking in X2 feature.
b. "PROG" indicates programming.
c. Numbers "1 - 2 - 3" indicate the cooking stage.
d. "HI - MED - DEF" Indicates power level used in
cooking.
e. Power level pad
f. X2 pad
g. Program pad
h. Stop/Reset pad
i. Start pad
j. Number/Memory pads
8
a. Door
b. Door Safety
Lock System
c. Door Handle
d. Oven Window
e. Control Panel
