A. O. SMITH
GREEN
E X P E R T S E R V I C E
1800-103-2468/1860-500-2468
+91 99410 32468 (WhatsApp) or
aosmithcs@aosmithindia.com
Monday to Friday: 9 a.m. to 8 p.m.
Saturday & Sunday: 9 a.m. to 6 p.m.
# For calls registered at A. O. Smith Call Centre before 4 p.m. only.
Available only in selected cities. For more details, please call our
Customer Care Centre or log on to www.aosmithindia.com
USER GUIDE
Water Purifier
With MIN-TECH
(Mineraliser Tecnology)

Advertisement

Table of Contents
loading

Related Manuals for A.O. Smith X4+

Summary of Contents for A.O. Smith X4+

  • Page 1 Water Purifier A. O. SMITH With MIN-TECH GREEN (Mineraliser Tecnology) E X P E R T S E R V I C E 1800-103-2468/1860-500-2468 +91 99410 32468 (WhatsApp) or aosmithcs@aosmithindia.com Monday to Friday: 9 a.m. to 8 p.m. Saturday & Sunday: 9 a.m. to 6 p.m. # For calls registered at A.
  • Page 3 Dear Customer, Congratulations and welcome to A. O. Smith family. We thank you for the trust you have shown in choosing the A. O. Smith Water Purifier. A. O. Smith Water Purifier is one of the most advanced RO Water Purifier available in the market today.

  • Page 4: Table Of Contents

    Contents Key Features of your A. O. Smith RO Water Purifier .......... 01 Pre-instruction literature ..................02 General instructions ....................03 Introduction ......................04 Product overview ..................... 06 Function of indicators ....................07 Water flow ....................... 08 Electrical diagram..................... 08 Safety precautions....................

  • Page 5: Key Features Of Your A. O. Smith Ro Water Purifier

    Key Features of your A. O. Smith RO Water Purifier PURITY THROUGH 7 STAGE PURIFICATION 7S TECHNOLOGY: Pre-filter + SCB filter™ (Sediment filter + Carbon block) + ART™ (Advance Recovery Technology™) + Patented Side Stream RO Membrane + SCM-TECH™ (Silver Activated Post Carbon + MIN-TECH). In A. O. Smith water purifier 100% water passes through the RO membrane.

  • Page 6: Pre-Instruction Literature

    Pre-instruction Literature On Receipt It is our policy to promote safe delivery of all orders. This product shipment has been thoroughly checked, packed and quality certified before leaving our plant. Visible Loss or Damage If any of the goods called for on the bill of lading or express receipt are damaged or the quantity is short, do not accept them until the freight or express delivery agent makes an appropriate notation on your freight bill or receipt.

  • Page 7: General Instructions

    General Instructions Safety Your safety and the safety of your loved ones is paramount to us. There are several safety-related messages in this manual, which have been provided during various stages such as installation, operation and maintenance of your A. O. Smith RO Water Purifier.

  • Page 8: Introduction

    Introduction A. O. Smith RO Water Purifier uses one of the latest technologies that is used in water purification process. A. O. Smith RO Water Purifier works under the principle of RO (Reverse Osmosis) technology which is found to be one of the most effective process.
  • Page 9 Stage 5 – RO (Reverse Osmosis) membrane  RO membrane contains semi-permeable membrane wherein the water is passed through the semi-permeable membrane to remove TDS (Total Dissolved Solids) and heavy metals like mercury, arsenic, lead, chromium, cadmium etc. It also removes microorganisms like bacteria, virus, protozoa and cysts.

  • Page 10: Product Overview

    Product Overview Figure 2 Cover Water Level Display Panel Indicator Indicators Faucet Lever Main Body Drip Tray Cover Removable Drip Tray Front View Rear Cover Back View Overflow Reject water water Feed water inlet...

  • Page 11: Function Of Indicators

    Function of indicators Figure 3 Power indicator This indicates, that the system is switch ON/OFF condition. • When the power LED is blinking check feed water supply to the purifier Note: Call A. O. Smith Customer Care Centre if you notice continuous blinking of Power light. Filter change indicator This indicates that the RO membrane and other filters needs to be replaced.

  • Page 12: Water Flow

    Water flow Figure 4 Inlet Solenoid Pressure valve Switch Flush Solenoid Ball Pump valve Valve water Inlet water 3-way joint Pre-filter SCB filter Waste Pure water Water Flow Overflow Restrictor Water Level 1 Check Storage Valve Sensor Tank Level 2 Sensor Faucet SCM-TECH...

  • Page 13: Safety Precautions

    Safety Precautions Electrical safety Even though this product is designed keeping highest safety standards in mind, there are certain Do’s and Dont’s which need to be followed while using this product. Power plug must be used with a Do not pull out or touch power plug with grounded 230V outlet.
  • Page 14 Do not connect hot water to the product. Product should be installed only by (Figure 10) A. O. Smith Company Authorised Service Technician. Do not open the purifier for cleaning the filters or for any part replacements. This must be done only by A.

  • Page 15: How To Use

    How to use 1. Turn ON the water connection 2. Switch ON the power supply and press through the ball valve. (Figure 14) the power button of the purifier. (Figure 15) Figure 14 Figure 15 3. To dispense water from the storage 4.

  • Page 16: Draining Drip Tray

    Draining Drip Tray We have provided removable Drip Tray with the product. In case there is slippage of water, it gets collected in Drip Tray. 1. Remove the Drip Tray assembly by 2. Remove Drip Tray cover by pulling pulling forward. (Figure 18) upward and then drain completely.

  • Page 17: How To Maintain Your Product

    How to maintain your product Do not splash water directly or clean with Replace filters regularly according to the benzene, pesticides, thinner, alcohol, etc., replacement indications. This must be but use a soft, dry cloth to clean the done only by A. O. Smith Company purifier.

  • Page 18: Troubleshooting

    Troubleshooting Your A. O. Smith RO Water Purifier may not function at its desired capability if used incorrectly. This may not necessarily mean that the product is faulty. For instances like these, please follow the steps given below to troubleshoot the problem without help from a certified technician.
  • Page 19 Power LED blinks . Low pressure alarm is Check feed water supply to 5 times triggered indicating that the purifier. If problem still the system input water persists, switch OFF the pressure is not in the water purifier and call required range Customer Care Centre.
  • Page 20 Filter change LED blinks RO membrane and other Call Customer Care Centre and unit is not functioning. filters life ends. for RO membrane and other filters replacement.

  • Page 21: Technical Specifications

    Technical Specifications Model A. O. Smith Product Dimensions (H x D x W) 503 mm x 325 mm x 314 mm Net Weight 8.5 kgs (approx.) Gross Weight 13.2 kgs (approx.) Flow rate* Up to 15 litres per hour Storage tank capacity 9 litres (approx.) Purification technology RO (Reverse Osmosis)
  • Page 22 Recommended input Feed water quality for the optimum performance of your product RECOMMENDED FEED WATER QUALITY Parameter Limits Total Dissolved Solids (TDS) Up to 2000 ppm Total hardness Up to 500 ppm Turbidity Up to 5 NTU Iron 0.3 ppm (max.) Feed water pressure 7 psi to 30 psi Feed water temperature...

  • Page 23: Faqs

    FAQs What is A. O. Smith RO Water Purifier? A. O. Smith RO Water Purifier is advanced 7 stages RO from A. O. Smith. It is 100% RO with no bypass of water for maximum purity. What is 100% RO? In ordinary RO+UV Water Purifiers, some amount of water is made to bypass the RO membrane.
  • Page 24 What is tank overflow protection? The tank overflow protection feature, protects the Water Purifier tank from spilling in case of a water level sensor failure. Can A. O. Smith RO Water Purifier be wall mounted and used as a table top as well? Yes, A.

  • Page 25: Warranty Terms And Conditions

    Warranty Terms and Conditions Product Warranty A. O. Smith India Water Products Private Limited (“A. O. Smith or Company”) warrants this Water Purifier (“product”) against the defects arising from faulty design, workmanship and material subject to the following terms and conditions: 1.
  • Page 26 input. In these instances, the customer will have the option of paying the difference between what was paid for the original model and the new model with the additional features, or receiving a refund of the portion of the purchase price on a pro rata basis allocable to the unexpired portion of the warranty.
  • Page 27 h. If the input water is discoloured. If product is used for commercial purpose. If the iron content is high (more than 0.3 ppm). This would be determined solely by the company based on the city where the product is installed. k.
  • Page 28 Post Warranty 1. The customer may be offered a yearly Service Contract (PHCP*) at the prevailing Company rates and terms. 2. In case the customer does not wish to enter the Service Contract, customer has the option of calling our Authorised Service Provider and get A. O. Smith Water Purifier unit serviced on actual basis i.e.

  • Page 29: Warranty Card

    Warranty Card Customer Copy to be retained by the Customer Invoice Number: ______________________________ Dated: _________________________ Unit Serial Number: __________________________________ Model: _________________________ Capacity: ______________________ Customer's Name: _______________________________________________ Address: ____________________________________________________________________________ ____________________________________________________________________________________ Dealer’s Stamp and Signature Phone: ________________________ Mobile: ________________________ E-mail: ________________________ Company Copy to be sent back to the Company Invoice Number: ______________________________ Dated: _________________________ Unit Serial Number: __________________________________...

  • Page 30: Service And Maintenance

    Service and Maintenance For Service needs: Please contact our Customer Care : 1800-103-2468/1860-500-2468. : +91 99410 32468 WhatsApp E-mail us : aosmithcs@aosmithindia.com Registered Office A. O. Smith India Water Products Private Limited (formerly known as A. O. Smith India Water Heating Private Limited) Plot No.

  • Page 31: Disclaimer

    Disclaimer Disclaimer Power of 1 is limited to: 1. Available in selected cities, for details log on to www.aosmithindia.com or call at 1800-103-2468/1860-500-2468. 2. Calls registered with A. O. Smith Customer Care Centre on working days before 4 p.m. 3. Within city municipal limits only. 4.
  • Page 32 OVER A CENTURY OF INNOVATION A. O. Smith enjoys a rich history of achievements. A glimpse at our 144-years history reveals numerous engineering and technical achievements. 1874 1906 1889 1927 The Smith family started a small A. O. Smith was North America’s largest Mechanical shop in Milwaukee, automobile frame manufacturer.
