Summary of Contents for A.O. Smith X8
- Page 2 Dear Customer, Congratulations and welcome to A. O. Smith family. We thank you for the trust you have shown in choosing the A. O. Smith Water Purifier. A. O. Smith Water Purifier is one of the most advanced RO Water Purifier available in the market today.
-
Page 3: Table Of Contents
Contents Key Features of your A. O. Smith Water Purifier ..........01 Pre-instruction literature ..................02 General instructions ....................03 Introduction ......................04 Product overview ..................... 06 Function of indicators ....................07 Water flow ....................... 09 Electrical diagram..................... 09 Safety precautions....................10 How to use....................... -
Page 4: Key Features Of Your A. O. Smith Water Purifier
Key Features of your A. O. Smith RO Water Purifier PURITY THROUGH 8 STAGE PURIFICATION 8S TECHNOLOGY: Pre-filter + Sediment filter + Carbon block + ART™ (Advance Recovery Technology™) + Patented Side Stream RO Membrane + MIN-TECH (Mineraliser Technology) + ZX Double Protection Dual Filter* (Silver Activated Post Carbon block + SCMT). -
Page 5: Pre-Instruction Literature
Pre-instruction Literature On Receipt It is our policy to promote safe delivery of all orders. This product shipment has been thoroughly checked, packed and quality certified before leaving our plant. Visible Loss or Damage If any of the goods called for on the bill of lading or express receipt are damaged or the quantity is short, do not accept them until the freight or express delivery agent makes an appropriate notation on your freight bill or receipt. -
Page 6: General Instructions
General Instructions Safety Your safety and the safety of your loved ones is paramount to us. There are several safety-related messages in this manual, which have been provided during various stages such as installation, operation and maintenance of your A. O. Smith RO Water Purifier. -
Page 7: Introduction
Introduction A. O. Smith RO Water Purifier uses one of the latest technologies that is used in water purification process. A. O. Smith RO Water Purifier works under the principle of RO (Reverse Osmosis) technology which is found to be one of the most effective process. - Page 8 Stage 4 – ART™ (Advance Recovery Technology™) The ART™ is scale control media which conditions the water to reduce scaling potential in water. Stage 5 – RO (Reverse Osmosis) membrane RO membrane contains semi-permeable membrane wherein the water is passed through the semi-permeable membrane to remove TDS (Total Dissolved Solids) and heavy metals like mercury, arsenic, lead, chromium, cadmium etc.
-
Page 9: Product Overview
Product Overview A. O. Smith Water Purifier Figure 2 Front View Top Cover Water Level Indicator Main Body Faucet Knob Water Dispensing Nozzle Changeable Panel LED Display Panel Indicators Drip Tray Cover Removable Drip Tray Back View Rear Cover LED Display Reject water Panel Indicators Feed water inlet... -
Page 10: Function Of Indicators
Function of indicators Power Button This button is used to switch ON/OFF the Water Purifier. • When the Power button is blinking, check feed water supply to the purifier. Tank full indicator This indicates that the Water Purifier tank is full. •... - Page 11 SCPA change indicator This indicates that the pre and post RO filters need to be replaced. • SCPA change indicator starts blinking (buzzer 10 times) indicating that the pre and post RO filters life is reaching its end time. • When pre and post RO filters life reaches its end, SCPA change indicator keeps on blinking and the unit stops functioning.
-
Page 12: Water Flow
Water flow Figure 3 Inlet Solenoid Low Pressure valve Switch Flush Solenoid valve Pump Ball water Valve Inlet water Pre-filter Sediment Carbon ART™ Pure Waste 3-way joint filter Block water water Flow Restrictor Overflow water Storage Level 1 Sensor Check Tank Valve Level 2 Sensor... -
Page 13: Safety Precautions
Safety Precautions Electrical safety Even though this product is designed keeping highest safety standards in mind, there are certain Do’s and Don’ts which need to be followed while using this product. Power plug must be used with a Do not pull out or touch power plug with grounded 230V outlet. - Page 14 Product should be installed only by Do not connect hot water to the product. A. O. Smith Company Authorised Service (Figure 10) Technician. Do not open the purifier for cleaning the filters or for any part replacements. This must be done only by A.
-
Page 15: How To Use
How to use 1. Turn ON the water connection 2. Switch ON the power supply and press through the ball valve. (Figure 13) the power button of the purifier. (Figure 14) Figure 14 Figure 13 3. To dispense water from the storage tank, turn the faucet knob in anti-clockwise direction. - Page 16 Attaching Drip Tray (optional) 1. Remove the Cover Strip by pulling it 2. Attach the Drip Tray assembly into the out gently from the main body. main body through slots provided in (Figure 16) the main body. (Figure 17) Figure 16 Figure 17 Cover Strip...
-
Page 17: Draining Drip Tray
Draining Drip Tray We have provided removable Drip Tray with the product. In case there is slippage of water, it gets collected in Drip Tray. 1. Remove the Drip Tray assembly by 2. Remove Drip Tray cover by pulling it pulling it forward. -
Page 18: How To Maintain Your Product
How to maintain your product Do not splash water directly or clean with Replace filters regularly according to the benzene, pesticides, thinner, alcohol, etc., replacement indications. This must be but use a soft, dry cloth to clean the done only by A. O. Smith Company purifier. -
Page 19: Troubleshooting
Troubleshooting Your A. O. Smith Water Purifier may not function at its desired capability if used incorrectly. This may not necessarily mean that the product is faulty. For instances like these, please follow the steps given below to troubleshoot the problem without help from a certified technician. - Page 20 Buzzer beeps and Overflow error. Switch OFF the Water tank full LED blinks Purifier and call Customer continuously. Care Centre. Buzzer beeps for 8 Low pressure alarm is Check feed water supply to times and power LED triggered indicating that the purifier.
-
Page 21: Technical Specifications
Technical Specifications Model A. O. Smith Product Dimensions (H x D x W) 490 mm x 329 mm x 315 mm Net weight 9.5 kgs (approx.) Gross weight 13.9 kgs (approx.) Flow rate* Up to 15 litres per hour Storage tank capacity 9 litres (approx.) Purification technology RO (Reverse Osmosis) + Silver Charged... - Page 22 Recommended input Feed water quality for the optimum performance of your product RECOMMENDED FEED WATER QUALITY Parameter Limits Total Dissolved Solids (TDS) Up to 2000 ppm Total hardness Up to 500 ppm Turbidity Up to 5 NTU Iron 0.3 ppm (max.) Feed water pressure 7 psi to 30 psi Feed water temperature...
-
Page 23: Faqs
FAQs What is A. O. Smith RO water purifier? A. O. Smith RO is advanced 8 stage RO from A. O. Smith. It is 100% RO with no bypass of water for maximum purity. It is double purified by SCMT (Silver Charged Membrane Technology) and required essential minerals are added back to water. - Page 24 What all alerts do A. O. Smith RO has? A. O. Smith RO has alerts to change the SCPA (Sediment and Carbon block) and RO membrane, Silver Activated Post Carbon block along with SCMT (Silver Charged Membrane Technology) and MIN-TECH (Mineraliser). When does the A.
-
Page 25: Warranty Terms And Conditions
Warranty Terms and Conditions Product Warranty A. O. Smith India Water Products Private Limited (“A. O. Smith or Company”) warrants this Water Purifier (“product”) against the defects arising from faulty design, workmanship and material subject to the following terms and conditions: 1. - Page 26 9. If an identical model is no longer available due to a change in law, regulation, or standard, A. O. Smith will replace the product with one having a similar capacity and input. In these instances, the customer will have the option of paying the difference between what was paid for the original model and the new model with the additional features, or receiving a refund of the portion of the purchase price on a pro rata basis allocable to the unexpired portion of the warranty.
- Page 27 d. If product is repaired by unauthorised personnel and usage of non-recommended parts or consumables. e. If product serial number is missing or altered. If damage is caused by pest infestation. g. If the input water emits pungent smell. h. If the input water is discoloured. If product is used for commercial purpose.
- Page 28 Post Warranty 1. The customer may be offered a yearly Service Contract (PHCP*) at the prevailing Company rates and terms. 2. In case the customer does not wish to enter the Service Contract, customer has the option of calling our Authorised Service Provider and get A. O. Smith Water Purifier unit serviced on actual basis i.e.
-
Page 29: Warranty Card
Warranty Card Customer Copy to be retained by the Customer Invoice Number: ______________________________ Dated: _________________________ Unit Serial Number: __________________________________ Model: _________________________ Capacity: ______________________ Customer's Name: _______________________________________________ Address: ____________________________________________________________________________ ____________________________________________________________________________________ Dealer’s Stamp and Signature Phone: ________________________ Mobile: ________________________ E-mail: ________________________ Company Copy to be sent back to the Company Invoice Number: ______________________________ Dated: _________________________ Unit Serial Number: __________________________________... -
Page 30: Service And Maintenance
Service and Maintenance For Service needs: Please contact our A. O. Smith Customer Care Number : 1800-103-2468/1860-500-2468. SMS us : +91 99410 32468 E-mail us : aosmithcs@aosmithindia.com Registered Office A. O. Smith India Water Products Private Limited (formerly known as A. O. Smith India Water Heating Private Limited) Plot No. -
Page 31: Disclaimer
Disclaimer Power of 1 is limited to: 1. Available in selected cities, for details log on to www.aosmithindia.com or call at 1800-103-2468/1860-500-2468. 2. Calls registered with A. O. Smith Customer Care Centre on working days before 4 pm. 3. Within city municipal limits only. 4.
