Grandstream
HandyTone 50X/70X ATA
Quick User Guide
Basic Phone Operation
For detailed information please
consult the HT50X/70X User Manual
available at:
www.grandstream.com
©2014 Grandstream Networks, Inc. All rights
reserved.
Reproduction or transmittal of the entire or any
part, in any form or by any means, electronic or
print, for any purpose without the express writ-
ten permission of Grandstream Networks, Inc.
is not permitted. Information in this document is
subject to change without notice.
Basic Features
In order to make calls, answer calls, and
hold/resume calls, please refer to the User
Manual of your analog phone. Usually
there are two ways to end your digit input
and dial out the number: 1) wait for time
out 2) using "#" key.
CALL TRANSFER
Assuming that you are in a call and wish to
transfer the call to another party
B
t
:
lind
rAnsfer
1) Use "Flash" button on the analog phone
to hold the current call.
2) After dial tone is played, you can use
star code 87 to make the transfer: press
"*87" + the transfer target number.
3) End your dialing with "#" or wait for time
out.
4) You will be disconnected after transfer
is finished.
A
t
:
ttended
rAnsfer
1) Use "Flash" button on the analog phone
to hold the current call.
2) After dial tone is played, you can input
the transfer target number and dial out.
3) After your transfer target answers, You
can simply hang up your call, and the ATA
will complete the transfer automatically.
4) If your target does not answer the
call, you can press "Flash" to resume the
original call.
3-WAY CONFERENCE
Assuming that you are in a call and wish to
bring a third party into conference:
1) Press "Flash" to hold the current call.
2) After dial tone is played, you can input
the third party's number and dial out.
3) If the third party answers, press "Flash"
to bring both parties into the conference.
4) If the third party does not answer the
call, you can press "Flash" to resume the
original call.
5) If "Flash" is pressed during conference,
the third party will be dropped out.
6) If you hang up you phone, the con-
ference will be terminated for all three
parties. If the "Transfer on Conference
Hang-up" feature is enabled by your ser-
vice provider, then after you hang up, the
rest parties will still remain on the line for
further conversation.
Advanced Features
DND
To setup "Do Not Disturb":
1) Off-hook your phone.
2) After hearing the dial tone, input "*78",
and follow by "#" or wait for time out.
3) When DND is successfully enabled, you
will hear dial tone again. Then you can
hang up.
To disable "Do Not Disturb":
1) Off-hook your phone.
2) After hearing the dial tone, input "*79",
and then press "#" or wait for time out.
3) When DND is successfully disabled,
you will hear dial tone again. Then you can
hang up.
CALL FORWARD
U
f
:
nconditionAl
orwArd
All incoming calls will be forwarded.
1) Off-hook your phone.
2) After hearing the dial tone, input "*72"+
forwarding number and follow by "#" or
wait for time out.
3) Wait for dial tone and hang up.
4) Dial "*73" to cancel Unconditional
Forward.
B
f
:
Usy
orwArd
Incoming calls will be forwarded when your
phone is busy.
1) Off-hook your phone.
2) After hearing the dial tone, input "*90"+
forwarding number and follow by "#" or
wait for time out.
3) Wait for dial tone and hang up.
4) Dial "*91" to cancel Busy Forward.
d
f
:
elAy
orwArd
Incoming calls will be forwarded after ring
time out without being answered.
1) Off-hook your phone.
2) After hearing the dial tone, input "*92"+
forwarding number and follow by "#" or
wait for time out.
3) Wait for dial tone and hang up.
4) Dial "*93" to cancel Busy Forward.
CALL RETURN
In order to call back to the latest incoming
number.
1) Off-hook your phone.
2) After hearing the dial tone, input "*69",
and follow by "#" or wait for time out.
3) Your phone will automatically call back
to the latest incoming number.
Note
All star code (*XX) related features men-
tioned above are supported by ATA default
settings. If your service provider provides
different feature codes, please contact
them for instructions.
