User Manual
HandyTone-488
Analog Telephone Adaptor
For SW Release Version 1.0.2.6
Grandstream Networks, Inc.
www.grandstream.com

Advertisement

Table of Contents
loading

Related Manuals for Grandstream Networks HandyTone-488

Summary of Contents for Grandstream Networks HandyTone-488

  • Page 1 User Manual HandyTone-488 Analog Telephone Adaptor For SW Release Version 1.0.2.6 Grandstream Networks, Inc. www.grandstream.com...

  • Page 2: Installation

    HandyTone-488 User Manual Grandstream Networks, Inc. Installation HandyTone-488 Analog Telephone Adaptor is an all-in-one VoIP integrated device designed to be a total solution for networks providing VoIP services. The HandyTone-488 VoIP functionalities are available via a regular analog telephone. The following photo illustrates the appearance of a HandyTone-488.
  • Page 3 HandyTone-488 has one FXS port and one FXO port. The PHONE port next to the LAN port is a FXS port. The LINE port on the side of the HandyTone-488 is a FXO port. Both the FXS port and the FXO port can have a separate SIP account.

  • Page 4: What Is Included In The Package

    3) One Ethernet cable Safety Compliances The HandyTone-488 is compliant with various safety standards including FCC/CE and C-tick. Its power adaptor is compliant with UL standard. The HandyTone-488 should only operate with the universal power adaptor provided in the package. Warranty Grandstream has a reseller agreement with our reseller customer.

  • Page 5: Get Familiar With Voice Prompt

    Grandstream Networks, Inc. Basic Operations Get Familiar with Voice Prompt HandyTone-488 has stored a voice prompt menu for quick browsing and simple configuration. To enter this voice prompt menu, simply press the button or “***” from the analog phone. Menu...

  • Page 6: Make Phone Calls

    HandyTone-488 User Manual Grandstream Networks, Inc. Make Phone Calls 5.2.1 Calling phone or extension numbers To make a phone or extension number call: a) Dial the number directly and wait for 4 seconds (default “No Key Entry Timeout”). Or b) Dial the number directly, and press # (assuming that “Use # as dial key” is selected in web configuration).
  • Page 7 HandyTone-488 User Manual Grandstream Networks, Inc. Examples: If the target IP address is 192.168.0.160, the dialing convention is Voice Prompt with option 47, then 192168000160 followed by pressing the “#” key if it is configured as a send key or wait 4 seconds. In this case, the default destination port 5060 is used if no port is specified.
  • Page 8 HandyTone-488 User Manual Grandstream Networks, Inc. Note: When intended Transfer failed, if A hangs up, the HandyTone-488 will ring user A again to remind A that B is still on the call, by pressing FLASH or Hook again will restore the conversation between A and B.
