Shaft Hedge Clipper
Operator's Manual
MODEL
Read rules for safe operation and instructions carefully. ECHO provides an
Operator's Manual and a Safety Manual. Both must be read and understood for
proper and safe operation. Failure to do so could result in serous injury.
X7502253400
SHC-2100
Serial Number 0517101 & Up
WARNING
H
EDGE
O
'
PERATOR
DANGER
C
LIPPER
1
M
S
ANUAL
X750004210
01/02
Advertisement
Table of Contents
Related Manuals for Echo SHC-2100
Summary of Contents for Echo SHC-2100
- Page 1 Serial Number 0517101 & Up WARNING DANGER Read rules for safe operation and instructions carefully. ECHO provides an Operator's Manual and a Safety Manual. Both must be read and understood for proper and safe operation. Failure to do so could result in serous injury.
- Page 3 Make sure the decals are legible and that you understand and follow the instructions on them. If a decal cannot be read, a new one can be ordered from your ECHO dealer. See PARTS ORDERING instructions for specific information.
-
Page 4: International Symbols
Wear sturdy work shoes with nonskid soles; • DO NOT WEAR OPEN TOED SHOES, Hearing Protection • DO NOT OPERATE UNIT BAREFOOTED. Wear hearing protection. ECHO recommends wearing hearing protection whenever unit is used. Wear no-slip, heavy duty work gloves. -
Page 5: Extended Operation/Extreme Conditions
Use only ECHO approved attachments. Serious injury may result from the use of a non-approved attachment combination. ECHO, INC. will not be responsible for the failure of cutting devices, attachments, or accessories which have not been tested and approved by ECHO. Read and comply with all safety instructions listed in this manual and safety manual. -
Page 6: Safe Operation
SAFE OPERATION WARNING DANGER Do not operate this product indoors or in inadequately ventilated areas. Engine exhaust contains poisonous emissions and can cause serious injury or death. Provide all users of this equipment with the Operator's Manual and instructions for Safe Operation. Keep a Solid Stance •... - Page 7 The ECHO product you have purchased has been factory pre-assembled for your convenience. Due to packaging restrictions, some assembly of SHC-2100 is required. After opening the carton, check for damage. Immediately notify your retailer or ECHO Dealer of damaged or missing parts. Use the contents list to check for missing parts.
- Page 8 16. HEDGE CLIPPER SAFETY VIDEO - P/N 99922202800 (Not included with unit and English version only) is available for your review and purchase at a cost of $5.00 from ECHO, INC. or any authorized ECHO dealer. The video over- views safety precautions and proper operating techniques provided in detail in the Safety Manual, and is supplemen-...
-
Page 9: Specifications
EDGE LIPPER PERATOR ANUAL PECIFICATIONS ) l i . t i . l f i r t... -
Page 10: Drive Shaft
SSEMBLY GEAR HOUSING ASSEMBLY DRIVE SHAFT Tools Required: 8mm x 10mm Open End Wrench, 4 mm Hex Wrench Parts Required: Power Head/Drive Shaft Assembly and Gear Housing Assembly. NOTE Hedge Clipper Blades are very sharp. Wear gloves to protect hands. Slide the Gear Housing Assembly on the Drive Shaft. -
Page 11: Pre-Operation
Echo Premium 2-Stroke Oil may be mixed at 50:1 ratio for application Leaks can occur. Return unused fuel to an approved fuel storage container. in all Echo engines sold in the past regardless of ratio specified in those manuals. Storage... - Page 12 DANGER Blades should not move at idle. If blades move, readjust carbure- tor according to Carburetor Adjustment instructions in the manual or see your ECHO dealer, otherwise serious personal injury may result. NOTE Refer to the Hedge Clipper Safety Manual for proper and safe hedge clipping operation.
-
Page 13: Starting Warm Engine
Blades should not move at idle. If blades move, readjust carburetor according to Carburetor Adjustment instructions in the manual or see your ECHO dealer, otherwise serious personal injury may result. Stop Switch -Start/Run. Move Stop Switch button (A) away from the STOP position. -
Page 14: Stopping Engine
ECHO Service Dealer for maintenance. To help you decide whether you want to DO-IT-YOURSELF or have the ECHO Dealer do it, each maintenance task has been graded. If the task is not listed, see your ECHO Dealer for repairs. SKILL LEVEL Level 1 = Easy to do. -
Page 15: Maintenance Intervals
EDGE LIPPER PERATOR ANUAL MAINTENANCE INTERVALS n i l t I - t l i t l i n i l l f f l i o s t l t n i ® ® y l l . . n... -
Page 16: Air Filter
AIR FILTER Level 1. Tools required: 25 or 50 mm (1 or 2 in.) medium bristle paint brush Parts required: 90008 REPOWER Air & Fuel Filter Kit 1. Close choke (Cold Start Position). This prevents dirt from entering the carburetor throat when the air filter is removed. Brush accumu- lated dirt from the air cleaner area. -
Page 17: Spark Plug
EDGE LIPPER PERATOR ANUAL SPARK PLUG Level 2. Tools Required: T-Wrench. Feeler gauge, preferably a wire gauge. Brush. Parts Required: Spark Plug, NGK BPM-7A P/N 15901010630 1. Remove spark plug and check for fouling, worn and rounded center electrode. 2. Clean the plug or replace with a new one. DO NOT sand blast to clean. -
Page 18: Exhaust System
Remove spark plug lead from the spark plug and throttle linkage end from the carburetor swivel. Remove the four screws that retain the engine cover. Two at the top of the starter, two on either side of the front. Lift the cover from the engine and lay to the front of the hedge clipper. -
Page 19: Carburetor Adjustment
ANUAL CARBURETOR ADJUSTMENT Emission Models (with limiter caps) Level 2. Tools required: Screwdriver, Tachometer (ECHO P/N 99051130017). Parts required: None. NOTE Every unit is run at the factory and the carburetor is set in compli- ance with emission regulations. In addition, the carburetor is equipped with HI and LO needle adjustment limiters that prevent settings outside acceptable limits. - Page 20 Loosen bolts 1/2 turn. Hold bolts (A) from turning and tighten locknuts (B) with other 10 mm wrench. Gear Case Tools required: Grease Gun with Lithium Grease, Rag. Parts required: ECHO LUBE (P/N 91014) or Lithium Based Grease. ®...
-
Page 21: Sharpening Blades
Drive Shaft Assembly NOTE Hedge Clipper drive shaft should be greased every 25-50 hours of operation. Tools required: 8 mm Open End Wrench, Screwdriver, Clean Rag, Small Brush. Parts required: ECHO LUBE (P/N 91014) or Lithium Based Grease. ® WARNING DANGER Blades are very sharp. -
Page 22: Troubleshooting
ROUBLESHOOTING r o t r o t i a r i l l r o t r e l i l y i l y r o t r e l f f u r e l h t i r u t r / n r i a... - Page 23 EDGE LIPPER PERATOR ANUAL TORAGE WARNING DANGER During operation the muffler or catalytic muffler and surrounding cover become hot. Always keep exhaust area clear of flammable debris during transportation or when storing, otherwise serious personal injury may result. Long Term Storage (over 30 days) Do not store your unit for a prolonged period of time (30 days or longer) without performing protective storage mainte- nance which includes the following: Store unit in a dry, dust free place, out of the reach of children.
-
Page 24: Echo Consumer Product Support
• Sending a check or money order for $2.00 per Parts Catalog or $1.50 per Operator's Manual made payable to ECHO, INCORPORATED. State on a sheet of paper the model number and serial number of the ECHO unit you have, part number of the manual (if known), your name and address and mail to address below. - Page 25 Please contact us if you have any questions, or if you need help assembling, operating, or maintaining your ECHO equipment. See the back page of your Operator's Manual for detailed instructions on how to contact ECHOConsumer Product Support for help, or how to order additional litera-...
- Page 26 If engine does not stop when stop switch is moved to STOP position, Manual and Safety Manual (if included) close choke - COLD START position - to stall engine. Have your ECHO for proper and safe operating tech- dealer repair stop switch before using trimmer again.
