DAILY REFERENCE
GUIDE
THANK YOU FOR BUYING AN INDESIT PRODUCT.
Before using the appliance carefully read Health and Safety guide.
PRODUCT DESCRIPTION
1
2
3
4
5
11
12
13
14
CONTROL PANEL
B. Thermostat Knob
MAX
-
TEMPERATURE SETTING
Thermostat set to MIN: low cooling intensity
Thermostat set between MIN and MAX : cooling intensity can be
adjusted according to the preferences.
Thermostat set to MAX: maximum refrigeration intensity.
7
8
9
MIN
MED
Download the Use and Care Guide by connecting
WWW
to the website www.indesit.eu and follow the
procedures outlined on the back cover.
6
10
For the best food conservation MED position is recommended.
Thermostat set to • : cooling and lighting off.
Note: Displayed set points correspond to the average temperature
throughout the whole refrigerator.
Refrigerator compartment
1. Electronic control panel / light unit
2. Shelves
3. Rating plate with commercial name
4. Fruits and vegetables crisper
5. Door reversibility kit
6. Door trays
7. Egg tray
8. Bottle holder
9. Bottle balcony
10. Door seal
Freezer compartment
10. Door seals
11. Freezer drawers
12. Shelves
13. Bottom drawer: coolest zone best for
freezing fresh food
14. Ice tray
A. Light bulb
B. Thermostat knob
C. Thermostat seeting indicator
D. Light button
A
B C D
EN
1
Advertisement
Related Manuals for Indesit LR8S1S
Summary of Contents for Indesit LR8S1S
-
Page 1: Product Description
DAILY REFERENCE GUIDE Download the Use and Care Guide by connecting THANK YOU FOR BUYING AN INDESIT PRODUCT. to the website www.indesit.eu and follow the procedures outlined on the back cover. Before using the appliance carefully read Health and Safety guide. -
Page 2: First Time Use
ACCESSORIES EGG TRAY BOTTLE HOLDER ICE TRAY FIRST TIME USE HOW TO START THE APPLIANCE After plugging the appliance to the mains, turn the thermostat knob After starting the appliance, wait at least 4-6 hours before placing to switch on the appliance: cooling and light will switch on; set the food into the fridge and into the freezer compartment. -
Page 3: Troubleshooting Guide
TROUBLESHOOTING GUIDE Problem Possible Cause Solution THE APPLIANCE IS NOT WORKING There may be an appliance power supply › Check if power cable plugged into a live problem. socket with the proper voltage. › Check if the protection devices and fuses of the electrical system in your home THERE IS WATER IN THE DEFROST PAN This is normal in hot, damp weather. - Page 4 HOW TO STORE FOOD AND BEVERAGE Legend TEMPERATE ZONE Suggested for the storage of tropical fruit, cans, drinks, eggs, sauces, pickles, butter, jam COOL ZONE Suggested for storage of cheese, milk, dairy food, delicatessen, yogurt, cold cuts, desserts FRUIT & VEGETABLE DRAWER NORMAL FREEZER DRAWERS FREEZING ZONE DRAWER (MAX COOL ZONE) Suggested to freeze...
