- Page 1 CS1912 / CS1914 2/4-Port USB 3.0 DisplayPort KVMP™ Switch User Manual www.aten.com...
-
Page 2: Emc Information
CS1912 / CS1914 User Manual EMC Information FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 3: User Information
CS1912 / CS1914 User Manual User Information Online Registration Be sure to register your product at our online support center: International http://eservice.aten.com Customer Support For contact information, see Technical Support, page 37. User Notice All information, documentation, and specifications contained in this manual are subject to change without prior notification by the manufacturer. -
Page 4: Package Contents
* Features may have been added to the CS1912 / CS1914 since this manual was printed. Please visit our website to download the most up-to-date version... -
Page 5: Table Of Contents
CS1912 Front View ........ - Page 6 CS1912 / CS1914 User Manual Chapter 5. Hotkey Operation Port Switching..........19 Cycling Through the Ports.
-
Page 7: About This Manual
CS1912 / CS1914 User Manual About this Manual This User Manual is provided to help you get the most from your CS1912 / CS1914 unit. It covers all aspects of installation, configuration and operation. An overview of the information found in the manual is provided below. -
Page 8: Conventions
For information about all ATEN products and how they can help you connect without limits, visit ATEN on the Web or contact an ATEN Authorized Reseller. Visit ATEN on the Web for a list of locations and telephone numbers: International http://www.aten.com... -
Page 9: Chapter 1 Introduction
3840 x 2160 @ 30 Hz resolution that displays high-definition images while pumping out premium sound for music, movies and games. As a KVM switch, the CS1912 / CS1914 allows users to access two or four DisplayPort computers from a single USB keyboard, USB mouse and monitor console. -
Page 10: Features
Supports HD audio through DisplayPort** Full bass response for high-quality 2.1 channel surround sound systems Power On Detection – if a computer is powered off the CS1912 / CS1914 automatically switches to the next powered-on computer Dual-Mode DisplayPort technology (DP++) supports passive HDMI and DVI adapters*** Hot pluggable –... - Page 11 Chapter 1. Introduction 4. PC keyboard combinations emulate Mac keyboards. Mac keyboards only work with their own operating system.
-
Page 12: Requirements
Audio port for sound Cables Two DisplayPort cables, two USB 3.0 cables and two 3.5 mm Audio cables included with the CS1912 package. Four DisplayPort cables, four USB 3.0 cables and four 3.5 mm Audio cables included with the CS1914 package. -
Page 13: Operating Systems
Chapter 1. Introduction Operating Systems Version Windows 2000 / XP / Vista / 7 / 8 / 8.1 / 10 Linux RedHat 6.0 and higher SuSE 8.2 and higher Mandriva 9.0 and higher (Mandrake) Novell Netware 5.0 and higher OS 9 and higher 6.2 and higher... -
Page 14: Components
CS1912 / CS1914 User Manual Components CS1912 Front View CS1914 Front View... - Page 15 Chapter 1. Introduction Component Description Port Selection For manual port selection (see Manual Switching, page 13): Pushbuttons Press a port selection pushbutton for longer than two seconds to bring the KVM, USB hub, and audio focus to the computer attached to its corresponding port. Press a port selection pushbutton twice to bring the audio focus to the computer attached to its corresponding port.
-
Page 16: Cs1912 Rear View
CS1912 / CS1914 User Manual CS1912 Rear View CS1914 Rear View Component Description Console Ports The cables from your DisplayPort monitor, USB keyboard, USB mouse, speakers, and microphone plug in here. Each connector is marked with an appropriate icon to indicate its use. -
Page 17: Chapter 2. Hardware Setup
Chapter 2 Hardware Setup 1. Important safety information regarding the placement of this device is provided on page 35. Please review it before proceeding. 2. Make sure that power to all the devices you will be installing has been turned off. You must unplug the power cords of any computers that have the Keyboard Power On function. - Page 18 CS1912 / CS1914 User Manual 7. (Optional) Plug your USB peripherals into the type A sockets in the USB hub section. 8. Plug the power adapter (provided with this package) into the switch’s Power Jack and then plug the other end into a power source.
-
Page 19: Installation Diagram
Chapter 2. Hardware Setup Installation Diagram Audio, DisplayPort, USB 3.0 Cables USB 3.0 DisplayPort Audio... - Page 20 CS1912 / CS1914 User Manual This Page Intentionally Left Blank...
-
Page 21: Chapter 3. Basic Operation
Chapter 3 Basic Operation Manual Switching There are three convenient methods to switch between the computers: Manual – by pressing the port selection pushbuttons on the front panel, Mouse – by clicking the scroll wheel of the mouse, and Hotkey – by entering combinations on the keyboard. -
Page 22: Hot Plugging
Each KVM port section on the CS1912 / CS1914 switch is assigned a port number. (1 or 2 for the CS1912; 1 to 4 for the CS1914). The port numbers are marked on the rear panel of the switch (see page 8 for details). -
Page 23: Alternative Manual Port Selection Settings
Chapter 3. Basic Operation Alternative Manual Port Selection Settings When Hotkey Setting Mode has been activated, pressing [S] will invoke the alternative front panel pushbutton manual port selection functions, as explained below: Press a port selection pushbutton once to bring the KVM, audio and USB focus to the computer attached to its corresponding port. - Page 24 CS1912 / CS1914 User Manual This Page Intentionally Left Blank...
-
Page 25: Chapter 4. Keyboard Emulation
Chapter 4 Keyboard Emulation Mac Keyboard PC-compatible (101/104 key) keyboards can emulate the functions of a Mac keyboard. The emulation mappings are listed in the table below. PC Keyboard Mac Keyboard [Shift] Shift [Ctrl] Ctrl [Ctrl] [1] [Ctrl] [2] [Ctrl] [3] [Ctrl] [4] [Alt] [Print Screen]... - Page 26 CS1912 / CS1914 User Manual This Page Intentionally Left Blank...
-
Page 27: Port Switching
Chapter 5 Hotkey Operation The CS1912 / CS1914 provides an extensive, easy-to-use, hotkey function that makes it convenient to control and configure your KVM installation from the keyboard. Hotkeys provide asynchronous (independent) switching of the KVM, USB hub, and audio focus. Therefore, you can give one computer the KVM focus, another the USB hub focus, while a third has the audio focus. -
Page 28: Going Directly To A Port
CS1912 / CS1914 User Manual Going Directly to a Port Hotkey Action [Scroll Lock] [Scroll Lock] Brings the KVM, USB, and audio focus to the computer [n] [Enter] attached to the port corresponding to the specified Port Note that the KVM, USB, and audio focus all go to this port even if they were on different ports to begin with. -
Page 29: Auto Scanning
Chapter 5. Hotkey Operation Auto Scanning The CS1912 / CS1914’s Auto Scan feature automatically cycles the KVM focus through the computer ports at regular intervals. This allows you to monitor the computer activity without having to take the trouble of switching from port to port manually. -
Page 30: Hotkey Setting Mode
CS1912 / CS1914 User Manual Hotkey Setting Mode Hotkey Setting Mode is used to set up your CS1912 / CS1914 switch’s configuration. All operations begin with invoking Hotkey Setting Mode (HSM). Invoking HSM To invoke HSM, do the following: 1. Press and hold down the Num Lock key. -
Page 31: Alternate Hsm Invocation Keys
Chapter 5. Hotkey Operation Alternate HSM Invocation Keys An alternate set of HSM invocation keys is provided in case the default set conflicts with programs running on the computers. To switch to the alternate HSM invocation set, do the following: 1. -
Page 32: Keyboard Operating Platform
CS1912 / CS1914 User Manual Keyboard Operating Platform The CS1912 / CS1914’s default port configuration is for a PC-compatible keyboard operating platform. If your console uses a PC-compatible keyboard and you have a Mac attached to a port, for example, you can change the port’s keyboard operating platform configuration so that the PC-compatible keyboard emulates the Mac keyboard. -
Page 33: Keyboard Language
Note: This procedure is a toggle. To enable the Port Switching keys, repeat steps 1 and 2. Firmware Upgrade Mode To set the CS1912 / CS1914 to Firmware Upgrade Mode, do the following: 1. Invoke HSM (see page 22 for details). 2. Key in: upgrade 3. -
Page 34: Restore Default Settings
CS1912 / CS1914 User Manual Restore Default Settings To reset the CS1912 / CS1914 to its default hotkey settings, do the following: 1. Invoke HSM (see page 22 for details). 2. Press [R] [Enter]. All hotkey settings return to the factory default values. See Hotkey Default Settings, page 40. -
Page 35: Keyboard Emulation
Chapter 5. Hotkey Operation Keyboard Emulation The console keyboard port emulation/bypass feature supports most gaming/ multimedia keyboards. The default setting is enabled. To disable, do the following: 1. Invoke HSM (see page 22). 2. Press [N]. This procedure is a toggle. Repeat to enable. Note: When keyboard emulation is disabled, the [M], [W], [F2], [F4], [F5], [F6], and [F10] hotkey operations are disabled. -
Page 36: Hsm Summary Table
CS1912 / CS1914 User Manual HSM Summary Table After invoking HSM (see page 22), key in one of the following keys to perform the corresponding function: Function Toggles the beeper On and Off. Enables/Disables the Power on Detection feature. Toggles between the default and alternate HSM invocation keys. -
Page 37: The Firmware Upgrade Utility
1. From a computer that is not part of your KVM installation, go to our Support & Download site and choose the model name that relates to your device (CS1912 / CS1914) to get a list of available Firmware Upgrade Packages. 2. Choose the Firmware Upgrade Package you want to install (usually the most recent), and download it to your computer. - Page 38 Port 1. 5. Press and hold the Port 1 selection pushbutton. While you are holding the button, connect the power adapter to the CS1912 / CS1914 to enter Firmware Upgrade Mode. The front panel LEDs flash together to indicate...
-
Page 39: Starting The Upgrade
6. The Firmware Upgrade Utility Starting the Upgrade 1. Run the downloaded Firmware Upgrade Package file – either by double clicking the file icon, or using a command line to enter the full path. The Firmware Upgrade Utility Welcome screen appears: 2. - Page 40 CS1912 / CS1914 User Manual 4. As you select a device in the list, its description appears in the Device Description panel.After you have made your device selection(s), click Next to perform the upgrade. If you enabled Check Firmware Version, the Utility compares the device’s firmware level with that of the upgrade files.
-
Page 41: Upgrade Successful
After the upgrade has completed, a screen appears to inform you that the procedure was successful: Click Finish to close the Firmware Upgrade Utility. After a successful completion, the CS1912 / CS1914 exits Firmware Upgrade Mode, and resets itself. Upgrade Failed... - Page 42 CS1912 / CS1914 User Manual This Page Intentionally Left Blank...
-
Page 43: Appendix
Appendix Safety Instructions Read all of these instructions. Save them for future reference. This device is for indoor use only. Follow all warnings and instructions marked on the device. Do not place the device on any unstable surface (cart, stand, table, etc.). If the device falls, serious damage will result. - Page 44 CS1912 / CS1914 User Manual purpose of the grounding-type plug. Always follow your local/national wiring codes. Do not allow anything to rest on the power cord or cables. Route the power cord and cables so that they cannot be stepped on or tripped over.
-
Page 45: Technical Support
International For online technical support – including troubleshooting, documentation, and software updates: http://support.aten.com For telephone support or to contact an ATEN regional office: www.aten.com/support When you contact us, please have the following information ready beforehand: Product model number, serial number, and date of purchase. -
Page 46: Specifications
CS1912 / CS1914 User Manual Specifications Function CS1912 CS1914 Connections Computer Console Port Selection Pushbuttons, Hotkey, Mouse* Connectors Console Keyboard 1 x USB Type A (Black) Ports Video 1 x DisplayPort (White) Mouse 1 x USB Type A (Black) Speakers 1 x 3.5 mm Mini Stereo Jack (Green: Front) -
Page 47: Troubleshooting
Appendix Troubleshooting Operation problems can be due to a variety of causes. The first step in solving them is to make sure that all cables are securely attached and seated completely in their sockets. In addition, updating the product’s firmware may solve problems that have been discovered and resolved since the prior version was released. -
Page 48: Hotkey Default Settings
CS1912 / CS1914 User Manual Hotkey Default Settings The hotkey factory default settings are as follows: Setting Default Port Switching [Scroll Lock] [Scroll Lock] Invoking HSM [Number Lock] [-] Auto Scan Interval 5 Seconds Beeper Keyboard Operating PC-Compatible Platform Port Switching Keys... -
Page 49: Limited Warranty
Appendix Limited Warranty IN NO EVENT SHALL THE DIRECT VENDOR'S LIABILITY EXCEED THE PRICE PAID FOR THE PRODUCT FROM DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THE PRODUCT, DISK, OR ITS DOCUMENTATION. The direct vendor makes no warranty or representation, expressed, implied, or statutory with respect to the contents or use of this documentation, and especially disclaims its quality, performance, merchantability, or fitness for any particular purpose. - Page 50 Printing Date: 2016-11-04 © Copyright 2016 ATEN® International Co., Ltd. ATEN and the ATEN logo are registered trademarks of ATEN International Co., Ltd. All rights reserved. All other brand names and trademarks are the registered property of their respective owners.
