SECTION 6 PARTS LIST
[MAIN UNIT]
REF ORDER
NO. NO.
IC1 1130007610 S.IC
IC2 1110003490 S.IC
IC3 1110003780 S.IC
IC4 1130008090 S.IC
IC5 1110001810 S.IC
IC6 1180001740 S.IC
IC7 1130009680 S.IC
IC8 1140003750 S.IC
IC10 1190000350 S.IC
IC11 1130009110 S.IC
IC12 1110003800 S.IC
Q1 1560001050 S.FET
Q2 1560001020 S.FET
Q3 1530003230 S.TRANSISTOR 2SC5085-Y (TE85R)
Q4 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q5 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q6 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q7 1530003230 S.TRANSISTOR 2SC5085-Y (TE85R)
Q8 1530003230 S.TRANSISTOR 2SC5085-Y (TE85R)
Q10 1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
Q11 1590001190 S.TRANSISTOR XP6501-(TX) .AB
Q12 1580000730 S.FET
Q13 1580000720 S.FET
Q14 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q15 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q16 1590001190 S.TRANSISTOR XP6501-(TX) .AB
Q17 1590002530 S.TRANSISTOR UN911H (TX)
Q18 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q19 1590001190 S.TRANSISTOR XP6501-(TX) .AB
Q20 1590000720 S.TRANSISTOR DTA144EUA T106
Q21 1510000920 S.TRANSISTOR 2SA1577 T107 Q
Q22 1510000920 S.TRANSISTOR 2SA1577 T107 Q
Q25 1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
Q31 1590000660 S.TRANSISTOR DTC144TU T107
Q32 1590000430 S.TRANSISTOR DTC144EUA T106
Q33 1590000430 S.TRANSISTOR DTC144EUA T106
Q34 1560000810 S.FET
Q35 1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
Q36 1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
Q37 1590000720 S.TRANSISTOR DTA144EUA T106
Q38 1590000430 S.TRANSISTOR DTC144EUA T106
D1 1790000620 S.DIODE
D2 1790000620 S.DIODE
D3 1790000620 S.DIODE
D4 1790000620 S.DIODE
D5 1750000710 S.VARICAP
D6 1790001260 S.DIODE
D7 1720000660 S.VARICAP
D8 1790000620 S.DIODE
D9 1720000370 S.VARICAP
D10 1720000370 S.VARICAP
D11 1720000370 S.VARICAP
D12 1720000370 S.VARICAP
D13 1750000710 S.VARICAP
D14 1790000620 S.DIODE
D26 1160000070 S.DIODE
D27 1790001670 S.DIODE
D28 1790000620 S.DIODE
D29 1730002260 S.ZENER
D32 1790001670 S.DIODE
D33 1790001670 S.DIODE
FI1 2010002430 S.XTAL
2010002440 S.XTAL
FI2 2020001080 S.CERAMIC
2020001490 S.CERAMIC
X1 6050010880 S.XTAL
X2 6050010870 S.XTAL
X3 6070000210 S.DISCRIMINATOR CDBCA450CX24
DESCRIPTION
µPD3140GS-E1 (DS8)
TA31136FN (D,EL)
NJM2902V-TE1
BU4066BCFV-E1
TA7368F (TP1)
TK11250BMCL
HN58X2432TI
HD6473877H (Z-TAT)
M62363FP-650C
S-80942ANMP-DD6-T2
NJM2904V-TE1
2SK2974
2SK2973 (MTS101P)
3SK293 (TE85L)
3SK239AXRTL
2SK1069-4-TL
MA77 (TX)
MA77 (TX)
MA77 (TX)
MA77 (TX)
HVC350BTRF
MA2S077-(TX)
1SV288 (TPH2)
MA77 (TX)
HVU350TRF
HVU350TRF
HVU350TRF
HVU350TRF
HVC350BTRF
MA77 (TX)
DAN202K T146
RB706F-40T106
MA77 (TX)
MA8030-H (TX)
RB706F-40T106
RB706F-40T106
FL-311 (31.05 MHz) [Narrow]
FL-312 (31.05 MHz) [Wide]
SFPC450G-TC01 [Narrow]
SFPC450E-TC01 [Wide]
CR-664 (15.3 MHz)
CR-663 (9.200 MHz)
[MAIN UNIT]
REF ORDER
NO. NO.
L1 6200008580 S.COIL
L2 6200008500 S.COIL
L4 6200008280 S.COIL
L5 6200008510 S.COIL
L6 6200007730 S.COIL
L7 6200009180 S.COIL
L8 6200009180 S.COIL
L9 6200009180 S.COIL
L10 6200009180 S.COIL
L11 6200004850 S.COIL
L12 6200003710 S.COIL
L13 6200001980 S.COIL
L14 6200009150 S.COIL
L15 6200008280 S.COIL
L16 6200007750 S.COIL
L17 6200007750 S.COIL
L18 6200007750 S.COIL
L19 6200007750 S.COIL
L20 6200004770 S.COIL
6200005540 S.COIL
L21 6200009170 S.COIL
L22 6200008280 S.COIL
L24 6200003090 S.COIL
L25 6200001980 S.COIL
L26 6200003590 S.COIL
L28 6200009150 S.COIL
L29 6200009180 S.COIL
L31 6200008490 S.COIL
L32 6200008330 S.COIL
L33 6200001980 S.COIL
L34 6200004920 S.COIL
R1 7030003670 S.RESISTOR
R2 7030003480 S.RESISTOR
R3 7030003480 S.RESISTOR
R5 7030003240 S.RESISTOR
R7 7030003320 S.RESISTOR
R9 7030003560 S.RESISTOR
R10 7030003310 S.RESISTOR
R11 7030003450 S.RESISTOR
R12 7030003500 S.RESISTOR
R13 7030003260 S.RESISTOR
R14 7030003520 S.RESISTOR
R15 7030003320 S.RESISTOR
R16 7030004050 S.RESISTOR
R17 7030003440 S.RESISTOR
R18 7030003630 S.RESISTOR
R19 7030003320 S.RESISTOR
R20 7030003660 S.RESISTOR
R21 7030003320 S.RESISTOR
R22 7030003660 S.RESISTOR
R23 7030003320 S.RESISTOR
R25 7030005040 S.RESISTOR
R26 7030005040 S.RESISTOR
R27 7030003400 S.RESISTOR
R28 7030003320 S.RESISTOR
R29 7030005120 S.RESISTOR
R30 7030003520 S.RESISTOR
R31 7030003440 S.RESISTOR
R32 7030003410 S.RESISTOR
R33 7030003480 S.RESISTOR
R34 7030003200 S.RESISTOR
R35 7030003420 S.RESISTOR
R41 7030003320 S.RESISTOR
R44 7030003560 S.RESISTOR
7030003590 S.RESISTOR
R45 7030003320 S.RESISTOR
R48 7030003560 S.RESISTOR
R49 7030003640 S.RESISTOR
R50 7030003760 S.RESISTOR
R51 7030003680 S.RESISTOR
R52 7030003680 S.RESISTOR
R53 7030003560 S.RESISTOR
R54 7030003710 S.RESISTOR
R57 7030003680 S.RESISTOR
6 - 1
DESCRIPTION
0.30-1.4-6TL 32N
0.30-1.3-6TL 28N
0.30-1.7-7TL 50N
0.30-0.9-4TR 10.5N
LQN21A 39NJ04
ELJRE R10J-F3
ELJRE R10J-F3
ELJRE R10J-F3
ELJRE R10J-F3
MC152-E558CN-100024
NL 252018T-2R7J
NL 252018T-1R0J
ELJRE 82NJ-F3
0.30-1.7-7TL 50N
LQN21A 56NJ04
LQN21A 56NJ04
LQN21A 56NJ04
LQN21A 56NJ04
ELJNC R56J-F [Wide]
ELJNC R47K-F [Narrow]
ELJRE 47NJ-F2
0.30-1.7-7TL 50N
NL 322522T-2R7J-3
NL 252018T-1R0J
EXCCL3225U1
ELJRE 82NJ-F3
ELJRE R10J-F3
0.30-0.9-3TR 7.5N
0.45-1.4-4TL 15N
NL 252018T-1R0J
MLF1608A 2R2K-T
ERJ3GEYJ 823 V (82 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 220 V (22 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 820 V (82 Ω)
ERJ3GEYJ 122 V (1.2 kΩ)
ERJ3GEYJ 332 V (3.3 kΩ)
ERJ3GEYJ 330 V (33 Ω)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 1R0 V (1 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 393 V (39 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 683 V (68 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 683 V (68 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ2GEJ 102 X (1 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 561 V (560 Ω)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 681 V (680 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 103 V (10 kΩ) [Narrow]
ERJ3GEYJ 183 V (18 kΩ) [Wide]
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 184 V (180 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
S.=Surface mount
