CONNECTION DIAGRAM

Please study the connection diagram above.
1. Connect the STEALTH CONTROL's USB PORT to an available USB port on your computer, using the included
USB cable. The STEALTH CONTROL will be powered through your computer's USB bus.
2. (Optional) You can power the STEALTH CONTROL by connecting an optional 6V 1A power adapter to the DC
IN input on the STEALTH CONTROL. Please note that it is not necessary to have the adapter plugged in for the
STEALTH CONTROL to work. However, you should connect this adapter if your computer is not able to supply
enough power to the STEALTH CONTROL.

REAR PANEL CONNECTIONS

1. USB PORT – Please use the supplied USB cable to connect this port to an available USB port on your computer.
When plugged into your computer, the unit will draw power from the USB connection.
2. DC IN – If your computer does not supply enough power through the USB bus, you may wish to power the unit
externally by connecting an optional 6V/1A adapter to this input and plugging the adapter into a power supply.
COMPUTER
2 1
3
2
POWER
SUPPLY
(OPTIONAL
