The product is exposed to water or excessive moisture, The AC power supply plug or cord is damaged, The product shows an inappropriate change in performance or does not operate normally, or The enclosure of the product has been damaged. Confidential Numark Service Manual...
SERVICE MANUAL MODEL: MIXTRACKPROFX SPECIFICATION FUNCTION 1. UI Browser----------------A standard detented encoder with push switch is used to navigate through the software 2. Master Volume-----------Controls the gain of the master outputs. 3. Gain------------------------This pot controls the gain for its associated channel on the mixer. 4.
Page 6
20. Sync---------------------This control sends a momentary MIDI message. This control is used to force the track to align with the other deck’s tempo and phase. It is up to the software to either hard align or gently nudge it into place, depending on the Smart or Simple Sync chosen from the settings. The LED for this control will light when active.
DISASSEMBLY PROCEDURES 1. REMOVAL OF THE B CABINET .(Fig1) (A) TAKE OUT THE 5 PCS VR CAP AND 17 PCS KNOB FROM OF CABINET. (B) TAKE OUT THE 14 PCS SCREWS FROM OF BOTTOM CHASSIS. Fig.1...
Page 8
2. REMOVAL PCB ASSEMBLY. (Fig. 2) (A) REMOVE THE 4 PCS SCREWS AND 2 PCS CONNECTORS BEFORE REMOVAL OF TOGGLE SW PCB DIP ASSEMBLY. (B) REMOVE THE 2 PCS SCREWS AND 1 PC CONNECTOR BEFORE REMOVAL OF IC VR PCB DIP ASSEMBLY. (C)REMOVE THE 6 PCS SCREWS AND 2 PCS CONNECTORS BEFORE REMOVAL OF LEFT&...
Page 14
Wheel Plate 0.1 PNKCJMAR01\06 Pack Assembly ..2 CGNKCJ310MAR01 Inner Box ..2 CTNKCJ513MAR01 Carton ..2 GEMAR119 DownloadCard ..2 LAC67MAR1093 LOGO Label(Numark) ..2 OPNK14MAR13 Sa ety Manual(1372-H) ..2 OPNKCJMAR01 Instruction Book ..2 PE230370404B09A Pe Bag ..2 PLNKCH01 Poly Foam(Le t) ..2 PLNKCH02 Poly Foam(Right) ..2 SD630330024B09...
Page 16
0.1 WR0720004001 Isolation Cable 7Pin Single Ro 0.1 WRUSB05200015B2 Shielding Cable USB 2.0 5Pin S 0.1 WS116010305O Washer 0.1 TWPC19C02001 Function PCB Integration Asse ..2 TWPC19C02001T Function PCB SMT Integration A ...3 PC19C020 Function PCB ...3 TWPC19C020A01T Right PAD PCB SMT Assembly ..4 AA822524X IC SN74HC165PW IC2,4,6...
Page 26
To USB PCB TE201 VR500 C500 TE500 0.1uF(DNS) Title: NKCJ/NKCH MIC-PC19C020F Size Number Revision 2020/02/10 Date : Sheet File Name: Design By : Approval Check Design DATE Description...
