This document contains sensitive proprietary information.
All recipients must have a current non-disclosure agreement on file
with Numark.
Do not make illegal copies of this document.
The information in this document contains privileged and confidential information. It is intended only for the use of
those authorized by Numark. If you are not the authorized, intended recipient, you are hereby notified that any review,
dissemination, distribution or duplication of this document is strictly prohibited. If you are not authorized, please
contact Numark and destroy all copies of this document. You may contact Numark at support@numark.com.
© Copyright Numark
Confidential
Numark
Party Mix Pro
[NPA3]
Service Manual
v1.0
ATTENTION!
Numark Service Manual
Advertisement
Related Manuals for Numark Party Mix Pro
Summary of Contents for Numark Party Mix Pro
- Page 1 The information in this document contains privileged and confidential information. It is intended only for the use of those authorized by Numark. If you are not the authorized, intended recipient, you are hereby notified that any review, dissemination, distribution or duplication of this document is strictly prohibited. If you are not authorized, please contact Numark and destroy all copies of this document.
- Page 2 As the owner of the copyright to the Manual, Numark does not give you the right to copy the Manual, and you agree not to copy the Manual without the written authorization of Numark. Numark has no obligation to provide to you any correction of, or supplement to, the Manual, or any new or superseding version thereof.
- Page 3 ALL REPAIRS DONE BY ANY ENTITY OTHER THAN AN AUTHORIZED NUMARK SERVICE CENTER SHALL BE SOLELY THE RESPONSIBILITY OF THAT ENTITY, AND NUMARK SHALL HAVE NO LIABILITY TO THAT ENTITY OR TO ANY OTHER PARTY FOR ANY REPAIRS BY THAT ENTITY.
- Page 4 The product is exposed to water or excessive moisture, The AC power supply plug or cord is damaged, The product shows an inappropriate change in performance or does not operate normally, or The enclosure of the product has been damaged. Confidential Numark Service Manual...
- Page 6 NPA3 Level One BOM Stage Part Number Part Name Specification Usage Location 10520184 Snap ring E ring,T=0.5mm,V1.0 30090009 Bundle line 2.5*120mm, Black 30060079 Foam 50*150*5mm 12030031 Rocker switch AN-S331,RF-1003-BB4,BBG8E2L1T,no silkscreen 13110033 switch power supply AN-T90034,16280,100-240VAC,50/60Hz,16.5VDC,4.1A 16040913 AN-W4473,2P,18#,UL1007,220mm Plug attachment 16040915 Plug attachment AN-W4475,2P,22#,UL1007,220mm 16041047...
- Page 7 DR001958 NK47 button with silkscreen ASSY DN-PC6705,(3),ABS,UL94-HB, ,black,(1)silkscreen white,V1.0 DR001959 NK47 button with silkscreen ASSY DN-PC6705,(3),ABS,UL94-HB, ,black,(2)silkscreen white,V1.0 DR001960 NK47 Fader cap with silkscreen ASSY DN-PL2013,ABS,UL94-HB,80%,black,silkscreen white,V1.0 DR001961 NK47 button with silkscreen ASSY DN-PC6703,PC+Silicon, (1) diffusers,UL94-HB,silkscreen black,V1.0 DR001993 NPA3 plate with silkscreen ASSY DN-PC1081,ABS(UL94V-2),80%,black,silkscreen Pantone White C,V1.0 DR001994 NPA3 Top housing with silkscreen ASSY...
- Page 8 20330072 Badge DN-PE3060,ABS,UL94-2,black,V1.0 20440026 Spacer column PC19-5, Φ 6.5*6.95mm 20660042 mound layer DN-PC6038,(1),ABS, ,black,MT11O20,Foam,V1.1 20660043 mound layer DN-PC6037,(2),ABS, ,black,MT11020,Foam,V1.1 20660044 mound layer DN-PC6036,(3),ABS, ,black,MT11020,Foam,V1.1 21010604 Wooden box DN-X10247,MDF,T=9mm,CARB,V1.3 22011245 User guide NPA3, user guide ,V1.7 22050006 desiccant 50g,Mineral desiccant, non-woven fabric,SGS 22140017 Cue Card NK47,279*177mm,black and white print,matt, V1.2...
- Page 9 Power Cable AN-W1123,3G,0.75mm2,H05VV-F,1830mm,blcak Europe California 65 ...3 90041659 Barcode sticker NPA3,Black on white,76*50mm ,For US V1.0 ...3 90200056 Label sticker BLACK&361C print, Φ 30mm,V1.0 ...3 90220738 Special sticker Numark,DINP,95*10.5,V1.1 ...3 22011492 Safty manual NUMARK,safty manual,7-51-1373-H ...3 22011109 User guide NPK2,user guide,V1.1...
- Page 10 NPA3 Full BOM Stage Part Number Part Name Specification Usage Location NPA3 NPA3 DR001939 NPA3 Assembly NPA3 ASSY 10520184 Snap ring E ring,T=0.5mm,V1.0 30090009 Bundle line 2.5*120mm, Black 30060079 Foam 50*150*5mm 12030031 Rocker switch AN-S331,RF-1003-BB4,BBG8E2L1T,no silkscreen 13110033 switch power supply AN-T90034,16280,100-240VAC,50/60Hz,16.5VDC,4.1A 16040913 AN-W4473,2P,18#,UL1007,220mm...
- Page 11 ...3 50030166 Metallized polyester capacitor 474J,100V,± 5%,Vertical box type, grey,7.2(W)*7.5(H)*3.5(T),taping 2 C130,C131 ...3 40370357 Male socket AN-JP512,PHS2.0-2P, white ,2P,with Buckle 1 CN15-B ...3 40370346 Male socket AN-JP528,HT-2.5-02P-01D,white,2P,with Buckle 1 CN14-A ...3 40370098 Male socket AN-JP410,VH-2A,P=3.96mm,180 degree,white 2 CN13-A,SW4-A ...3 40370326 Male socket AN-JP410,VH-2A,P=3.96mm,180 degree,red 1 CN1...
- Page 12 ..4 11170434 chip resistor 1/10W,200K Ω ,± 5%,0603 1 R194 ..4 11171179 chip resistor 1/10W,243K Ω ,± 1%,0603 1 R191 1/10W,1M Ω ,± 5%,0603 ..4 11170444 chip resistor 2 R172,R173 ..4 11170009 chip resistor 1/8W,10 Ω ,± 5%,0805 2 R161,R162 ..4 11170266 chip resistor...
- Page 13 ...3 15010519 Rotary potentiometer AN-V1219,single,B10K,R11102NOBXH1-B103a-27.5F012P-01C,L=27.5mm 4 P1,P7,P8,P16 ...3 15020028 Sliding potentiometer AN-V227,single,B10K,C04508NOAXH1-B103b,AD pin L=15mm 4 P11-14 ...3 15020027 Sliding potentiometer AN-V226,dual,B10K,RA45D2F-211-12C2-B10K,C2 pin L=12mm, 1 P10 ...3 12040001 Tact Switch AN-S401,TSF6273DJ-250AH 2 SW67,SW73 ...3 12080021 Coding switch AN-S821,E1201MX1H1-0065,24P24,A1E30F12,L=30mm 1 ENC1 ...3 18040294 AN-L0252,SL-RUB1V1D-C,square,2*5*7,red 6 D1,D2,D38,D40,D66,D67...
- Page 14 ..4 11171044 chip resistor 1/10W,22K Ω ,± 1%,0603 4 R30,R62,R66,R70 ..4 11170957 chip resistor 1/10W,820K Ω ,± 5%,0603 1 R15 1/10W,1M Ω ,± 1%,0603 ..4 11170742 chip resistor 1 R1 ..4 11170186 chip resistor 1/8W,1K Ω ,± 1%,0805 3 R7,R9,R148 ..4 11170123 chip resistor...
- Page 15 ..4 14041329 CY8C3246LTI-125,QFN-48,CYPRESS 1 U23 ..4 14041056 AK4430ET,TSSOP16,AKM,silkscreen :AKM 4430ET 2 U2,U7 ..4 14040073 74HC595D,SOP16,PHILIPS 4 U36-39 ..4 40360307 AN-JP369,2*5,SMT,SAMTEC:FTSH-105-01-L-DV-K 1 J2 CR011269 NPA3 PER(NEW) NPA3 PER(NEW) ASSY ...3 17010212 Electrolytic capacitor 220uF/16V,± 20%,-40/+85 ℃ , Φ 6.3*11mm,P=2.5mm,black 2 C161,C136 ...3 40370345 Male socket...
- Page 16 ..4 50050137 Chip ceramic capacitor 331,VDC50,± 10%,X7R,0603,taping 8 C16,C17,C18,C19,C20,C21,C94,C95 ..4 50050052 Chip ceramic capacitor 102,VDC50,± 10%,X7R,0603,taping 2 C38,C39 ..4 50050161 Chip ceramic capacitor 472,VDC50,± 10%,X7R,0603,taping 2 C33,C34 ..4 50050073 Chip ceramic capacitor 104,VDC50,± 5%,X7R,0603,taping 13 C9,C27,C28,C37,C48,C90,C91,C116,C133,C134,C135,C137,C160 ..4 50050423 Chip ceramic capacitor 224,VDC25,±...
- Page 17 ...3 20260043 LED cap LED3B-11 7 LED1,2,3,4,5,15,17 ...3 18040204 BRL-10C05A06,high bright,0.5W,red,SMD 3 LED6,LED9,LED12 ...3 18040205 BGL-10C05A06,high bright ,0.5W,green,SMD 3 LED7,LED10,LED13 ...3 18040206 BBL-10C05A06,high bright,0.5W,blue,SMD 3 LED8,LED11,LED14 ...3 CR011272 NPA3 DLED SMT NPA3 DLED SMT ASSY ..4 26021063 FR4 double sided plate AN-B20722,DLED,304*116.5*1.6mm,blue,V1.6 ..4 11171008...
- Page 18 LM339DT,SOIC-14,ST,silkscreen :339 1 U14 ..4 14041077 HCR1530,SOP8 1 U12 ..4 40330016 Connector IPEX,IPEX-001,SMD 1 ANT1 ..4 12040052 Tact Switch AN-S452,TSTPP6650K-250BH-8,6*6*5H,SMD,taping 2 SW1,SW2 ..4 60210097 Module NPA3,CSR BT module,JS-BTM8605,Party Mix Pro,V2.07 1 BT1 DR001956 NK47 button with silkscreen ASSY DN-PC6704,(2),PC+Silicon, diffusers,UL94-HB,(1)silkscreen black,V1.0...
- Page 19 ...3 20670032 Button DN-PC6704,(2)PC+Silicon, diffusers,UL94-HB,ROHS,V1.0 DR001957 NK47 button with silkscreen ASSY DN-PC6704,(2)PC+Silicon, diffusers,UL94-HB,(2)silkscreen black,V1.0 ...3 20670032 Button DN-PC6704,(2)PC+Silicon, diffusers,UL94-HB,texture,ROHS,V1.0 DR001958 NK47 button with silkscreen ASSY DN-PC6705,(3),ABS,UL94-HB, ,black,(1)silkscreen white,V1.0 ...3 20670033 Button DN-PC6705,(3),ABS,UL94-HB, ,black,texture,ROHS,V1.0 DR001959 NK47 button with silkscreen ASSY DN-PC6705,(3),ABS,UL94-HB, ,black,(2)silkscreen white,V1.0 ...3 20670033 Button...
- Page 20 ..4 11170132 chip resistor 1/8W,10 Ω ,± 1%,0805 1 R303 ..4 11170207 chip resistor 1/8W,2K Ω ,± 1%,0805 1 R304 1/8W,10.5K Ω ,± 1%,0805 ..4 11170269 chip resistor 1 R305 ..4 11170353 chip resistor 1/10W,10 Ω ,± 5%,0603 1 R312 ..4 11170483 chip resistor...
- Page 21 ..4 11170762 chip resistor 1/8W,27 Ω ,± 1%,0805 36 R4,R6,R13,R15,R19,R21,R25,R27,R31,R33,R37,R39,R43,R45,R49,R5 1,R55,R57,R58,R60,R64,R66,R67,R69,R70,R72,R73,R75,R76,R78,R79 ,R81,R82,R84,R85,R87 ..4 18040311 AN-L0268,TO-5050BC-MRPBGGF-3,Antipolarity,code:05B 18 LED1-LED18 ..4 26020959 FR4 double sided plate AN-B20662,LED01,110*313*1.6mm,white,V1.2 ..4 40350070 Pin male socket AN-JP250,1.27-2*6P,H=4.9,L=7.0,180 degree,SMT 2 J1-A1,J2-A1 CR011093 IPA82 LED02 IPA82 LED02 ASSY ...3 40360401 AN-JP461,P1.27,P/H,2*6PIN,TYPE,inner distance 8.5mm 6 J3-A1-J8-A1...
- Page 22 20660043 mound layer DN-PC6037,(2),ABS, ,black,MT11020,Foam,V1.1 20660044 mound layer DN-PC6036,(3),ABS, ,black,MT11020,Foam,V1.1 21010604 Wooden box DN-X10247,MDF,T=9mm,CARB,V1.3 22011245 User guide NPA3, user guide ,V1.7 22050006 50g,Mineral desiccant, non-woven fabric,SGS desiccant 22140017 NK47,279*177mm,black and white print,matt, V1.2 Cue Card 23010533 Package bag （ 290+390 ） *750*0.1mm, red print,punching,V1.1 23010562 Package bag PE,120*280*0.06mm,punching,red print,V1.0...
- Page 23 Power Cable AN-W1123,3G,0.75mm2,H05VV-F,1830mm,blcak Europe California 65 ...3 90041659 Barcode sticker NPA3,Black on white,76*50mm ,For US V1.0 ...3 90200056 Label sticker BLACK&361C print, Φ 30mm,V1.0 ...3 90220738 Special sticker Numark,DINP,95*10.5,V1.1 ...3 22011492 Safty manual NUMARK,safty manual,7-51-1373-H ...3 22011109 User guide NPK2,user guide,V1.1...
- Page 24 MODULE SWITCH POWER AC INPUT 100-240VAC HEAT SINK COMPANY: TITLE: NPA3 AMP SCH DRAWN: DATED: CHECKED: DATED: APPROVED: DATED: 20170309 DWG NO.: PT-X-XXXXX-XX SCALE: SIZE:A2 REV: V1.4 SHEET: 1 OF 1...
- Page 30 COMPANY: TITLE: NPA3 LED1 SCH DRAWN: DATED: CHECKED: DATED: APPROVED: DATED: 20170309 DWG NO.: PT-X-XXXXX-XX SCALE: SIZE:A2 REV: V1.4 SHEET: 1 OF 5...
- Page 31 COMPANY: TITLE: NPA3 LED1 SCH DRAWN: DATED: CHECKED: DATED: APPROVED: DATED: 20170309 DWG NO.: PT-X-XXXXX-XX SCALE: SIZE:A2 REV: V1.4 SHEET: 2 OF 5...
- Page 32 COMPANY: TITLE: NPA3 LED1 SCH DRAWN: DATED: CHECKED: DATED: APPROVED: DATED: 20170309 DWG NO.: PT-X-XXXXX-XX SCALE: SIZE:A2 REV: V1.4 SHEET: 3 OF 5...
- Page 33 COMPANY: TITLE: NPA3 LED1 SCH DRAWN: DATED: CHECKED: DATED: APPROVED: DATED: 20170309 DWG NO.: PT-X-XXXXX-XX SCALE: SIZE:A2 REV: V1.4 SHEET: 4 OF 5...
- Page 34 COMPANY: TITLE: NPA3 LED1 SCH DRAWN: DATED: CHECKED: DATED: APPROVED: DATED: 20170309 DWG NO.: PT-X-XXXXX-XX SCALE: SIZE:A2 REV: V1.4 SHEET: 5 OF 5...
- Page 35 MIC VOLUME Master VOLUME THD:1% COMPANY: TITLE: NPA3 PRE SCH DRAWN: DATED: CHECKED: DATED: APPROVED: DATED: 20170309 DWG NO.: PT-X-XXXXX-XX SCALE: SIZE:A2 REV: V1.5 SHEET: 1 OF 2...
- Page 36 COMPANY: TITLE: NPA3 PRE SCH DRAWN: DATED: CHECKED: DATED: APPROVED: DATED: 20170309 DWG NO.: PT-X-XXXXX-XX SCALE: SIZE:A2 REV: V1.5 SHEET: 2 OF 2...
