Paradyne 6211-I1 User Manual

Adsl2+ router
Hide thumbs Also See for 6211-I1:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Command Manual, User Manual
I
6211-
1 ADSL2+ Router
User's Guide
Document Number 6211-A2-GB21-20
January 2005

Advertisement

Table of Contents
loading

Related Manuals for Paradyne 6211-I1

Summary of Contents for Paradyne 6211-I1

  • Page 1 6211- 1 ADSL2+ Router User’s Guide Document Number 6211-A2-GB21-20 January 2005...
  • Page 2 Paradyne worldwide office locations, use one of the following methods: Internet: Visit the Paradyne World Wide Web site at www.paradyne.com. (Be sure to register your warranty at www.paradyne.com/warranty.) Telephone: Call our automated system to receive current information by fax or to speak with a company representative.
  • Page 3 CE Marking When the product is marked with the CE mark on the equipment label, a supporting Declaration of Conformity may be downloaded from the Paradyne World Wide Web site at www.paradyne.com. Select Support -> Technical Manuals -> Declarations of Conformity.

  • Page 4: Fcc Part 15 Declaration

    6211 ADSL2+ Router User’s Guide FCC Part 15 Declaration An FCC Declaration of Conformity may be downloaded from the Paradyne World Wide Web site at www.paradyne.com. Select Support -> Technical Manuals -> Declarations of Conformity. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 5: Notice To Users Of The Canadian Telephone Network

    6211 ADSL2+ Router User’s Guide The user may make no repairs to the equipment. Connection to party line service is subject to state tariffs. Contact the state public utility commission, public service commission or corporation commission for information. If the site has specially wired alarm equipment connected to the telephone line, ensure the installation of the modem does not disable the alarm equipment.
  • Page 6 6211 ADSL2+ Router User’s Guide January 2005 6211-A2-GB21-20...

  • Page 7: Table Of Contents

    6211 ADSL2+ Router User’s Guide Table of Contents INTRODUCTION ............................9 ..................................9 EATURES ..............................9 YSTEM EQUIREMENTS ..............................9 SING THIS OCUMENT GETTING TO KNOW THE 6211 ADSL ROUTER................11 ..................................11 ARTS ................................12 RONT ANEL ..................................13 ANEL GETTING STARTED...........................14 ............................14 ONNECTING THE ARDWARE USB D ............................16 NSTALLING RIVERS...
  • Page 8 6211 ADSL2+ Router User’s Guide MANAGEMENT ............................66 ..................................66 ETTINGS ..................................72 YSTEM ................................76 CCESS ONTROL ...............................80 PDATE OFTWARE ................................81 EBOOT OUTER January 2005 6211-A2-GB21-20...

  • Page 9: Introduction

    10/100BaseT Ethernet port to provide Internet connectivity to all computers on your LAN via additional Ethernet Switch/HUB. USB port allows quick installation. Built-in splitter provides you to connect telephone directly without using extra splitter (Model 6211-I1-x0x). Configuration program accessible via a web browser, such as Microsoft Internet Explorer. Note that Netscape is not supported.
  • Page 10 6211 ADSL2+ Router User’s Guide Special messages This document uses the following icons to call your attention to specific instructions or explanations. Provides clarification or non-essential information on the current topic. Note Provides messages of high importance, including messages relating to personal safety or system integrity.

  • Page 11: Getting To Know The 6211 Adsl Router

    6211 ADSL2+ Router User’s Guide Getting to Know the 6211 ADSL Router Parts List In addition to this document, your 6211 ADSL router should come with the following: 6211 ADSL router Power adapter Ethernet cable (RJ45, “straight-through” type), Phone cable (RJ11), and USB cable. Figure 2-1 6211 ADSL router Package Contents 6211-A2-GB21-20 January 2005...

  • Page 12: Front Panel

    6211 ADSL2+ Router User’s Guide Front Panel The front panel contains LED indicators that show the status of the unit. Figure 2-2 Front Panel LEDs Table 2-1 Front Panel Label and LEDs Label Color Function POWER green On: Unit is powered on Off: Unit is powered off STATUS green...

  • Page 13: Rear Panel

    Connects the CPE to your PC's Ethernet port, or to the uplink port on your LAN's hub or switch, using the cable provided USB outlet, for PC USB port connection PHONE Connects to your telephone (Model 6211-I1-x0x) LINE Connects to your ADSL line 6211-A2-GB21-20 January 2005...

  • Page 14: Getting Started

    6211 ADSL Router User’s Guide Getting Started This chapter provides basic instructions for connecting the 6211 ADSL router to a PC or LAN, and to the Internet via ADSL. Part 1 provides instructions to set up the hardware. Part 2 describes how to configure Internet properties on your PC. Part 3 shows you how to access your 6211 ADSL router.

  • Page 15: Connect The Adsl Line And Telephone

    Connect your ADSL line to the LINE port on the rear panel of the router, and connect the other end of the line to the wall phone jack. Optionally connect your telephone to the port labeled PHONE on the rear panel of the router (Model 6211-I1-x0x only).

  • Page 16: Installing Usb Drivers

    6211 ADSL2+ Router User’s Guide Installing USB Drivers As soon as you connect the USB cable between your PC and device, Windows will detect new hardware and the Found New Hardware Wizard will appear on your PC monitor. Follow this procedure: 1.
  • Page 17 6211 ADSL2+ Router User’s Guide 3. The Wizard will ask you to confirm the hardware installation. Choose ”Continue Anyway” then it will start to install the supplied USB driver to your PC automatically. Figure 3-3 Compatibility Warning Figure 3-4 Progress Screen 4.

  • Page 18: Configuring Your Computers

    6211 ADSL2+ Router User’s Guide Configuring Your Computers Before you can access the router over the LAN or the USB port, you have to configure your PC’s TCP/IP address to be 192.168.1.x (where x is any number between 3 and 254), with a subnet mask of 255.255.255.0. Your router’s default IP address is 192.168.1.1.
  • Page 19 6211 ADSL2+ Router User’s Guide In the Internet Protocol (TCP/IP) Properties dialog box, click on the radio button labeled Use the following IP address. Type an address between 192.168.1.3 and 192.168.1.254 in the IP Address field (192.168.1.20 is shown here as an example) and 255.255.255.0 in the Subnet Mask field. Figure 3-8 TCP/IP Property in Windows XP Click on twice to confirm your changes, and close the Control Panel.

  • Page 20: A2-Gb21

    6211 ADSL2+ Router User’s Guide 16. In the Local Area Connection Properties dialog box, select Internet Protocol (TCP/IP), and then click on 17. In the Internet Protocol (TCP/IP) Properties dialog box, click on the radio button labeled Use the following IP address. Type an address between 192.168.1.3 and 192.168.1.254 in the IP Address field and 255.255.255.0 in the Subnet Mask field.
  • Page 21 6211 ADSL2+ Router User’s Guide Click on Microsoft in the Manufacturers list box, and then click on TCP/IP in the Network Protocols list box. lick on to return to the Network dialog box, and then click on again. You may be prompted t o install files from your Windows 95/98 installation CD.

  • Page 22: Logging In To Your Router

    6211 ADSL2+ Router User’s Guide Logging in to your router This section shows how to connect to the router’s web interface, configure settings, and observe some statistics of your Internet connection. Open your Web browser, and type the following URL in the address/location box, and press <Enter>: http://192.168.1.1 This is the predefined IP address for the LAN port on the router.
  • Page 23 6211 ADSL2+ Router User’s Guide The home page is shown in Figure 3-10. Figure 3-10 6211 ADSL Router Home Page 6211-A2-GB21-20 January 2005...

  • Page 24: Device Information

    6211 ADSL2+ Router User’s Guide Device Information This chapter describes the system information available using the menu items under Device Info. Summary You can get the general status report from the router by clicking on the “Summary” item under “Device Info” (shown in Figure 4.1) Figure 4.1 Status Summary January 2005...

  • Page 25: Wan

    6211 ADSL2+ Router User’s Guide You can get the WAN status report from the router by clicking on the “WAN” item under “Device Info” (shown in Figure 4.2) Figure 4.2 WAN Status 6211-A2-GB21-20 January 2005...

  • Page 26: Statistics

    6211 ADSL2+ Router User’s Guide Statistics LAN Statistics You can get LAN statistics from the router by clicking on the “LAN” item under “Statistics” (shown in Figure 4.3) Figure 4.3 LAN Statistics Page January 2005 6211-A2-GB21-20...

  • Page 27: Wan Statistics

    6211 ADSL2+ Router User’s Guide WAN Statistics You can get WAN statistics from the router by clicking on the “WAN” item under “Statistics” (shown in Figure 4.4). Figure 4.4 WAN Statistics Page 6211-A2-GB21-20 January 2005...

  • Page 28: Atm Statistics

    6211 ADSL2+ Router User’s Guide ATM Statistics You can get ATM statistics from the router by clicking on the “ATM” item under “Statistics” (shown in Figure 4.5). Figure 4.5 ATM Statistics Page January 2005 6211-A2-GB21-20...

  • Page 29: Adsl Statistics

    6211 ADSL2+ Router User’s Guide ADSL Statistics You can get ADSL statistics from the router by clicking on the “ADSL” item under “Statistics” (shown in Figure 4.6). Figure 4.6 ADSL Status ADSL BER Test The ADSL Bit Error Rate (BER) test determines the quality of the ADSL connection. The test is performed by transferring idle cells containing a known pattern and comparing the received data with this known pattern to check for any errors (shown in Figures 4.7 and 4.8).

  • Page 30: Route

    6211 ADSL2+ Router User’s Guide Route You can get the Routing status report from router by clicking on the “Route” item under “Device Info” (shown in Figure 4.9) Figure 4.9 Device Info - Route January 2005 6211-A2-GB21-20...

  • Page 31: Arp

    6211 ADSL2+ Router User’s Guide You can get the ARP status report from the router by clicking on the “ARP” item under “Device Info” (shown in Figure 4.10) Figure 4.10 ARP Status 6211-A2-GB21-20 January 2005...

  • Page 32: Quick Setup

    6211 ADSL2+ Router User’s Guide Quick Setup This chapter guides you through the steps to configure your router. Auto PVC Auto-connect will automatically detect the first usable PVC and automatically detect PPPoE, PPPoA, and Bridge Protocol (with DHCP Server available). January 2005 6211-A2-GB21-20...
  • Page 33 6211 ADSL2+ Router User’s Guide Figure 5.1 Detecting available PVC Figure 5.2 Detecting available PVC – Available PVC detected 6211-A2-GB21-20 January 2005...

  • Page 34: Setting Apvc Without Auto Detecting

    6211 ADSL2+ Router User’s Guide Setting a PVC without Auto detecting Figure 5.3 Without Auto PVC, the detail setting can reference “Advanced Setup” January 2005 6211-A2-GB21-20...

  • Page 35: Advanced Setup

    6211 ADSL2+ Router User’s Guide Advanced Setup The chapter contains informations about WAN, LAN, and ADSL settings. Set up WAN parameters as directed by your ISP. Figure 6-1 WAN Setup Page 6211-A2-GB21-20 January 2005...
  • Page 36 6211 ADSL2+ Router User’s Guide Add Function If you want to add a new rule for the WAN interface, click on the “Add” button. The ATM PVC Configuration screen appears. ATM PVC Configuration Screen The ATM PVC Configuration screen allows you to configure an ATM PVC identifier (VPI and VCI) and select a service category.
  • Page 37 6211 ADSL2+ Router User’s Guide Connection Type Screen Select the type of network protocol and encapsulation mode over the ATM PVC that your ISP has instructed you to use, then click on Next button. Figure 6-3 Connection Type Page 6211-A2-GB21-20 January 2005...
  • Page 38 6211 ADSL2+ Router User’s Guide Bridge Service and Quality of Service Screen This WAN service can be enabled or disabled by clicking in the check box. Enabling QoS for a PVC improves performance for selected classes of applications. However, since QoS also consumes system resources, the number of PVCs is reduced.
  • Page 39 6211 ADSL2+ Router User’s Guide WAN Setup – Summary Make sure that the settings on the WAN Setup screen match the settings provided by your ISP. If all settings are correct, click on the Save button to save these settings; if not, click on the Back button to make any modifications. If you want to change some items after being finished settings, you also click on the Edit button to make any modifications.

  • Page 40: Remove Function

    6211 ADSL2+ Router User’s Guide Remove Function If you want to delete a connection from the listed WAN setup, click in the Remove check box next to the item, then click on the Remove button. Figure 6-6 WAN Setup Finish Function After you change any item in WAN Setup, remember to click on the Finish button to apply the changes and reboot the system.

  • Page 41: Lan

    6211 ADSL2+ Router User’s Guide Local Area Network (LAN) Setup You can configure the DSL Router IP address and Subnet Mask for the LAN interface to conform your LAN’s IP Subnet. The Save button only saves the LAN configuration data. The Save/Reboot button saves the LAN configuration data and reboots the router to make the new configuration effective.
  • Page 42 6211 ADSL2+ Router User’s Guide Figure 6.8 Virtual Server Setup Page You can select a Service or make new one. Enter the Server IP Address, then click on Save/Apply to submit your configuration. Figure 6.7 Virtual Server Add Page January 2005 6211-A2-GB21-20...
  • Page 43 6211 ADSL2+ Router User’s Guide On this screen you can view and delete servers. Click in the check box under Remove and click on the Remove button to delete selected virtual servers. Figure 6.8 Virtual Server List 6211-A2-GB21-20 January 2005...

  • Page 44: Port Triggering

    6211 ADSL2+ Router User’s Guide Port Triggering Click the on the Add button to add Port Triggering for your Internet application. Figure 6.9 Port Triggering Setup Page January 2005 6211-A2-GB21-20...
  • Page 45 6211 ADSL2+ Router User’s Guide You can select an application every time or create new one for your application. Then click on Save/Apply to save your settings. Figure 6.10 Port Triggering Add Page On this screen you can view and delete applications. Click in the check box under Remove and click on the Remove button to delete selected applications.

  • Page 46: Dmz Host

    6211 ADSL2+ Router User’s Guide DMZ Host You can define the IP address of the DMZ Host on this screen. Enter the IP address and click on Save/Apply. Figure 6.12 DMZ Host Setup Page January 2005 6211-A2-GB21-20...

  • Page 47: Firewall

    6211 ADSL2+ Router User’s Guide Firewall IP Filtering Outgoing The outgoing filter will block the traffic from the LAN side to the WAN side. Click on Add to create filters. Figure 6.13 IP Filtering – Outgoing Filtering Setup Page 6211-A2-GB21-20 January 2005...
  • Page 48 6211 ADSL2+ Router User’s Guide Input the filter name, source information (from the LAN side), and Destination information (from the WAN side). Then click on Save/Apply. Figure 6.14 IP Filtering – Outgoing Filtering Add Page You can view and delete the outgoing filter settings on this screen. Figure 6.15 IP Filtering –...
  • Page 49 6211 ADSL2+ Router User’s Guide Incoming Incoming filter filters the traffic from the WAN side to the LAN side. Click on Add to add incoming filter settings. Figure 6.16 IP Filtering – Incoming Filtering Setup Page 6211-A2-GB21-20 January 2005...
  • Page 50 6211 ADSL2+ Router User’s Guide Enter a filter name, information about the source address (from the WAN side), and information about the destination address ( to the LAN side). Select the protocol and WAN interface. Then click on Save/Apply to add the setting. Figure 6.17 IP Filtering –...

  • Page 51: Mac Filtering

    6211 ADSL2+ Router User’s Guide MAC Filtering MAC filtering can forward or block traffic by MAC address. You can change the policy or add settings to the MAC filtering table using the MAC Filtering Setup screen. Figure 6.19 IP Filtering – MAC Filtering Setup Page 6211-A2-GB21-20 January 2005...
  • Page 52 6211 ADSL2+ Router User’s Guide If you click on Change Policy, a confirmation dialog lets you verify your change. Figure 6.20 IP Filtering – MAC Filtering Policy Change Confirmation If you want to add a setting to the MAC filtering table, enter the Source and Destination MAC address, and select protocol type, frame direction, and WAN interface.
  • Page 53 6211 ADSL2+ Router User’s Guide On this screen you can view and delete MAC filtering rules. Figure 6.22 IP Filtering – MAC Filtering List 6211-A2-GB21-20 January 2005...

  • Page 54: Quality Of Service

    6211 ADSL2+ Router User’s Guide Quality of Service You can configure the Quality of Service to apply different priorities to traffic on the router. Figure 6.23 Quality of Service Setup Page January 2005 6211-A2-GB21-20...
  • Page 55 6211 ADSL2+ Router User’s Guide Click on Add and the Add Network Traffic Class Rule screen appears. Enter and select QoS parameters, then click on Save/Apply. Figure 6.24 Quality of Service Add Page 802.1p Priority and TOS are mutually exclusive. Note 6211-A2-GB21-20 January 2005...
  • Page 56 6211 ADSL2+ Router User’s Guide On this screen you can view and delete QoS settings. Figure 6.25 Quality of Service List January 2005 6211-A2-GB21-20...

  • Page 57: Routing

    6211 ADSL2+ Router User’s Guide Routing Default Gateway You can change the Default Gateway on the Routing – Default Gateway screen. Figure 6.26 Default Gateway Setup Page 6211-A2-GB21-20 January 2005...

  • Page 58: Static Route

    6211 ADSL2+ Router User’s Guide Static Route Use the Routing – Static Route screen to add a static route to the routing table. Figure 6.27 Static Route Setup Page January 2005 6211-A2-GB21-20...
  • Page 59 6211 ADSL2+ Router User’s Guide Enter the route information and click on Save/Apply to make it active. No reboot is required. Figure 6.28 Static Route Add Page 6211-A2-GB21-20 January 2005...
  • Page 60 6211 ADSL2+ Router User’s Guide If RIP is enabled, the router operation can be configured as Active or Passive. Figure 6.29 RIP Setup Page January 2005 6211-A2-GB21-20...

  • Page 61: Dns

    6211 ADSL2+ Router User’s Guide DNS Server Use the DNS Server screen to request automatic assignment of a DNS or to specify a primary and secondary DNS. Figure 6.30 DNS Setup Page 6211-A2-GB21-20 January 2005...

  • Page 62: Adsl

    6211 ADSL2+ Router User’s Guide ADSL There are three major items in the ADSL settings: Modulation Methods Six modulation methods for different linking speed are supported by the 6211 ADSL router: G.Dmt Enabled, G.lite Enabled, T1.413 Enabled, ADSL Enabled, Annex L Enabled, and ADSL2+ Enabled. Set this value only as directed by your ISP.
  • Page 63 6211 ADSL2+ Router User’s Guide DSL Advanced Settings Do not change the DSL Advanced Settings unless so directed by your ISP. There are five test modes between the router and your ISP: Normal test: Puts the router in a test mode in which it only sends a Normal signal. Reverb test: Puts the router in a test mode in which it only sends a Reverb signal.
  • Page 64 6211 ADSL2+ Router User’s Guide Tone Selection The frequency band of ADSL is split up into 256 separate tones, each spaced 4.3125 kHz apart. With each tone carrying separate data, the technique operates as if 256 separate modems were running in parallel. The tone range is from 0 to 31 for upstream and from 32 to 255 for downstream.

  • Page 65: Diagnostics

    6211 ADSL2+ Router User’s Guide Diagnostics Your router is capable of testing your DSL connection. The individual tests are listed below. If a test displays a failure status, click on “Test” at the bottom of this page to make sure the failure status is consistent. If the test result continues to show a failure, click on “Help”...

  • Page 66: Management

    6211 ADSL2+ Router User’s Guide Management Settings The configuration of your router can be backed up to a file, and also can be restored from a file. You can also restore the router to its factory default configuration. Backup Setting To back up your settings, select Management→Settings→Backup Settings.
  • Page 67 6211 ADSL2+ Router User’s Guide Verify that you would like to save the file. Figure 8.2 Backup Settings Dialog Select the location where you want to save the file. Figure 8.3 Backup Settings File Location 6211-A2-GB21-20 January 2005...

  • Page 68: Restore User Settings

    6211 ADSL2+ Router User’s Guide Restore User Settings To restore saved settings, select Management→Settings→Restore User Settings. Figure 8.4 Restore Settings Page Select the backup file you want to restore and click on Update Settings. Figure 8.5 Restore Setting Location Page January 2005 6211-A2-GB21-20...
  • Page 69 6211 ADSL2+ Router User’s Guide The router will restore settings and reboot to activate the restored settings. Figure 8.6 Restore Settings Reboot Page 6211-A2-GB21-20 January 2005...

  • Page 70: Restore Default

    6211 ADSL2+ Router User’s Guide Restore Default Restore Default will erase all current settings and restore the router to factory default settings. To restore the router to factory default settings, select Management→Settings→Restore Default. Figure 8.7 Restore Default Page Reply OK to the confirmation dialog. Figure 8.8 Restore Default Confirmation January 2005 6211-A2-GB21-20...
  • Page 71 6211 ADSL2+ Router User’s Guide The router will restore the default settings and reboot. Figure 8.9 Restore Default Reboot Page 6211-A2-GB21-20 January 2005...

  • Page 72: System Log

    6211 ADSL2+ Router User’s Guide System Log The System Log dialog allows you to view the System Log and configure the System Log options. Figure 8-1 System Log January 2005 6211-A2-GB21-20...
  • Page 73 6211 ADSL2+ Router User’s Guide View System Log Click on the “View System Log” button to check the log file. 6211-A2-GB21-20 January 2005...
  • Page 74 6211 ADSL2+ Router User’s Guide Configure System Log If the log is enabled, the system will log selected events: Emergency, Alert, Critical, Error, Warning, Notice, Informational, and Debugging. All events above or equal to the selected log level will be logged and displayed. January 2005 6211-A2-GB21-20...
  • Page 75 6211 ADSL2+ Router User’s Guide If the selected mode is “Remote” or “Both”, events will be sent to the specified IP address and UDP port of a remote system log server. If the selected mode is “Local” or “Both”, events will be recorded in the local memory. Select the desired values and click on the “Save/Apply”...

  • Page 76: Access Control

    6211 ADSL2+ Router User’s Guide Access Control Services You can enable or disable some services of your router by LAN or WAN. If no WAN connection is defined, only the LAN side can be configured. Figure 8.14 Service Setup Page January 2005 6211-A2-GB21-20...
  • Page 77 6211 ADSL2+ Router User’s Guide If a WAN connection is defined, services of both the LAN side and WAN side can be configured. Figure 8.15 Service Setup with WAN Page 6211-A2-GB21-20 January 2005...
  • Page 78 6211 ADSL2+ Router User’s Guide IP Addresses Web access to the router can be limited when Access Control Mode is enabled. The IP addresses of allowed hosts can be added using Access Control→IP Address. Figure 8.16 Access Control – IP Address Setup Page January 2005 6211-A2-GB21-20...
  • Page 79 6211 ADSL2+ Router User’s Guide First, add the IP address to the IP address list. Figure 8.17 Access Control – IP Address Add Page Then select “Enabled” to enable Access Control Mode. Figure 8.18 Access Control – IP Address Setup 6211-A2-GB21-20 January 2005...

  • Page 80: Update Software

    6211 ADSL2+ Router User’s Guide Passwords Use Access Control→Passwords to change a password. Select an account and enter the current password and the new password. Then click on Save/Apply. Update Software Tools – Update software If your ISP releases new software for this router, follow these steps to perform an upgrade. Obtain an updated software image file from your ISP.

  • Page 81: Reboot Router

    6211 ADSL2+ Router User’s Guide Reboot Router Select Management→Reboot Router to reboot the router using the web interface. The router will save the current configuration and reboot itself using the new configuration. Figure 8.20 Reboot Router Page 6211-A2-GB21-20 January 2005...
  • Page 82 6211 ADSL2+ Router User’s Guide Figure 8.21 Rebooting Router Page The rebooting process takes about 2 minutes to complete. Note January 2005 6211-A2-GB21-20...
