- Page 1 SUUNTO COMBOS AND MECHANICAL INSTRUMENTS INSTRUCTION MANUAL Combo Consoles I Console Compasses CB-71/STD and CB-71/DS Depth Gauge SM-16 I Pressure Gauge SM-36...
- Page 2 The combos consist of four main modules: the pressure gauge module, the instrument module and two different compass modules. The pressure gauge module is designed for the Suunto pressure gauges and it can also be used with the new Suunto Quick Release (QR). The basic combinations are displayed below:...
- Page 3 Assembling the Combo Modules CB-ONE module front cover with SM-36 pressure gauge in place (see section CB-ONE Module assembly) CB-IN-LINE module front cover CB-end piece or CB-71/STD compass (optional) CB-IN-LINE module back cover with instrument CB-ONE module back cover or CB-71/DS compass (optional)
- Page 4 Before assembling the CB-ONE module the hose cover needs to be fi tted on the pressure hose. The hose cover ensures that the SM-36 pressure gauge fi ts properly on the CB-ONE module. If the Suunto Quick Release is used, the hose cover is not to be used (See section CB-ONE module assembly using the SUUNTO Quick Release).
- Page 5 CB-ONE Module Assembly when using the SUUNTO Quick Release If the SUUNTO Quick Release (QR) is used the hose cover should be attached on the high pressure hose below the female end of the QR. The male part is attached to the pressure gauge which is then fi tted onto the CB-ONE front cover according to the picture below.
- Page 6 SUUNTO Console Compasses CB-71/SK-7/STD and CB-71/SK-7/DS The CB-71/SK-7 is available in two versions: the CB-71/SK-7/STD for attachment on top of the combo modules or the Cobra dive computer, and the CB-71/SK-7/DS for attachment on the back side of the CB-ONE module.
- Page 7 Compass Balancing The horizontal and vertical components of earth’s magnetic fi eld vary in different locations. For this reason Suunto compass- es are balanced for 2 different zones. If the compass is used in an adjacent balancing zone the compass needle will tilt only slightly.
-
Page 8: Before Usage
SUUNTO Mechanical Gauges Suunto depth gauge SM-16 Models available: 45 m, 70 m, 150 ft, 230 ft Suunto pressure gauge SM-36 Models available: 300 bar and 4000 psi Before usage Depth gauge: Before diving, check the position of the depth indicating pointer. Atmospheric conditions (altitude, temperature) may cause the point to not indicate zero. - Page 9 immovable object. Do not subject the gauges to pressures beyond their maximum range. Temperature extremes can be damaging. In general, the gauges should not be exposed to temperatures to which you would not expose yourself. CAUTION! After use, rinse the gauges or the console with fresh water and store them out of direct sunlight, in a dry place at room temperature.
-
Page 10: Operating And Storage Temperatures
SM-36 Operating and storage temperature 0° C to 40° C [32° F to 104° F] Technical Specifi cations The Suunto depth gauge SM-16 complies with the prEN 13319 standard. The tolerances for depth gauges are: At 3m +0.8 / -0.4 m At 6m +0.8 / -0.4 m... -
Page 11: Suunto Limited Warranty
Service Center; 3. serial number has been removed, altered or made illegible in any way, as determined at the sole discretion of Suunto; 4. has been exposed to chemicals including but not limited to mosquito repellents. -
Page 12: Limitation Of Liability
To the maximum extent permitted by applicable mandatory laws, this Limited Warranty is your sole and exclusive remedy and is in lieu of all other warranties, expressed or implied. Suunto shall not be liable for special, incidental, punitive or consequential damages, including but not limited to loss of anticipated benefi ts, loss of data, loss of use, cost of capital, cost... - Page 13 SUUNTO HELP DESK GLOBAL +358-2-284-1160 USA (toll-free) +1-800-543-9124 CANADA (toll-free) +1-800-267-7506 www.suunto.com © Suunto Oy 11/2005, 09/2006, 11/2011. All rights reserved. Suunto is a registered trademark of Suunto Oy.
