TopPage
In the interests of user safety (required by safety regulations in some countries) the set should be restored to its
original condition and only parts identical to those specified should be used.
This model is based on the LC-60LE925X and partially modified.
For the contents not covered in this Service Manual, accordingly, please refer to the LC-60LE925X
(No. S90K7LC60L92X) Service Manual.
DIFFERENCES FROM BASE MODEL.. . ............i
MAJOR SERVICE PARTS ..................... . ..........iv
[1]
SPECIFICATIONS ................................. . ....... 1-1
[1]
Parts Names .......................................... . ....... 2-1
Parts marked with "
" are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for maintaining the
safety and performance of the set.
SERVICE MANUAL
LCD COLOUR TELEVISION
MODEL
OUTLINE
CONTENTS
CHAPTER 3. ADJUSTMENT
[1]
ADJUSTMENT PROCEDURE ......................3-1
[1]
OVERALL WIRING DIAGRAM ......................4-1
[1]
DESCRIPTION OF SCHEMATIC DIA-
GRAM............................................................5-1
[2]
MAIN Unit ......................................................5-2
No. SY0L6LC60F3DT
LC-60XF3DT
This document has been published to be used for
after sales service only.
The contents are subject to change without notice.
LC-60XF3DT
Advertisement
Table of Contents
Related Manuals for Sharp LC-60XF3DT
Summary of Contents for Sharp LC-60XF3DT
-
Page 1: Table Of Contents
TopPage LC-60XF3DT SERVICE MANUAL No. SY0L6LC60F3DT LCD COLOUR TELEVISION LC-60XF3DT MODEL In the interests of user safety (required by safety regulations in some countries) the set should be restored to its original condition and only parts identical to those specified should be used. -
Page 2: Outline And Differences From Base Model Outline
LC-60XF3DT LC60XF3DT Service Manual OUTLINE AND DIFFERENCES FROM BASE MODEL OUTLINE This model is based on the LC-60LE925X and partially modified. For the contents not covered in this Service Manual, accordingly, please refer to the LC-60LE925X (No. S90K7LC60L92X) Service Manual. -
Page 3: Safety Precaution Important Service Safety Pre- Caution
LC-60XF3DT LC60XF3DT Service Manual SAFETY PRECAUTION IMPORTANT SERVICE SAFETY PRECAUTION Service work should be performed only by qualified service technicians who are thoroughly familiar with all safety checks and the servicing guidelines which follow: WARNING All checks must be repeated with the AC cord plug connection reversed. -
Page 4: Precautions For Using Lead-Free Solder
LC-60XF3DT PRECAUTIONS FOR USING LEAD-FREE SOLDER Employing lead-free solder • “PWBs” of this model employs lead-free solder. The LF symbol indicates lead-free solder, and is attached on the PWBs and service manuals. The alphabetical character following LF shows the type of lead-free solder. -
Page 5: Major Service Parts
LC-60XF3DT LC60XF3DT Service Manual MAJOR SERVICE PARTS MAJOR SERVICE PARTS PWB UNIT Ref No. Parts Code Description DKEYMF612FM54 MAIN Unit *1 DUNTKF493FM06 LOGO Unit DUNTKF494FM03 R/C OPC Unit DUNTKF638FM03 ICON Unit RDENCA410WJQZ POWER Unit RUNTKA761WJQZ TOUCH SENSOR KEY Unit *2... -
Page 6: Chapter 1. Specifications Specifications
0 °C to + 40 °C • As a part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification figures indicated are nominal values of production units. -
Page 7: Chapter 2. Operation Manual Parts Names
LC-60XF3DT LC60XF3DT Service Manual CHAPTER 2. OPERATION MANUAL [1] Parts Names TV (Front) VOL + / - (Volume up/down) buttons OPC sensor* (Channel up/down) buttons Remote control sensor INPUT button Infrared emitter MENU button Centre Icon illumination** POWER (On/Off) button... - Page 8 LC-60XF3DT TV (Rear) USB terminal ETHERNET (10/100) terminal OUTPUT (Headphones/AUDIO (L/R)) terminal INPUT2 terminal INPUT3 (PC input) terminal * The AUDIO IN terminal can use the AUDIO IN terminal* same audio input terminal (INPUT3 (PC)/INPUT5 (HDMI)). However, the proper item must be selected in the INPUT4 (HDMI/ARC) “Audio select”...
- Page 9 LC-60XF3DT Remote control unit (Flashback) Press to return to the previous selected channel or external input mode. Select the sound multiplex mode. WIDE Change the wide image mode. (Mute) Mute the sound. 10 VOL + / - Set the volume.
- Page 10 LC-60XF3DT LC60XF3DT Service Manual CHAPTER 3. ADJUSTMENT [1] ADJUSTMENT PROCEDURE The adjustment values are set to the optimum conditions at the factory before shipping. If a value should become improper or an adjustment is required due to part replacement, make an adjustment according to the following procedure.
- Page 11 LC-60XF3DT 2.3. Monitor microprocessor software version upgrade Create the USB memory for monitor microprocessor software version upgrade in the same manner as explained in the “Main software version upgrade”. Copy the file SFIAT925TBxxx.USB and SFIAESUBxxx.BIN (named temporarily) for monitor microprocessor software version upgrade to the USB memory.
- Page 12 LC-60XF3DT 3. Entering and exiting the adjustment process mode 1) Before entering the adjustment process mode, the AV position RESET in the video adjustment menu. 2) At the state TV is turned on, touch the power key for 5seconds. NOTE: Picture will disappear when you touch the power key, but keep touching the power key.
- Page 13 LC-60XF3DT 5. List of adjustment process mode menu The character string in brackets [ ] will appear as a page title in the adjustment process menu header. Page Line Item Description Remarks (adjustment detail, etc.) 1/21 MAIN Version 1xxx (xxxxx)
- Page 14 LC-60XF3DT Page Line Item Description Remarks (adjustment detail, etc.) 6/21 HDTV ADJ Enter HDTV video level adjustment HDTV Y GAIN HDTV Y GAIN adjustment value HDTV CB GAIN HDTV Cb adjustment value HDTV CR GAIN HDTV Cr adjustment value HDTV Y OFFSET...
- Page 15 LC-60XF3DT Page Line Item Description Remarks (adjustment detail, etc.) 15/21 POWER LED BRIGHTNESS MENU LED BRIGHTNESS INPUT LED BRIGHTNESS CH UP LED BRIGHTNESS CH DOWN LED BRIGHTNESS VOL UP LED BRIGHTNESS VOL DOWN LED BRIGHTNESS LOGO LED BRIGHTNESS ICON LED BRIGHTNESS...
- Page 16 LC-60XF3DT Page Line Item Description Remarks (adjustment detail, etc.) 21/21 EEP SAVE Writing setting values to EEPROM. EEP RECOVER Reading setting values from EEPROM. MONITOR ERROR CAUSE RESET Reset of monitor error cause MODEL NAME XF3DT MODEL NAME PANEL SIZE Panel size setting.
-
Page 17: Adjustment Procedure
LC-60XF3DT 10. Video signal adjustment procedure The adjustment process mode menu is listed in Section 5. Signal generator level adjustment check (Adjustment to the specified level) : 0.7Vp-p ± 0.02Vp-p (Pedestal to white level) • Composite signal PAL/SECAM : 0.7Vp-p ± 0.02Vp-p •... - Page 18 LC-60XF3DT 10.4. ADC adjustment (Component 15K) Adjustment point Adjustment conditions Adjustment procedure Setting [Signal] • Feed the COMPONENT 15K 100% full field colour bar signal (100% COMP15K, 60Hz (480i) colour saturation) to INPUT1 COMPONENT IN. 100% Full field colour bar Signal...
-
Page 19: Chapter 4. Overall Wiring Diagram
LC-60XF3DT Service Manual LC60XF3DT CHAPTER 4. OVERALL WIRING DIAGRAM [1] OVERALL WIRING DIAGRAM 4 – 1... -
Page 20: Chapter 5. Schematic Diagram
LC-60XF3DT Service Manual LC60XF3DT CHAPTER 5. SCHEMATIC DIAGRAM [1] DESCRIPTION OF SCHEMATIC DIAGRAM 1. VOLTAGE MEASUREMENT CONDITION: 1) The voltages at test points are measured on exclusive AC adaptor and the stable supply voltage of AC 110V. Signals are fed by a colour bar signal gener- ator for servicing purpose and the above voltages are measured with a 20k ohm/V tester. -
Page 21: Main Unit
LC-60XF3DT [2] MAIN Unit MAIN Unit-1 5 – 2... - Page 22 LC-60XF3DT MAIN Unit-4 5 – 3...
- Page 23 LC-60XF3DT MAIN Unit-6 5 – 4...
- Page 24 LC-60XF3DT - MEMO - 5 – 5...
-
Page 25: Parts Guide
LC-60XF3DT PartsGuide PARTS GUIDE No. SY0L6LC60F3DT LCD COLOUR TELEVISION LC-60XF3DT MODEL Note: The reference numbers on the PWB are arranged in alphabetical order. CONTENTS PRINTED WIRING BOARD CABINET AND MECHANICAL ASSEMBLIES PARTS LCD PANEL SUPPLIED ACCESSORIES DKEYMF612FM54 (MAIN Unit) PACKING PARTS (NOT REPLACEMENT ITEM) Parts marked with "... - Page 26 LC-60XF3DT PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [1] PRINTED WIRING BOARD ASSEMBLIES DKEYMF612FM54 MAIN Unit DUNTKF494FM03 R/C OPC Unit DUNTKF638FM03 ICON Unit DUNTKF493FM06 LOGO Unit RUNTKA761WJQZ TOUCH SENSOR Key Unit RDENCA410WJQZ POWER Unit RUNTKA780WJQZ HDMI Transmitter Unit RUNTKA741WJQZ...
- Page 27 LC-60XF3DT [4] CABINET AND MECHANICAL PARTS 58 34 60" LCD Panel Module Unit LOGO Unit R/C OPC Unit ICON Unit IR EMITTER Unit TOUCH SENSOR KEY Unit HDMI TRANSMITTER Unit MAIN Unit POWER Unit...
- Page 28 LC-60XF3DT PRICE PARTS CODE PART DESCRIPTION RANK MARK DELIVERY [4] CABINET AND MECHANICAL PARTS CCABAC609WJ33 Front Cabinet Ass'y Not Available Front Cabinet Not Available R/C Decoration Cover Not Available Front Decoration Not Available Corner Tape, x4 Not Available Spacer Not Available...
- Page 29 LC-60XF3DT [5] SUPPLIED ACCESSORIES Remote control uni t “AAA” size alkaline battery (x2) AV cable Used with batteries inserted. Cable clamp 3D glasses For bundling cables. Operation manual English-Chinese contrast table Warranty certificate PRICE PART PARTS CODE DESCRIPTION RANK MARK...
- Page 30 LC-60XF3DT [6] PACKING PARTS (NOT REPLACEMENT ITEM)
- Page 31 LC-60XF3DT PRICE PARTS CODE PART DESCRIPTION RANK MARK DELIVERY [6] PACKING PARTS (NOT REPLACEMENT ITEM) SPAKCG120WJZZ Packing Case SPAKCG121WJZZ Packing Case (Bottom) SSAKA0005PEZZ Polyethylene Bag TLABK0001TAZZ No. Label SPAKAA653WJZZ Rear Pad SPAKPB596WJZZ Wrapping Paper SPAKPB597WJZZ Wrapping Paper (Stand) SPAKXD097WJZZ Packing Add. (Top) SPAKXD098WJZZ Packing Add.
- Page 32 LC-60XF3DT © COPYRIGHT 2010 BY SHARP CORPORATION ALL RIGHTS RESERVED. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of the publisher.
