Page 2
PARTS LIST & EXPLODED VIEW HP6491/Japan Service code Description 4203 035 52650 Epilation Head 4203 035 53230 Cooling Accu Legs - Japan 4203 035 52690 Protecting Sleeve 4822 479 30183 Cleaning Brush 4203 035 51760 Adapter JPN (symbolic photo) 4203 035 52530 Soothing Cap 4203 035 53060 Gearwheel 3...
Page 3
Instruction for exchanging the Gearwheel 3 HP6491/Japan Remove the small gearing cover with a small screwdriver. Here you see the opened gearing. As you can see, the small edge from the release knob is hampering you by removing the damaged gearwheel. Cut this small edge with a very sharp knife, so that the damaged gearwheel becomes free.
Page 4
Instruction for exchanging the Gearwheel 3 HP6491/Japan Cutted edge. Now you are able to exchange the damaged gearwheel.
