Philips Satinelle ICE HP6492 Service Manual

Philips Domestic Appliances and Personal Care
Service Manual
PRODUCT INFORMATION
The new Satin Ice combinates a new ceramic epilating
system with a contour following skin cooler and a
massaging system. With the shaving head you can
smoothly shave the armpits and bikini line.
Safety
- This product meets the requirements regarding
interference suppression on radio and TV.
- After the product has been repaired, it should function
properly and has to meet the safety requirements as
officially laid down at this moment.
TECHNICAL INFORMATION
- Power Source
- Voltage
- Motor
- Power Consumption
- Number of Discs
- Number of catching points
- RPM speed I
speed II
- Pulling actions/second
speed I
speed II
= changed
Published by Philips Domestic Appliances and Personal Care
06/11
: AC (mains)
: 100 V - 240 V
(50 - 60 Hz)
: DC - Motor 14 V
: 7,5 W
: 13
: 24
: 2200
: 2700
: 880
: 1080
Printed in the Netherlands
DISASSEMBLY- AND RE-ASSEMBLY ADVISE
- No specific issues.
REPAIR INSTRUCTION
- This is a replacement appliance.
For this Epilator only the parts shown in the exploded view
will be supplied.
Hints for repairs:
- No specific issues.
OPTIONAL (accessories)
- No specific issues.
PACKAGING
F-box dimensions
- Width : 196 mm
- Depth : 94 mm
- Height : 235 mm
- Weight F-box : 0.65 kg
© Copyright reserved
Satinelle - ICE
HP6492/Japan
Subject to modification
