- Page 1 Operator's Manual PCB Separator MAESTRO 3E...
- Page 2 Edition: 11/2009 - Part No. 9008929 Copyright This documentation as well as translation hereof are property of cab Produkttechnik GmbH & Co. KG. The replication, conversion, duplication or divulgement of the whole manual or parts of it for other intentions than its original intended purpose demand the previous written authorization by cab.
-
Page 3: Table Of Contents
Table of Contents Introduction ............................4 Instructions ............................... 4 Intended Use ............................4 Safety Instructions ............................ 4 Safety Marking ............................5 Environment ............................. 5 Specification ............................6 Installation .............................. 7 Unpacking and Setting-up the Device ...................... 7 Earthing Connection ..........................7 Releasing the Upper Blade Lock ...................... -
Page 4: Introduction
Introduction Instructions Important information and instructions in this documentation are designated as follows: Danger! Draws your attention to an exceptionally grave, impending danger to your health or life. Warning! Indicates a hazardous situation that could lead to injuries or material damage. Attention! Draws attention to possible dangers, material damage or loss of quality. -
Page 5: Safety Marking
Introduction Safety Marking Fig. 1 Safety marking Hazard by electrical charge ! Provide an earthing connection via press stud. Risk of hand injury ! Wear protective gloves while PCB separating. Table 1 Safety marking Environment Obsolete devices contain valuable recyclable materials that should be sent for recycling. ... -
Page 6: Specification
21.5 3..30 30° 30° Fig. 2 Device and PCB dimensions MAESTRO 3E/450 MAESTRO 3E/600 Length D in mm Height E in mm Separation Length F in mm Weight in kg Separating Principle Components side circular blade, Soldering side lineal blade... -
Page 7: Installation
Installation Unpacking and Setting-up the Device Lift the device out of the box. Check device for damage which may have occurred during transport. Set up device on a level surface. Check delivery for completeness. Contents of delivery: •... -
Page 8: Height Adjustment Of The Upper Blade
Installation Height Adjustment of the Upper Blade Notice! To avoid possible damage on the blades during transport the upper blade (5) is fixed in the "Park Position" so that there is a maximum distance to the lower blade. Set the upper blade into the working position before starting operation. Fig. -
Page 9: Adjustment Of The Stop Of The Upper Blade
Installation Adjustment of the Stop of the Upper Blade Notice! The lower stop of the upper blade adjustment is already adjusted by delivery. After a long operation time, while working at strongly varying temperatures or else after replacing a blade, it is recommended to re-adjust the lower stop. -
Page 10: Check The Blade Alignment
Installation Check the Blade Alignment Notice! When the machine is put into operation for the first time, or following a move of equipment or a change of blades, it is advantageous to re-check the alignment of the blades in relationship to one another. For this purpose a dial gauge assembly (Part No. -
Page 11: Adjustment Of Table And Platform
Installation Adjustment of Table and Platform Fig. 9 Adjustment of Table and Platform Adjust the height of table (3) and platform (4) as follows : 1. Loosen screws (1). 2. Move table (3) or platform (4) in the holes (2). 3. -
Page 12: Blade Replacement
Type Circular Blade Lineal Blade Part No. Description Part No. Description Part No. Description 8933945 MAESTRO 3E/450 8930509.001 Circular Blade 8933394.001 Lineal Blade 450/370 8935000 MAESTRO 3E/600 8930509.001 Circular Blade 8933682.001 Lineal Blade 600/520 Table 4 Replacement Blades Replacement of the Upper (Circular) Blade... -
Page 13: Replacement Of The Lower (Lineal) Blade
Blade Replacement Replacement of the Lower (Lineal) Blade Warning! Risk of hand injury ! Wear protective gloves while handling the blades. Fig. 12 Replacement of the lower blade 1. Move the blade carrier (1) to the end of the lower blade (7) above the eccentric adjuster (9). 2. -
Page 14: Index
Index Blade alignment ........10 Circular blade ........12 Contents of delivery ......7 Dial gauge assembly ......10 Earthing ..........7 Important information......4 Intended use ........4 Lineal blade ........12, 13 Lower blade Replacement .......13 Platform ..........11 Protective gloves ......11, 12 Recycling ..........5 Replacement blades ......12 Safety instructions ......4 Separation forces .......8...
