For questions or help with this product contact Tech Support at (570) 546-9663 or techsupport@grizzly.com
The following changes were recently made since the owner's manual was printed:
Revised inventory list.
Revised Step 15 in Assembly section.
Aside from this information, all other content in the owner's manual applies and MUST be read and under-
stood for your own safety. IMPORTANT: Keep this update with the owner's manual for future reference.
For questions or help, contact our Tech Support at (570) 546-9663 or techsupport@grizzly.com.
Revised Outfeed Table Inventory
Box Contents: (Figure 10)
F.
Front Outfeed Table Bracket ...................... 1
Fasteners (and where used):
Tap Screws M4 x 16
(Outfeed Table/Bracket) ............................. 8
F
Figure 10. Outfeed table components.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
READ THIS FIRST
Qty
Qty
COPYRIGHT © JULY, 2017 BY GRIZZLY INDUSTRIAL, INC.
#ES19102 PRINTED IN TAIWAN
Model G0651/G0652
***IMPORTANT UPDATE***
For Machines Mfd. Since 07/17
and Owner's Manual Revised 09/10
Revised Assembly Steps
15. Attach front outfeed table bracket to outfeed
table with (8) M4 x 16 tap screws (see Figure
23), and then repeat Steps 8-11 to install the
feet, support legs, and shelf end plate on the
outfeed table.
Figure 23. Outfeed table fastened to rear rail.
Outfeed Table Bracket
x8
