1.4

Overview of the meter

08424705001 (01) 2017-04 USA • Accu-Chek Inform II Operator's Manual Version 6
The meter has the following elements:
1
1 Test strip port
Insert the test strip here.
2 Touchscreen
(touch-sensitive display)
This screen allows you to perform patient tests, per-
form controls tests, and review results. To select
any of these functions, simply touch the button on
the screen.
2
3 On/Off button
Press this button to power the meter on or off.
4 Barcode scanner
The integrated barcode scanner can be used to
read operator and patient IDs, and patient
3
information.
5 Battery compartment cover
Remove to insert the battery pack.
6 Charging contacts
4
These contacts are used to charge the battery pack
when the meter is in the base unit.
7 Infrared window
Facilitates data communication with code key
reader and base unit.
5
6
7
