- Page 1 14-540.fm Page 1 Wednesday, June 30, 1999 2:27 PM Cat. No. 14-540 OWNER’S MANUAL Please read before using this equipment. CD-3316 PORTABLE AM/FM STEREO/ SINGLE CASSETTE DECK/ CD PLAYER...
-
Page 2: Cd Player Features
Automatic Level Control -- automati- cally adjusts the recording level. © 1995 Tandy Corporation. Radio Shack is a registered trademark used by Tandy Corporation. Multiple-Source Recording -- lets you record from the CD player or radio. Synchronous Recording System -- simplifies recording from the CD player to a cassette tape. - Page 3 14-540.fm Page 3 Wednesday, June 30, 1999 2:27 PM The CD player in this stereo system is made and tested to meet exacting safety standards. It meets UL and FCC requirements and complies with safety performance standards of the U.S. De- partment of Health and Human Servic- es.
- Page 4 14-540.fm Page 4 Wednesday, June 30, 1999 2:27 PM CONTENTS...
-
Page 5: Power Sources
Note: The CD-3316 automatically dis- connects internal batteries when you connect the AC power cord. USING BATTERIES You can power the CD-3316 from 6 D batteries (not supplied). For the best results, we recommend alkaline batter- ies (such as Radio Shack Cat. No. 23- 550). - Page 6 14-540.fm Page 6 Wednesday, June 30, 1999 2:27 PM USING YOUR CAR BATTERY You can power the CD-3316 from your car battery using a DC-to-AC Inverter (such as Radio Shack Cat. No. 22-132, not supplied). Cautions: • Always plug the AC power cord...
-
Page 7: Radio Operation
3. Adjust TUNING to the desired sta- tion. Notes: • For the best AM reception, rotate the CD-3316 to position the built- in AM antenna. • For the best FM reception, fully extend the telescoping antenna and swivel it to the position that produces the best reception. -
Page 8: Cd Player Operation
PLAY/ 5. To completely stop play, press STOP/CLEAR Note: If you do not stop the CD player, it plays to the end of the last track and automatically stops. When the CD player is stopped, the play indicator to the... - Page 9 14-540.fm Page 9 Wednesday, June 30, 1999 2:27 PM turns off and the total number of tracks appears on the display.
-
Page 10: Audible Search
6. To remove the CD, press after the CD stops turning. OPEN Caution: Remove a loaded CD before you move the CD-3316 to prevent pos- sible damage to the CD or the CD play- AUDIBLE SEARCH While playing any track on a CD, you can press and hold down >>... -
Page 11: Cassette Player Operation
14-540.fm Page 11 Wednesday, June 30, 1999 2:27 PM CASSETTE PLAYER OPERATION LOADING A CASSETTE TAPE Note: Take up any slack in the tape by turning the hub with a pencil. If you do not remove excess slack, the tape might become tangled in the record/ playback mechanism. -
Page 12: Recording Acassette Tape
90-minute) cassette tapes. Long-play cassette tapes such as C-120s are not recom- mended. For low-noise, wide- range recordings, use normal-bias tape. • The CD-3316’s Automatic Level Control (ALC) automatically adjusts the recording level. VOL- UME and TONE have no effect on recording. -
Page 13: Tape Care Tips
5. Press to begin record- RECORD ing. Note: You might hear a low-vol- ume tone from the CD-3316’s speakers during playback after you record an AM radio program. To insure a tone-free recording, make a test recording before you record the desired program. If you... -
Page 14: Restoring Tape Tension And Sound Quality
14-540.fm Page 14 Wednesday, June 30, 1999 2:27 PM • Remove all input sources so you can record silence over all or part of the tape. • Use a bulk tape eraser (such as Cat. No. 44-232, not supplied), available at your local Radio Shack store. -
Page 15: Using Headphones
For private listening, you can use a pair of stereo headphones (not sup- plied) with an 1/8-inch plug. Your local Radio Shack store carries a wide se- lection of stereo headphones. To connect the headphones, insert the headphones’ 1/8-inch plug into the jack. -
Page 16: Care And Maintenance
Modifying or tampering with the CD-3316’s internal components can cause a mal- function and might invalidate its warranty and void your FCC authorization to oper- ate it. If your CD-3316 is not performing as it should, take it to your local Radio Shack store for assistance. -
Page 17: Fcc Information
• Reorient or relocate the radio or TV’s receiving antenna • Increase the distance between the CD-3316 and the radio or TV • Use outlets on different electrical circuits for the CD-3316 and the radio or TV... -
Page 18: Specifications
1bs 11 oz (3.5 Kg) (Without Batteries) Specifications are typical; individual units might vary. Specifications are subject to change and improvement without notice. 90-Day Warranty RADIO SHACK A Division of Tandy Corporation Fort Worth, Texas 76102 Flutter 14709-0199-13 6A5 Printed in Indone- (10% THD) - Page 19 14-540.fm Page 19 Wednesday, June 30, 1999 2:27 PM...
- Page 20 14-540.fm Page 20 Wednesday, June 30, 1999 2:27 PM...
- Page 21 Shack franchisees and dealers. Within this period, we will repair it with- out charge for parts and labor. Simply bring your Radio Shack sales slip as proof of purchase date to any Radio Shack store. Warranty does not cover transportation costs. Nor does it cover a product subjected to misuse or accidental damage.
