Summary of Contents for Toyota Prius C 2011

Page 2: Ing Column
TABLE OF CONTENTS Information on the hybrid system and adjusting and op- Before driving erating features such as door locks, mirrors, and steer- ing column. When driving Driving, stopping and safe-driving information. Air conditioning and audio systems, as well as other Interior features interior features for a comfortable driving experience.
Page 3: Table Of Contents
TABLE OF CONTENTS Index 1-5. Opening and closing the Before driving windows Power windows ....82 1-1. Hybrid system 1-6. Refueling Hybrid system features ..24 Opening the fuel tank cap ..85 Hybrid system precautions ... 28 Energy monitor/ 1-7.
Page 4 2-3. Operating the lights and Interior features wipers Headlight switch....182 Fog light switch ....185 3-1. Using the air conditioning Windshield wipers and system and defogger washer ......186 Automatic air Rear window wiper and conditioning system ..208 washer ......
Page 5 TABLE OF CONTENTS Index 3-4. Using the interior lights Maintenance and care Interior lights list....287 • Interior lights/ personal lights ....288 4-1. Maintenance and care Cleaning and protecting 3-5. Using the storage features the vehicle exterior... 306 List of storage features ..290 Cleaning and protecting •...
Page 6 When trouble arises Vehicle specifications 5-1. Essential information 6-1. Specifications Emergency flashers .... 372 Maintenance data (fuel, oil level, etc.) ... 432 If your vehicle needs to be towed ......373 Fuel information ....444 If you think something is wrong ......378 6-2.
Page 7 Pictorial index Exterior Headlights (high beam) P. 182 Headlights (low beam) P. 182 Windshield wipers P. 186 Outside rear view mirrors P. 80 Hood P. 319 Side turn signal lights P. 157 Front fog lights P. 185 Front position lights P.
Page 8 Fuel filler door P. 85 Rear window defogger P. 216 Side doors P. 57 Rear window wiper P. 189 Tires ●Rotation License plate lights P. 182 P. 337 ●Replacement P. 400 ●Inflation pressure P. 441 Back door P. 60 Rear turn signal lights P.
Page 9 Pictorial index Interior SRS driver airbag P. 91 Head restraints P. 68 SRS driver knee airbag P. 91 Seat belts P. 70 Power window switch P. 82 SRS front passenger airbag P. 91 Luggage cover P. 303 Rear seats P. 65 Front seats P.
Page 10 Vanity mirrors P. 298 Personal lights P. 288 Interior lights P. 288 Microphone P. 262 SRS curtain shield airbags P. 91 Sun visors P. 297 Anti-glare inside rear view mirror P. 79...
Page 11 Pictorial index Interior Door lock switch P. 57 Inside door lock buttons P. 57 Window lock switch P. 82 Bottle holders P. 296 Power window switches P. 82...
Page 12 Hybrid transmission shift lever P. 154 Parking brake lever P. 158 “EV MODE” switch P. 151 Cup holders P. 295 “ECO MODE” switch Shift lock override button P. 155 P. 414...
Page 13 Pictorial index Instrument panel Windshield wiper and washer switch P. 186 Rear window wiper and washer switch P. 189 Gauges and meters P. 160 Headlight switch P. 182 Multi-information display P. 165 Turn signal lever P. 157 Fog light switch P.
Page 14 Air conditioning system P. 208 Rear window defogger button P. 216 ∗ : If equipped...
Page 15 Pictorial index Instrument panel “TRIP” switch P. 166 “DISP” switch P. 166 Audio remote control switches P. 253 Climate remote control switches P. 213 Horn P. 159 Cruise control switch P. 192...
Page 16 Vehicles with halogen headlights Headlight leveling dial P. 183 Outside rear view mirror switches P. 80 Power (ignition) switch P. 143 Vehicles with LED headlights Headlight cleaner switch P. 191 Outside rear view mirror switches P. 80 Power (ignition) switch P.
Page 17 Accessories, spare parts and modification of your Toyota A wide variety of non-genuine spare parts and accessories for Toyota vehi- cles are currently available in the market. Using these spare parts and accessories which are not genuine Toyota produces may adversely affect the safety of your vehicle, even though these parts may be approved by cer- tain authorities in your country.
Page 18 ● SRS airbag system ● Seat belt pretensioner system Be sure to check with your Toyota dealer for precautionary measures or spe- cial instructions regarding installation of a mobile two-way radio system. High voltage parts and cables on the hybrid vehicles emit approximately the...
Page 19 The computers do not record conversations, sound or pictures. ● Data usage Toyota may use the data recorded in these computers to diagnose malfunc- tions, conduct research and development, and improve quality. Toyota will not disclose the recorded data to a third party except: •...
Page 20 EDR. ● Disclosure of the EDR data Toyota will not disclose the data recorded in an EDR to a third party except when: • An agreement from the vehicle’s owner (or the lessee for a leased vehicle) is obtained •...
Page 21 Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.
Page 22 In the event that your vehicle must be disposed of, the hybrid battery must be disposed of by your Toyota dealer or a qualified service shop. If the hybrid battery is not disposed of properly, it...
Page 23 This is a warning against something which, if ignored, may cause damage to the vehicle or its equipment. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Toyota and its equipment.
Page 24: Before Driving
Before driving 1-1. Hybrid system 1-5. Opening and closing the windows Hybrid system features..24 Power windows....82 Hybrid system precautions ....... 28 1-6. Refueling Energy monitor/ consumption screen ..34 Opening the fuel tank Hybrid vehicle driving cap........85 tips ........
Page 25: Hybrid System Hybrid System Features
1-1. Hybrid system Hybrid system features Your vehicle is a hybrid vehicle. It has characteristics different from conventional vehicles. Be sure you are closely familiar with the char- acteristics of your vehicle, and operate with care. The hybrid system combines the use of a gasoline engine and an electric motor (traction motor) according to driving conditions, improving fuel efficiency and reducing exhaust emissions.
Page 26 1-1. Hybrid system ■ When stopped/during start off The gasoline engine stops* when the vehicle is stopped. During start off, the electric motor (traction motor) drives the vehicle. At slow speeds or when traveling down a gentle slope, the engine is stopped* and the motor is used.
Page 27 For this reason, be sure to drive the vehicle at least once every few months for at least 30 minutes or 16 km (10 miles). If the hybrid bat- tery becomes fully discharged and you are unable to jump-start the vehi- cle with the 12-volt battery, contact your Toyota dealer.
Page 28 After the 12-volt battery has discharged or has been changed or removed The gasoline engine may not stop even if the vehicle is running on the hybrid battery (traction battery). If this continues for a few days, contact your Toyota dealer. ■...
Page 29: Hybrid System Precautions
1-1. Hybrid system Hybrid system precautions Take care when handling the hybrid system, as it contains a high voltage system (about 520 V at maximum) as well as parts that become extremely hot when the hybrid system is operating. Obey the caution labels attached to the vehicle.
Page 30 If the emergency shut off system activates, your vehicle will not restart. To restart the hybrid system, contact your Toyota dealer. Hybrid warning message A message is automatically displayed when a malfunction occurs in the hybrid system or an improper operation is attempted.
Page 31 If a warning light comes on, a warning message is displayed, or the 12- volt battery is disconnected The hybrid system may not start. In that case, try to start the system again. If the “READY” indicator does not come on, contact your Toyota dealer. ■ Running out of fuel...
Page 32 1-1. Hybrid system CAUTION ■ High voltage and high temperature precautions The vehicle has high voltage DC and AC systems as well as a 12-volt sys- tem. DC and AC high voltage is very dangerous and can cause severe burns and electric shock that may result in death or serious injury.
Page 33 Carefully inspect the ground under the vehicle. If you find that liquid has leaked onto the ground, the fuel system may have been damaged. Leave the vehicle as soon as possible and contact your Toyota dealer. ■ Nickel-metal hydride battery Your vehicle contains a sealed nickel-metal hydride battery.
Page 34 1-1. Hybrid system NOTICE ■ Hybrid battery air vent ● Do not place foreign objects over or in front of the air vent. The hybrid bat- tery (traction battery) may overheat and be damaged. ● Clean the air vent regularly to prevent the hybrid battery (traction battery) from overheating.
Page 35: Energy Monitor/Consumption Screen
1-1. Hybrid system Energy monitor/consumption screen You can view the status of your hybrid system on the multi-informa- tion display. Energy monitor Push the “DISP” switch on the steering wheel several times to select the energy monitor dis- play.
Page 36 1-1. Hybrid system When the vehicle is powered by the electric motor (traction motor) When the vehicle is powered by the gasoline engine When the vehicle is powered by both the gasoline engine and the electric motor (traction motor) When the vehicle is charging the hybrid battery (traction battery) When there is no energy flow Full...
Page 37 1-1. Hybrid system Fuel consumption screen There are 2 menu items available for the fuel consumption screen. After pressing the “DISP” switch, select one of the menu items below and the system will change to the details screen. The “5min Consumption”, “Past Record” and “ECO Savings Record” (→P.
Page 38 1-1. Hybrid system ■ “Past Record” There are 2 types of displays for the past record. Personal best and monthly average can be changed between on the settings screen. (→P. 38) Personal Best Displays the best 3 fuel consumption records and the current fuel consumption ranking.
Page 39 1-1. Hybrid system ■ Remaining hybrid battery (traction battery) charge display The charge amount of the hybrid battery (traction battery) is automatically controlled by the hybrid system. For this reason, even if electricity is recov- ered via the regenerative braking, or electricity is generated via the gasoline engine, the displayed hybrid battery (traction battery) charge amount may not reach the highest level (level 8).
Page 40: Hybrid Vehicle Driving Tips
1-1. Hybrid system Hybrid vehicle driving tips For economical and ecological driving, pay attention to the following points: ■ Using Eco drive mode →P. 155 ■ Use of Hybrid System Indicator By keeping Hybrid System Indicator within Eco area, more Eco-friendly driving may be possible.
Page 41 1-1. Hybrid system ■ Checking tire inflation pressure Make sure to check the tire inflation pressure frequently. Improper tire inflation pressure can cause poor fuel consumption. Also, as snow tires can cause large amounts of friction, their use on dry roads can lead to poor fuel consumption.
Page 42: Key Information
1-2. Key information Keys The following keys are provided with the vehicle. Electronic keys • Operating the smart entry & start system (→P. 44) • Operating wireless remote control function (→P. 55) Mechanical keys Key number plate Using the mechanical key To take out the mechanical key, push the release button and take the key out.
Page 43 Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a mechanical key is lost, a new key can be made at your Toyota dealer using the key number plate. (→P. 415) ■...
Page 44 Take your vehicle with all the electronic keys provided with your vehicle to your Toyota dealer. ■ When a vehicle key is lost If the key remains lost, the risk of vehicle theft increases significantly. Visit your Toyota dealer immediately with all remaining electronic keys that was provided with your vehicle.
Page 45: Opening, Closing And Locking The Doors
1-3. Opening, closing and locking the doors Smart entry & start system The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. (The driver should always carry the electronic key.) Electronic key Electronic key Electronic key...
Page 46 1-3. Opening, closing and locking the doors Unlocking and locking the doors (front door handles only) Grip the handle to unlock the doors. Make sure to touch the sensor on the back of the handle. The doors cannot be unlocked for 3 seconds after the doors are locked.
Page 47 1-3. Opening, closing and locking the doors Press the button to lock the back door. Antenna location and effective range ■ Antenna location Antennas inside the cabin Antennas outside the cabin Antenna outside the luggage compartment...
Page 48 1-3. Opening, closing and locking the doors ■ Effective range (areas within which the electronic key is detected) When locking or unlocking the doors The system can be operated when the electronic key is within about 0.7 m (2.3 ft.) of outside door handle.
Page 49 1-3. Opening, closing and locking the doors ■ When the door cannot be locked by the lock sensor on the surface of the door handle Use your palm to touch the lock sensor. ■ Alarms and warning indicators A combination of exterior and interior alarms as well as warning messages shown on the multi-information display is used to prevent theft of the vehicle and accidents resulting from erroneous operation.
Page 50 1-3. Opening, closing and locking the doors ■ Security feature If a door is not opened within approximately 30 seconds after the vehicle is unlocked, the security feature automatically locks the vehicle again. (How- ever, depending on the location of the electronic key, the key may be detected as being in the vehicle.
Page 51 1-3. Opening, closing and locking the doors ■ Conditions affecting operation The smart entry & start system uses weak radio waves. In the following situ- ations, the communication between the electronic key and the vehicle may be affected, preventing the smart entry & start system, wireless remote con- trol and immobilizer system from operating properly.
Page 52 1-3. Opening, closing and locking the doors ■ Notes for the entry function ● Even when the electronic key is within the effective range (detection areas), the system may not operate properly in the following cases: • The electronic key is too close to the window or outside door handle, near the ground, or in a high place when the doors are locked or unlocked.
Page 53 (6 ft.) of the vehicle. ● The smart entry & start system can be deactivated in advance. Ask your Toyota dealer for details. ■ To operate the smart entry & start system properly Make sure to carry the electronic key when operating the system. Do not get the electronic key too close to the vehicle when operating the system from the outside of the vehicle.
Page 54 1-3. Opening, closing and locking the doors ■ If the smart entry & start system does not operate properly ● Locking and unlocking the doors: Use the mechanical key. (→P. 416) Starting the hybrid system: →P. 417 ● ■ Electronic key battery depletion ●...
Page 55 (→P. 46) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of emitting the radio waves.
Page 56: Wireless Remote Control
1-3. Opening, closing and locking the doors Wireless remote control The wireless remote control can be used to lock and unlock the vehi- cle. Locks all the doors Unlocks all the doors ■ Operation signals A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked.
Page 57 The number of keys already registered to the vehicle can be confirmed. Ask your Toyota dealer for details. ■ Customization that can be configured at Toyota dealer Settings (e.g. wireless remote control system) can be changed. (Customizable features →P. 445)
Page 58: Side Doors
1-3. Opening, closing and locking the doors Side doors The vehicle can be locked and unlocked using the entry function, wireless remote control or door lock switch. ■ Entry function →P. 44 ■ Wireless remote control →P. 55 ■ Door lock switch Locks all the doors Unlocks all the doors ■...
Page 59 1-3. Opening, closing and locking the doors Locking the driver’s door from the outside without a key Move the inside door lock button to the lock position. STEP Close the door while pulling the door handle. STEP The door cannot be locked if the “POWER” switch is in ACCESSORY or ON mode, or the electronic key is left inside the vehicle.
Page 60 1-3. Opening, closing and locking the doors CAUTION ■ To prevent an accident Observe the following precautions while driving the vehicle. Failing to do so may result in a door opening and an occupant falling out, resulting in death or serious injury. ●...
Page 61: Back Door
1-3. Opening, closing and locking the doors Back door The back door can be locked/unlocked and opened by the following procedures. ■ Locking and unlocking the back door Wireless remote control →P. 55 Door lock switch →P. 57 Entry function →P.
Page 62 1-3. Opening, closing and locking the doors CAUTION ■ Caution while driving ● Keep the back door closed while driving. If the back door is left open, it may hit near-by objects while driving or lug- gage may be unexpectedly thrown out, causing an accident. In addition, exhaust gases may enter the vehicle, causing death or a seri- ous health hazard.
Page 63 1-3. Opening, closing and locking the doors CAUTION ■ Operating the back door Observe the following precautions. Failure to do so may cause parts of the body to be caught, resulting in death or serious injury. ● Remove any heavy loads, such as snow and ice, from the back door before opening it.
Page 64 If a bicycle carrier or similar heavy object is attached to the back door, it may fall closed again after being opened, causing someone’s hands, head or neck to be caught and injured. When installing an accessory part to the back door, using a genuine Toyota part is recommended. NOTICE ■...
Page 65: Adjustable Components (Seats, Mirrors, Steering Wheel) Front Seats
1-4. Adjustable components (seats, mirrors, steering wheel) Front seats Seat position adjustment lever Seatback angle adjustment lever Vertical height adjustment lever (driver’s seat only) CAUTION ■ Seat adjustment ● Be careful that the seat does not hit passengers or luggage. ●...
Page 66: Rear Seats
1-4. Adjustable components (seats, mirrors, steering wheel) Rear seats The seatbacks of the rear seats can be folded down. Folding down the rear seatbacks ■ Before folding down the rear seatbacks Stow the rear seat belt buckles STEP as shown. Stow the seat belts.
Page 67 1-4. Adjustable components (seats, mirrors, steering wheel) ■ Folding down rear seatbacks Pull the seatback lock release knob and fold the seatback down. Each seatback may be folded separately. CAUTION ■ When folding the rear seatbacks down Observe the following precautions. Failure to do so may result in death or serious injury.
Page 68 1-4. Adjustable components (seats, mirrors, steering wheel) CAUTION ■ After returning the rear seatback to the upright position Observe the following precautions. Failure to do so may result in death or serious injury. ● Make sure that the seatback is securely locked in position by lightly pushing it back and forth.
Page 69: Head Restraints
1-4. Adjustable components (seats, mirrors, steering wheel) Head restraints Pull the head restraint up. Down Push the head restraint down while pushing the lock release Lock release button. button ■ Removing the head restraints Front and rear center head restraints Pull the head restraint up while pushing the lock release button.
Page 70 1-4. Adjustable components (seats, mirrors, steering wheel) ■ Adjusting the height of the front seat head restraints Make sure that the head restraints are adjusted so that the center of the head restraint is closest to the top of your ears. ■...
Page 71: Seat Belts
1-4. Adjustable components (seats, mirrors, steering wheel) Seat belts Make sure that all occupants are wearing their seat belts before driv- ing the vehicle. ■ Correct use of the seat belts ● Extend the shoulder belt so that it comes fully over the shoulder, does come into contact with the...
Page 72 1-4. Adjustable components (seats, mirrors, steering wheel) Rear center seat belt ■ Fastening the seat belt The rear center seat belt is a 3-point type restraint with 2 buckles. Both seat belt buckles must be correctly located and securely latched for proper operation.
Page 73 1-4. Adjustable components (seats, mirrors, steering wheel) ■ Releasing the seat belt Release the rear center seat belt only when necessary, such as when folding down the rear seat. For safety, always store the plate in the designated place after releasing it. To release tab “A”, press the STEP release button.
Page 74 1-4. Adjustable components (seats, mirrors, steering wheel) Holding tab “A” and “B” together, STEP insert both tabs all the way into the cover on the roof. With tab “B” inserted all the way STEP into the cover, move tab “A” slightly back toward the cover’s inlet, so that it blocks the inlet.
Page 75 1-4. Adjustable components (seats, mirrors, steering wheel) Seat belt pretensioners (front seats) The pretensioner helps the seat belt to quickly restrain the occu- pant by retracting the seat belt when the vehicle is subjected to certain types of severe frontal collision.
Page 76 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children. ● Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system. ●...
Page 77 If this occurs and the buckle cannot be unfastened, scissors should be used to cut the belt. ■ Seat belt pretensioners If the pretensioner has activated, the SRS warning light will come on. In that case, the seat belt cannot be used again and must be replaced at your Toyota dealer.
Page 78 ● Ensure that the belt and plate are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Toyota dealer. ● Replace the seat assembly, including the belts, if your vehicle has been involved in a serious accident, even if there is no obvious damage.
Page 79: Steering Wheel
1-4. Adjustable components (seats, mirrors, steering wheel) Steering wheel The steering wheel can be adjusted to a comfortable position. Hold the steering wheel and STEP push the lever down. Adjust to the ideal position by STEP moving the steering wheel horizontally and vertically.
Page 80: Anti-Glare Inside Rear View Mirror
1-4. Adjustable components (seats, mirrors, steering wheel) Anti-glare inside rear view mirror The rear view mirror’s position can be adjusted to enable sufficient confirmation of the rear view in accordance with the driver's seating posture. Adjusting the height of rear view mirror Adjust the height of the rear view mirror by moving it up and down.
Page 81: Outside Rear View Mirrors
1-4. Adjustable components (seats, mirrors, steering wheel) Outside rear view mirrors Mirror angle can be adjusted using the switch. To select a mirror to adjust, STEP press the switch. Left Right To adjust the mirror, press the STEP switch. Right Down Left Folding the mirrors...
Page 82 1-4. Adjustable components (seats, mirrors, steering wheel) Vehicles with a folding switch Press the switch to fold the mir- rors. Press it again to extend them to the original position. ■ Mirror angle can be adjusted when The “POWER” switch is in ACCESSORY or ON mode. CAUTION ■...
Page 83: Opening And Closing The Windows
1-5. Opening and closing the windows Power windows The power windows can be opened and closed using the switches. Operating the switch moves the windows as follows: Closing One-touch closing (driver’s window only) Opening One-touch opening (driver’s window only) : Pushing the switch in the opposite direction will stop win- dow travel partway.
Page 84 If you release the switch while the window is moving, start again from the beginning. If the window continues to close but then re-open slightly even after perform- ing the above procedure correctly, have the vehicle inspected by your Toyota dealer.
Page 85 1-5. Opening and closing the windows CAUTION ■ Closing the windows Observe the following precautions. Failure to do so may result in death or serious injury. ● Check to make sure that all passengers do not have any part of their body in a position where it could be caught when a window is being operated.
Page 86: Refueling Opening The Fuel Tank Cap
1-6. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap: ■ Before refueling the vehicle ● Turn the “POWER” switch off and close all the doors and win- dows. ● Confirm the type of fuel. (→P. 86) ■...
Page 87 ■ Use of ethanol blended gasoline in a gasoline engine Toyota allows the use of ethanol blended gasoline where the ethanol content is up to 10%. Make sure that the ethanol blended gasoline to be used has a suitable Research Octane Number. (→P. 434) CAUTION ■...
Page 88 Do not top off the fuel tank ■ When replacing the fuel cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
Page 89: Theft Deterrent System
1-7. Theft deterrent system Immobilizer system The vehicle’s keys have built-in transponder chips that prevent the hybrid system from starting if a key has not been previously regis- tered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehicle. The indicator light flashes after the “POWER”...
Page 90: Safety Information
1-8. Safety information Correct driving posture Drive with a good posture as follows: Sit upright and well back in the seat. (→P. 64) Adjust the position of the seat forward or backward to ensure the pedals can be reached easily depressed to the extent required.
Page 91 1-8. Safety information CAUTION ■ While driving ● Do not adjust the position of the driver's seat. Doing so could cause the driver to lose control of the vehicle. ● Do not place a cushion between the driver or passenger and the seatback. A cushion may prevent correct posture from being achieved, and reduce the effectiveness of the seat belt and head restraint, increasing the risk of death or serious injury to the driver or passenger.
Page 92: Srs Airbags
1-8. Safety information SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. SRS front airbags SRS driver airbag/front passenger airbag Can help protect the head and chest of the driver and front pas-...
Page 93 1-8. Safety information SRS airbag system components Curtain shield airbags Seat belt pretensioners and force limiters SRS warning light Airbag sensor assembly Side airbags Front impact sensors Side impact sensors (rear) Driver’s knee airbag Front passenger airbag Driver airbag Side impact sensors (front) The main SRS airbag system components are shown above.
Page 94 1-8. Safety information ■ If the SRS airbags deploy (inflate) ● Bruising and slight abrasions may result from contact with a deploying (inflating) SRS airbag. ● A loud noise and white powder will be emitted. ● Parts of the airbag module (steering wheel hub, airbag cover and inflator) as well as the front seats, parts of the front and rear pillars, and roof side rails, may be hot for several minutes.
Page 95 1-8. Safety information ■ Conditions under which the SRS airbags may deploy (inflate), other than a collision The SRS front airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration. ●...
Page 96 Vehicle rollover ■ When to contact your Toyota dealer In the following cases, the vehicle will require inspection and/or repair. Con- tact your Toyota dealer as soon as possible. ● Any of the SRS airbags have been inflated. ● The front of the vehicle is damaged or...
Page 97 1-8. Safety information ● A portion of a door is damaged or deformed, or the vehicle was involved in an accident that was not severe enough to cause the SRS side and cur- tain shield airbags to inflate. ● The pad section of the steering wheel, dashboard near the front passenger airbag or lower portion of the instru- ment panel is scratched, cracked, or...
Page 98 1-8. Safety information CAUTION ■ SRS airbag precautions Observe the following precautions regarding the SRS airbags. Failure to do so may cause death or serious injury. ● The driver and all passengers in the vehicle must wear their seat belts properly.
Page 99 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are safer for infants and children than the front passenger seat.
Page 100 1-8. Safety information CAUTION ■ SRS airbag precautions ● Do not lean against the door, the roof side rail or the front, side and rear pil- lars. ● Do not allow anyone to kneel on the passenger seat toward the door or put their head or hands outside the vehicle.
Page 101 1-8. Safety information CAUTION ■ SRS airbag precautions ● Do not attach anything to areas such as a door, windshield glass, side door glass, front or rear pillar, roof side rail and assist grip. ● Do not hang coat hangers or other hard objects on the coat hooks. All of these items could become projectiles and may cause death or serious injury, should the SRS curtain shield airbags deploy.
Page 102 Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury.
Page 103: Child Restraint Systems
General installation instructions are provided in this manual. (→P. 111) ● If child restraint system regulations exist in the country where you reside, please contact your Toyota dealer for the child restraint sys- tem installation. ● Toyota recommends that you use a child restraint system which conforms to the regulation ECE No.44.
Page 104 1-8. Safety information Baby seat (infant seat) Equal to Group 0 and 0 of ECE No.44 Child seat (convertible seat) Equal to Group 0 and I of ECE No.44 Junior seat (booster seat) Equal to Group II and III of ECE No.44...
Page 105 1-8. Safety information Child restraint system suitability for various seating positions Information provided in the table shows your child restraint system suitability for various seating positions. Seating Rear seat position Front Mass passenger seat groups Outside Center Up to 10 kg (22 lb.) Never put (0 - 9 months)
Page 106 L1: Suitable for “TOYOTA DUO+” (without ISOFIX, 9 to 18 kg [20 to 39 lb.]) approved for the use in this mass group. L2: Suitable for “TOYOTA KID” (15 to 36 kg [34 to 79 lb.]) approved for the use in this mass group.
Page 107 1-8. Safety information Child restraint system suitability for various seating positions (with ISOFIX rigid anchors) Information provided in the table shows your child restraint system suitability for various seating positions. Vehicle ISOFIX positions Mass groups Size class Fixture Rear outside ISO/L1 Carrycot ISO/L2...
Page 108 1-8. Safety information (1) For the CRS which do not carry the ISO/XX size class identifica- tion (A to G), for the applicable mass group, the car manufac- turer shall indicate the vehicle specific ISOFIX child restraint system(s) recommended for each position. Key of letters inserted in the above table: IUF: Suitable for ISOFIX forward-facing child restraints systems of universal category approved for use in this mass group.
Page 109 1-8. Safety information ■ When installing a child restraint system on the front passenger seat When you have to use a child restraint system on the front passenger seat, perform the following: ● Move the seat as far back as possible. ●...
Page 110 ● Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Page 111 1-8. Safety information CAUTION ■ When children are in the vehicle Do not allow children to play with the seat belt. If the seat belt becomes twisted around a child’s neck, it may lead to choking or other serious injuries that could result in death.
Page 112: Installing Child Restraints
1-8. Safety information Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure child restraints to the seats using a seat belt or ISOFIX rigid anchors. Attach the top strap when installing a child restraint. Seat belts equipped with a child restraint locking mecha- nism (ALR/ELR belts on out- side rear seats) (→P.
Page 113 1-8. Safety information Child restraint anchor fitting An anchor fitting is provided for each rear seat. Installing child restraints using a seat belt (child restraint lock function belt) Rear facing  Baby seat (Infant seat)/child seat (Convertible ■ seat) Place the child restraint system STEP on the rear seat facing the rear of the vehicle.
Page 114 1-8. Safety information Fully extend the shoulder belt STEP and then allow it to retract slightly in order to activate the ALR lock mode. Lock mode allows the seat belt to retract only. While pushing the child restraint STEP system down into the rear seat, allow the shoulder belt to retract until the child restraint system is securely in place.
Page 115 1-8. Safety information Remove the head restraint. STEP (→P. 68) Latch the attaching clip of the STEP upper anchorage strap onto the anchor fitting. (→P. 124) Make sure the seat belt is tightly secured, and that there is no slack in the belt. Reinstall the head restraint.
Page 116 1-8. Safety information Forward facing  Child seat (convertible seat) ■ Remove the head restraint. STEP (→P. 68) Place the child restraint system STEP on the seat facing the front of the vehicle. Run the seat belt through the STEP child restraint system and insert the plate into the buckle.
Page 117 1-8. Safety information While pushing the child restraint STEP system into the rear seat, allow the shoulder belt to retract until the child restraint system is securely in place. After shoulder belt retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
Page 118 1-8. Safety information ■ Junior seat (booster seat) Place the child restraint system STEP on the seat facing the front of the vehicle. Sit the child in the child restraint STEP system. Fit the seat belt to the child restraint system according to the manufacturer’s instruc- tions and insert the plate into the buckle.
Page 119 1-8. Safety information Installing child restraints using a seat belt (Locking clip requiring belt) Rear-facing  Baby seat (infant seat)/child seat (convertible ■ seat) Place the child restraint system STEP on the rear seat facing the rear of the vehicle. Run the seat belt through the STEP child restraint system and insert...
Page 120 1-8. Safety information Remove the head restraint. STEP (→P. 68) Latch the attaching clip of the STEP upper anchorage strap onto the anchor fitting. (→P. 124) Make sure the seat belt is tightly secured, and that there is no slack in the belt. Reinstall the head restraint.
Page 121 1-8. Safety information Forward-facing  Child seat (convertible seat) ■ Remove the head restraint. STEP (→P. 68) Place the child restraint system STEP on the seat facing the front of the vehicle. Run the seat belt through the STEP child restraint system and insert the plate into the buckle.
Page 122 1-8. Safety information Latch the attaching clip of the STEP upper anchorage strap onto the anchor fitting. (→P. 124) Make sure the seat belt is tightly secured, and that there is no slack in the belt. If the child restraint system does STEP not touch the head restraint, reinstall the head restraint.
Page 123 1-8. Safety information ■ Junior seat (booster seat) Place the child restraint system STEP on the seat facing the front of the vehicle. Sit the child in the child restraint STEP system. Fit the seat belt to the child restraint system according to the manufacturer’s instruc- tions and insert the plate into the buckle.
Page 124 1-8. Safety information Installation with ISOFIX rigid anchors (ISOFIX child restraint system) Widen the gap in the seat STEP cushion slightly. Latch the buckles onto STEP the exclusive fixing bars. If the child restraint has a upper anchorage strap, upper anchorage strap should...
Page 125 1-8. Safety information Using the child restraint anchor fitting Remove the luggage cover. (→P. 303) STEP Remove the head restraint. STEP (→P. 68) Secure the child restraint system using a seat belt or ISOFIX STEP rigid anchors. Attaching clip STEP Front of Upper anchorage strap vehicle...
Page 126 You need a locking clip to install the child restraint system. Follow the instructions provided by the manufacturer of the system. If your child restraint system does not provide a locking clip, you can purchase the fol- lowing item from your Toyota dealer: Locking clip for child restraint system (Part No. 73119-22010)
Page 127 1-8. Safety information CAUTION ■ When installing a junior (booster) seat To prevent the belt from going into ALR lock mode, do not fully extend the shoulder belt. ALR mode causes the belt to tighten only. This could cause injury or discomfort to the child. (→P. 74) ■...
Page 128 1-8. Safety information CAUTION ■ When installing a child restraint system ● Extreme Hazard! Do not use a rear- ward facing child restraint on a seat protected by an airbag in front of it! This is because the force of the rapid infla- tion of the front passenger airbag can cause death or serious injury to the child.
Page 129 When installing a child restraint system ● If child restraint system regulations exist in the country where you reside, please contact your Toyota dealer for the child restraint system installation. ● When a junior (booster) seat is installed, always ensure that the shoulder belt is positioned across the center of the child’s shoulder.
Page 130 1-8. Safety information CAUTION ■ When installing a child restraint system ● When using the right side seat for the child restraint system, do not sit in the center seat. Seat belt function may be impaired, such as being positioned overly high or loose-fitting, which may result in death or serious injury in the event of sudden braking or an accident.
Page 131 1-8. Safety information...
Page 132: When Driving
When driving 2-1. Driving procedures 2-5. Driving information Driving the vehicle .... 132 Cargo and luggage ... 201 Power (ignition) switch..143 Winter driving tips ..... 203 EV drive mode ....151 Trailer towing ....206 Hybrid transmission ..154 Turn signal lever ....
Page 133: Driving Procedures Driving The Vehicle
2-1. Driving procedures Driving the vehicle The following procedures should be observed to ensure safe driv- ing: ■ Starting the hybrid system →P. 143 ■ Driving With the brake pedal depressed, shift the shift lever to D. STEP (→P. 154) Release the parking brake.
Page 134 The vehicle is judged to be driving uphill or downhill ● When the accelerator pedal is released ■ Breaking in your new Toyota To extend the life of the vehicle, observing the following precautions is rec- ommended: ● For the first 300 km (200 miles): Avoid sudden stops.
Page 135 2-1. Driving procedures ■ Operating your vehicle in a foreign country Comply with the relevant vehicle registration laws and confirm the availability of the correct fuel. (→P. 434) ■ For efficient use ● Shift the shift lever to D when driving. In the N position, the gasoline engine operates but electricity cannot be generated.
Page 136 Large amounts of exhaust in the vehi- cle can cause driver drowsiness and an accident, resulting in death or a serious health hazard. Have the vehicle inspected by your Toyota dealer immediately. ●...
Page 137 2-1. Driving procedures CAUTION ● Do not shift the shift lever to R while the vehicle is moving forward. Doing so can damage the transmission and may result in a loss of vehicle control. ● Do not shift the shift lever to D while the vehicle is moving backward. Doing so can damage the transmission and may result in a loss of vehicle control.
Page 138 ■ If you hear a squealing or scraping noise (brake pad wear indicators) Have the brake pads checked and replaced by your Toyota dealer as soon as possible. Rotor damage may result if the pads are not replaced when needed.
Page 139 2-1. Driving procedures CAUTION ■ When the vehicle is stopped ● Do not depress the accelerator pedal unnecessarily. If the vehicle is in any gear other than P or N, the vehicle may accelerate suddenly and unexpectedly, causing an accident. ●...
Page 140 The exhaust system should be checked occasionally. If there is a hole or crack caused by corrosion, damage to a joint or abnormal exhaust noise, be sure to have the vehicle inspected and repaired by your Toyota dealer. Failure to do so may allow exhaust gases to enter the vehicle, resulting in...
Page 141 If the brake system warning light (red indicator) comes on, there may be a malfunction with the brake’s hydraulic system. Immediately stop the vehi- cle in a safe place and contact your Toyota dealer. In this case, the brake pedal should be depressed more firmly than usual and the braking distance will increase.
Page 142 2-1. Driving procedures NOTICE ■ When driving the vehicle ● Do not depress the accelerator and brake pedals at the same time during driving, as this may restrain driving torque. ● Do not use the accelerator pedal or depress the accelerator and brake pedals at the same time to hold the vehicle on a hill.
Page 143 Short in electrical components ● Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following: ● Brake function ●...
Page 144: Power (Ignition) Switch
2-1. Driving procedures Power (ignition) switch Performing the following operations when carrying the electronic key on your person starts the hybrid system or changes “POWER” switch modes. ■ Starting the hybrid system Check that the parking brake is set. STEP Check that the shift lever is set in P.
Page 145 2-1. Driving procedures Check that the “READY” indicator is on. STEP If the “READY” indicator changes from a flashing light to a solid light and a beep sound, the hybrid system is starting normally. The vehicle will not move when the “READY” indicator is off. The vehicle can move when the “READY”...
Page 146 2-1. Driving procedures ■ Changing “POWER” switch modes Modes can be changed by pressing the “POWER” switch with brake pedal released. (The mode changes each time the switch is pressed.) Off* The emergency flashers can be used. The multi-information display is off.
Page 147 2-1. Driving procedures When stopping the hybrid system with the shift lever in a position other than P If the hybrid system is stopped with the shift lever in a position other than P, the “POWER” switch will not be turned off but instead be turned to ACCESSORY mode.
Page 148 If the hybrid system does not start ● The immobilizer system may not have been deactivated. (→P. 88) Contact your Toyota dealer. ● Check that the shift lever is securely set in P. The hybrid system may not start if the shift lever is not securely in the P position.
Page 149 If the “READY” indicator does not come on If the “READY” indicator does not come on when you press the “POWER” switch with the shift lever in P and the brake pedal depressed, contact your Toyota dealer immediately. ■ If the hybrid system is malfunctioning →P.
Page 150 When “CHECK ENTRY & START SYSTEM” is displayed on the multi- information display The system may be malfunctioning. Have the vehicle inspected by your Toyota dealer immediately. Failure to do so may lead to the system operat- ing abnormally and possibly cause an accident or damage to the vehicle. ■...
Page 151 Toyota dealer immediately. ■ Symptoms indicating a malfunction with the “POWER” switch If the “POWER” switch seems to be operating somewhat differently than usual, such as the switch sticking slightly, there may be a malfunction. Con- tact your Toyota dealer immediately.
Page 152: Ev Drive Mode
2-1. Driving procedures EV drive mode In EV drive mode, the electric motor (traction motor), powered by the hybrid battery (traction battery), is used to drive the vehicle. This mode allows you to drive in residential areas early in the morn- ing and late at night, or in indoor parking lots etc.
Page 153 2-1. Driving procedures ■ Situations in which EV drive mode cannot be turned on It may not be possible to turn EV drive mode on in the following situations. If it cannot be turned on, a buzzer will sound and a message will be shown on the multi-information display.
Page 154 2-1. Driving procedures CAUTION ■ Caution while driving When driving in EV drive mode, pay special attention to the area around the vehicle. Because there is no engine noise, pedestrians, people riding bicy- cles or other people and vehicles in the area may not be aware of the vehicle starting off or approaching them, so take extra care while driving.
Page 155: Hybrid Transmission
2-1. Driving procedures Hybrid transmission Select a shift position appropriate for the driving conditions. ■ Shifting the shift lever While the “POWER” switch is in ON mode, move the shift lever with the brake pedal depressed. When shifting from P to another position; from D to R or P; or from R to P, D or B;...
Page 156 2-1. Driving procedures ■ Selecting Eco drive mode Suitable for enhancing the fuel economy, because the torque corresponding to the accelerator pedal depression amount can be generated more smoothly than it is in normal conditions and the operation of the air conditioning system (heating/cooling) will be minimized.
Page 157 2-1. Driving procedures CAUTION ■ When driving on slippery road surfaces Do not accelerate or shift gears suddenly. Sudden changes in engine braking may cause the vehicle to spin or skid, resulting in an accident.
Page 158: Turn Signal Lever
2-1. Driving procedures Turn signal lever The turn signal lever can be used to show the following intentions of the driver: Left turn Right turn Lane change to the left (push and hold the lever partway) The left hand signals will flash until you release the lever.
Page 159: Parking Brake
2-1. Driving procedures Parking brake To set the parking brake, fully pull the parking brake lever while depressing the brake pedal. release parking brake, slightly raise the lever and lower it com- pletely while pressing the button. ■ Parking brake engaged warning buzzer A buzzer will sound if the vehicle is driven at a speed of approximately 5 km/h (3 mph) or more with the parking brake engaged.
Page 160: Horn
2-1. Driving procedures Horn To sound the horn, press on or close to the mark. ■ After adjusting the steering wheel Make sure that the steering wheel is securely locked. The horn may not sound if the steering wheel is not securely locked. (→P.
Page 161: Instrument Cluster Gauges And Meters
2-2. Instrument cluster Gauges and meters Multi-information display Presents the driver with a variety of driving-related data. (→P. 165) Fuel gauge Displays the quantity of fuel remaining in the tank. Shift position display Displays the selected shift position. (→P. 154) Speedometer Displays the vehicle speed.
Page 162 2-2. Instrument cluster ■ The meters and multi-information display illuminate when The “POWER” switch is in ON mode. ■ Engine speed On hybrid vehicles, engine speed is precisely controlled in order to help improve fuel efficiency and reduce exhaust emissions etc. There are times when the engine speed that is displayed may differ even when vehicle operation and driving conditions are the same.
Page 163: Indicators And Warning Lights
2-2. Instrument cluster Indicators and warning lights The indicators and warning lights on the instrument cluster inform the driver of the status of the vehicle’s various systems. For the purpose of explanation, the following illustration displays all indicators and warning lights illuminated.
Page 164 There may be a malfunction in a system if a light does not come on, or if the light does not turn off. Have the vehicle inspected by your Toyota dealer. : The light flashes to indicate that the system is operating.
Page 165 There may be a malfunction in a system if a light does not come on, or if the lights do not turn off. Have the vehicle inspected by your Toyota dealer.
Page 166: Multi-Information Display
2-2. Instrument cluster Multi-information display The multi-information display presents the driver with a variety of driving-related data including the current outside air temperature. ● Drive information Displays information such as the hybrid system operating conditions and fuel consump- tion. ● Settings and screen off Perform operations such as changing the date/time and screen settings.
Page 167 2-2. Instrument cluster Touch tracer display When a steering wheel switch is touched, an illustration of the switch is shown on the screen, helping the driver to confirm which switch they are touching without needing to look down at their hands. The touch tracer display can be turned off.
Page 168 2-2. Instrument cluster Items displayed in the upper part of the screen The following items are always displayed in the upper part of the screen. (When using some menu items, these items will not be dis- played.) Odometer/trip meter/meter light control display →P.
Page 169 2-2. Instrument cluster ■ Odometer/trip meter/meter light control display Each time the “TRIP” switch is pressed, the display changes as fol- lows: Odometer Displays the total distance that the vehicle has been driven. Trip meter Displays the distance the vehicle has been driven since the meter was last reset.
Page 170 2-2. Instrument cluster Switching menu screens Each time the “DISP” switch is pressed, the menu screen changes. When the desired menu screen is displayed, stop pressing the “DISP” switch. The details screen will soon be displayed. However, to display the “Settings & Screen Off” details screen, press and hold the “DISP”...
Page 171 2-2. Instrument cluster “ECO Savings” If the price of gasoline is input, the cost of the consumed fuel according to the driven distance is displayed. If the fuel consumption comparison is set, the difference between the input fuel consumption and your vehicle's actual fuel consumption is expressed as an amount of money that was possibly saved.
Page 172 2-2. Instrument cluster ● When the trip meter is displayed: the record since the trip meter was reset is displayed. The record for trip meter A and trip meter B is displayed separately. When the trip meter is reset, the record is also reset. (→P. 168) Average speed Average speed will be displayed.
Page 173 2-2. Instrument cluster ■ “ECO Score” Hybrid battery (traction battery) charge level display EV drive indicator lamp Illuminates when only the electric motor is used to drive the vehicle. Hybrid System Indicator Hybrid System Indicator represents the hybrid system power output and regenerative charging.
Page 174 2-2. Instrument cluster ■ “ECO Savings” Detailed display Basic display With 2 types of displays available, the cost of the consumed fuel can be displayed or the fuel consumption's comparison can be displayed. Switching between basic display and detailed display can be performed on the screen settings screen.
Page 175 2-2. Instrument cluster The cost of consumed fuel per kilometer (your car) The more fuel efficient your driving is, the further left the vehicle mark moves. ■ “ECO Savings Record” If the fuel consumption compari- son is input in “ECO Savings”, the savings history will be dis- played.
Page 176 2-2. Instrument cluster Hybrid System Indicator Charge area Shows energy regeneration* status. Regenerated energy will be used to charge the hybrid battery (traction battery). *: When used in this manual, “regeneration” refers to the conversion of energy created by the movement of the vehicle into electrical energy. Hybrid Eco area Shows that gasoline engine power is not being used very often.
Page 177 2-2. Instrument cluster Screen settings If “Settings & Screen Off” is selected on the menu screen, the follow- ing items can be set. Always perform this operation after stopping the vehicle in a safe place. (Some items cannot be set while driving.) Press the “DISP”...
Page 178 2-2. Instrument cluster ■ Basic settings/Changing the clock shortcut The date, time, clock mode (12 or 24 hour) and touch tracer settings can be changed. ● Pressing the “DISP” (forward) or “TRIP” (back) switch changes the date. ● Press the “DISP” switch to select hours or minutes. Pressing the “TRIP”...
Page 179 2-2. Instrument cluster ■ “ECO Savings” settings The gasoline price and fuel consumption comparison settings can be set, and the screen settings can be changed between basic and detailed. ● To input the gasoline price, press the “DISP” (to increase) or “TRIP”...
Page 180 2-2. Instrument cluster ■ Menu screen selection The following screen changes and settings can be performed: • The savings record screen can be switched on or off. • The 5 minute fuel consump- tion screen can be switched on or off. •...
Page 181 2-2. Instrument cluster ■ The clock is displayed when The “POWER” switch is in ON mode. ■ The brightness of the meter lights When the headlight switch is turned to on, the brightness will be reduced slightly unless the meter is set to maximum brightness. ■...
Page 182 2-2. Instrument cluster CAUTION ■ Eco score Eco score should be used as a guide only. Always drive safely in accor- dance with road and traffic conditions. NOTICE ■ The multi-information display at low temperatures Allow the interior of the vehicle to warm up before using the liquid crystal information display.
Page 183: Operating The Lights And Wipers
2-3. Operating the lights and wipers Headlight switch The headlights can be operated manually. Turning the end of the lever turns on the lights as follows: The front position, tail, license plate and instrument panel lights turn on. The headlights and all the lights listed above turn on.
Page 184 2-3. Operating the lights and wipers Manual headlight leveling dial (vehicles with halogen headlights) The level of the headlights can be adjusted according to the number of passengers and the loading condition of the vehicle. Raises the level of the head- lights Lowers the level of the head- lights...
Page 185 2-3. Operating the lights and wipers ■ Automatic light off system (vehicles with LED headlights) The headlights and all the lights turn off automatically when the “POWER” switch is turned to ACCESSORY mode or turned off and the driver’s door is opened.
Page 186: Fog Light Switch
2-3. Operating the lights and wipers Fog light switch The fog lights secure excellent visibility in difficult driving condi- tions, such as in rain and fog. Turns the front fog lights off Turns the front fog lights on ■ Fog lights can be used when The headlights or front position lights are turned on.
Page 187: Windshield Wipers And Washer
2-3. Operating the lights and wipers Windshield wipers and washer When “INT” is selected, the wiper interval can be adjusted for intermittent operation. Intermittent windshield wiper operation Low speed windshield wiper operation High speed windshield wiper operation Temporary operation Decreases the intermittent windshield wiper frequency Increases the intermittent windshield wiper frequency...
Page 188 2-3. Operating the lights and wipers Washer/wiper dual opera- tion The wipers will automatically operate a couple of times after the washer squirts. If the headlights are on, the headlight cleaners will operate once. ■ The windshield wipers and washer can be operated when The “POWER”...
Page 189 Do not operate the switch continually as the washer fluid pump may over- heat. ■ When a nozzle becomes blocked In this case, contact your Toyota dealer. Do not try to clear it with a pin or other object. The nozzle will be damaged.
Page 190: Rear Window Wiper And Washer
2-3. Operating the lights and wipers Rear window wiper and washer The wiper operation is selected by moving the lever as follows: Intermittent window wiper operation Normal window wiper oper- ation Washer/wiper dual opera- tion Washer/wiper dual opera- tion The wipers will automatically operate a couple of times after the washer squirts.
Page 191 Do not operate the switch continually as the washer fluid pump may over- heat. ■ When a nozzle becomes blocked In this case, contact your Toyota dealer. Do not try to clear it with a pin or other object. The nozzle will be damaged.
Page 192: Headlight Cleaner Switch
2-3. Operating the lights and wipers ∗ Headlight cleaner switch Washer fluid can be sprayed on the headlights. Press the switch to clean the headlights. ■ The headlight cleaners can be operated when The “POWER” switch is in ON mode and the headlight switch is turned on. ■...
Page 193: Using Other Driving Systems
2-4. Using other driving systems Cruise control Use the cruise control to maintain a set speed without depressing the accelerator pedal. Indicators Cruise control switch ■ Setting the vehicle speed Press the “ON-OFF” button to STEP activate the cruise control. Cruise control indicator will come on.
Page 194 2-4. Using other driving systems ■ Adjusting the set speed To change the set speed, operate the lever until the desired set speed is obtained. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direction.
Page 195 If the cruise control speed cannot be set or if the cruise control cancels immediately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by your Toyota dealer.
Page 196 2-4. Using other driving systems CAUTION ■ To avoid operating the cruise control by mistake Switch the cruise control off using the “ON-OFF” button when not in use. ■ Situations unsuitable for cruise control Do not use cruise control in any of the following situations. Doing so may result in loss of control and could cause an accident resulting in death or serious injury.
Page 197: Driving Assist Systems
2-4. Using other driving systems Driving assist systems To help enhance driving safety and performance, the following sys- tems operate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehicle. ■...
Page 198 2-4. Using other driving systems When the TRC/VSC/ABS/hill-start assist control systems are operating The slip indicator light will flash while TRC/VSC/ABS/hill- start assist control systems are operating. The stop lights and high mounted stoplight turn on when the hill- start assist control system is operating.
Page 199: Tires
The ABS, TRC and VSC systems will not function correctly if different tires are installed on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. ■ Handling of tires and the suspension Using tires with any kind of problem or modifying the suspension will affect the driving assist systems, and may cause a system to malfunction.
Page 200: Hill-Start Assist Control
2-4. Using other driving systems Hill-start assist control Assists with starting off and temporarily maintains braking power even if the foot is removed from the brake pedal when starting off on an incline or a slippery slope. To engage hill-start assist con- trol, further depress the brake pedal when the vehicle is stopped completely.
Page 201 If a buzzer other than the hill-start assist control buzzer is sounding, the hill-start assist control buzzer may not sound. ■ If the slip indicator comes on It may indicate a malfunction in the system. Contact your Toyota dealer. CAUTION ■ Hill-start assist control ●...
Page 202: Driving Information Cargo And Luggage
2-5. Driving information Cargo and luggage Take notice of the following information about storage precautions, cargo capacity and load: ● Stow cargo and luggage in the luggage compartment whenever possible. ● Be sure all items are secured in place. ● To maintain vehicle balance while driving, position luggage evenly within the luggage compartment.
Page 203 2-5. Driving information CAUTION ■ Storage precautions Observe the following precautions. Failure to do so may result in death or serious injury. ● Stow cargo and luggage in the luggage compartment whenever possible. ● Do not stack cargo and luggage in the luggage compartment higher than the seatbacks.
Page 204: Winter Driving Tips
2-5. Driving information Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a manner appropri- ate to the prevailing weather conditions. ■ Pre-winter preparations ● Use fluids that are appropriate to the prevailing outside tem- peratures.
Page 205 2-5. Driving information ■ When driving the vehicle Accelerate the vehicle slowly, keep a safe distance between you and the vehicle ahead, and drive at a reduced speed suitable to road conditions. ■ When parking the vehicle Park the vehicle and move the shift lever to P without setting the parking brake.
Page 206: Tires
2-5. Driving information ■ Tire chain installation Observe the following precautions when installing and removing chains: ● Install and remove tire chains in a safe location. ● Install tire chains on the front tires only. Do not install tire chains on the rear tires.
Page 207: Trailer Towing
Trailer towing Toyota does not recommend towing a trailer with your vehicle. Toyota also does not recommend the installation of a tow hitch or the use of a tow hitch carrier for a wheelchair, scooter, bicycle, etc. Your vehicle is not designed for trailer towing or for the use of tow...
Page 208: Interior Features
Interior features 3-1. Using the air conditioning 3-4. Using the interior lights system and defogger Interior lights list....287 • Interior lights/ Automatic air personal lights ....288 conditioning system ..208 Rear window defogger..216 3-5. Using the storage features 3-2.
Page 209: Using The Air Conditioning System And Defogger
3-1. Using the air conditioning system and defogger Automatic air conditioning system Air outlets and fan speed are automatically adjusted according to the temperature setting. Cooling and dehumidification Windshield Temperature display function on/off button defogger button Fan speed display Air outlet display Outside/recirculated air mode button Air outlet selector button...
Page 210 3-1. Using the air conditioning system and defogger Using the automatic air conditioning system Press STEP The air conditioning system begins to operate. Air outlets and fan speed are automatically adjusted according to the temper- ature setting. To adjust the temperature setting, turn clockwise to STEP increase the temperature and turn...
Page 211 3-1. Using the air conditioning system and defogger Defogging the windshield Press dehumidification function operates speed increases. Set the outside/recirculated air mode button to the outside air mode if the recirculated air mode is used. (It may switch automati- cally.) To defog the windshield and the side windows early, turn the air flow and temperature up.
Page 212 3-1. Using the air conditioning system and defogger Air flows to the upper body and feet. Air flows mainly to the feet. *: When the warming function is operating, air flows to the upper body as well to warm the upper body effectively.
Page 213 3-1. Using the air conditioning system and defogger Adjusting the position of and opening and closing the air outlets Center outlets Direct air flow to the left or right, up or down. Right and left side outlets Direct air flow to the left or right, up or down.
Page 214 3-1. Using the air conditioning system and defogger Steering wheel switches Temperature control Press “∧” on to increase temperature “∨” decrease the temperature. Outside air or recirculated air mode The mode switches between out- side air mode and recirculated air mode each time is pressed.
Page 215 3-1. Using the air conditioning system and defogger ■ Using automatic mode Fan speed is adjusted automatically according to the temperature setting and the ambient conditions. Therefore, the fan may stop for a while until warm or cool air is ready to flow immediately after is pressed.
Page 216 3-1. Using the air conditioning system and defogger ■ Air conditioning filter →P. 344 ■ When operating the steering switches →P. 166 CAUTION ■ To prevent the windshield from fogging up Do not use during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the windshield can cause the outer surface of the windshield to fog up, blocking your vision.
Page 217: Rear Window Defogger
3-1. Using the air conditioning system and defogger Rear window defogger A defogger is used to defog the rear window. Turns the defogger on/off The defoggers will automati- cally turn off after approxi- mately 15 minutes. ■ The rear window defogger can be operated when The “POWER”...
Page 218: Using The Audio System
3-2. Using the audio system ∗ Audio system type CD player and AM/FM radio Title Page Using the radio P. 219 Using the CD player P. 221 Playing back MP3 and WMA discs P. 226 Operating an iPod P. 233 Operating a USB memory P.
Page 219 3-2. Using the audio system ■ Using cellular phones Interference may be heard through the audio system's speakers if a cellular phone is being used inside or close to the vehicle while the audio system is operating. NOTICE ■ To prevent 12-volt battery discharge Do not leave the audio system on longer than necessary when the hybrid system is stopped.
Page 220: Using The Radio
3-2. Using the audio system Using the radio Power Volume Adjusting the Station selector frequency or selecting items Seeking the frequency AM/FM mode Scanning for receivable stations button Setting station presets or pressing “ ∧ ” Search for desired stations by turning STEP or “∨”...
Page 221 3-2. Using the audio system Scanning radio stations ■ Scanning the preset radio stations Press and hold until you hear a beep. STEP Preset stations will be played for 5 seconds each. When the desired station is reached, press again. STEP ■...
Page 222: Using The Cd Player
3-2. Using the audio system Using the CD player Power Volume CD eject Selecting a track or displays track list Random playback Displays text Playback Search playback message Repeat play Selecting a track, fast-forwarding or reversing Loading CDs Insert a CD. Ejecting CDs Press and remove the CD.
Page 223 3-2. Using the audio system Selecting a track from a track list Press STEP The track list will be displayed. Turn and press to select a track. STEP To return to the previous display, press (BACK). Scanning tracks Press STEP The first 10 seconds of each track will be played.
Page 224 Operation has stopped due to a high temperature inside the player. Wait for a while and then press . If the CD still cannot be played back, contact your Toyota dealer. ■ Discs that can be used Discs with the marks shown below can be used.
Page 225 3-2. Using the audio system CAUTION ■ Certification for the CD player This product is a class I laser product. ● A laser beam leak may result in hazardous radiation exposure. ● Do not open the cover of the player or attempt to repair the unit yourself. Refer servicing to qualified personnel.
Page 226 3-2. Using the audio system NOTICE ● CDs with a transparent or translucent recording area ● CDs that have had tape, stickers or CD- R labels attached to them, or that have had the label peeled off ■ CD player precautions Failure to follow the precautions below may result in serious damage to the CDs or the player itself.
Page 227: Playing Back Mp3 And Wma Discs
3-2. Using the audio system Playing back MP3 and WMA discs Power Volume Disc eject Selecting a file or displays folder list Random playback Search Displays text Playback Repeat play playback message Selecting a folder Selecting a file, fast-forwarding or reversing Loading and ejecting MP3 and WMA discs →P.
Page 228 3-2. Using the audio system Turn and press to select a folder and a file. STEP To return to the previous display, press (BACK). ■ Returning to the first folder Press and hold ) until you hear a beep. Scanning a folder Press and hold until you hear a beep.
Page 229 3-2. Using the audio system Random playback Pressing (RDM) changes modes in the following order: Folder random → Disc random → Off Repeat play Pressing (RPT) changes modes in the following order: File repeat → Folder repeat* → Off *: Available except when RDM (random playback) is selected Switching the display Press Track title, Artist name and Album title (MP3 only) are shown on the dis-...
Page 230 3-2. Using the audio system ■ Display →P. 223 ■ Error messages “ERROR”: This indicates a problem either in the CD or inside the player. “CD CHECK”: The CD may be dirty, damaged or inserted up-side down. “NO SUPPORT”: This indicates that MP3/WMA files are not included in the ■...
Page 231 3-2. Using the audio system ■ MP3 and WMA files MP3 (MPEG Audio LAYER3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size by using MP3 compression. WMA (Windows Media Audio) is a Microsoft audio compression format. This format compresses audio data to a size smaller than that of the MP3 format.
Page 232 3-2. Using the audio system ● Compatible media Media that can be used for MP3 and WMA playback are CD-Rs and CD- RWs. Playback in some instances may not be possible, depending on the status of the CD-R or CD-RW. Playback may not be possible or the audio may jump if the disc is scratched or marked with fingerprints.
Page 233 3-2. Using the audio system ● MP3 and WMA playback When a disc containing MP3 or WMA files is inserted, all files on the disc are first checked. Once the file check is finished, the first MP3 or WMA file is played.
Page 234: Operating An Ipod
3-2. Using the audio system Operating an iPod Connecting an iPod enables you to enjoy music from the vehicle speakers. ■ Connecting an iPod Open the cover and connect STEP an iPod using an iPod cable. Turn on the power of the iPod if it is not turned on.
Page 235 3-2. Using the audio system Selecting a play mode Press (MENU) to select iPod menu mode. STEP Turning clockwise changes the play mode in the fol- STEP lowing order: “Playlists”→“Artists”→“Albums”→“Songs”→“Podcasts”→“Genres” →“Composers”→“Audiobooks” Press to select the desired play mode. STEP ■ Play mode list First Second...
Page 236 3-2. Using the audio system ■ Selecting a list Turn to display the first selection list. STEP Press to select the desired item. STEP Pressing the knob changes to the second selection list. Repeat the same procedure to select the desired item. STEP To return to the previous selection list, press (BACK).
Page 237 3-2. Using the audio system Fast-forwarding and reversing songs To fast-forward or reverse, press and hold “ ∧ ” or “∨” on Shuffle playback Pressing (RDM) changes modes in the following order: Track shuffle → Album shuffle → Off Repeat play Press (RPT) To cancel, press...
Page 238 3-2. Using the audio system ■ Cord hook A cord can be secured as shown in the illustration. Cords with a diameter of approximately 5 mm (0.2 in.) can be secured. ■ About iPod ● “Made for iPod” and “Made for iPhone” mean that an electronic acces- sory has been designed to connect specifically to iPod, or iPhone, respectively, and has been certified by the developer to meet Apple per- formance standards.
Page 239 3-2. Using the audio system ■ iPod functions ● When an iPod is connected and the audio source is changed to iPod mode, the iPod will resume play from the same point in which it was last used. ● Depending on the iPod that is connected to the system, certain functions may not be available.
Page 240 3-2. Using the audio system ■ Compatible models      The following iPod , iPod nano , iPod classic , iPod touch and iPhone devices can be used with this system. ● Made for • iPod touch (4th generation) •...
Page 241 3-2. Using the audio system NOTICE ■ Cord hook Do not secure items other than cords on the cord hook. Doing so may dam- age the cord hook. ■ To prevent damage to iPod ● Do not leave iPod in the vehicle. The temperature inside the vehicle may become high, resulting in damage to the iPod.
Page 242: Operating A Usb Memory
3-2. Using the audio system Operating a USB memory Connecting a USB memory enables you to enjoy music from the vehicle speakers. ■ Connecting a USB memory Open the cover and connect a STEP USB memory. Turn on the power of the USB memory if it is not turned on.
Page 243 3-2. Using the audio system Selecting a folder ■ Selecting folders one at a time To select the desired folder, press ) or ■ Selecting a folder and file from a folder list Press STEP The folder list will be displayed. Turn and press to select a folder and a file.
Page 244 3-2. Using the audio system Scanning files Press STEP The first 10 seconds of all files in the folder will be played. When the desired folder is reached, press again. STEP Fast-forwarding and reversing files To fast-forward or reverse, press and hold “ ∧ ” or “∨” on Random playback Pressing (RDM) changes modes in the following order:...
Page 245 3-2. Using the audio system ■ Cord hook →P. 237 ■ USB memory functions ● Depending on the USB memory that is connected to the system, the device itself may not be operable and certain functions may not be avail- able.
Page 246 3-2. Using the audio system ■ USB memory ● Compatible devices USB memory that can be used for MP3 and WMA playback ● Compatible device formats The following device formats can be used: • USB communication formats: USB2.0 FS (12 Mbps) •...
Page 247 3-2. Using the audio system ● MP3 file compatibility • Compatible standards MP3 (MPEG1 AUDIO LAYERIII, MPEG2 AUDIO LAYERIII, MPEG2.5) • Compatible sampling frequencies MPEG1 AUDIO LAYERII, III: 32, 44.1, 48 (kHz) MPEG2 AUDIO LAYERII, III: 16, 22.05, 24 (kHz) MPEG2.5: 8, 11.025, 12 (kHz) •...
Page 248 3-2. Using the audio system ● MP3 and WMA playback • When a device containing MP3 or WMA files is connected, all files in the USB memory are checked. Once the file check is finished, the first MP3 or WMA file is played. To make the file check finish more quickly, we recommend that you do not include any files other than MP3 or WMA files or create any unnecessary folders.
Page 249 3-2. Using the audio system NOTICE ■ Cord hook (→P. 240) ■ To prevent damage to USB memory ● Do not leave USB memory in the vehicle. The temperature inside the vehi- cle may become high, resulting in damage to the player. ●...
Page 250: Optimal Use Of The Audio System
3-2. Using the audio system Optimal use of the audio system Displays the current mode Changes the following set- tings • Sound quality and vol- ume balance (→P. 250) The sound quality and bal- ance setting changed to produce the best sound.
Page 251 3-2. Using the audio system Using the audio control function ■ Changing sound quality modes Press STEP Turn to select “Sound Setting”. STEP Press STEP Turn to select the desired mode. STEP “BASS”, “TREBLE”, “FADER”, “BALANCE”, or “ASL” Press STEP ■...
Page 252 3-2. Using the audio system ■ Adjusting the Automatic Sound Levelizer (ASL) When ASL is selected, turning to the right changes the amount of ASL in the order of “LOW”, “MID” and “HIGH”. Turning to the left turns ASL off. ASL automatically adjusts the volume and tone quality according to vehi- cle speed.
Page 253: Using The Aux Port
3-2. Using the audio system Using the AUX port This port can be used to connect a portable audio device and listen to it through the vehicle’s speakers. Open the cover and connect STEP the portable audio device. Press until “AUX” is displayed. STEP ■...
Page 254: Using The Steering Wheel Audio Switches
3-2. Using the audio system Using the steering wheel audio switches Some audio features can be controlled using the switches on the steering wheel. Operation may differ and usage may not be possible with audio/nav- igation systems that are not compatible with the steering switches in this vehicle.
Page 255 3-2. Using the audio system Adjusting the volume Press “+” on to increase the volume and “-” to decrease the vol- ume. Hold down “+” or “-” on to continue increasing or decreasing the vol- ume. Silencing a sound Press and hold To cancel, press and hold again.
Page 256 3-2. Using the audio system Selecting a folder or album (MP3 and WMA, USB memory and ® Bluetooth audio) ® Press to select CD, USB memory or Bluetooth audio STEP mode. Press and hold “∧” or “∨” on until you hear a beep. STEP CAUTION ■...
Page 257: Using The Bluetooth ® Audio System
® 3-3. Using the Bluetooth audio system ® Bluetooth audio/phone ® ■ Bluetooth audio ® The Bluetooth audio system enables you to enjoy music played on a portable digital audio player (portable player) from the vehi- cle speakers via wireless communication. ®...
Page 258 ® 3-3. Using the Bluetooth audio system ■ Conditions affecting operation ® The Bluetooth audio/phone may not operate normally in the following situa- tions: ® ● The portable player does not support Bluetooth ● The cellular phone is located outside the service area ®...
Page 259 ® 3-3. Using the Bluetooth audio system ■ Compatible models ® ● Bluetooth specifications: Ver. 1.1, or higher (recommended: Ver. 2.1 + EDR or higher) ● Following Profiles: • A2DP (Advanced Audio Distribution Profile) Ver. 1.0, or higher (recom- mended: Ver. 1.2 or higher) •...
Page 260 ® 3-3. Using the Bluetooth audio system ■ ® Certification for the Bluetooth audio system...
Page 261 ® 3-3. Using the Bluetooth audio system CAUTION ■ Caution while driving ● Do not use a cellular phone. ® ● Do not connect Bluetooth device or operate the controls. NOTICE ■ ® To prevent damage to Bluetooth device ® Do not leave Bluetooth device in the vehicle.
Page 262: Audio/Phone
® 3-3. Using the Bluetooth audio system ® Using the Bluetooth audio/phone ■ Audio unit ® Bluetooth connection con- dition If “BT” is not displayed, the ® Bluetooth audio/phone cannot be used. Display A message, name, number, etc. is displayed. Lower-case characters and special characters cannot be displayed.
Page 263 ® 3-3. Using the Bluetooth audio system ■ Steering wheel switches →P. 253 ■ Microphone...
Page 264 ® 3-3. Using the Bluetooth audio system ® Using the Bluetooth audio/phone for the first time ® Before using the Bluetooth audio/phone, it is necessary to register a ® Bluetooth device in the system. Follow the procedure below to reg- ister (pair) a device: Press and select “Bluetooth”...
Page 265: Bluetooth
® 3-3. Using the Bluetooth audio system ® Menu list of the Bluetooth audio/phone First menu Second menu Third menu Operation details Registering a “Pairing” ® Bluetooth device Listing the registered “List Phone” cellular phones Listing the registered “List Audio” portable players Changing the “Passkey”...
Page 266 ® 3-3. Using the Bluetooth audio system First menu Second menu Third menu Operation details “Add contacts” Adding a new number Registering a speed “Add SD” dial Deleting a number “Delete Call stored in the call his- History” “Phonebook” tory Deleting a number “Delete contacts”...
Page 267: Using The Bluetooth
® 3-3. Using the Bluetooth audio system ® Operating a Bluetooth enabled portable player Power Volume Playback/Pause Selecting items Random playback Selecting a track, Repeat play Playback fast-forwarding or Search playback reversing Selecting an album Displays text message Selecting an album Press ) or ) to select the desired album.
Page 268 ® 3-3. Using the Bluetooth audio system Scanning tracks Press STEP The first 10 seconds of all tracks in the album will be played. When the desired track is reached, press again. STEP Playing and pausing tracks Press ) to play or pause a track. Fast-forwarding and reversing tracks To fast-forward or reverse, press and hold “...
Page 269 ® 3-3. Using the Bluetooth audio system ® ■ Bluetooth audio system functions Depending on the portable player that is connected to the system, certain functions may not be available.
Page 270: Making A Phone Call
® 3-3. Using the Bluetooth audio system Making a phone call To enter the “PHONE” mode, press the off-hook switch. ■ Making a phone call ● Dialing by selecting a name ● Speed dialing ● Dialing by entering the number ●...
Page 271 ® 3-3. Using the Bluetooth audio system Dialing by selecting a name Select “Phonebook” using STEP Select the desired name using and press the off-hook STEP switch. By pressing (Add S. Dial) and then one of the speed dial but- tons (from ) while the desired name is selected, it can be registered as a speed dial.
Page 272 ® 3-3. Using the Bluetooth audio system Dialing from call histories Select “All calls”, “Missed calls”, “Incoming calls” or “Outgoing STEP calls” using Select the desired number using and press the off- STEP hook switch. The following operations can be performed: ●...
Page 273 ® 3-3. Using the Bluetooth audio system Operations during a call ● Transferring a call A call can be transferred between the cellular phone and system while dialing, receiving a call, or during a call. Use one of the fol- lowing methods: a.
Page 274 ® 3-3. Using the Bluetooth audio system Adjusting the ringtone volume when receiving a call Change the ringtone volume using To decrease the volume: Turn counterclockwise. To increase the volume: Turn clockwise. ■ When talking on the phone ● Do not talk simultaneously with the other party. ●...
Page 275: Using The "Set Up" Menu ("Bluetooth" Menu)
® 3-3. Using the Bluetooth audio system Using the “SET UP” menu (“Bluetooth” menu) ® Registering a Bluetooth device in the system allows the system to function. The following functions can be used for registered devices: ■ Functions and operation procedures Press and select “Bluetooth”...
Page 276 ® 3-3. Using the Bluetooth audio system Registering a portable player Select “Pairing” using , and perform the procedure for register- ing a portable player. (→P. 263) Listing the registered cellular phones Select “List Phone” using . The list of registered cellular phones will be displayed.
Page 277 ® 3-3. Using the Bluetooth audio system Listing the registered portable players Select “List Audio” using . The list of registered portable play- ers will be displayed. ● Connecting the registered portable player to the audio system Select the name of the portable player to be connected STEP using Select “Select”...
Page 278 ® 3-3. Using the Bluetooth audio system Changing the passkey Select “Passkey” using STEP Select a 4 to 8-digit passkey using STEP Input the number 1 digit at a time. When the entire number to be registered as a passkey has STEP been input, press again.
Page 279 ® 3-3. Using the Bluetooth audio system Displaying the device status Select “Bluetooth info” using ● Displaying the device name Select “Device Name” using ● Displaying the device address Select “Device Address” using Setting the automatic connection confirmation display to on or off If the “Display Setting”...
Page 280 ® 3-3. Using the Bluetooth audio system Initialization Select “Initialize” using ● Initializing the sound settings Select “Sound Setting” using and press (YES). For details about sound settings: →P. 280 ● Initializing the device information Select “Car Device Info” using and press (YES).
Page 281: Using The "Set Up" Menu ("Phone" Menu)
® 3-3. Using the Bluetooth audio system Using the “SET UP” menu (“Phone” menu) ■ Functions and operation procedures To enter the menu of each function, press and follow the steps below using ● Adding a new phone number 1. “Phone” → 2. “Phonebook” → 3. “Add contacts” ●...
Page 282 ® 3-3. Using the Bluetooth audio system Adding a new phone number Select “Add contacts” using ● Transferring all contacts from the cellular phone Select “Overwrite all contacts” using and press (YES). ● Transferring one contact from the cellular phone Select “Add one contact”...
Page 283 ® 3-3. Using the Bluetooth audio system Deleting call histories Select “Delete Call History” using ● Deleting outgoing call history Select “Outgoing Calls” using STEP Select the desired phone number using and press STEP (YES). To delete all outgoing call history data, press (ALL) and then press (YES).
Page 284 ® 3-3. Using the Bluetooth audio system ● Deleting missed call history Select “Missed Calls” using STEP Select the desired phone number using and press STEP (YES). To delete all missed call history data, press (ALL) and then press (YES). ●...
Page 285 ® 3-3. Using the Bluetooth audio system Deleting a registered phone number Select “Delete contacts” using STEP Select the desired phone number using and press STEP (YES). To delete all of the registered phone numbers, select “All delete” using and press (YES).
Page 286 ® 3-3. Using the Bluetooth audio system Setting ringtone volume Select “Ringtone Volume” using STEP Change the ringtone volume. STEP To decrease the volume: Turn counterclockwise. To increase the volume: Turn clockwise. Setting ringtone Select “Ringtone” using STEP Using , select a ringtone (1 - 3). To set the selected STEP ringtone, press Transferring call histories...
Page 287 ® 3-3. Using the Bluetooth audio system ■ Phone number Up to 1000 names can be stored. ■ Call history Up to 10 numbers can be stored in each of the outgoing, incoming and missed call history memories. ■ Limitation of number of digits A phone number that exceeds 24 digits cannot be registered.
Page 288: Using The Interior Lights
3-4. Using the interior lights Interior lights list Interior lights/personal lights (→P. 288) Luggage compartment light...
Page 289: Interior Lights/Personal Lights
“POWER” switch is off, the lights will go off automatically after 20 minutes. ■ Customization that can be configured at Toyota dealer Settings (e.g. the time elapsed before lights turn off) can be changed. (Customizable features →P. 445)
Page 290 3-4. Using the interior lights Interior lights/personal lights NOTICE ■ To prevent 12-volt battery discharge Do not leave the lights on longer than necessary when the hybrid system is off.
Page 291: Using The Storage Features List Of Storage Features
3-5. Using the storage features List of storage features Glove box Auxiliary boxes Bottle holders Console box Cup holders CAUTION ■ Items that should not be left in the storage spaces Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause the following when cabin temperature becomes high: ●...
Page 292: Glove Box
3-5. Using the storage features Glove box and console box Glove box Pull up the lever to open the glove box. CAUTION ■ Caution while driving Keep the glove box closed. In the event of sudden braking, an accident may occur due to an occupant being struck by the open glove box or the items stored inside.
Page 293 3-5. Using the storage features Console box Remove the lid at the bottom of the console box. Small items can be stored in this space. ■ When using the console box lid as an armrest The lid can be slid forward or backwards. CAUTION ■...
Page 294: Auxiliary Boxes
3-5. Using the storage features Auxiliary boxes Auxiliary boxes Type A Type B Type C...
Page 295 3-5. Using the storage features Auxiliary boxes Type D CAUTION ■ Items unsuitable for the box Do not place items that easily roll over or extend past the box’s rim. The items may be thrown out of the tray, causing an accident.
Page 296: Cup Holders
3-5. Using the storage features Cup holders Cup holders Front Rear Pull down the cup holder lid. CAUTION ■ Items unsuitable for the cup holder Do not place anything other than cups or beverage cans in the cup holders. Items in the cup holders may be thrown out of the holders in the event of an accident or sudden braking, causing injury.
Page 297: Bottle Holders
3-5. Using the storage features Bottle holders Bottle holders ■ When using the bottle holder ● When storing a bottle, close the cap. ● The bottle may not be stored depending on its size or shape. CAUTION ■ Items unsuitable for the bottle holder Do not place anything other than a bottle in the bottle holders.
Page 298: Other Interior Features Sun Visors
3-6. Other interior features Sun visors To set the visor in the for- ward position, flip it down. To set the visor in the side position, flip down, unhook, and swing it to the side.
Page 299: Vanity Mirrors
3-6. Other interior features Vanity mirrors Slide the cover to open.
Page 300: Outside Temperature Display
When the vehicle is stopped, or moving at low speeds (less than 25 km/h [16 mph]) ● When the outside temperature has changed suddenly (at the entrance/ exit of a garage, tunnel, etc.) When “− −” or “E” is displayed ■ The system may be malfunctioning. Take your vehicle to your Toyota dealer.
Page 301: Power Outlet
3-6. Other interior features Power outlet The power outlet can be used for 12 V accessories that run on less than 10 A. ■ The power outlet can be used when The “POWER” switch is in ACCESSORY or ON mode. NOTICE ■...
Page 302: Floor Mat
3-6. Other interior features Floor mat Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet. Insert the retaining hooks STEP (clips) into the floor mat eye- lets.
Page 303 When installing the driver's floor mat ● Do not use floor mats designed for other models or different model year vehicles, even if they are Toyota Genuine floor mats. ● Only use floor mats designed for the driver's seat. ●...
Page 304: Luggage Compartment Features
3-6. Other interior features Luggage compartment features ■ Auxiliary box ■ Removing the luggage cover Unhook the cords. STEP Push the luggage cover for- STEP ward disengage anchors.
Page 305 3-6. Other interior features Remove the luggage cover. STEP ■ Installing the luggage cover Place the luggage cover on STEP the anchors. Push the luggage cover until a STEP click sound is heard. Hook the cords. STEP...
Page 306: Maintenance And Care
Maintenance and care 4-1. Maintenance and care Cleaning and protecting the vehicle exterior ..306 Cleaning and protecting the vehicle interior ..309 4-2. Maintenance Maintenance requirements....312 4-3. Do-it-yourself maintenance Do-it-yourself service precautions ..... 315 Hood ......... 319 Positioning a floor jack..321 Engine compartment..
Page 307: Maintenance And Care Cleaning And Protecting The Vehicle Exterior
4-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition: ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 308 4-1. Maintenance and care ■ Touch-up paint (if equipped) Touch-up paint may be used to cover small chips or scratches. Apply the paint soon after the damage occurs or corrosion may set in. To apply the touch-up paint so it is hardly noticeable, the trick is to apply it only to the bare spots.
Page 309 4-1. Maintenance and care NOTICE ■ To prevent paint deterioration and corrosion on the body and compo- nents (aluminum wheels etc.) ● Wash the vehicle immediately in the following cases: • After driving near the sea coast • After driving on salted roads •...
Page 310: Cleaning And Protecting The Vehicle Interior
4-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle's interior and keep it in top condition: ■ Protecting the vehicle interior Remove dirt and dust using a vacuum cleaner. Wipe dirty sur- faces with a cloth dampened with lukewarm water.
Page 311 4-1. Maintenance and care ■ Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle's interior. ■ Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
Page 312 4-1. Maintenance and care NOTICE ■ Cleaning detergents ● Do not use the following types of detergent, as they may discolor the vehi- cle interior or cause streaks or damage to painted surfaces: • Non-seat portions: Organic substances such as benzene or gasoline, alkaline or acidic solutions, dye, and bleach •...
Page 313: Maintenance
These are best performed by qualified technicians. Even if you are an experienced do-it-yourself mechanic, we recommend that repairs and maintenance be conducted by your Toyota dealer who will keep a record of maintenance on your vehicle. This record could be...
Page 314 4-2. Maintenance ■ Where to go for service? It makes good sense to take your vehicle to your local Toyota dealer for ser- vice. Toyota technicians are well-trained specialists receiving the latest service information through technical bulletins, service tips, and in-dealership train- ing programs.
Page 315: Maintenance
4-2. Maintenance CAUTION ■ If your vehicle is not properly maintained Improper maintenance could result in serious damage to the vehicle and possible serious injury or death. ■ Handling of the 12-volt battery 12-volt battery posts, terminals and related accessories contain lead and lead compounds which are known to cause brain damage.
Page 316: Do-It-Yourself Maintenance
Parts and tools • Grease 12-volt battery condition (→P. 332) • Conventional wrench (for terminal clamp bolts) • “Toyota Super Long Life Coolant” or a similar high quality ethylene glycol based non-silicate, non- amine, non-nitrite and non-borate coolant with long-life hybrid...
Page 317 4-3. Do-it-yourself maintenance Items Parts and tools • Bulb with same number and watt- age rating as original Light bulbs (→P. 359) • Phillips-head screwdriver • Flathead screwdriver • Wrench Radiator and condenser  (→P. 330) • Tire pressure gauge Tire inflation pressure (→P.
Page 318 4-3. Do-it-yourself maintenance CAUTION The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury, observe the following precautions: ■ When working on the engine compartment ● Make sure that the indicator on the “POWER”...
Page 319 4-3. Do-it-yourself maintenance NOTICE ■ If you remove the air cleaner filter Driving with the air cleaner filter removed may cause excessive engine wear due to dirt in the air. Also, a backfire could cause a fire in the engine com- partment.
Page 320: Hood
4-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood release lever. STEP The hood will pop up slightly. Pull up the auxiliary catch STEP lever and lift the hood. Hold the hood open by insert- STEP ing the supporting rod into the...
Page 321 4-3. Do-it-yourself maintenance CAUTION ■ Pre-driving check Check that the hood is fully closed and locked. If the hood is not locked properly, it may open while the vehicle is in motion and cause an accident, which may result in death or serious injury. ■...
Page 322: Positioning A Floor Jack
4-3. Do-it-yourself maintenance Positioning a floor jack When raising your vehicle with a floor jack, position the jack cor- rectly. Improper placement may damage your vehicle or cause injury. Front Rear...
Page 323 4-3. Do-it-yourself maintenance CAUTION ■ When raising your vehicle Make sure to observe the following precautions to reduce the possibility of death or serious injury: ● Lift up the vehicle using a floor jack such as the one shown in the illustra- tion.
Page 324: Engine Compartment
4-3. Do-it-yourself maintenance Engine compartment Fuse boxes (→P. 348) Engine/power control unit coolant radiator (→P. 330) Engine oil filler cap (→P. 325) Electric cooling fan Engine coolant radiator cap Condenser (→P. 330) Power control unit coolant Engine oil level dipstick reservoir (→P.
Page 325 4-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. ■ Checking the engine oil Park the vehicle on level ground. After warming up the engine STEP and turning off the hybrid system, wait more than 5 minutes for the oil to drain back into the bottom of the engine.
Page 326 4-3. Do-it-yourself maintenance ■ Adding engine oil If the oil level is below or near the low level mark, add engine oil of the same type as that already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
Page 327 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal.
Page 328 4-3. Do-it-yourself maintenance NOTICE ■ To prevent serious engine damage Check the oil level on a regular basis. ■ When replacing the engine oil ● Be careful not to spill engine oil on the vehicle components. ● Avoid overfilling, or the engine could be damaged. ●...
Page 329 4-3. Do-it-yourself maintenance Coolant Engine coolant reservoir The coolant level is satisfactory if it is between the “FULL” and “LOW” lines on the reservoir when the engine is cold. Reservoir cap “FULL” line “LOW” line If the level is on or below the “LOW”...
Page 330 If the coolant level drops within a short time of replenishing Visually check the radiators, hoses, engine/power control unit coolant reser- voir caps, drain cock and water pump. If you cannot find a leak, have your Toyota dealer test the cap and check for leaks in the cooling systems. CAUTION ■...
Page 331 Check the radiator and condenser and clear away any foreign objects. If either of the above parts is extremely dirty or you are not sure of their condition, have your vehicle inspected by your Toyota dealer. CAUTION ■ When the hybrid system is hot Do not touch the radiators or condenser as they may be hot and cause seri- ous injuries, such as burns.
Page 332 4-3. Do-it-yourself maintenance NOTICE ■ Do not use any fluid other than washer fluid Do not use soapy water or engine antifreeze instead of washer fluid. Doing so may cause streaking on the vehicle’s painted surfaces. ■ Diluting washer fluid Dilute washer fluid with water as necessary.
Page 333: 12-Volt Battery
4-3. Do-it-yourself maintenance 12-volt battery ■ Location The 12-volt battery is located under the rear right seat. ■ Removing the 12-volt battery cover Remove the 12-volt battery cover after removing the clips.
Page 334 4-3. Do-it-yourself maintenance ■ Exterior Make sure that the 12-volt battery terminals are not corroded and that there are no loose connections, cracks, or loose clamps. Terminals Hold-down clamp ■ Installing the 12-volt battery cover Install the 12-volt battery cover with the clips.
Page 335 12-volt battery. Take extra care when connecting the 12-volt battery if the “POWER” switch mode prior to discharge is unknown. If the system will not start even after multiple attempts, contact your Toyota dealer.
Page 336 4-3. Do-it-yourself maintenance CAUTION ■ Chemicals in the 12-volt battery The 12-volt battery contains poisonous and corrosive sulfuric acid and may produce hydrogen gas which is flammable and explosive. To reduce the risk of death or serious injury, take the following precautions while working on or near the 12-volt battery: ●...
Page 337 Use a 12-volt battery designed for this vehicle. Failure to do so may cause gas (hydrogen) to enter the passenger compartment, causing a fire or explo- sion. For replacement of the 12-volt battery, contact your Toyota dealer. NOTICE ■ When recharging the 12-volt battery Never recharge the 12-volt battery while the hybrid system is operating.
Page 338: Tires
Vehicles with a spare tire of a different wheel type from the installed tires Rotate the tires in the order shown. To equalize tire wear and help extend tire life, Toyota recom- mends that tire rotation is car- Front ried out approximately every 10000 km (6000 miles).
Page 339 ● A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage If you are not sure, consult with your Toyota dealer. ■ Tire life Any tire over 6 years old must be checked by a qualified technician even if it has seldom or never been used or damage is not obvious.
Page 340 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear. ● Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
Page 341: Tire Inflation Pressure
Reduced driving comfort and tire life ● Reduced safety ● Damage to the drive train If a tire needs frequent inflating, have it checked by your Toyota dealer. ■ Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: ●...
Page 342 4-3. Do-it-yourself maintenance CAUTION ■ Proper inflation is critical to save tire performance Keep your tires properly inflated. Otherwise, the following conditions may occur and result in an accident causing death or serious injury: ● Excessive wear ● Uneven wear ●...
Page 343: Wheels
● Bent wheels that have been straightened ■ Aluminum wheel precautions (if equipped) ● Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1600 km (1000 miles).
Page 344 4-3. Do-it-yourself maintenance CAUTION ■ When replacing wheels ● Do not use wheels that are a different size from those recommended in the Owner’s Manual, as this may result in a loss of handling control. ● Never use an inner tube in a leaking wheel which is designed for a tube- less tire.
Page 345: Air Conditioning Filter
4-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be changed regularly to maintain air conditioning efficiency. ■ Removal method Turn the “POWER” switch off. STEP Open the glove box. Slide off STEP the damper. Disconnect the upper claws STEP one at a time by pushing in the respective side of the glove...
Page 346 4-3. Do-it-yourself maintenance Remove the filter cover. STEP Remove the air conditioning STEP filter and replace it with a new one. The “↑UP” mark shown on the filter should be pointing up. ■ Checking interval Inspect and replace the air conditioning filter according to the maintenance schedule.
Page 347: Electronic Key Battery
4-3. Do-it-yourself maintenance Electronic key battery Replace the battery with a new one if it is depleted. ■ You will need the following items: ● Flathead screwdriver ● Small flathead screwdriver ● Lithium battery CR1632 ■ Replacing the battery Take out the mechanical key. STEP Remove the cover.
Page 348 4-3. Do-it-yourself maintenance ■ Use a CR1632 lithium battery ● Batteries can be purchased at your Toyota dealer, local electrical appli- ance shops or camera stores. ● Replace only with the same or equivalent type recommended by the manufacturer. ●...
Page 349: Checking And Replacing Fuses
4-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as necessary. Turn the “POWER” switch off. STEP Open the fuse box cover. STEP Engine compartment (type A fuse box) Push the tab in and lift the lid...
Page 350 4-3. Do-it-yourself maintenance Under the instrument panel Remove the lid. After a system failure, see “Fuse layout and amperage rat- STEP ings” (→P. 352) for details about which fuse to check. Remove the fuse with the pull-out tool. STEP Only type A fuse can be removed using the pullout tool.
Page 351 4-3. Do-it-yourself maintenance Check if the fuse is blown. STEP Type A Normal fuse Blown fuse Replace the blown fuse with a new fuse of an appropriate amperage rating. The amper- age rating can be found on the fuse box lid. Type B Normal fuse Blown fuse...
Page 352 Type D Normal fuse Blown fuse Replace the blown fuse with a new fuse of an appropriate amperage rating. The amper- age rating can be found on the fuse box lid. Type E Normal fuse Blown fuse Contact your Toyota dealer.
Page 353 4-3. Do-it-yourself maintenance Fuse layout and amperage ratings Engine compartment (type A fuse box) Fuse Ampere Circuit Multiport fuel injection system/ EFI-MAIN 20 A sequential multiport fuel injection system, EFI NO.2 HORN 10 A Horn 30 A IG2 NO.2, METER, IGN SPARE 7.5 A Spare fuse...
Page 354 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Multiport fuel injection system/ sequential multiport fuel injection IG2 NO.2 10 A system, steering switches, brake system, starter system, smart entry & start system, SRS airbag system Audio system, vehicle control and operation data recording, main DOME 15 A body ECU, personal lights, luggage...
Page 355 4-3. Do-it-yourself maintenance Fuse Ampere Circuit STRG LOCK 20 A Starter system ABS NO.2 10 A Brake system IGCT NO.2, IGCT NO.3, IGCT IGCT-MAIN 30 A NO.4, PCU, BATT FAN D/C CUT 30 A DOME, ECU-B NO.1 PTC HTR 30 A No circuit NO.1 PTC HTR...
Page 356 4-3. Do-it-yourself maintenance Engine compartment (type B fuse box) Fuse Ampere Circuit DC/DC 100 A Hybrid system ABS MTR 30 A Brake system NO.2 40 A Air conditioning system 50 A Electric power steering system...
Page 357 4-3. Do-it-yourself maintenance Under the instrument panel Fuse Ampere Circuit Front position lights, tail lights, license plate lights, headlight TAIL 10 A leveling system, front fog lights, gauge and meters PANEL Instrument panel lights DOOR R/R 20 A Rear power window (right side) DOOR P 20 A Front power window (left side)
Page 358 (→P. 359) ● If the replaced fuse blows again, have the vehicle inspected by your Toyota dealer. ■ If there is an overload in a circuit The fuses are designed to blow, protecting the wiring harness from damage.
Page 359 Never use a fuse of a higher amperage rating than that indicated, or use any other object in place of a fuse. ● Always use a genuine Toyota fuse or equivalent. Never replace a fuse with a wire, even as a temporary fix. This can cause extensive damage or even fire.
Page 360: Light Bulbs
You may replace the following bulbs by yourself. The difficulty level of replacement varies depending on the bulb. As there is a danger that components may be damaged, we recommend that replacement is carried out by your Toyota dealer. ■ Preparing for light bulb replacement Check the wattage of the light bulb to be replaced.
Page 361 4-3. Do-it-yourself maintenance ■ Rear bulb locations Rear turn signal lights Tail lights License plate lights Back-up lights...
Page 362 4-3. Do-it-yourself maintenance Replacing light bulbs ■ Headlights (vehicles with halogen headlights) Turn the bulb base counterclock- STEP wise. High beam (inside) Low beam (outside) Unplug connector while STEP pushing the lock release. High beam Low beam...
Page 363 4-3. Do-it-yourself maintenance Replace the light bulb, and install STEP the bulb base. Align the 3 tabs on the light bulb with the mounting, and insert. Turn and secure the bulb base. STEP Shake the bulb base gently to check that it is not loose, turn the headlight high beams and head- light low beams on once and visu- ally confirm that no light is leaking...
Page 364 4-3. Do-it-yourself maintenance Unplug connector while STEP pushing the lock release. Replace the light bulb, and install STEP the bulb base. Align the 3 tabs on the light bulb with the mounting, and insert. Turn and secure the bulb base. STEP Shake the bulb base gently to check that it is not loose, turn the...
Page 365 4-3. Do-it-yourself maintenance ■ Front fog lights Turn the steering wheel in the STEP opposite direction of the light to be replaced. Turn the steering wheel to a point that allows your hand to easily fit between the tire and fender liner. Partly remove the fender liner.
Page 366 4-3. Do-it-yourself maintenance Install a new bulb. STEP Align the 3 tabs on the light bulb with the mounting, and insert. Turn and secure the bulb. Install STEP the connector. Shake the bulb base gently to check that it is not loose, turn the front fog light on once and visu- ally confirm that no light is leaking through the mounting.
Page 367 4-3. Do-it-yourself maintenance ■ Front position lights Unplug connector while STEP pushing the lock release. Turn the bulb base counterclock- STEP wise. Remove the light bulb. STEP When installing, reverse the steps listed. STEP...
Page 368 4-3. Do-it-yourself maintenance ■ Front turn signal lights Partly remove the fender liner as described in STEP STEP STEP of “Front fog lights”. (→P. 364) STEP STEP Turn the bulb base counterclock- STEP wise. Remove the light bulb. STEP When installing, reverse the steps listed. STEP...
Page 369 4-3. Do-it-yourself maintenance ■ Rear turn signal lights, tail lights and back-up lights Open the back door and remove STEP the bolts. Pull the lamp assembly straight back to disengage the clip and 2 pins. Where the clip attaches Turn the bulb base counterclock- STEP wise.
Page 370 STEP ■ Lights other than the above If any of the lights listed below has burnt out, have it replaced by your Toyota dealer. ● Headlight low beam (vehicles with LED headlights) ● Side turn signal lights ● Stop lights...
Page 371 The headlight low beam (vehicles with LED headlights), stop lights and high mounted stoplight consist of a number of LEDs. If any of the LEDs burn out, take your vehicle to your Toyota dealer to have the light replaced. ■...
Page 372 When trouble arises 5-1. Essential information Emergency flashers ..372 If your vehicle needs to be towed ......373 If you think something is wrong......378 5-2. Steps to take in an emergency If a warning light turns on or a warning buzzer sounds ......
Page 373: Essential Information
5-1. Essential information Emergency flashers The emergency flashers are used to warn other drivers when the vehicle has to be stopped in the road due to a breakdown, etc. Press the switch. All the turn signal lights will flash. To turn them off, press the switch once again.
Page 374: If Your Vehicle Needs To Be Towed
If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or a commercial towing service, using a lift-type truck or flatbed truck. Use a safety chain system for all towing, and abide by all state/pro- vincial and local laws.
Page 375 5-1. Essential information Installing towing eyelet Push the eyelet cover and then STEP open it. Insert the towing eyelet into the STEP hole and tighten partially by hand. Tighten down the towing eyelet STEP securely using a wheel nut wrench.
Page 376 5-1. Essential information Towing with a sling-type truck Do not tow with a sling-type truck to prevent body damage. Towing with a wheel-lift type truck From the front Release the parking brake. From the rear Use a towing dolly under the front wheels.
Page 377 5-1. Essential information Using a flatbed truck If you use chains or cables to tie down your vehicle, the angles shaded in black must be 45°. Do not overly tighten the tie downs or the vehicle may be damaged. ■ Before emergency towing Turn the “POWER”...
Page 378 5-1. Essential information CAUTION ■ Caution while towing ● Use extreme caution when towing the vehicle. Avoid sudden starts or erratic driving maneuvers which place excessive stress on the emergency towing eyelet and the cables or chains. Always be cautious of the surroundings and other vehicles while towing. ●...
Page 379: If You Think Something Is Wrong
5-1. Essential information If you think something is wrong If you notice any of the following symptoms, your vehicle probably needs adjustment or repair. Contact your Toyota dealer as soon as possible. ■ Visible symptoms ● Fluid leaks under the vehicle (Water dripping from the air conditioning after use is normal.)
Page 380: Steps To Take In An Emergency
If a light comes on or flashes, but then goes off, this does not necessarily indicate a malfunction in the system. However, if this continues to occur, have the vehicle inspected by your Toyota dealer. Stop the vehicle immediately. Continuing to drive the vehicle may be dangerous.
Page 381 Stop the vehicle immediately. The following warning indicates the possibility of damage to the vehi- cle that may lead to an accident. Immediately stop the vehicle in a safe place and contact your Toyota dealer. Warning light Warning light/Details Charging system warning light...
Page 382 5-2. Steps to take in an emergency Have the vehicle inspected by your Toyota dealer immediately. Failure to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident. Have the vehicle inspected by your Toyota dealer immediately.
Page 383 5-2. Steps to take in an emergency Follow the correction procedures. After taking the specified steps to correct the suspected problem, check that the warning light goes off. Warning light Warning light/Details Correction procedure Low fuel level warning light Remaining fuel is low When the remaining fuel is approximately 4.7 L (1.2 Refuel the vehicle.
Page 384 5-2. Steps to take in an emergency ■ Front passenger detection sensor, passenger seat belt reminder and warning buzzer ● If luggage is placed on the front passenger seat, the front passenger detection sensor may cause the warning light to flash and the warning buzzer to sound even if a passenger is not sitting in the seat.
Page 385: If A Warning Message Is Displayed
Multi-information display Warning message details and/ or correction procedures are shown on the multi-informa- tion display. If any of the warning lights comes on again after the following actions have been performed, contact your Toyota dealer.
Page 386 Stop the vehicle immediately. The following warning indicates the possibility of damage to the vehi- cle that may lead to an accident. Immediately stop the vehicle in a safe place and contact your Toyota dealer. Warning message Details Indicates a malfunction in the hybrid system A buzzer sounds in accordance with the warning message that is displayed.
Page 387 A buzzer sounds and a warning message is shown on the multi-infor- mation display. Failure to investigate the cause of the following warn- ings may lead to the system operating abnormally and possibly cause an accident. Have the vehicle inspected by your Toyota dealer immediately. Warning message Details •...
Page 388 5-2. Steps to take in an emergency Warning message Details Indicates a malfunction in the cruise control system A buzzer also sounds.
Page 389 5-2. Steps to take in an emergency Follow the correction procedures. A buzzer sounds and a warning message is shown on the multi-infor- mation display. After taking the specified steps to correct the sus- pected problem, check that the warning message goes off. Warning message Details Correction procedure...
Page 390 5-2. Steps to take in an emergency Warning message Details Correction procedure Indicates that the parking brake is still engaged If the vehicle reaches a speed of 5 km/h (3 Release the parking mph), flashes brake. and a buzzer sounds (red) to indicate that the parking brake is still...
Page 391 5-2. Steps to take in an emergency Warning message Details Correction procedure Indicates that the hybrid battery (trac- tion battery) power Shift the shift lever to P has dropped because and restart the hybrid a long period of time system when starting has elapsed after the vehicle.
Page 392 5-2. Steps to take in an emergency Warning message Details Correction procedure Indicates that the EV drive mode is not available A buzzer also sounds. The reason the EV drive mode is not available (the vehicle Use the EV drive mode is idling, battery when it becomes avail- charge is low, speed is...
Page 393 5-2. Steps to take in an emergency Have the malfunction repaired immediately. After taking the specified steps to correct the suspected problem, check that the warning message and light go off. Interior Exterior Correction Warning message Details buzzer buzzer procedure The electronic key is not Start the hybrid...
Page 394 5-2. Steps to take in an emergency Correction Interior Exterior Warning message Details buzzer buzzer procedure The electronic key was carried outside the vehicle and the Turn the driver’s door “POWER” was opened switch off or and closed bring the elec- while the shift tronic key back lever was in P...
Page 395 5-2. Steps to take in an emergency Correction Interior Exterior Warning message Details buzzer buzzer procedure An attempt was made to lock the doors using the entry func- Turn the tion after the “POWER” Continuous electronic key switch off and Once (For 5 seconds) was carried out-...
Page 396 5-2. Steps to take in an emergency Correction Interior Exterior Warning message Details buzzer buzzer procedure The driver’s door was opened while a shift lever posi- tion other than Shift the shift  Continuous P was selected lever to P. without turning (Flashes) off the...
Page 397 5-2. Steps to take in an emergency Correction Interior Exterior Warning message Details buzzer buzzer procedure An attempt was made to lock the doors using the smart entry & start system while the elec- tronic key was still inside the vehicle.
Page 398 5-2. Steps to take in an emergency Correction Interior Exterior Warning message Details buzzer buzzer procedure • The electronic key could not be detected when the “POWER” switch was pressed after the doors were Touch the elec- unlocked with tronic key to the the mechanical “POWER”...
Page 399 5-2. Steps to take in an emergency Correction Interior Exterior Warning message Details buzzer buzzer procedure Replace the The electronic electronic key  key has a low Once battery. battery. (→P. 346) The driver's door was opened and closed with the “POWER”...
Page 400 5-2. Steps to take in an emergency Correction Interior Exterior Warning message Details buzzer buzzer procedure The steering Press the lock could not “POWER” be released switch while within 3 sec- depressing the  Once onds of the brake pedal and “POWER”...
Page 401: If You Have A Flat Tire
5-2. Steps to take in an emergency If you have a flat tire Remove the flat tire and replace it with the spare tire provided. ■ Before jacking up the vehicle ● Stop the vehicle on a hard, flat surface. ●...
Page 402 5-2. Steps to take in an emergency Taking out the jack Move the front left seat to the STEP front most position. Push the tabs in and remove the STEP cover by pulling it towards you. For tightening STEP For loosening...
Page 403 5-2. Steps to take in an emergency Taking out the spare tire Remove the deck board. STEP Loosen the center fastener that STEP secures the spare tire.
Page 404 5-2. Steps to take in an emergency Replacing a flat tire Chock the tires. STEP Wheel chock Flat tire positions Behind the Left- rear right- hand hand side side tire Front Behind the Right- rear left- hand hand side side tire In front of Left-...
Page 405 5-2. Steps to take in an emergency Slightly loosen the wheel nuts STEP (one turn). Turn the tire jack portion “A” by STEP hand until the notch of the jack is in contact with the jack point. Raise the vehicle until the tire is STEP slightly raised off the ground.
Page 406 5-2. Steps to take in an emergency Installing the tire Remove any dirt or foreign mat- STEP ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, causing the tire to come off.
Page 407 5-2. Steps to take in an emergency When replacing an aluminum Disc wheel wheel with an aluminum wheel, turn the wheel nuts until the washers come into contact with the disc wheel. Washer Lower the vehicle. STEP Firmly tighten each wheel nut STEP two or three times in the order shown in the illustration.
Page 408 5-2. Steps to take in an emergency ■ The compact spare tire (if equipped) ● The compact spare tire is identified by the label “TEMPORARY USE ONLY” on the tire sidewall. Use the compact spare tire temporarily, and only in an emergency. ●...
Page 409 5-2. Steps to take in an emergency CAUTION ■ When using the compact spare tire (if equipped) ● Remember that the compact spare tire provided is specifically designed for use with your vehicle. Do not use your compact spare tire on another vehicle.
Page 410 5-2. Steps to take in an emergency CAUTION ■ Using the tire jack Improper use of the tire jack may cause the vehicle to suddenly fall off the jack, leading to death or serious injury. ● Do not use the tire jack for any purpose other than replacing tires or install- ing and removing tire chains.
Page 411 • If there are any cracks or deformations in the bolt screws, nut threads or bolt holes of the wheel, have the vehicle inspected by your Toyota dealer. • When installing the wheel nuts, be sure to install them with the tapered...
Page 412 5-2. Steps to take in an emergency NOTICE ■ Do not drive the vehicle with a flat tire. Do not continue driving with a flat tire. Driving even a short distance with a flat tire can damage the tire and the wheel beyond repair.
Page 413: If The Hybrid System Will Not Start
5-2. Steps to take in an emergency If the hybrid system will not start Reasons for the hybrid system not starting vary depending on the situation. Check the following and perform the appropriate proce- dure: ■ The hybrid system will not start even though the correct starting procedure is being followed.
Page 414 ● One or both of the 12-volt battery terminals may be discon- nected. ● The 12-volt battery may be discharged. (→P. 418) Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. Emergency start function...
Page 415: If The Shift Lever Cannot Be Shifted From P
(a system to pre- vent accidental operation of the shift lever). Have the vehicle inspected by your Toyota dealer immediately. The following steps may be used as an emergency measure to ensure that the shift lever can be shifted: Set the parking brake.
Page 416: If You Lose Your Keys
5-2. Steps to take in an emergency If you lose your keys New genuine Toyota keys can be made by your Toyota dealer using the other key and the key number stamped on your key number plate.
Page 417: If The Electronic Key Does Not Operate Properly
5-2. Steps to take in an emergency If the electronic key does not operate properly If communication between the electronic key and vehicle is inter- rupted (→P. 50) or the electronic key cannot be used because the battery is depleted, the smart entry & start system and wireless remote control cannot be used.
Page 418 5-2. Steps to take in an emergency Starting the hybrid system Ensure that the shift lever is in P and depress the brake pedal. STEP Touch the Toyota emblem side of STEP electronic “POWER” switch. When electronic detected, a buzzer sounds and the “POWER”...
Page 419: If The Vehicle 12-Volt Battery Is Discharged
The following procedures may be used to start the hybrid system if the vehicle’s 12-volt battery is discharged. You can also call your Toyota dealer or a qualified repair shop. If you have a set of jumper (or booster) cables and a second vehi- cle with a 12-volt battery, you can jump start your vehicle by follow- ing the steps below.
Page 420 ON mode. Make sure the “READY” indicator comes on. If the indicator STEP does not come on, contact your Toyota dealer. Once the hybrid system has started, remove the jumper STEP cables in the exact reverse order from which they were con- nected.
Page 421 5-2. Steps to take in an emergency ■ Starting the hybrid system when the 12-volt battery is discharged The hybrid system cannot be started by push-starting. ■ To prevent 12-volt battery discharge ● Turn off the headlights and the audio system while the hybrid system is off.
Page 422 12-volt battery. ■ After recharging the 12-volt battery Have the 12-volt battery inspected at your Toyota dealer as soon as possi- ble. If the 12-volt battery is deteriorating, continued use may cause the 12-volt battery to emit a malodorous gas, which may be detrimental to the health of passengers.
Page 423 5-2. Steps to take in an emergency CAUTION ■ 12-volt battery precautions The 12-volt battery contains poisonous and corrosive acidic electrolyte, while related parts contain lead and lead compounds. Observe the following precautions when handling the 12-volt battery: ● When working with the 12-volt battery, always wear safety glasses and take care not to allow any battery fluids (acid) to come into contact with skin, clothing or the vehicle body.
Page 424: If Your Vehicle Overheats
Check to see if the cooling fans are operating. STEP If the fans are operating: Wait until disappears and then stop the hybrid system. If the fans are not operating: Stop the hybrid system immediately and call your Toyota dealer.
Page 425 Add engine coolant if necessary. STEP Water can be used in an emer- gency if engine coolant is unavail- able. (→P. 438) Have the vehicle inspected at the nearest Toyota dealer as soon as possible.
Page 426 Add power control unit coolant if STEP necessary. Water can be used in an emer- gency if power control unit cool- ant is unavailable. (→P. 438) Have the vehicle inspected at the nearest Toyota dealer as soon as possible.
Page 427 5-2. Steps to take in an emergency ■ Overheating The following symptoms may occur when your vehicle is overheating: ● Hybrid system output decreases. ● Steam comes out from the engine area. CAUTION ■ To prevent an accident or injury when inspecting under the hood of your vehicle ●...
Page 428 ■ To prevent damage to the cooling system Observe the following precautions: ● Avoid contaminating the coolant with foreign matter (such as sand or dust etc.). ● When using coolant additives, use genuine Toyota products or equivalent.
Page 429: If The Vehicle Becomes Stuck
5-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt or snow: Shift the shift lever to P and set the parking brake. Stop the STEP hybrid system.
Page 430: If Your Vehicle Has To Be Stopped In An Emergency
5-2. Steps to take in an emergency If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the following pro- cedure: Steadily step on the brake pedal with both feet and firmly STEP...
Page 431 5-2. Steps to take in an emergency...
Page 432: Vehicle Specifications
Vehicle specifications 6-1. Specifications Maintenance data (fuel, oil level, etc.)..432 Fuel information ....444 6-2. Customization Customizable features ..445...
Page 433: Specifications Maintenance Data (Fuel, Oil Level, Etc.)
6-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions Overall length 3995 mm (157.3 in.) Overall width 1695 mm (66.7 in.) 1450 mm (57.1 in.) Overall height 1455 mm (57.3 in.) 1475 mm (58.1 in.) Wheelbase 2550 mm (100.4 in.) 1480 mm (58.3 in.) 1460 mm (57.5 in.) Front...
Page 434 ■ Vehicle identification number The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped under the right-hand front seat.
Page 435 6-1. Specifications Engine Model 1NZ-FXE Type 4-cylinder in line, 4-cycle, gasoline 75.0 × 84.7 mm (2.95 × 3.33 in.) Bore and stroke Displacement 1497 cm (91.3 cu.in.) Intake: 0.15  0.25 mm (0.006  0.010 in.) Valve clearance Exhaust: 0.25  0.35 mm (0.010  0.014 in.) (engine cold) Fuel Fuel type...
Page 436 5 minutes, and check the oil level on the dipstick. ■ Engine oil selection “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity.
Page 437 6-1. Specifications Recommended viscosity (SAE): If you use SAE 10W-30 or a higher viscosity engine oil in extremely low temperatures, the engine may become difficult to start, so SAE 5W-30 or lower vis- cosity engine recom- mended. Temperature range anticipated before next oil change.
Page 438 6-1. Specifications How to read oil container labels: Either or both API registered marks are added to some oil containers to help you select the oil you should use. API Service Symbol Top portion: The oil quality desig- nation by API (American Petro- leum Institute) (SN) Center portion: The SAE viscosity grade (SAE 0W-20)
Page 439 4.5 L (4.8 qt., 4.0 Imp. qt.) Power control unit 1.6 L (1.7 qt., 1.4 Imp. qt.) Use either of the following: • “Toyota Super Long Life Coolant” • A similar high-quality ethylene glycol-based non- Coolant type silicate, non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technol- Do not use plain water alone.
Page 440 : The fluid capacity is a reference quantity. If replacement is necessary, con- tact your Toyota dealer. NOTICE ■ Transmission fluid type Using transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration in shift quality, locking up of the transmission accompanied by vibration and, ultimately, damage to the vehicle’s transmission.
Page 441 6-1. Specifications Brakes Pedal clearance 70 mm (2.8 in.) Min. 1  6 mm (0.04  0.24 in.) Pedal free play 8  11 clicks Parking brake lever travel Fluid type SAE J1703 or FMVSS No.116 DOT 3 : Minimum pedal clearance when depressed with a force of 294 N (30 kgf, 66 lbf) while the hybrid system is operating : Parking brake lever travel when pulled up with a force of 200 N (20 kgf, 45 lbf)
Page 442 6-1. Specifications Tires and wheels Type A 175/65R15 84H, Tire size T125/70D16 96M (compact spare) Front wheel Rear wheel Tire inflation pressure (Recommended cold 230 kPa (2.3 kgf/cm 220 kPa (2.2 kgf/cm tire inflation pressure) bar, 33 psi) bar, 32 psi) Tire inflation pressure (compact spare) 420 kPa (4.2 kgf/cm...
Page 443 6-1. Specifications Type C Tire size 185/60R15 84H Tire inflation pressure (Recommended cold 220 kPa (2.2 kgf/cm or bar, 32 psi) tire inflation pressure) 15 × 5 1/2J Wheel size Wheel nut torque 103 N•m (10.5 kgf•m, 76 ft•lbf)
Page 444 6-1. Specifications Light bulbs Light Bulbs Type Headlights Low beam (halogen bulbs) High beam Front position lights Front turn signal lights Front fog lights Exterior Tail lights License plate lights Back-up lights Side turn signal lights Rear turn signal lights Interior lights/personal lights Interior Luggage compartment light...
Page 445: Fuel Information
■ If your engine knocks ● Consult your Toyota dealer. ● You may occasionally notice light knocking for a short time while acceler- ating or driving uphill. This is normal and there is no need for concern.
Page 446: Customization
Programming these preferences requires specialized equipment and may be performed by your Toyota dealer. Some function settings are changed simultaneously with other functions being customized. Contact your Toyota dealer for further details. Default Customized Item...
Page 447 6-2. Customization Default Customized Item Function setting setting 7.5 seconds Time elapsed before 15 seconds the lights turn off 30 seconds Operation when the doors are unlocked using the wireless remote control Illumination → P. 287) Operation after the “POWER” switch is turned off Operation when you approach the vehicle...
Page 448: Index
Index Abbreviation list ...... 448 Alphabetical index....449 What to do if......458...
Page 449: Abbreviation List
Abbreviation list Abbreviation/Acronym list ABBREVIATIONS MEANING Air Conditioning Anti-lock Brake System Automatic Locking Retractor Child Restraint System DISP Display Electric Control Unit Event Data Recorder Emergency Locking Retractor Electric Power Steering Electric Vehicle Light Emitting Diode Supplemental Restraint System Traction Control Treadwear Indicators Vehicle Identification Number Vehicle Stability Control...
Page 450: Alphabetical Index
Alphabetical index Alphabetical index A/C..........208 Audio system ABS ........... 196 Antenna ........ 220 ACCESSORY mode ....145 Audio input.... 233, 241, 252 Air conditioning filter ....344 AUX port ....... 252 Air conditioning system CD player......221 Air conditioning filter....344 Cord hook ......
Page 451 Alphabetical index Back door ........60 Care Back-up lights Exterior ......... 306 Replacing light bulbs..... 359 Interior........309 Wattage......... 443 Seat belts......310 Battery CD player........221 Checking ....... 332 Chains........203 Hybrid battery Child-protectors......58 (traction battery) ....28 Child restraint system If the vehicle 12-volt Baby seat (infant seat), battery is discharged ..
Page 452 Alphabetical index Cleaning Eco drive mode......155 Exterior........306 Electric power steering ... 196 Interior........309 Electronic key Seat belts ......310 If the electronic key does Clock ......... 177 not operate properly ... 416 Condenser ........ 330 Emergency flashers Console box ......
Page 453 Alphabetical index Engine Floor mat ........301 Accessory mode ....145 Fluid Compartment ......323 Washer ......... 330 Hood ........319 Fog lights How to start the hybrid Replacing light bulbs..... 359 system ........ 143 Switch ........185 Identification number..... 433 Wattage ........
Page 454 Alphabetical index Gas station information ..460 Jack Gauges........160 Positioning a floor jack..321 Glove box ......... 291 Vehicle-equipped jack... 400 Jack handle ......400 Hazard lights Switch ........372 Keyless entry ......55 Head restraints Keys Adjusting ........68 Electronic key ......
Page 455 Alphabetical index License plate lights Odometer........168 Replacing light bulbs..... 359 Wattage......... 443 Engine oil ......324 Light bulbs Opener Replacing ......359 Back door........ 60 Wattage......... 443 Fuel filler door ......85 Lights Hood ........319 Emergency flasher switch ..372 Outside rear view mirrors Fog light switch .....
Page 456 Alphabetical index Seat belts Shift lock system ..... 414 Adjusting the seat belt.....70 Side airbags ....... 91 Automatic Locking Side mirror Retractor (ALR) ....74 Adjusting and folding ....80 Child restraint system Side turn signal lights installation......111 Wattage ........ 443 Cleaning and maintaining Smart entry &...
Page 457 Alphabetical index Switch Tail lights Cruise control......192 Replacing light bulbs..... 359 “ECO MODE” switch ..... 155 Switch ........182 Emergency flasher switch ..372 Wattage ........ 443 EV drive mode switch ... 151 Theft deterrent system Fog light switch ..... 185 Immobilizer system ....
Page 458 Alphabetical index USB memory ....233, 241 Warning messages Back door......388 Cruise control......386 Vanity mirrors ......298 EV drive mode ...... 388 Vehicle control and Hybrid system ....... 385 operation data recording ..18 Hybrid system overheat ..388 Vehicle identification N position......
Page 459: What To Do If
What to do if... What to do if... If you have a flat tire A tire punctures P. 400 If the hybrid system will not start P. 412 P. 88 Immobilizer system The hybrid system does not start If the vehicle 12-volt battery is dis- P.
Page 460 What to do if... ■ Warning lights Brake system warning light Slip indicator (red indicator) P. 379 P. 381 light Brake system warning light Charging system warn- (yellow indicator) ing light P. 380 P. 381 Malfunction indicator Low fuel level warning lamp P.
Page 461: Lock Release Lever P
GAS STATION INFORMATION Auxiliary catch lever Fuel filler door P. 319 P. 85 Hood lock release lever Fuel filler door opener Tire inflation pressure P. 319 P. 85 P. 441 Fuel tank capacity (Reference) 36 L (9.5 gal., 7.9 Imp. gal.) Unleaded gasoline, Research Octane Fuel type Number of 91 or higher...
