- Page 1 International International Wireless Tag Reader Wireless Tag Reader Installation Guide Installation Guide...
-
Page 2: Warranty
United States and international copyright laws. The compi- lation of all content is likewise the exclusive property of The Stanley Works (or the Affil- iate identified in any copyright notice) and is protected by United States and international copyright laws. -
Page 3: Included In This Package
This document Wireless Tag Reader Overview The Wireless Tag Reader (WTR) is one component of a Stanley Healthcare Solutions Radio Frequency Identification (RFID) system. The WTR detects tags and then wire- lessly transmits the tag identification data to the RFID system. -
Page 4: Installation Tips
• The WTR must be installed within 15’ (4.5m) of a receiver, so that the signals can be relayed to the RoamAlert server. The WTR is often located in view of facility visitors and personnel. To maintain secure operation in this environment, the WTR case was designed so that it cannot be opened once installed. - Page 5 Figure 2: WTR Mounted Beside a Door to Illustrate Maximum LF Field The LF detection field is approximately spherical and has a maximum 6 ft. (1.8 m) radius. The range remains the same regardless of the WTR’s physical orientation. The LF Field radius can be varied as described in “Setting the LF Field Strength” on page 8.
- Page 6 Open the WTR using a Number 1 Phillips screwdriver to remove the 4 screws. Note the settings on the two red DIP switches, but do NOT adjust them. Push the power wire through the WTR backplate and work it towards the wiring connector.
- Page 7 Configuring the WTR WTR configuration involves four steps: • Setting the LF field strength (the WTR must be in Test Mode), • Selecting the operating mode, • Setting the unique address for the WTR, and • Setting the indicator LEDs and buzzer. Power Supply and Dry Contact Input Terminal Block...
- Page 8 Options DIP Switch Settings The Options DIP switch block is used to enable or disable End of Line (EOL) resistors and annunciation, and to set edge selection and the operating mode. Figure 6: Switches on the Options DIP Switch Block Setting the LF Field Strength Varying the LF Field strength changes the size of the tag detection zone.
-
Page 9: Selecting The Operating Mode
Check along the floor and near the ceilings to ensure that the entire space is filled with the LF Field. If the LF Field is inconsistent, turn the field adjustment slightly clockwise. If you have increased the LF Field strength, repeat Step 5 to ensure that the field does not extend beyond the detection area. -
Page 10: Standby Mode
Standby Mode In Standby Mode the WTR can be triggered by an opening or closing contact to generate an LF Field for a 10 second interval. During this interval, tags in the LF Field are scanned and the tag data transmitted to the RFID system. •... - Page 11 To use EOL resistors, move switch 1 of the Options DIP switch block to the position. See Figure 6 on page 8. For a definition of EOL, see “Using End Of Line Resistors in Standby Mode” on page 10. Setting the WTR Address Each WTR must have an address unique within the system.
-
Page 12: Verifying Operation
Verifying Operation To verify WTR operations and wiring, see Table 2 on page 11. Low Power Mode If main power fails the WTR enterd low power mode. Low power mode is indicated by the following: • The green LED remains off, –... -
Page 13: Address Dip Switch Settings
Wireless Tag Reader Notes Wireless Tag Reader Specifications Part Number 804A5901 Operating Temperature 32° F to 131° F (0° C to 55° C) Relative Humidity 0-90% RH non-condensing Dimensions (W x H x D) 9.0 in. x 1.7 in. x 4.1 in. (22.8 cm x 4.3 cm x 10.4 cm) including mounting plate Weight 17.6 oz (500 g), including mounting plate... - Page 14 Address 1 2 3 4 5 6 7 8 Address 1 2 3 4 5 6 7 8 ...
- Page 15 Address 1 2 3 4 5 6 7 8 Address 1 2 3 4 5 6 7 8 ...
- Page 16 Address 1 2 3 4 5 6 7 8 Address 1 2 3 4 5 6 7 8 ...
- Page 17 Address 1 2 3 4 5 6 7 8 Address 1 2 3 4 5 6 7 8 ...
- Page 18 Notes: Wireless Tag Reader Installation Guide...
- Page 19 Notes: Wireless Tag Reader Installation Guide...
- Page 20 Stanley Security Solutions Stanley Healthcare Solutions Division 1550 N. 20th Circle Lincoln, NE 68503 Telephone: USA: 800-824-2996 Canada: 866-559-6275 Int’l: +1 (613) 592-6997 Web site: www.stanleyhealthcare.com © 2011 Stanley Security Solutions Inc. All Rights Reserved. February 2011. 981-000362-000 Rev A.
