Model No. PFTL69806.0
USER'S MANUAL
Serial No.
Serial Number
Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if parts are
damaged or missing, PLEASE
CONTACT OUR CUSTOMER
SERVICE DEPARTMENT
DIRECTLY.
CALL TOLL-FREE:
1-888-533-1333
Mon.–Fri., 6 a.m.–6 p.m. MST
ON THE WEB:
www.proformservice.com
CAUTION
Visit our website at
Read all precautions and instruc-
tions in this manual before using
www.proform.com
this equipment. Save this manual
new products, prizes,
for future reference.
fitness tips, and much more!

Advertisement

Table of Contents
loading

Summary of Contents for ProForm PFTL69806.0

  • Page 1 Model No. PFTL69806.0 USER'S MANUAL Serial No. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if parts are damaged or missing, PLEASE CONTACT OUR CUSTOMER SERVICE DEPARTMENT DIRECTLY.
  • Page 2: Table Of Contents

    HOW TO FOLD AND MOVE THE TREADMILL ........
  • Page 3: Important Precautions

    11. Use only a single-outlet surge suppressor that meets all of the specifications described on page 9. To purchase a surge suppressor, see your local PROFORM dealer or call the toll-free telephone number on the front cover of this manual and order part number 146148, or see your local electronics store.
  • Page 4 SAVE THESE INSTRUCTIONS The decals shown here have been placed on the treadmill. If a decal is missing, or if it is not legible, call the toll-free tele- phone number on the front cover of this manual and order a free replacement decal.
  • Page 5: Before You Begin

    Adjustment Bolts ® number and serial number before calling. The model number of the treadmill is PFTL69806.0. The serial number can be found on a decal attached to the tread- mill (see the front cover of this manual for the location).
  • Page 6: Assembly

    During shipping, a small amount of lubricant may be transferred to the top of the walking belt or the shipping carton. This is a normal condition and does not affect treadmill perfor- mance. If there is lubricant on top of the walking belt, simply wipe off the lubricant with a soft cloth and a mild, non-abrasive cleaner.
  • Page 7 2. With the help of a second person, carefully raise the Uprights (84) to a vertical position. Have the second person hold the console assembly near the Uprights (84) as shown. Look under the console as- sembly and locate the Console Wire Harness (78). Remove the band securing the Upright Wire Harness (77) to the right Upright (84).
  • Page 8 Then, unplug the power cord. 7. Make sure that all parts are properly tightened before you use the treadmill. If there are sheets of clear plastic on the treadmill decals, remove the plastic. To protect the floor or carpet, place a mat under the tread- mill.
  • Page 9: Operation And Adjustment

    (see drawing 1 at the right). To purchase a surge suppressor, see your local PROFORM dealer or call the toll-free telephone number on the front cover of this man- ual and order part number 146148, or see your local electronics store.
  • Page 10 In addition, the console features six preset programs. Each program automatically controls the speed and in- cline of the treadmill as it guides you through an effec- tive workout. The console also offers two heart rate pro- grams that control the speed and incline of the treadmill to keep your heart rate near target heart rates during your workouts.
  • Page 11 Stand on the foot rails of the treadmill. Find the clip at- tached to the key (see the drawing on page 10), and slide the clip onto the waistband of your clothes. Next, insert the key into the console.
  • Page 12 When you are finished exercising, remove the key. Step onto the foot rails, press the Stop button, and adjust the incline of the treadmill to the lowest setting. The incline must be at the lowest setting when the treadmill is folded to the storage posi- tion or the treadmill will be damaged.
  • Page 13 If the speed and/or in- cline of the treadmill is about to change, the speed setting and/or the incline setting will flash in the display to alert you.
  • Page 14 2 (P2) is se- lected, a heart symbol will appear in the matrix. Heart rate program 2 will automatically adjust the speed and incline of the treadmill to keep your heart rate near a target heart rate that you select.
  • Page 15 7.5 mph and your heart rate is still too far below the target heart rate setting, the incline of the treadmill will also increase. If the speed or incline setting is too high or too low at any time during the program, you can adjust the setting with the Speed or Incline buttons.
  • Page 16 THE INFORMATION MODE/DEMO MODE The console features an information mode that keeps track of the total number of hours that the treadmill has been operated and the total number of miles that the walking belt has moved. The information mode also al-...
  • Page 17: How To Fold And Move The Treadmill

    1. Hold the upper ends of the handrails. Place one foot against one of the wheels. 2. Tilt the treadmill back until it rolls freely on the front wheels. Carefully move the treadmill to the desired location. To re- duce the risk of injury, use extreme caution while mov- ing the treadmill.
  • Page 18 HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand. Pull the latch knob to the left and hold it. Pivot the frame down until the catch is past the latch pin.
  • Page 19: Troubleshooting

    TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please see the front cover of this manual. PROBLEM: The power does not turn on SOLUTION: a.
  • Page 20 Switch is about 1/8”. If necessary, loosen the Screw (33), move the Reed Switch slightly, and then retighten the Screw. Reattach the Hood (not shown), and run the treadmill for a few minutes to check for a correct speed reading. PROBLEM: The walking belt slows when walked on SOLUTION: a.
  • Page 21: Conditioning Guidelines

    For maximum fat burning, adjust the speed and incline of the treadmill until your heart rate is near the middle number in your training zone. Aerobic Exercise If your goal is to strengthen your cardiovascular sys- tem, your exercise must be “aerobic.”...
  • Page 22 SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch—never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.
  • Page 23: Part List

    PART LIST—Model No. PFTL69806.0 To locate the parts listed below, see the EXPLODED DRAWING attached in the center of this manual. Key No. Qty. Description Foot Rail Cover 3/4” Screw Screw Catch Foot Rail Screw Isolator Hood Screw Star Washer...
  • Page 26: Ordering Replacement Parts

    • the MODEL NUMBER of the product (PFTL69806.0) • the NAME of the product (PROFORM 695 Pi treadmill) • the SERIAL NUMBER of the product (see the front cover of this manual) • the KEY NUMBER and DESCRIPTION of the part(s) (see the EXPLODED DRAWING in the center of this manual and the PART LIST on page 23) ICON Health &...
