24 LCD Color Monitor
Service
Service
Service
Description
Table of Contents......................................................1
Revision List.............................................................2
Important Safety Notice............................................3
1. Monitor Specifications............................................5
2. LCD Monitor Description........................................7
3. Operation Instructions............................................8
3.1General Instructions........................................8
3.2 Control Buttons..........................................8
3.3 OSD Menu......................................................10
4. Input/output Specification..................................11
4.1 Input Signal Connector.......................................11
4.2 Resolution & Preset Modes.................................12
4.3 Pixel Defect Policy.......................................14
4.4 Failure Mode of Panel...................................16
5. Block Diagram...............................................17
5.1 Scaler Board.....................................................17
5.2 Power/USB Board..............................................18
6. Schematic Diagram.............................................. 19
ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE
CHASSIS AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN
SERVICING ELECTRONIC EQUIPMENT CONTAINING HIGH VOLTAGES.
CAUTION: USE A SEPARATE ISOLATION TRANSFOMER FOR THIS UNIT WHEN SERVICING
REFER TO BACK COVER FOR IMPORTANT SAFETY GUIDELINES
Copyright 2013 Philips Consumer Lifestyle
247E4LHAB/00
247E4LHSB/00
247E4LHAB/57
247E4LHSB/01
247E4LHSB/27
247E4LHAB/69
247E4LHSB/96
247E4LHSB/75
Page
SAFETY NOTICE
Subject to modification
Description
6.1 Scaler Board..............................................19
6.2 Power Board.......................................................31
6.3 Key Board..............................................32
7. PCB Layout................................................33
7.1 Scaler Board............................................33
7.2 Power Board.............................................34
7.3 Key Board.................................................36
8. Wiring Diagram.............................................37
9. Scaler Board Overview..................................38
10. Mechanical Instructions...............................39
11. Repair Flow Chart........................................41
12. ISP Instructions..................................................45
13. DDC Instructions................................................54
14. White Balance, Luminance Adjustment..............72
15. Monitor Exploded View.......................................74
16. Recommended & Spare Parts List...................76
17. General Product Specification.......................79
Aug. 30, 2013
K
Chassis: Meridian 3
Page
Advertisement
Table of Contents
Related Manuals for Philips 247E4LHAB/57
Summary of Contents for Philips 247E4LHAB/57
- Page 1 CHASSIS AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN SERVICING ELECTRONIC EQUIPMENT CONTAINING HIGH VOLTAGES. CAUTION: USE A SEPARATE ISOLATION TRANSFOMER FOR THIS UNIT WHEN SERVICING REFER TO BACK COVER FOR IMPORTANT SAFETY GUIDELINES Copyright 2013 Philips Consumer Lifestyle Subject to modification Aug. 30, 2013...
-
Page 2: Revision List
Release Date Revision History Jan.11, 2013 Initial release, Draft Version Mar.15,2013 Add new model 247E4LHSB/01 Jun.7,2013 Add new model 247E4LHSB/27 Jul.12,2013 Add new model 247E4LHAB/57 Aug.2,2013 Add new model 247E4LHSB/96 Aug.16,2013 Add new model 247E4LHAB/69 Aug.30,2013 Add new model 247E4LHSB/75... -
Page 3: Important Safety Notice
Meridian 3 Important Safety Notice This electronic user guide is intended for anyone who uses the Philips monitor. Take time to read this user manual before you use your monitor. It contains important information and notes regarding operating your monitor. The... - Page 4 Meridian 3 IMPORTANT: Always activate a moving screen saver program when you leave your monitor unattended. Always activate a periodic screen refresh application if your monitor will display unchanging static content. Uninterrupted display of still or static images over an extended period may cause “burn in”, also known as “after-imaging”...
-
Page 5: Monitor Specifications
Meridian 3 1. Monitor Specifications Technical specifications... - Page 6 Meridian 3 Note: 1. EPEAT Gold or Silver is valid only where Philips registers the product. Please visit www.epeat.net registration status in your country. 2. This data is subject to change without notice. Go to www.philips.com/support to download the latest...
-
Page 7: Lcd Monitor Description
Meridian 3 2. LCD Monitor Description The LCD monitor will contain a scaler board and a key board. The scaler board houses the flat panel control logic, brightness control logic and DDC. Monitor Block Diagram LED Drive LED Panel Scaler Board Adapter board Key Board Video signal, DDC... -
Page 8: General Instructions
Meridian 3 3. Operating Instructions 3.1 General Instructions Press the power button to turn the monitor on or off. The other control knobs are located at front panel of the monitor. By changing these setting, the picture can be adjusted to your personal preference. The power cord should be connected. - Page 9 Meridian 3 Connect to PC Connecting to your PC 1. Connect the power cord to the back of the monitor firmly. 2. Turn off your computer and unplug its power cable. 3. Connect the monitor signal cable to the video connector on the back of your computer.
-
Page 10: Osd Menu
Meridian 3 3.3 OSD Menu The OSD Menu On-screen Display (OSD) is feature in all Philips LCD Below is an overall view of the structure of the monitors. It allows an end user to adjust screen On-Screen Display. You can use this as a reference... -
Page 11: Input/Output Specification
Meridian 3 4. Input/ Output Specification 4.1 Input Signal Connector HDMI Connector D-sub Connector Pin No. Description Pin No. Signal Name TMDS Data2+ TMDS Data2 Shield Green/ SOG TMDS Data2– Blue TMDS Data1+ Sense (GND) TMDS Data1 Shield Cable Detect (GND) TMDS Data1–... -
Page 12: Resolution & Preset Modes
Meridian 3 4.2 Resolution & Preset Modes Maximum Resolution 1920 x 1080 at 60 Hz (analog input) 1920 x 1080 at 60 Hz (digital input) Recommended Resolution 1920 x 1080 at 60 Hz (digital input) Note: Please notice that your display works best at native resolution of 1920 x 1080@60Hz. For best display quality, please follow this resolution recommendation. - Page 13 Meridian 3 Power Management Definition If you have VESA DPM compliance display card or software installed in your PC, the monitor can automatically reduce its power consumption when not in use. If an input from a keyboard, mouse or other input device is detected, the monitor will 'wake up' automatically.
-
Page 14: Pixel Defect Policy
Meridian 3 4.3 Pixel Defect Policy defects and several types of sub pixel defects within Philips strives to deliver the highest quality products. each category. We use some of the industry's most advanced manufacturing processes and practice stringent quality Bright Dot Defects Bright dot defects appear as pixels control. - Page 15 In order to qualify for repair or replacement due to pixel defects during the warranty period, a TFT LCD panel in a Philips flat panel monitor must have pixel or sub pixel defects exceeding the tolerances listed in the following tables.
-
Page 16: Failure Mode Of Panel
Meridian 3 4.4 Failure Mode Of Panel Quick reference for failure mode of LCD panel this page presents problems that could be made by LCD panel. It is not necessary to repair circuit board. Simply follow the mechanical Polarizer has bubbles instruction on this manual to eliminate failure by replace LCD panel. - Page 21 D405 NC/PDZ5.6B C429 NC/100N16V D404 NC/PDZ5.6B C428 NC/100N16V D403 NC/PDZ5.6B C427 NC/100N16V C426 100N 16V C425 100N 16V C432 NC/0.1UF50V D406 NC/PDZ5.6B...
- Page 23 R617 NC/750R 1/10W 5% OUTR R616 0R05 OHM SE-1 R615 NC/750R 1/10W 5% OUTL R614 0R05 1/10W R613 0R05 1/10W...
- Page 27 D405 NC/PDZ5.6B C429 NC/100N16V D404 NC/PDZ5.6B C428 NC/100N16V D403 NC/PDZ5.6B C427 NC/100N16V C426 100N 16V C425 100N 16V C432 NC/0.1UF50V D406 NC/PDZ5.6B...
- Page 29 R617 NC/750R 1/10W 5% OUTR R616 NC/0R05 OHM SE-1 R615 NC/750R 1/10W 5% OUTL R614 NC/0R05 1/10W R613 NC/0R05 1/10W...
-
Page 33: Scaler Board
Meridian 3 7. PCB Layout 7.1 Scaler Board (715G5452M01000004Q) Remark: Parts position can be searched by using FIND function in PDF. CN408 C722 C813 C805 ZD702 ZD610 C731 C716 R715 Q705 C804 C713 C728 C641 U705 D801 C714 R659 CN409 R714 C634 C643... -
Page 34: Power Board
Meridian 3 7.2 Power Board (715G4962P01000001S) Remark: Parts position can be searched by using FIND function in PDF. 19V1 C919 C921 L902 C914 LED2 D905 C923 GND2 C909 SG15 T901 IC903 R911 C906 Q901 D901 C926 R988 C904 FB902 J902 SG19 L901 C903... - Page 35 Meridian 3 Remark: Parts position can be searched by using FIND function in PDF. R916 R917 IC904 R989 R909 D902 JR902 R967 R910 C912 R922 R906 IC901 R914 R920 R904 R905...
-
Page 36: Key Board
Meridian 3 7.3 Key Board 715G5453K02000004S Remark: Parts position can be searched by using FIND function in PDF. Remark: Parts position can be searched by using FIND function in PDF. U001 CN001... -
Page 38: Scaler Board Overview
Meridian 3 9. Scaler Board Overview FFC Cable DC-DC Flash ROM Scaler IC HDMI EEPROM Audio IC D-SUB EEPROM HDMI EEPROM... -
Page 39: Mechanical Instructions
Meridian 3 10. Mechanical Instructions Note: 247E4LHSB/00 have no speakers, so some steps are needless for it. 2. Disconnect the connector to remove the Rear cover. Needless for 247E4LHSB/00 Step 2: Remove the scaler board 1. Disconnect all the connectors and remove the screw to remove the scaler board. - Page 40 Meridian 3 Step 3: Panel and Bezel. Separate 1. The panel 2. The Bezel and Key Board. Step 4: Rear cover with Speakers stand and HINGE ASSY Note 247E4LHSB/00 have no Speaker. 2. The scaler board. Step 5: Remove the screw to remove the Base.
-
Page 41: Repair Flow Chart
Meridian 3 11. Repair Flow Chart 1. No Power No power Check power cable is Re-plug the power cable tightened? Check Power “On/Off” Turn on the Power “On/Off” switch is “On”? Check the LED Check the AC power indicator is OK? Replace the power board and check connections Replace main board and check connections Replace key board and check connections... - Page 42 Meridian 3 Video (Power LED White) No Video (Power LED White) Press the power Replace the main board button is OK? Replace the power The end board and connection Replace the main The end board and connection Check the FFC cable Replace the FFC cable or panel or panel...
- Page 43 Meridian 3 3. DIM DIM (image overlap, focus or flicker) Reset in factory mode The end Set to the optimal The end frequency, select the recommended frequency Readjust the phase and pixel The end clock in the user mode Pull out signal cable and Check the signal cable check “Self Test Feature and the PC...
- Page 44 Meridian 3 4. Color is not optimal Color is not optimal Color shift Miss color Reset the factory mode Replace the signal cable In the user mode, set the “color settings” until customer satisfy The end Pull out the signal cable and check the screen color display is normal? Replace the signal cable or PC...
-
Page 45: Isp Instructions
Meridian 3 12. ISP Instruction 12.1 Materials list ISP JIG: 715GT089-B/C VGA cable TPV P/N: 089G728 GAA DB Monitor USB cable USB port driver TPV P/N: 089G1758 X ISP tool: New F/W... - Page 46 Meridian 3 12.2 Connect the ISP board, PC and monitor as follow: 12.3 Install USB driver. 12.3.1 When insert the USB cable to PC USB port, will pop up a Hardware Wizard to help you install the USB driver if you use this ISP board first time. You can install it successfully as the below instruction step by step. Remark: The USB driver files path: D:\FTC100103(Mstar)\FTCUSB.INF...
- Page 47 Meridian 3 Click “Finish” to complete the USB serial port driver installation.
- Page 48 Meridian 3 12.4 Install the ISP tool. 12.4.1 Double-click to install ISP program. 12.4.2 Double-click to run the ISP tool. 12.4.3 Set the parameters to restore the HDCP key if the monitor has DVI or HDMI port. (1) Click the “Option” item. (2) Tick “FE2P Mode Enable”.
- Page 49 Meridian 3 12.4.4 Setup ISP tool. Click “Setup ISP tool” to open the configuration window. 12.4.5 Configuration for ISP tool. Tick “FTDI”.
- Page 50 Meridian 3 12.4.6 Load the F/W you want to upgrade. 12.4.7 Start to program. Click “Auto” to start programming.
- Page 51 Meridian 3 12.4.8 Programing success. There will be the message in the red frame after successful programming. 12.5 Check the FW version after upgrade. 12.5.1 The way to open factory menu. (1)Connect video source to monitor and AC on. (2)The way to factory menu: Press “MENU” and “+” keys synchronously (The rightmost and leftmost keys in the touch keyboard), and DC on.
- Page 52 Meridian 3 (4)Please do “Auto Color” in factory menu after change main board and upgrade F/W. 12.5.2 Do factory reset in user menu. User menu – Setup – Reset - Yes. (1)Restart the monitor after open factory menu. And then open the user menu. (2)Factory reset will turn off “Burn in”...
- Page 53 Meridian 3 Method: Tick the “Send MX2060 CMD” at Option item. 12.6.2 When can’t upgrade, please retry below several ways to upgrade. (1) When the tool appears erase error, you can change another version tool to try. (2) The program must be in the monitor standby state, while the fail communication with monitor might result the monitor power off.
-
Page 54: Ddc Instructions
Meridian 3 13. DDC Instruction General DDC Data Re-programming In case the main EEPROM with Software DDC which store all factory settings were replaced because a defect repaired monitor’ the serial numbers have to be re-programmed. It is advised to re- soldered the main EEPROM with Software DDC from the old board onto the new board if circuit board have been replaced, in this case the DDC data does not need to be re-programmed. - Page 55 13.3 Prepare the EDID written 1. Change the EDID files name as below rule. Anolog EDID WA.dat HDMI2 EDID WH2.dat HDMI EDID WH.dat 2. Copy these four files to one folder named as PHILIPS 247E4LHAB which must contains “config.ini” file.
- Page 56 Meridian 3 3. Copy PHILIPS 247E4LHAB to DDC folder and put DDC and ISP tool together. 13.4. Run the ISP tool. 1. Double-click the icon to open the tool. 2. Tick the “Analog+DVI” and click “Loadfile” to set the parameters.
- Page 57 Meridian 3 3. Select the EDID folder. Select correct folder.
- Page 58 Meridian 3 4. Load EDID successful. 5. Tick the “Only connect HDMI”and “write SN”, and type in the 14 digit S/N.
- Page 59 Meridian 3 6. Start to writing. Click “Program” to start writing. When The green “PASS” appear, the process is finished. 7. Check the S/N in monitor user menu. Press “MENU” and select “Information”—“SN”, you can check the SN. 13.5. Troubleshooting. 1.
- Page 60 Meridian 3 write into. (3)Take apart the monitor and connect the 7pin of EEPROM to GND to diable write protection then write EDID one by one. (4)Set the Burn in on last to try again.
- Page 61 Meridian 3 247E4LHAB/00 EDID Analog 00 01 02 03 04 05 06 07 08 09 0A 0B 0C 0D 0E 0F ----------------------------------------------- 00| 00 FF FF FF FF FF FF 00 41 0C C0 C0 01 01 01 01 10| 1F 16 01 03 6E 34 1D 78 2A 2C C5 A4 56 50 A1 28 20| 0F 50 54 BD 4B 00 D1 C0 81 80 95 0F 95 00 B3 00 30| 81 C0 01 01 01 01 02 3A 80 18 71 38 2D 40 58 2C 40| 45 00 09 25 21 00 00 1E 00 00 00 FF 00 0A 20 20...
- Page 62 1440 x 900 @ 60Hz 1680 x 1050 @ 60Hz 1280 x 720 @ 60Hz <-Detailed Timing Descriptions:-> FC (Monitor Name) : Philips 247E4 FD (Monitor Limits): Min. V. rate: 56 Hz Max. V. rate: 76 Hz Min. H. rate: 30 KHz Max.
- Page 63 Meridian 3 Digital 00 01 02 03 04 05 06 07 08 09 0A 0B 0C 0D 0E 0F ----------------------------------------------- 00| 00 FF FF FF FF FF FF 00 41 0C C0 C0 01 01 01 01 10| 1F 16 01 03 80 34 1D 78 2A 2C C5 A4 56 50 A1 28 20| 0F 50 54 BD 4B 00 D1 C0 81 80 95 0F 95 00 B3 00 30| 81 C0 01 01 01 01 02 3A 80 18 71 38 2D 40 58 2C 40| 45 00 09 25 21 00 00 1E 00 00 00 FF 00 0A 20 20...
- Page 64 1440 x 900 @ 60Hz 1680 x 1050 @ 60Hz 1280 x 720 @ 60Hz <-Detailed Timing Descriptions:-> FC (Monitor Name) : Philips 247E4 FD (Monitor Limits): Min. V. rate: 56 Hz Max. V. rate: 76 Hz Min. H. rate: 30 KHz Max.
- Page 65 Meridian 3 HDMI 1 00 01 02 03 04 05 06 07 08 09 0A 0B 0C 0D 0E 0F --------------------Block 0-------------------- 00| 00 FF FF FF FF FF FF 00 41 0C C0 C0 01 01 01 01 10| 1F 16 01 03 80 34 1D 78 2A 2C C5 A4 56 50 A1 28 20| 0F 50 54 BD 4B 00 D1 C0 81 80 95 0F 95 00 B3 00 30| 81 C0 01 01 01 01 02 3A 80 18 71 38 2D 40 58 2C 40| 45 00 09 25 21 00 00 1E 00 00 00 FF 00 0A 20 20...
- Page 66 1280 x 720 @ 60Hz <-Detailed Timing Descriptions:-> Detailed Timing : 1920x1080 @ 60Hz FF (Monitor SN) : FC (Monitor Name) : Philips 247E4 FD (Monitor Limits): Min. V. rate: 56 Hz Max. V. rate: 76 Hz Min. H. rate: 30 KHz Max.
- Page 67 Meridian 3 Extension Flag : 01 Block0 Checksum : 85 ------------------------------------------------------- Block 1: Extended Block Type: CEA 861B Detailed Timing Blocks start at Byte: 22 DTV Underscan YES DTV Basic Audio YES YCbCr (4:4:4) YES YCbCr (4:2:2) YES <-Video Short Block Description:-> 640 x 480 P 59.94/60Hz 4:3 720 x 480 P 59.94/60Hz 4:3 720 x 480 P 59.94/60Hz 16:9...
- Page 68 Meridian 3 Detailed Timing Descriptions: 1920x1080 @ 60Hz H Image Size: 521 mm V Image Size: 293 mm Pixel Clock: 148 Hz Refreshed Mode: Non-Interlaced Detailed Timing Descriptions: 720x480 @ 60Hz H Image Size: 521 mm V Image Size: 293 mm Pixel Clock: 27 Hz Refreshed Mode: Non-Interlaced Detailed Timing Descriptions: 1280x720 @ 60Hz...
- Page 69 Meridian 3 ------------------------------------------------------- Block 0: EDID Structure Version/Revision: 01 03 <-Vendor/Product Identification:-> ID Manufacturer Name: PHL ID Product Code: C0C0 ID Serial Number: No Use Week of Manufacture: Year of Manufacture: 2012 <-Basic Display Parameters/Features:-> Video i/p definition: Digital Max. H. Image Size : 52cm Max.
- Page 70 1280 x 720 @ 60Hz <-Detailed Timing Descriptions:-> Detailed Timing : 1920x1080 @ 60Hz FF (Monitor SN) : FC (Monitor Name) : Philips 247E4 FD (Monitor Limits): Min. V. rate: 56 Hz Max. V. rate: 76 Hz Min. H. rate: 30 KHz Max.
- Page 71 Meridian 3 720 x 576 P 50Hz 4:3 720 x 576 P 50Hz 16:9 1280 x 720 P 50Hz 16:9 1920 x 1080 I 50Hz 16:9 720(1440) x 576 I 50Hz 4:3 720(1440) x 576 I 50Hz 16:9 1920 x 1080 P 50Hz 16:9 1280 x 720 P 59.94/60Hz 16:9 <-Audio Short Block Description:->...
-
Page 72: White Balance, Luminance Adjustment
Meridian 3 14. White Balance, Luminance Adjustment 1. Apparatuses and program: analyzer CA-210, PC, tool, FGA adjustment program (Philips LEDFGA.DDCI), Pattern generator. 2. Equipment installation: a. Connect analyzer CA-210 to PC by USB connector, install drive program CA-SDK Ver4.00 for CA-210 and restart PC after finish installing b. - Page 73 Meridian 3 5. Color Temp confirmation Connect the signal to the monitor, the monitor displays white-picture, use CA-210 to measure the Color Temp of the screen center and select the OSD to make sure whether the Color Temps accord with the SPEC. 11500K 9300K 8200K...
-
Page 76: Recommended & Spare Parts List
084G 56 4 B FUSE 4A 250V T901 S80GL19P522V X'FMR 620UH 5% FQ002 756GQCCB0PH0950000 SCALER BOARD ASSY(CBPC*) U402 100GPNVD006NT1 PHILIPS 247E4LHAB U401 056G 562A61 MCU ASSY(056G2233501) U704 056G 563145 IC AZ1117D-1.2TRE1 1A/1.2V TO252-2 U702 056G 563204 C HF LDO G960PT43U 1A 3.3V TO-252... - Page 77 Meridian 3 247E4LHSB/00 Item Location PCM Codes Description Remark FQ105 A34G3106AFLC3B0130 BEZEL FQ153 A33G1333 2 1C0100 LENS_POWER FQ004 KEPCVQP9 KEY BOARD ASSY E750 750GBV236GE231N000 LCD TPM236H3-HGEL02 C1C FQ TPV FQ002 CBPCVN7PHQ2 SCALER BOARD ASSY FQ124 A15G1803L01401 ZA MAINFRAME FQ104 A37G03120120FH HINGE ASSY FQ119 A34G2942AFL 1B0100...
- Page 78 Meridian 3 Service Kit Description Part No. Picture ISP TOOL 715GT089-B/C EDID TOOL 715GT034-B...
-
Page 79: General Product Specification
. SOG SUPPORT . Windows 7compliant . HDCP support for DVI input . SMART Contrast 20M:1(max.) . True Vision (FACTORY GAMMA ALIGNMENT) (FGA) REQUIREMENT . POWER ON PHILIPS LOGO REQUIREMENT . WEEE REQUIREMENT . RoHS REQUIREMENT Quick Specification table: Model... - Page 80 All optical characteristics are determined according to panel specification after warming up longer than 30 minutes. PRODUCT PROFILE EDID header Data for EDID & .inf file Philips 247E4 (24inch Wide LCD MONITOR User visible strings on .inf file 247E4) Manufacturer ID ( EDID data) Product ID, "xxxx" 4 codes...
- Page 81 Scaler should be capable of below items. 1) Scaler must support color engine for Image enhancement feature (SmartImage) 2) Scaler must have enough memory to support PerfecTune feature and Philips OSD 3) Scaler must support SmartContras, 20M:1 DCR preferred 4) VGA signal Auto adjustment: Monitor automatically adjusts and optimizes resolution and frequency based on input signal defined by “Source”...
- Page 82 Meridian 3 Vsync Positive/Negative Composite sync TTL level, input impedance 2.2k ohm terminate (Positive/Negative) Sync on green video 0.3 Vp-p Negative (Video 0.7 Vp-p Positive) 2). DVI-D Digital Input signal: Single TMDS link (Three channels: RX0-/+, RX1-/+, RX2-/+) 3) HDMI ( option , refer to Quick specification table) Follow HDMI 1.4 specification 4).
- Page 83 Meridian 3 Over Scan - 1. RGB signal : OFF (no this function) 2. YUV signal : (Video timming) ON (Be use and set ON/OFF) (But only 1080p define is OFF ) PC timing: to follow PC timing table TMDS/+5V/DDC/HPD/CEC Signals (TMDS Signal) Termination Supply Voltage AV 3.3V±5%...
- Page 84 Meridian 3 Interface D-Sub Cable Length : Please refer to M3 cable bundle summary file Fix with monitor when packing, with transplant pin protective cover. Connector type : D-Sub male with DDC2B pin assignments. Blue connector thumb-operated jack screws Pin assignments: PIN No.
- Page 85 Meridian 3 T.M.D.S. data0 shield No Connect No Connect T.M.D.S clock shield T.M.D.S. clock+ T.M.D.S. clock- HDMI Cable The input signals are applied to the display through HDMI cable. Length : Please refer to M4 cable bundle summary file Connector type : HDMI male with DDC-2B pin assignments White connector thumb-operated jackscrews With transplant pin protective cover.
- Page 86 English, French, German, Spanish, Italian, Russian, Simplified Chinese, Portuguese, Turkish (9) Power On logo Power On Logo: Power Show up Philips logo 3 seconds Change to input signal. This picture is reference only. The official drawing will send out by PM.
- Page 87 Meridian 3 PS : Item 3.4 and 3.5 , as far as possible to be display (another Horizontal and Vertical) Vertical scanning Sync polarity : Positive or Negative Scanning frequency : 56 - 76 Hz Power input connection Power cord length :please refer to M4 cable bundle summary file Power cord type : 3 leads power cord with protective earth plug.
- Page 88 Meridian 3 24"(16:10) 1920x1200 36.8 24"(16:9) 1920x1080 EPA 5.1 VS EPA6.0 VGA Display identification In accordance with VESA Display Channel Standard Ver.1.0 and DDC 2B capability DVI Display identification In accordance with DVI requirement (DDWG digital Visual Interface revision 1.0) use DDC-2B, DDC/CI, and EDID V1.3 DDC /CI Support and Smart Manage/Control In accordance with VESA DDC/CI and MCCS ver.2.0, the monitor should be workable with ,...
- Page 89 Meridian 3 audio 3.17.1 Frequency Response The amplifier and speaker combination shall provide a frequency response of 300 Hz to 20 kHz, with +/- 3 dB variation over the entire response range. 3.17.2 Total Harmonic Distortion Total harmonic distortion shall be limited to 5% THD at the maximum wattage speaker rating specified in section 1.3, at 1 kHz, when the input is 1.0Vrms.
- Page 90 Meridian 3 VISUAL CHARACTERISTICS Test conditions Unless otherwise specified, this specification is defined under the following conditions. (1) Input signal : As defined in 3.3, 1920 x 1080 non-interlaced mode (1920 x 1080@60Hz), signal sources must have 75 ohm output impedance. (2) Luminance setting : controls to be set to nits with full screen 100 % duty cycle white signal (3) Warm up: more than 30 minutes after power on with signal supplied.
- Page 91 Meridian 3 y = 0.306 ± 0.02 7500K x = 0.298 ± 0.02 PerfecTune II y = 0.314 ± 0.02 6500K/sRGB x = 0.313 ± 0.02 PerfecTune II y = 0.329 ± 0.02 sRGB x = 0.313 ± 0.02 PerfecTune II y = 0.329 ±...
- Page 92 Base / Pedestal to be Flame Retardant UL 94-HB. All major plastic parts (bezel, back cover) need to be molded from same resin. Plastic resin type selection should be referred to “plastic-Philips Pool monitor”. Texture/Glossing of housing The texture area and texture no should follow Philips make-up sheet.
- Page 93 MMD request metal plate in Kensington hole. Label Regulatory label / Carton label should follow Philips requirement. Detail document refer to Philips Engineering Reference Book. Product dimension / Weight ( Refer to Philips approved SHT 191/SHT560 ) Unit dimension Packed unit dimension: Net weight...
- Page 94 3. Cold Drop test (for design reference) Un-package test 1. Sine vibration (operating) 2. Half sine shock test (non operation) Pallet / Container loading (Refer to Philips approved SHT 560) Transportation standards refer to TYE-M0002 ,UAN-D1534 and UAW-0309. Air shipment - Sea container 20'(pallet/slip sheet)
- Page 95 Meridian 3 - Humidity : 95% max - Altitude : 0-12192m - Air pressure : 300-1100 mBAR Note: recommend at 5 to 35 C, Humidity less than 60 % 7.2Transportation tests Refer to 5.15.2 7.3Display disturbances from external environment According to IEC 801-2 for ESD disturbances 7.4 Display disturbances to external environment...
- Page 96 4. When the HV circuitry is operating properly there is no possibility of an x- tube must be the same type as the original, including suffix letter, or a Philips radiation problem. High voltage should always be kept at the manufacturer's approved type.
