Setup
This section thoroughly describes how to set up your new Audity 2000 for
use. Setup includes unpacking instructions and how to connect the Audity
2000 cables.
Unpacking
Carefully remove Audity 2000 from the packaging material. Take care to
save the packing materials in case you need to transport the unit. Check to
make sure all components are included and in good condition. If there are
missing or damaged components, contact E-mu Systems immediately for
replacement or repair.
Your Audity 2000 should include the following components:
• Audity 2000 unit
• Power cable
• Rack mounting ears
• This Operation Manual
Audity 2000 Operations Manual 13
Advertisement
Related Manuals for E-Mu Audity 2000
Summary of Contents for E-Mu Audity 2000
- Page 1 Setup This section thoroughly describes how to set up your new Audity 2000 for use. Setup includes unpacking instructions and how to connect the Audity 2000 cables. Unpacking Carefully remove Audity 2000 from the packaging material. Take care to save the packing materials in case you need to transport the unit. Check to make sure all components are included and in good condition.
-
Page 2: Connection Instructions
MIDI guitar controller. Outputs Audity 2000 is a high quality, stereo audio device. In order to reproduce its wide dynamic range and frequency response, use a high quality amplifi- cation and speaker system such as a keyboard amplifier or home stereo system. -
Page 3: Studio Setup
Mixer MIDI In In this setup, Audity 2000 is controlled by MIDI messages, received at the MIDI In connector, which are routed by the MIDI interface. The MIDI interface allows any MIDI controller, such as a MIDI keyboard, MIDI wind controller or a computer to be connected to the module easily. -
Page 4: Performance Setup
MIDI In Audity 2000 is controlled by MIDI messages received at the MIDI In connector. Connect the MIDI In of Audity 2000 to the MIDI Out connector of a MIDI controller such as E-mu's Launchpad, a MIDI keyboard, MIDI drum pads or a MIDI sequencer. - Page 5 The power switch is located on the right side of the front panel. You can turn on the Audity 2000 and its MIDI controller in any order. When power is applied, the liquid crystal display will light, indicating that Audity 2000 is operating.
- Page 6 Gratification Playing the Demo Audity 2000 has four factory demo sequences that let you hear what Audity can do. You can play any of these demo sequences using the Demo Sequences Sequence page of the Master menu.
- Page 7 “click” of the knob. If you spin the knob quickly, the numbers advance much faster (more than one numer per click). Play the keyboard and listen to the sounds made by your Audity 2000! TURN THE FOUR KNOBS on the front panel and note how they change the sound of each preset! The button to the left of the knobs changes the knob’s function.
- Page 8 Let’s check out the pattern generator. Go back to the Mode screen and set the mode to “Pattern”. Now advance to the Pattern screen (shown below) and move the cursor to the Pattern Number field (the second field from the left). MASTER ARPEGGIATOR Pattern 38 Inversions 20 E-MU Systems...
- Page 9 32 notes. on creating Patterns. Multi-Channel Audity 2000 is totally unique in its ability to run up to 16 arpeggiators at once! Even two or three patterns at once can create very complex sequences Arpeggiator and dynamic landscapes of sound.
- Page 10 From the Master Arpeggiator menu, set the Mode to “Pattern” then explore the different patterns. There are 200 patterns available! MASTER ARPEGGIATOR Pattern Pattern Name You’re starting to get the picture of how versatile and easy to use the Audity 2000 really is. 22 E-MU Systems...
