ProForm PFEX17910 User Manual

Pro-form stationary bike user manual
Hide thumbs

Advertisement

Quick Links

Model No. PFEX17910
Serial No.
Serial
Number
Decal
QUESTIONS?
If you have questions, or if there
are missing or damaged parts,
we will guarantee complete sat-
isfaction through direct assis-
tance from our factory.
TO AVOID UNNECESSARY
DELAYS, PLEASE CALL DIRECT
TO OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our customer hot line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.–Fri., 6 a.m.–6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
USER'S MANUAL
Patent Pending
Visit our website at
www.proform.com
new products, prizes,
fitness tips, and much more!

Advertisement

loading

Related Manuals for ProForm PFEX17910

Summary of Contents for ProForm PFEX17910

  • Page 1 Model No. PFEX17910 Serial No. Serial Number Decal QUESTIONS? If you have questions, or if there are missing or damaged parts, we will guarantee complete sat- isfaction through direct assis- tance from our factory. TO AVOID UNNECESSARY DELAYS, PLEASE CALL DIRECT TO OUR TOLL-FREE CUSTOMER HOT LINE.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS IMPORTANT PRECAUTIONS .............2 BEFORE YOU BEGIN .

  • Page 3: Before You Begin

    (excluding holidays). To help us assist you, please note the product model number and serial number before calling. The model number is PFEX17910. The serial number can be found on a decal attached to the exercise cycle (see the front cover of this manual).

  • Page 4: Assembly

    ASSEMBLY Assembly requires two persons. Place all parts of the exercise cycle in a cleared area and remove the packing materials. Do not dispose of the packing materials until assembly is completed. Assembly requires the included tools and your own adjustable wrench and Phillips screw- driver Use the part drawings below to identify the small parts used in assembly.
  • Page 5 1. Identify the Front Stabilizer (2), which has Wheels (30) on the ends. While another person lifts the front of the Frame (1) slightly, attach the Front Stabilizer to the Frame with two M10 x 112mm Carriage Bolts (65) and two M10 Black Nylon Locknuts (63).
  • Page 6 5. Connect the wire harness on the Handgrip Pulse Sensor (15) to the indicated wire harness on the Console (16). Insert both wire harnesses into the open- ing in the bottom of the Console. Then, insert the metal tube on the Handgrip Pulse Sensor into the opening in the bottom of the console.
  • Page 7 9. Identify the Left Pedal (24), which is marked with an “L.” Using an adjustable wrench, firmly tighten the Left Pedal counterclockwise into the Left Crank Arm (42). Tighten the Right Pedal (not shown) clockwise into the Right Crank Arm. Important: Tighten both Pedals as firmly as possible.

  • Page 8: How To Operate The Exercise Cycle

    HOW TO OPERATE THE EXERCISE CYCLE HOW TO ADJUST THE SEAT POST For effective exer- cise, the seat should be at the Seat proper height. As you pedal, there should be a slight bend in your knees when the pedals are in the lowest position.
  • Page 9 FEATURES OF THE CONSOLE The easy-to-use console offers a selection of features designed to help you get the most from your workouts. When the manual mode of the console is selected, the resistance of the exercise cycle can be adjusted with a touch of a button.
  • Page 10 HOW TO USE THE MANUAL MODE Turn on the console. Note: The console requires four “D” batteries (not included). If you have not installed batteries, refer to step 4 on page 5 and install batteries. To turn on the console, press the On/Reset button or begin pedaling.
  • Page 11 HOW TO USE A PERSONAL TRAINER PROGRAM Turn on the console. Refer to step 1 on page 10. Select one of the four personal trainer programs. Each time the console is turned on, the manual mode will be selected. To select a per- sonal trainer program, press the Program button repeatedly until a “P 1,”...

  • Page 12: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING Inspect and tighten all parts of the exercise cycle reg- ularly. Replace any worn parts immediately. To clean the exercise cycle, use a damp cloth and a small amount of mild soap. Important: To avoid damage to the console, keep liquids away from the console and keep the console out of direct sunlight.

  • Page 13: Conditioning Guidelines

    CONDITIONING GUIDELINES The following guidelines will help you to plan your exercise program. Remember that proper nutrition and adequate rest are essential for successful results. WARNING: Before beginning this or any exercise program, consult your physician. This is especially important for persons over the age of 35 or persons with pre-existing health problems.

  • Page 14: Exploded Drawing

    EXPLODED DRAWING—Model No. PFEX17910 Key No. Qty. Description Frame Front Stabilizer Rear Stabilizer Rear Endcap Seat Post Seat Bracket Handlebar Endcap Foam Grip Seat Adjustment Knob M8 Nylon Locknut M6 x 38mm Screw Seat Upright Upright Bushing Handgrip Pulse Sensor/Handlebar...
  • Page 15 EXPLODED DRAWING—Model No. PFEX17910 R1201A...

  • Page 16: How To Order Replacement Parts

    • The KEY NUMBER and DESCRIPTION of the part(s) (see the PART LIST on page 14 of this manual). PROFORM is a registered trademark of ICON Health & Fitness, Inc. ICON Health & Fitness, Inc. (ICON), warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of ninety (90) days from the date of pur- chase.

This manual is also suitable for:
