12. The Console (5) requires four 1.5V "D" batteries
(not included); alkaline batteries are recom-
mended. IMPORTANT: If the elliptical exercis-
er has been exposed to cold temperatures,
allow it to warm to room temperature before
inserting batteries into the Console. If you
do not do this, the console displays or other
electronic components may become dam-
aged.
Press the two tabs on the battery cover, and
remove the battery cover. Next, insert four bat-
teries into the Console (5). Make sure that the
batteries are oriented as shown by the dia-
grams inside the battery compartment. Then,
reattach the battery cover to the Console.
13. Tip: Be careful not to pinch the wire har-
nesses during this step. While another person
holds the Console (5) near the Upright (3), con-
nect the wire harness on the Console to the
Upper Wire Harness (48). Insert the excess
wire harness into the Upright. Next, attach the
Console to the Upright with four M4 x 16mm
Round Head Screws (101).
14. Make sure that all parts of the elliptical exerciser are properly tightened. Note: Some hardware may be
left over after assembly is completed. To protect the floor or carpet from damage, place a mat under the
elliptical exerciser.
12
5
13
11
Tabs
Battery
Batteries
Cover
Avoid pinching the
wire harnesses dur-
5 ing this step
Console Wire
48
3
101
101
