Page 3
(MONO) VIDEO L–AUDIO–R VIDEO 3 INPUT ENTER MENU AUTO PROGR S1 VIDEO AUTO PROGRAM PR : 0 1 T V SYS : B / G VHF L O W AUTO PROGR...
Page 5
WARNING Table of contents • Dangerously high voltages are present inside the TV. Getting Started • Operate the TV only at 110-240 V AC. • Do not open the cabinet and the rear cover of the TV. 6 Connections Refer servicing to qualified personnel. 8 Getting to know the remote commander •...
Getting Started Connections Connecting a VHF antenna or a combination VHF/UHF antenna — 75-ohm coaxial cable (round) Attach an optional IEC antenna connector to the 75-ohm coaxial cable. Plug the connector into the (antenna) socket at the rear of the TV. Rear of TV Rear of TV On a wall...
Page 7
Front of TV Camcorder to video and audio outputs (MONO) VIDEO L–AUDIO–R VIDEO 3 INPUT S1 VIDEO to S or S1 video output : Signal flow When connecting a monaural VCR Connect the yellow plug to VIDEO and the black plug to AUDIO-L (MONO). When connecting video game equipment Connect video game equipment to the VIDEO 3 INPUT jacks at the front of your TV or the VIDEO IN 3 jacks at the rear of your TV.
Page 8
Getting to know the remote commander Names of buttons on the remote commander are indicated in different colors to represent the available functions. Label color Button function White For general TV operations. Green For Teletext operations. Yellow For PIP and PROGRAM INDEX operations. Blue For the wide picture mode operations.
Introducing the menus You can preset TV channels, adjust the picture and sound qualities, and select some settings using the on-screen menus. You can use the buttons on the remote commander or the TV to operate the menus. A/V CONTROL FEATURES PRESET PRES E T...
Make sure the cursor (z) appears beside Changing the menu LANGUAGE/ #### and press ENTER. language Press V/b/v/B to select ####, and press ENTER. PRES E T : L A NGUAGE / # # # # ARABIC ENTER ENTER AUTO PROGRAM MANUA L PROGRAM T V S Y S : B / G COL SYS : AUTO...
Note Presetting channels • If you want to return to the normal screen while the nine sub screens are being displayed, you can press PROGR INDEX on the remote commander. To preset channels automatically using the menu Press MENU. Press V or v to move the cursor (z) to the PRESET menu ( ), and press ENTER.
Page 12
ENTER. Notes • The TV system and the ATT (attenuator) settings are memorized for each program position. • If you do not know your local TV system, consult your nearest Sony dealer or authorized service center. Getting Started...
Operations To scan through program positions Watching the TV Press PROGR +/– on the remote commander or the TV until the program position you want appears. PROGR Press VOL +/– on the remote commander or VOLUME +/– on the TV to adjust the volume. POWER TV/VIDEO VOLUME...
To watch TV Setting the Wake Up Timer Press TV on the remote commander or TV/VIDEO on the TV. You can set the TV to turn on automatically after the period of time you want. Press WAKE UP/INDEX repeatedly to set the timer.
Setting the Sleep Timer You can set the TV to turn off automatically after the period of time you want. Press SLEEP. SLEEP TEXT CLR SLEEP TIMER:30M SLEEP TIMER:60M After 30 minutes After 60 minutes SLEEP TIMER:OFF SLEEP TIMER:90M No Sleep Timer After 90 minutes To cancel the Sleep Timer, press SLEEP repeatedly until “SLEEP TIMER: OFF”...
SUBTITLE Watching the The entire picture is enlarged to fully fit the screen, and the height of the subtitle area is reduced. This mode is picture in wide ideal for viewing a movie with subtitles. mode (WIDE MODE) SUBTITLE Good-bye.Jane Good luck, Jane.
To watch a picture in wide mode using Scrolling a picture the menu up or down Press MENU. (SCROLL) MENU A / V CONT ROL DY NAM I C S T A NDARD SOF T P ERSONAL V I DEO AD J UST A UD I O AD J UST T I L T CORRECT: The SCROLL feature allows you to scroll a picture up...
Adjusting the Adjusting the picture settings (VIDEO ADJUST) picture and sound You can adjust the picture settings to suit your taste with the VIDEO ADJUST option. The adjusted settings are stored in the PERSONAL option. Press MENU. MENU A / V CONT ROL Selecting the picture and sound modes DY NAM I C S T A NDARD...
If the picture is slightly snowy Press V/b/v/B to adjust the selected item, You may try to improve the picture by changing the and press ENTER. VM setting as described below: For details on each item, see “Description of adjustable Display the VIDEO ADJUST menu.
Listening to the POWER BASSO sound The POWER BASSO sound enables you to enjoy a high quality sound mode with the best combination of all types of sound. It reproduces dynamic and clear sounds and emphasizes low and high audio effects as well.
Turn off the surround sound. MENU Notes • The BBE is manufactured by Sony Corporation under license from BBE Sound, Inc. It is covered by U.S. Patent No. 4,638,258 and No. 4,482,866. The word “BBE” and the BBE symbol are ENTER the trademarks of BBE Sound, Inc.
Receiving area for NICAM and A2 (German) Selecting a stereo or programs System Receiving area bilingual program NICAM Hong Kong, Singapore, New Zealand, etc. A2 (German) Australia, Malaysia, Thailand, etc. Notes • If the signal is very weak, the sound becomes monaural automatically.
To restore the normal screen Viewing multiple Press PROGR INDEX again or PIP. You can also select PROGR INDEX or PIP : OFF from programs at the the PIP menu, and press ENTER to restore the normal screen. same time To view multiple programs on the nine sub (PROGRAM INDEX) screens using the menu...
Displaying frame- Using the Picture-in- by-frame pictures Picture (PIP) (STROBE) features You can watch a slow motion movement of the main With the Picture-in-Picture (PIP) feature, you can screen picture which is displayed frame-by-frame on display a sub screen within the main picture of the nine sub screens within the main screen.
Changing the position of the PIP screen Swapping pictures between the main and PIP screens MENU Press SWAP. ENTER SWAP Press MENU. MENU A / V CONT ROL DY NAM I C S T A NDARD SOF T P ERSONAL V I DEO AD J UST A UD I O AD J UST T I L T CORRECT:...
Viewing Teletext Checking the contents of a Teletext service (INDEX) Press WAKE UP/INDEX to display an overview of the Teletext contents and page numbers. Using FASTEXT This feature allows you to quickly access a Teletext TV stations broadcast an information service called page that uses FASTEXT.
Revealing concealed information (REVEAL) The REVEAL option lets you disclose concealed information, such as an answer to a quiz that you find on some of the Teletext pages. Press DISPLAY/REVEAL. To conceal the information Press DISPLAY/REVEAL again. Enlarging the Teletext display (ENLARGE) Press A/B/ENLARGE.
To display a Teletext page on the PIP screen Displaying Teletext using the menu on the PIP screen MENU (PIP TEXT) ENTER The PIP TEXT feature enables you to display a Teletext Press MENU. page on the PIP screen while watching a TV program. MENU A / V CONT ROL DY NAM I C...
Viewing a video game screen You can view a video game screen in the optimum mode that gives soft picture and dynamic sound effect. Press GAME. GAME GAME The picture and sound change to the mode that is suitable for a video game. To restore the normal picture and sound modes Press TV, VIDEO/HOLD, or PROGR +/–.
Customizing the TV Adjusting the picture tilt You can adjust the picture tilt if it is not aligned to the TV screen. This may happen due to the direction of the earth’s magnetic fields in relation to the TV position. Press MENU.
If you have any problems, read this manual again and No sound check the countermeasure for each of the symptoms listed below. If the problem persists, contact your nearest Sony dealer or authorized service center. Snowy picture Noisy sound / Press POWER.
Page 32
AVERTISSEMENT Table des matières • Le téléviseur renferme des hautes tensions Préparation dangereuses. • Faites uniquement fonctionner le téléviseur sur une 6 Raccordements tension CA de 110-240 V. 8 Manipulation de la télécommande • N’ouvrez pas le boîtier et le couvercle arrière du 9 Présentation des menus téléviseur.
Page 33
Préparation Raccordements Raccordement à une antenne VHF ou VHF/UHF — câble coaxial de 75 ohms (rond) Reliez le connecteur de l’antenne IEC (non fourni) au câble coaxial de 75 ohms. Introduisez le connecteur dans la prise (antenne) située à l’arrière du téléviseur. Arrière du téléviseur Arrière du téléviseur A une prise murale...
Page 34
Avant du téléviseur Caméscope vers les sorties vidéo et audio (MONO) VIDEO L–AUDIO–R VIDEO 3 INPUT S1 VIDEO vers la sortie S ou S1 Vidéo : Sens du signal Raccordement d’un magnétoscope mono Introduisez la fiche jaune dans l’entrée VIDEO et la fiche noire dans la prise AUDIO-L (MONO). Raccordement d’un équipement pour jeu vidéo Raccordez l’équipement pour jeu vidéo aux prises VIDEO 3 INPUT à...
Page 35
Manipulation de la télécommande Les noms des touches de la télécommande sont indiqués dans différentes couleurs afin de représenter les fonctions disponibles. Couleur Fonction de la touche Blanc Pour l’utilisation générale du téléviseur Vert Pour l’utilisation générale du télétexte Jaune Pour l’utilisation de PIP et PROGRAM INDEX Blue...
Page 36
Présentation des menus Vous pouvez présélectionner des chaînes télévisées, régler la qualité de l’image et du son et sélectionner quelques réglages à l’aide des menus sur écran. Vous pouvez utiliser les touches de la télécommande ou du téléviseur pour le pilotage par menus.
Page 37
Assurez-vous que le curseur (z) apparaît en Modification de la regard de LANGUAGE/#### et appuyez sur ENTER. langue du menu Appuyez sur V/b/v/B pour sélectionner #### et appuyez sur ENTER. PRES ET L ANGUAGE / # # # # : CH I NESE ENTER ENTER...
Page 38
Le téléviseur entame la recherche et présélectionne les Présélection des canaux automatiquement. Lorsque toutes les chaînes captables sont mémorisées, le menu AUTO PROGRAM canaux disparaît et les neuf premiers canaux présélectionnés apparaissent en mosaïque. Les neuf sous-écrans disparaissent après avoir été affichés pendant quelques secondes.
Page 39
• Si vous ne connaissez pas votre système de télévision local, AT T : OFF VHF L O W adressez-vous à votre revendeur Sony le plus proche ou à un centre de service agréé. Sélectionnez la position de programme que Désactivation des positions de...
Page 40
Opérations Pour sélectionner une position de programme à Regarde le deux chiffres, appuyez sur “÷” avant d’appuyer sur les touches numériques. téléviseur Par exemple: pour sélectionner la position de programme 25, appuyez sur “÷” et puis sur “2” et “5”. -/-- Pour effectuer une recherche sur les POWER...
Page 41
Visualisation de l’entrée vidéo Affichage des informations sur écran Appuyez sur VIDEO/HOLD de la télécommande Appuyez sur DISPLAY/REVEAL. ou TV/VIDEO du téléviseur. DISPLAY REVEAL VIDEO HOLD VIDEO 1 VIDEO 2 VIDEO 3 DYNAMIC WIDEZOOM POWER BASSO: ON Pour regarder la télévision Remarque •...
Page 42
Pour annuler le programmateur d’éveil, appuyez plusieurs fois sur WAKE UP/INDEX jusqu’à ce que “WAKE UP TIMER: OFF” apparaisse ou coupez l’alimentation du téléviseur. Remarques • Le programmateur d’éveil commence dès que l’affichage sur écran disparaît. • La dernière position du programme télévisé ou du mode vidéo avant le passage en mode veille apparaîtra lorsque le téléviseur se mettra sous tension avec le programmateur d’éveil.
SUBTITLE Visualisation de La totalité de l’image est élargie de manière à remplir complètement l’écran, et la hauteur de la zone de sous- l’image en mode de titres est réduite. Ce mode est idéal pour regarder un film avec des sous-titres. grand écran (WIDE MODE) SUBTITLE...
Page 44
Pour visualiser une image en mode de Défilement d’une grand écran à l’aide du menu image vers le haut Appuyez sur MENU. ou vers le bas MENU A / V CONT ROL DY NAM I C S T A NDARD SOF T (SCROLL) P ERSONAL...
Réglage de l’image Ajustement des réglages de l’image (VIDEO ADJUST) et du son Vous pouvez ajuster les réglages de l’image à votre gré à l’aide de l’option VIDEO ADJUST. Les réglages effectués sont conservés dans l’option PERSONAL. Appuyez sur MENU. MENU A / V CONT ROL DY NAM I C...
Remarque Appuyez sur V ou v pour déplacer le curseur • Vous ne pouvez ajuster le réglage HUE que pour le système (”) sur AUDIO ADJUST et appuyez sur NTSC. ENTER. Si l’image est légèrement neigeuse AUD I O AD J UST Vous pouvez essayer d’améliorer l’image en changeant BASS TREBL E...
Page 47
Ecoute du son POWER BASSO Le son POWER BASSO vous permet de profiter d’une excellente qualité sonore combinant tous les types de son. Ce son reproduit les sons dynamiques et cristallins tout en accentuant les effets audio bas et élevés. Appuyez sur POWER BASSO.
Remarques MENU • BBE est fabriqué par Sony Corporation sous licence de BBE Sound, Inc. Il est protégé par le brevet U.S. Patent No. 4,638,258 et No. 4,482,866. L’indication “BBE” et le symbole BBE sont des marques de commerce de BBE Sound, Inc.
Page 49
Zone de réception des programmes NICAM et Sélection d’un A2 (allemand) Système Zone de réception programme stéréo NICAM Hongkong, Singapour, Nouvelle-Zélande, etc. ou bilingue A2 (allemand) Australie, Malaisie, Thaïlande, etc. Remarques • Si le signal est très faible, le son est automatiquement diffusé en mono.
Page 50
Pour revenir à l’écran normal Visualisation de Appuyez de nouveau sur PROGR INDEX ou PIP. Vous pouvez également sélectionner PROGR INDEX plusieurs programmes ou PIP : OFF dans le menu PIP et appuyez sur ENTER pour revenir à l’écran normal. en même temps Pour visualiser les programmes multiples en (PROGRAM INDEX)
Page 51
Affichage des Utilisation des images trame par options Image dans trame (STROBE) image (PIP) Vous pouvez visualiser un mouvement au ralenti de L’option Image dans image (PIP) vous permet l’image de l’écran principal qui est affichée trame par d’afficher un sous-écran dans l’image principale avec trame sur les neuf petits écrans dans l’écran principal.
Page 52
Appuyez sur V/b/v/B pour sélectionner ON et Permutation d’images entre l’écran appuyez sur ENTER. principal et l’écran PIP Appuyez sur MENU pour revenir à l’écran Appuyez sur SWAP. normal. SWAP Changement de la position de l’écran MENU ENTER Arrêt sur l’image PIP Appuyez sur MENU.
Page 53
Utilisation du Superposition de la page du télétexte sur l’image du téléviseur télétexte Appuyez sur TEXT. Chaque fois que vous appuyez sur TEXT, l’écran change comme suit: n Télétexte n Télétexte et TV n TV Certaines chaînes émettent un service d’informations Visualisation du contenu du service appelé...
Page 54
Maintien d’une page de télétexte (HOLD) Une page de télétexte peut contenir plusieurs sous- pages. Vous pouvez arrêter le défilement des pages de manière à pouvoir lire le texte à votre propre rythme. Appuyez sur VIDEO/HOLD. Le symbole HOLD “H” apparaît dans le coin supérieur gauche de l’écran.
Page 55
Pour afficher une page de télétexte sur l’écran Affichage du PIP à l’aide du menu télétexte dans MENU l’écran PIP (PIP TEXT) ENTER Appuyez sur MENU. L’option PIP TEXT vous permet d’afficher une page de télétexte sur l’écran PIP tout en regardant un MENU A / V CONTROL DYNAM I C...
Page 56
Visualisation d’un jeu vidéo Vous pouvez visualiser un jeu vidéo dans le mode optimal qui reproduit une image douce et un son dynamique. Vous pouvez afficher un jeu vidéo à l’aide de la touche de la télécommande ou du menu. Appuyez sur GAME.
Page 57
Personnalisation du Réglage de l’inclinaison de l’image téléviseur Vous pouvez régler l’inclinaison de l’image de façon à l’aligner correctement à l’écran. Cette opération est nécessaire lorsque le téléviseur est orienté vers un champ magnétique terrestre. Appuyez sur MENU. MENU A / V CONT ROL DY NAM I C S T A NDARD Utilisation de la borne AV OUT...
Page 58
Absence de son En cas d’anomalie, relisez ce manuel et vérifiez les points présentés ci-après. Si le problème persiste, contactez votre centre de service agréé ou votre représentant Sony le plus proche. / Appuyez sur POWER. Neige sur l’image / Appuyez sur POWER pour mettre le Son parasité...
28 in. (Wide Trinitron Plus) Tube size (cm) Measured diagonally Screen size (cm) Measured diagonally 768 × 511 × 518 Dimensions (w/h/d, mm) Mass (kg) 44.5 Accessory (optional) TV stand (SU-V28G) Design and specifications are subject to change without notice. Sony Corporation Tokyo, Japan...
