Setting The Time - Garmin Delta Inbounds Owner's Manual

Setting the Time

1
Select Time.
2
Select an option:
• To set the time to a 12-hour or 24-hour format, select
Time Format.
• To set the time of day, select Time.
Resetting the Device to Factory Settings
You can restore all of the device settings to factory default
values.
Select Factory Reset.
Device Information
Viewing Dog Collar Device Information on
the Base Unit
You can view dog collar device status information, such as the
remaining battery power of a dog collar device.
Select or to scroll through the list of collars.
Base Unit Specifications
Battery type
Battery life
Operating temperature range
Wireless frequency/protocol
Water rating
*The device withstands incidental exposure to water of up to 1 m
for up to 30 min. For more information, go to
/waterrating.
Delta Inbounds Dog Collar Device
Specifications
Battery type
Battery life
Operating temperature range
Charging temperature range
Storage temperature range
Wireless frequency/protocol
Water rating
*The device withstands pressure equivalent to a depth of 10 m.
For more information, go to www.garmin.com/waterrating.
Keep Away Tag Specifications
Battery type
Battery life
Operating temperature range
Wireless frequency/protocol
Water rating
*The device withstands incidental exposure to water of up to 1 m
for up to 30 min. For more information, go to
/waterrating.
Product Updates
On your computer, install Garmin Express
/express).
This provides easy access to these services for Garmin devices:
• Software updates
8
User-replaceable alkaline for back up
Up to 4 days
From -20° to 60°C (from -4° to 140°F)
2.4 GHz @ 18 dBm nominal
IEC 60529 IPX7*
www.garmin.com
Rechargeable lithium-ion
Up to 2 wk.
Up to 1 wk. with Keep Away Tag
From -20° to 60°C (from -4° to 140°F)
From 0° to 45°C (from 32° to 113°F)
From -20° to 85°C (from -4° to 185°F)
2.4 GHz @ 3 dBm nominal
1 ATM*
User-replaceable CR2032, 3 V
Up to 3 mo.
From -20° to 60°C (from -4° to 140°F)
2.4 GHz @ 3 dBm nominal
IEC 60529 IPX7*
www.garmin.com
™ (www.garmin.com
• Product registration
Updating the Software Using Garmin Express
Before you can update your device software, you must
download and install the Garmin Express application and add
your device.
1 Connect the device to your computer using the USB cable.
When new software is available, the Garmin Express
application sends it to your device.
2
After the Garmin Express application finishes sending the
update, disconnect the device from your computer.
Your device installs the update.
Garmin Support Center
Go to support.garmin.com
product manuals, frequently asked questions, videos, and
customer support.
Troubleshooting
Tips for Improving Corrections
If your dog is being corrected at unexpected times, you can try
these options.
• Place the flags at the exact location of the correction.
The actual range of the boundary may vary based on
interference.
• Ensure there are no 2.4 GHz transmitters nearby, such as
wireless routers or microwaves.
• Ensure there are no large metal objects nearby, such as
sheds or cars.
• Ensure the base unit is mounted at least 1.5 m (5 ft.) above
the ground.
• Increase or reduce the boundary based on your testing.
You can set a boundary of up to 50 m (170 ft.). You may
need to reduce the range to be most effective.
• Turn off the dog collar device before turning off the base unit.
The dog is corrected when the collar loses communication
with the base unit.
How can I keep my dog away from an area
inside the containment area?
Install a Keep Away Tag sensor on an object inside the
containment area, such as a flower bed or trash can
Away Tag Sensor, page
Can I use the containment system for the
entire yard?
For best results, you should contain your dog in either your front
or back yard. Depending on the size of your house and yard, the
range might be sufficient for your entire yard. You should mount
the base unit in a central location and test the effective range.
The base unit displays an error
If the base unit displays an error when retrieving data, you can
try these options.
• From the collar screen, select OK.
A message appears when the base unit is retrieving data.
• Ensure there are no 2.4 GHz transmitters nearby, such as
wireless routers or microwaves.
The base unit is not sounding an alert tone
If the base unit is not sounding an alert tone when the dog
approaches the boundary, you can try these options.
for help and information, such as
7).
Device Information
(Keep
