Configuring RSPAN
Command
Step 4 monitor session session_number
destination remote vlan vlan-id
reflector-port interface
Step 5 end
Step 6
show monitor [session session_number]
Step 7
copy running-config startup-config
This example shows how to clear any existing RSPAN configuration for session 1, configure RSPAN
session 1 to monitor multiple source interfaces, and configure the destination RSPAN VLAN and the
reflector-port.
Switch(config)# no monitor session 1
Switch(config)# monitor session 1 source interface fastEthernet0/10 tx
Switch(config)# monitor session 1 source interface fastEthernet0/2 rx
Switch(config)# monitor session 1 source interface fastEthernet0/3 rx
Switch(config)# monitor session 1 source interface port-channel 102 rx
Switch(config)# monitor session 1 destination remote vlan 901 reflector-port
fastEthernet0/1
Switch(config)# end

Creating an RSPAN Destination Session

Beginning in privileged EXEC mode, follow these steps to create an RSPAN destination session and to
specify the source RSPAN VLAN and the destination port:
Command
Step 1 configure terminal
Step 2
monitor session session_number source
remote vlan vlan-id
Step 3 monitor session session_number
destination interface interface-id
[encapsulation {dot1q | isl}]
Step 4
end
Catalyst 3550 Multilayer Switch Software Configuration Guide
24-18
Purpose
Specify the RSPAN session, the destination remote VLAN, and the
reflector port.
For session_number, enter 1 or 2.
For vlan-id, specify the RSPAN VLAN to carry the monitored traffic
to the destination port. (See the
VLAN" section on page 12-8
RSPAN VLAN.)
For interface, specify the interface that will flood the RSPAN traffic
onto the RSPAN VLAN.
Return to privileged EXEC mode.
Verify your entries.
(Optional) Save your entries in the configuration file.
Purpose
Enter global configuration mode.
Specify the RSPAN session and the source RSPAN VLAN.
For session_number, specify 1 or 2.
For vlan-id, specify the source RSPAN VLAN to monitor.
Specify the RSPAN session and the destination interface.
For session_number, specify 1 or 2.
For interface-id, specify the destination interface.
(Optional) Specify the encapsulation header for outgoing packets. If
not specified, packets are sent in native form.
• isl—Use ISL encapsulation.
• dot1q—Use 802.1Q encapsulation.
Return to privileged EXEC mode.
Chapter 24 Configuring SPAN and RSPAN
"Creating or Modifying an Ethernet
for more information about creating an
78-11194-09
