Poulan Pro 530163735 Instruction Manual

Poulan pro trimmer/edger instruction manual
Hide thumbs
Table of Contents

Advertisement

Quick Links

For Occasional Use Only
WARNING:
Read and follow all Safety Rules and Operating Instructions before
using this product. Failure to do so can result in serious injury.
ADVERTENCIA:
Lea el manual de instrucciones y siga todas las advertencias e
instrucciones de seguridad. El no hacerlo puede resultar en le-
siones graves.
AVERTISSEMENT:
Lire le manuel d'instructions et bien respecter tous les avertisse-
ments et toutes les instructions de sécurité. Tout défaut de le
faire pourrait entraîner des blessures graves.
Electrolux Home Products, Inc.
250 Bobby Jones Expressway
Augusta, GA 30907
Copyright E2002 Electrolux Home Products, Inc.
Instruction Manual
Manual de Instrucciones
Manuel d'Instructions
R
PP445
530163735
7/16/04

Advertisement

Table of Contents
loading

Related Manuals for Poulan Pro 530163735

Summary of Contents for Poulan Pro 530163735

  • Page 1 Lire le manuel d’instructions et bien respecter tous les avertisse- ments et toutes les instructions de sécurité. Tout défaut de le faire pourrait entraîner des blessures graves. Electrolux Home Products, Inc. 250 Bobby Jones Expressway Augusta, GA 30907 Copyright E2002 Electrolux Home Products, Inc. Instruction Manual PP445 530163735 7/16/04...

  • Page 2: Identification Of Symbols

    IDENTIFICATION OF SYMBOLS DANGER! This pruner can be dangerous! Careless or im- proper use can cause serious or even fatal injury. Always wear appropriate ear protection, eye protection and head protection. DANGER! Falling objects can cause severe head injury. Wear head protection when operating this unit.

  • Page 3: Kickback Warning

    S Keep others away when making carburetor adjustments. S Use only Poulan PROR accessories and replacement parts as recommended. HANDLE FUEL WITH CAUTION S Do not smoke while handling fuel or while operating the pruner.

  • Page 4: Maintain Control

    contacts a foreign object in the wood in the cut along the bottom of the guide bar and the chain is suddenly stopped. This sudden stopping pulls the pruner forward and away from the operator and could easily cause the operator to lose control of the pruner.

  • Page 5: Special Notice

    Remove objects (rocks, broken glass, nails, wire, etc.) which can be thrown by or become entangled in line. Hard objects can damage the trimmer head and be thrown causing serious injury. S Use only for trimming, scalping, mowing and sweeping.
  • Page 6 Blade can thrust violently away from material it does not cut. Blade thrust can cause amputation of arms or legs. WARNING: Do not use trimmer head as a fastening device for the blade. WARNING: The blade continues to spin after the throttle is released or engine is turned off.

  • Page 7: Hedge Trimmer Safety

    The tines become very sharp from use. S Do not run unit at high speed unless culti- vating. HEDGE TRIMMER SAFETY DANGER: RISK OF CUT; KEEP HANDS AWAY FROM BLADE - - Blade moves momentarily after the trigger is re- leased.
  • Page 8 ASSEMBLY WARNING: If received assembled, repeat all steps to ensure your unit is properly assembled and all fasteners are secure. Examine parts for damage. Do not use dam- aged parts. NOTE: If you need assistance or find parts missing or damaged, call 1-800-554-6723. It is normal for the fuel filter to rattle in the empty fuel tank.

  • Page 9: Operation

    PoulanR or Poulan PROR oil resists high temperature thinning. If PoulanR or Poulan PROR bar and chain oil is not avail- able, use a good grade SAE 30 oil.
  • Page 10 lubrication. S Always stop the engine before removing the oil cap. IMPORTANT Experience indicates that alcohol blended fuels (called gasohol or using ethanol or methanol) can attract moisture which leads to separation and formation of acids during stor- age. Acidic gas can damage the fuel system of an engine while in storage.

  • Page 11: Operating Position

    1. Move ON/OFF switch to the ON position. 2. Move the choke lever to the HALF CHOKE position. 3. Squeeze and hold the throttle trigger. Keep throttle trigger fully squeezed until the engine runs smoothly. 4. Pull starter rope sharply until engine runs, but no more than 5 pulls.

  • Page 12: Important Points

    clamp, stand as shown and check for the fol- lowing: S Extend your left arm and hold assist handle with your left hand. S Hold throttle grip with your right hand with finger on throttle trigger. S Keep engine end below waist level. S Keep shoulder strap pad centered on your left shoulder and danger sign centered on your back.

  • Page 13: Check Chain Tension

    shows signs of damage or leaks. INSPECT AND CLEAN UNIT AND LA- BELS S After each use, inspect complete unit for loose or damaged parts. Clean the unit and labels using a damp cloth with a mild deter- gent. S Wipe off unit with a clean dry cloth. CHECK CHAIN TENSION WARNING: Wear protective gloves...

  • Page 14: Service And Adjustments

    Remove Sawdust From Guide Bar Groove Oil Holes S Burring of guide bar rails is a normal process of rail wear. Remove these burrs with a flat file. S When rail top is uneven, use a flat file to restore square edges and sides. File Rail Edges and Sides Square...
  • Page 15 in guide bar groove. Ensure all drive links are in the bar groove. 12. Now, install bar clamp making sure the adjusting pin is positioned in the lower hole in the guide bar. Lower Hole Adjusting Pin Guide Bar 13. Install bar clamp nut and finger tighten only.
  • Page 16 WARNING: Always stop unit and disconnect spark plug before performing all of the recommended remedies below except remedies that require operation of the unit. TROUBLE CAUSE Engine will not 1. ON/OFF switch in start. OFF position. 2. Engine flooded. 3. Fuel tank empty. 4.

  • Page 17: Limited Warranty

    LIMITED WARRANTY ELECTROLUX HOME PRODUCTS, INC., warrants to the original purchaser that each Poulan PROr brand gasoline tool or at- tachment is free from defects in material and workmanship and agrees to repair or replace under this warranty any defective gasoline product or attachment as follows from the original date of purchase.
  • Page 18 you should contact your nearest authorized service center or call ELECTROLUX HOME PRODUCTS, INC., at 1- -800- -554- -6723. WARRANTY PERIOD: Any warranted part which is not scheduled for replacement as re- quired maintenance, or which is scheduled only for regular inspection to the effect of “re- pair or replace as necessary”...
