Manual de Instrucciones
For Occasional Use Only
WARNING:
Read and follow all Safety Rules and Operating Instructions before
using this product. Failure to do so can result in serious injury.
ADVERTENCIA:
Lea el manual de instrucciones y siga todas las advertencias e
instrucciones de seguridad. El no hacerlo puede resultar en le-
siones graves.
AVERTISSEMENT:
Lire le manuel d'instructions et bien respecter tous les avertisse-
ments et toutes les instructions de sécurité. Tout défaut de le
faire pourrait entraîner des blessures graves.
Electrolux Home Products, Inc.
250 Bobby Jones Expressway
Augusta, GA 30907
Copyright E2002 Electrolux Home Products, Inc.
Instruction Manual
Manuel d'Instructions
530163516
R
PP135
11/8/02
Advertisement
Table of Contents
Related Manuals for Poulan Pro 530163516
Summary of Contents for Poulan Pro 530163516
- Page 1 Lire le manuel d’instructions et bien respecter tous les avertisse- ments et toutes les instructions de sécurité. Tout défaut de le faire pourrait entraîner des blessures graves. Electrolux Home Products, Inc. 250 Bobby Jones Expressway Augusta, GA 30907 Copyright E2002 Electrolux Home Products, Inc. PP135 530163516 11/8/02...
-
Page 2: Safety Rules
Never use flailing de- vices with any attachment. This unit (when used with supplied line trimmer attachment) is designed for line trimmer use only. Use of any other accessories with line trimmer attach- ment will increase the risk of injury. - Page 3 Look for and repair fuel leaks before use. Keep in good working condition. S Replace trimmer head parts that are chipped, cracked, broken, or damaged in any other way before using the unit. S Maintain unit according to recommended procedures.
-
Page 4: Edger Safety
Blade can thrust violently away from material it does not cut. Blade thrust can cause amputation of arms or legs. WARNING: Do not use trimmer head as a fastening device for the blade. WARNING: The blade continues to spin after the throttle is released or engine is turned off. -
Page 5: Hedge Trimmer Safety
The tines become very sharp from use. S Do not run unit at high speed unless culti- vating. HEDGE TRIMMER SAFETY DANGER: RISK OF CUT; KEEP HANDS AWAY FROM BLADE -- Blade moves momentarily after the trigger is re- leased. - Page 6 WARNING: To prevent serious inju- ry, do not use more than one boom extension with a pole pruner attachment. WARNING: Keep the pruner away from power lines or electrical wires. S Only use for pruning limbs or branches up to 4 inches in diameter. S Do not operate the unit faster than the speed needed to prune.
-
Page 7: Adjusting The Handle
Knob TIGHTEN 2. Remove shipping protector from coupler. 3. Remove the tube cap from the trimmer at- tachment (if present). 4. Position locking/release button of attach- ment into guide recess of coupler. 5. Push the attachment into the coupler until the locking/release button snaps into the primary hole. -
Page 8: Operation
2-cycle air-cooled engine oil designed to be mixed at a ratio of 40:1. Poulan/Weed Eater brand synthetic oil is recommended. Mix gasoline and oil at a ratio of 40:1. A 40:1 ratio is obtained by mixing 3.2 ounces (95 ml) of oil... -
Page 9: Starting A Cold Engine
ON/OFF Switch HOW TO START YOUR UNIT WARNING: The trimmer head will turn while starting the engine. Avoid any contact with the muffler. A hot muf- fler can cause serious burns. STARTING A COLD ENGINE (or a warm engine after running out of... - Page 10 TRIMMER LINE ADVANCE The trimmer line will advance approximately 2 in. (5 cm) each time the bottom of the trimmer head is tapped on the ground with the engine running at full throttle. The most efficient line length is the maximum length allowed by the line limiter.
-
Page 11: Cutting Methods
S Tap the bottom of the trimmer head lightly on the ground one time. Approximately 2 inches (5 cm) of line will be advanced with each tap. Always tap the trimmer head on a grassy area. Tapping on surfaces such as concrete or asphalt can cause excessive wear to the trimmer head. -
Page 12: Maintenance
2. Clean entire surface of hub and spool. 3. Replace with a pre-wound spool, or cut two lengths of 12-1/2 feet of 0.080! (2 mm) di- ameter Poulan/Weed Eaterr brand line. WARNING: Never use wire, rope, string, etc., which can break off and become a dangerous missile. - Page 13 The carburetor has been carefully set at the factory. Adjustments may be necessary if you notice any of the following conditions: S Engine will not idle when the throttle is released. S The trimmer head moves/spins at idle. STORAGE WARNING: Perform the following steps after each use: S Allow engine to cool before storing or trans- porting.
-
Page 14: Troubleshooting Table
TROUBLESHOOTING TABLE WARNING: Always stop unit and disconnect spark plug before performing all of the recommended remedies below except remedies that require operation of the unit. TROUBLE CAUSE Engine will not 1. ON/OFF switch in start. OFF position. 2. Engine flooded. 3. -
Page 15: Limited Warranty
As the small off--road engine owner, you should be aware that POULAN/ WEED EATER may deny you warranty cover- age if your small off--road engine or a part of it has failed due to abuse, neglect, improper main-... - Page 16 PARTS: The use of add--on or modified parts can be grounds for disallowing a warranty claim. POULAN/WEED EATER is not liable to cover failures of warranted parts caused by the use of add--on or modified parts. HOW TO FILE A...
