Option
Service
LAN IPs
Start IP
End IP
SMCD3GN2 Wireless Cable Modem Gateway Administrator Manual
錯誤! 尚未定義樣式。
Figure 60. Predefined Filter Menu
Table 29. Predefined Filter Menu Options
List of predefined services from which you can choose.
Lets you apply the filter to any LAN IP addresses, a single LAN IP address, or a range of LAN
IP addresses.
If you select one LAN IP address, enter the IP address in the Start IP field.
•
• If you select a range of LAN IP addresses, enter the starting IP address in the Start IP field
and the ending IP address in the End IP field.
To apply the predefined filter to:
A single local IP address, enter the local IP address.
•
A range of local IP addresses, enter the starting IP address here and the ending IP address
•
range in the next field.
This field is unavailable if the Gateway is configured for any local IP addresses.
Ending IP address in the local IP address range to which the filter will be applied. This field is
unavailable if the Gateway is configured for any local IP address or a single local IP address.
119
Description
