IMPORTANT MANUAL
OPERATOR'S MANUAL
MODEL:
DRT65
REAR TINE TILLER
ALWAYS WEAR EYE PROTECTION DURING OPERATION
Visit our website: www.poulan-pro.com
Do Not Throw Away
WARNING:
Read this Man u al and follow all Warnings and
Safety Instructions. Fail ure to do so can re sult
in serious in ju ry.
401423 11.23.05 TR
Printed in U.S.A.
Advertisement
Table of Contents
Related Manuals for Poulan Pro 401423
Summary of Contents for Poulan Pro 401423
- Page 1 MODEL: DRT65 REAR TINE TILLER ALWAYS WEAR EYE PROTECTION DURING OPERATION Visit our website: www.poulan-pro.com Do Not Throw Away WARNING: Read this Man u al and follow all Warnings and Safety Instructions. Fail ure to do so can re sult in serious in ju ry.
-
Page 2: Safety Rules
• Always refer to the operator’s guide instructions for im por tant details if the tiller is to be stored for an ex- tended period. CAUTIONS, IMPORTANTS, AND NOTES ARE A MEANS OF ATTRACTING ATTENTION TO IMPORTANT OR CRIT I CAL IN FOR MA TION IN THIS MANUAL. -
Page 3: Table Of Contents
We have com pe tent, well-trained tech ni cians and the proper tools to service or repair this unit. Please read and retain this manual. The in struc tions will enable you to assemble and main tain your tiller prop erly. Always observe the “SAFETY RULES”. TABLE OF CONTENTS SAFETY RULES ...2... -
Page 4: Assembly
Your new tiller has been assembled at the factory with exception of those parts left unassembled for shipping purposes. To ensure safe and proper operation of your tiller all parts and hardware you assemble must be tightened securely. Use the correct tools as necessary to insure proper tightness. - Page 5 LOCK LEVER TO MOVE • Rotate handle assembly down. Insert rear carriage bolt fi rst, with bolt head on L.H. side of tiller and loosely assemble locknut (See Fig. 5). • Insert pivot bolt in front part of plate and tighten.
- Page 6 Tilt tiller forward by lifting handle. Separate cardboard cover from leveling shield. • Rotate tiller handle to the right and pull tiller out of carton. CHECK TIRE PRESSURE The tires on your unit were overinfl ated at the factory for shipping purposes.
-
Page 7: Operation
KNOW YOUR TILLER READ THIS OWNER'S MANUAL AND SAFETY RULES BEFORE OPERATING YOUR TILLER. Compare the illustrations with your tiller to familiarize yourself with the location of various controls and adjustments. Save this manual for future reference. These symbols may appear on your Tiller or in literature supplied with the product. Learn and understand their meaning. - Page 8 The operation of any tiller can result in foreign objects thrown into the eyes, which can result in severe eye damage. Always wear safety glasses or eye shields before starting your tiller and while tilling. We recommend a wide vision safety mask for over spectacles or standard safety glasses.
- Page 9 AROUND THE YARD • Release the depth stake pin. Move the depth stake down to the top hole for transporting the tiller. Place “LOCKED” depth stake pin in hole of depth stake to lock in posi- POSITION tion.
- Page 10 Loose, unpacked soil helps root growth. Best tilling depth is 4" to 6" (10-15 cm). A tiller will also clear the soil of unwanted vege ta tion. The de com po si tion of this vegetable mat ter enriches the soil.
-
Page 11: Operation
(See Fig. 16). • Do not lean on handle, this takes weight off the wheels, reduces traction, and may cause the tiller to skip over the ground. • Always lower the drag stake when using the for ward rotating tine drive. -
Page 12: Maintenance Schedule
2 - Service more often when operating in dirty or dusty conditions. GENERAL RECOMMENDATIONS The warranty on this tiller does not cover items that have been subjected to operator abuse or negligence. To receive full value from the warranty, the operator must main tain tiller as instructed in this manual. -
Page 13: Maintenance
Change the oil after every 25 hours of operation or at least once a year if the tiller is not used for 25 hours in one year. Check the crankcase oil level before starting the engine and after each fi... - Page 14 fl er, air fi l ter and car bu re tor are cov ered to keep wa ter out. Wa ter in en gine will short en the useful life of your tiller. •...
-
Page 15: Service & Adjustments
FIG. 24 TO REMOVE BELT GUARD (See Fig. 25) NOTE: For ease of removal, remove hairpin clip and clevis pin from left wheel. Pull wheel out from tiller about 1 inch. • Remove two (2) screws from side of belt guard. -
Page 16: Service And Adjustments
SERVICE AND ADJUSTMENTS TO REPLACE GROUND DRIVE BELT (See Figs. 25 and 26) • Remove belt guard as described in “TO REMOVE BELT GUARD”. • Remove old belt by slipping off engine pulley fi rst then remove from transmission pulley. •... - Page 17 A badly worn tine causes your tiller to work harder and dig more shallow. Most important, worn tines cannot chop and shred organic matter as effectively nor bury it as deeply as good tines.
-
Page 18: Service & Adjustments
SERVICE AND ADJUSTMENTS ENGINE TO ADJUST THROTTLE CONTROL CABLE (See Fig. 30) The throttle control has been preset at the factory and ad just ment should not be necessary. If adjustment is necessary, proceed as follows: • With engine not running, move remote throttle control lever to “FAST”... -
Page 19: Storage
Immediately prepare your tiller for storage at the end of the season or if the unit will not be used for 30 days or more. CAUTION: Never store the tiller with gasoline in the tank inside a build ing where fumes may reach an open fl ame or spark. -
Page 20: Troubleshooting
Briefl y engage drive control bar and release or rock tiller forward and back ward until are able to shift gears. Shift to either counter rotating till position or forward rotating till position. -
Page 21: Warranty
The Manufacturer warrants to the original consumer purchaser that this product as manufactured is free from de- fects in materials and work man ship. For a period of two (2) years from date of purchase by the original consumer purchaser, we will repair or replace, at our option, without charge for parts or labor incurred in replacing parts, any part which we fi... -
Page 22: Parts And Service
