Page 1 TABLE OF CONTENTS Adjusting and operating features such as door locks, mir- Before driving rors, and steering column. When driving Driving, stopping and safe-driving information. Air conditioning and audio systems, as well as other interior Interior features features for a comfortable driving experience. Maintenance Cleaning and protecting your vehicle, performing do-it-your- and care...
Page 2: Table Of Contents
TABLE OF CONTENTS Index For vehicles with a navigation system, refer to the “Navigation System Owner’ s Manual” for information regarding the equipment listed below. • Navigation system • Audio/video system • Air conditioning • Rear window and outside rear view •...
Page 3 2-4. Using other driving systems When driving Cruise control ........ 190 Dynamic radar cruise control..........194 2-1. Driving procedures Intuitive parking assist ....208 Driving the vehicle......138 Driving assist systems....214 Engine (ignition) switch ....147 Hill-start assist control ....220 Automatic transmission....
Page 4 TABLE OF CONTENTS Index ® 3-3. Using the Bluetooth Interior features audio system ® Bluetooth audio system ..303 ® 3-1. Using the air conditioning Using the Bluetooth audio system ........... 306 system and defogger ® Operating a Bluetooth Automatic air conditioning enabled portable player....
Page 5 3-6. Using the storage features Maintenance and care List of storage features....355 • Glove box ........356 • Console box........ 357 4-1. Maintenance and care • Cup holders........ 358 Cleaning and protecting • Auxiliary box ........ 361 the vehicle exterior....396 Cleaning and protecting 3-7.
Page 6 TABLE OF CONTENTS Index If your vehicle has to When trouble arises be stopped in an emergency........550 5-1. Essential information Vehicle specifications Emergency flashers....482 If your vehicle needs to be towed..........483 6-1. Specifications If you think something is Maintenance data wrong ..........
Page 7 Index Abbreviation list ........608 Alphabetical index........ 610 What to do if......... 622...
Page 8 Pictorial index Exterior Windshield wipers P. 182 Retractable hardtop P. 86 Hood P. 413 Outside rear view mirrors P. 79 Turn signal lights P. 158 Fog lights P. 180 Daytime Headlights P. 176 running lights P. 178 Turn signal lights P.
Page 9 Doors P. 47 Fuel filler door P. 95 Rear window defogger P. 251 Tail lights P. 176 Trunk P. 51 Side marker lights P. 176 Turn signal lights P. 158 Tires ●Rotation P. 431 ●Replacement P. 513, 522 ●Inflation pressure P.
Page 10 Pictorial index Interior AUX port P. 298 USB port P. 279, 287 Head restraints P. 67 Floor mat P. 373 SRS driver airbag P. 106 Seat belts P. 70 SRS knee airbags P. 106 SRS front passenger airbag P. 106 Front seats P.
Page 11 Anti-glare inside rear view mirror P. 78 Personal lights P. 354  “SOS” button P. 387 Garage door opener switches P. 377  Compass P. 383 Interior lights P. 354 Sun visors P. 362 Vanity mirrors P. 363  : If equipped...
Page 12 Pictorial index Interior  Driving position memory switches P. 61  Seat position memory switches P. 65 Outside rear view mirror switches P. 79 Window lock switch P. 82 Door lock switch P. 47 Power window switches P. 82...
Page 13 Automatic transmission shift lever P. 151  Seat heater/ventilator switches P. 371 Shift lock override button P. 526  Cigarette lighter P. 369  Ashtray P. 368  Auxiliary box P. 361  : If equipped...
Page 14 Pictorial index Instrument panel Headlight switch P. 176 Turn signal lever P. 158 Fog light switch P. 180 Shift paddle switches P. 155 Gauges and meters P. 161 Multi-information display P. 171 Windshield wiper and washer switch P. 182 Engine (ignition) switch P.
Page 15: Air Conditioning
Without navigation system (type A) Air conditioning system P. 242 Rear window and out- side rear view mirror Audio defoggers P. 251 system P. 253 Clock Security indicator P. 364 P. 98, 100 Emergency flasher switch P. 482 Without navigation system (type B) Air conditioning system P.
Page 16 Pictorial index Instrument panel With navigation system Rear window and outside rear view mirror defoggers Security indicator Navigation P. 98, 100 system Air conditioning Clock P. 364 system Audio system Emergency flasher switch P. 482...
Page 17 Telephone switch P. 326 “DISP” switch P. 172  Distance switch P. 194  Cruise control switch P. 190  Dynamic radar cruise control switch P. 194 Talk switch P. 326 ECT switch P. 152 Windshield wiper de-icer  switch P.
Page 18 Pictorial index Instrument panel  Headlight cleaner switch P. 189 Roof switch P. 86 All window control switch P. 82 Instrument panel light control dial P. 162 Satellite switches P. 365 VSC off switch P. 216 Fuel filler door opener P.
Page 19: For Your Information
All specifications provided in this manual are current at the time of printing. How- ever, because of the Lexus policy of continual product improvement, we reserve the right to make changes at any time without notice. Depending on specifications, the vehicle shown in the illustration may differ from your vehicle in terms of color and equipment.
Page 20 Dynamic radar cruise control system ● Anti-lock brake system ● SRS airbag system ● Seat belt pretensioner system ● Be sure to check with your Lexus dealer for precautionary measures or special instructions regarding installation of a mobile two-way radio system.
Page 21 ● Usage of data collected through Safety Connect/Lexus Enform (U.S. mainland only) If your Lexus has Safety Connect or Lexus Enform and if you have subscribed to those services, please refer to the Safety Connect/Lexus Enform Telematics Sub- scription Service Agreement for information on data collected and its usage.
Page 22: Event Data Recorder
Event data recorder This vehicle is equipped with an event data recorder (EDR). The main purpose of an EDR is to record, in certain crash or near crash-like situations, such as an air bag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle’...
Page 23 ● Disclosure of the EDR data Lexus will not disclose the data recorded in an EDR to a third party except when: • An agreement from the vehicle's owner (or the lessee for a leased vehicle) is obtained • In response to an official request by the police, a court of law or a government agency •...
Page 24 CAUTION General precautions while driving ■ Driving under the influence: Never drive your vehicle when under the influence of alcohol or drugs that have impaired your ability to operate your vehicle. Alcohol and certain drugs delay reaction time, impair judgment and reduce coordination, which could lead to an accident that could result in death or serious injury.
Page 25 This is a warning against anything which may cause damage to the vehicle or its equipment if the warning is ignored. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Lexus and its equipment. Symbols used in illustrations Safety symbol The symbol of a circle with a slash through it means “Do not”,...
Page 27: Before Driving
Before driving 1-1. Key information 1-4. Opening and closing the windows and retractable Keys..........28 hardtop Power windows......82 1-2. Opening, closing and Retractable hardtop ....86 locking the doors and trunk Smart access system with 1-5. Refueling push-button start....32 Opening the fuel tank cap ..
Page 28: Keys
1-1. Key information Keys The following keys are provided with the vehicle. Electronic keys • Operating the smart access system with push-button start (P. 32) • Operating wireless remote control function (P. 44) Mechanical keys Key number plate ■ Card key (if equipped) Electronic key Operating the smart access sys- tem with push-button start...
Page 29 1-1. Key information Using the mechanical key Take out the mechanical key. The mechanical key can only be inserted in one direction, as the key only has grooves on one side. If the key cannot be inserted in a lock cylinder, turn it over and re-attempt to insert it.
Page 30 Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a mechanical key is lost, a new key can be made at your Lexus dealer using the key number plate. (P. 527) When riding in an aircraft ■...
Page 31 (To remove the battery cover, lightly grasp it and pull.) If the battery is corroded, have your Lexus dealer replace the battery. Do not crush the battery cover or use a screwdriver to remove the battery cover.
Page 32: 1-2. Opening, Closing And Locking The Doors And Trunk
1-2. Opening, closing and locking the doors and trunk Smart access system with push-button start The following operations can be performed simply by carrying the elec-  tronic key (including the card key ) on your person, for example in your pocket.
Page 33 1-2. Opening, closing and locking the doors and trunk Unlocking and locking the doors Grip the driver’ s door handle to unlock the door. Grip the passen- ger’ s door handle to unlock all the doors.* Make sure to touch the sensor on the back of the handle.
Page 34 1-2. Opening, closing and locking the doors and trunk Antenna location and effective range ■ Antenna location Antennas outside cabin Antennas inside cabin Antenna inside trunk Antenna outside trunk...
Page 35 1-2. Opening, closing and locking the doors and trunk ■ Effective range (areas within which the electronic key is detected) When locking or unlocking the doors The system can be operated when the electronic key is out- side the vehicle, within about 2.3 ft.
Page 36 1-2. Opening, closing and locking the doors and trunk Operation signals ■ A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: Once; Unlocked: Twice) Conditions affecting operation ■ The smart access system with push-button start uses weak radio waves. In the fol- lowing situations, the communication between the electronic key and the vehicle may be affected, preventing the smart access system with push-button start from operating properly:...
Page 37 1-2. Opening, closing and locking the doors and trunk Switching the door unlock function ■ It is possible to set which doors the entry function unlocks. Turn the “ENGINE START STOP” switch OFF. STEP When the indicator on the key surface is turned off, push and STEP hold for approximately 5 seconds while pushing...
Page 38 1-2. Opening, closing and locking the doors and trunk Battery-saving function ■ In the following circumstances, the entry function is disabled in order to prevent the vehicle and electronic key batteries from discharging. When the entry function has not been used for a month or more ●...
Page 39 1-2. Opening, closing and locking the doors and trunk To operate the system properly ■ Make sure to carry the electronic key when operating the system. Actions such ● as locking and unlocking the doors cannot be performed from outside the vehi- cle if the electronic key is inside the vehicle, even when the retractable hardtop is open.
Page 40 1-2. Opening, closing and locking the doors and trunk If the wireless remote control is used to lock the doors when the electronic key ● is near the vehicle, there is a possibility that the door may not be unlocked by the entry function.
Page 41 When the electronic key battery is fully depleted ■ P. 449 Customization that can be configured at Lexus dealer ■ It is possible to deactivate the operation signals of the system, such as the emer- gency flashers. (Customizable features P. 586)
Page 42 1-2. Opening, closing and locking the doors and trunk Certification for the smart access system with push-button start ■ For vehicles sold in the U.S.A. FCC ID: NI4TMLF-1 NOTE: This device complies with part 15 of the FCC Rules. Operation is subject to the fol- lowing two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 43 The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Lexus dealer for details, such as the frequency of radio waves and timing of emitting the radio waves. Then, consult your doctor to see if you should disable the entry function.
Page 44: Wireless Remote Control
(push and hold) Sounds alarm (push and hold) (P. 45) *: This setting must be customized at your Lexus dealer. Operation signals ■ Doors: A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: Once; Unlocked: Twice) Trunk: A buzzer sounds to indicate that the trunk has been unlocked.
Page 45 P. 40 When the electronic key battery is fully depleted ■ P. 449 Conditions affecting operation ■ P. 36 Customization that can be configured at Lexus dealer ■ Settings (e.g. trunk unlocking function) can be changed. (Customizable features P. 586)
Page 46 1-2. Opening, closing and locking the doors and trunk Certification for wireless remote control ■ For vehicles sold in the U.S.A. FCC ID: HYQ14ABK FCC ID: HYQ14AEM FCC ID: HYQ14ABS FCC ID: HYQ14ABB FCC ID: HYQ13BZW FCC ID: HYQ13BZH NOTE: This device complies with part 15 of the FCC Rules.
Page 47: Doors
1-2. Opening, closing and locking the doors and trunk Doors The vehicle can be locked and unlocked using the entry function, wireless remote control or door lock switch. ■ Entry function P. 33 ■ Wireless remote control P. 44 ■ Door lock switch Locks both side doors Unlocks both side doors...
Page 48 1-2. Opening, closing and locking the doors and trunk Locking the doors from the outside without a key The door cannot be locked if the “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode, or the electronic key is left inside the vehicle.
Page 49 1-2. Opening, closing and locking the doors and trunk ■ Setting and canceling the functions To switch between setting and canceling, follow the procedure below: Close both side doors and switch the “ENGINE START STOP” STEP switch to IGNITION ON mode. (Perform the step 2 within 20 seconds.) Shift the shift lever to P or N, press STEP...
Page 50 Using the mechanical key ■ The doors can also be locked and unlocked with the mechanical key. (P. 528) Customization that can be configured at Lexus dealer ■ Settings (e.g. unlocking function using a key) can be changed. (Customizable features P. 586)
Page 51: Trunk
1-2. Opening, closing and locking the doors and trunk Trunk The trunk can be opened using the trunk opener, entry function or wireless remote control. ■ Opening the trunk from inside the vehicle Press the opener switch. ■ Opening the trunk from outside the vehicle Entry function P.
Page 52 1-2. Opening, closing and locking the doors and trunk Trunk light ■ When the trunk light switch is set to on, the trunk light turns on when the trunk is opened. Trunk handle ■ Use the trunk handle when closing the trunk. Internal trunk release lever ■...
Page 53 1-2. Opening, closing and locking the doors and trunk Which key to the vehicle is to leave with a parking attendant after disabling the ■ trunk opener main switch P. 30 CAUTION Caution while driving ■ Keep the trunk lid closed while driving. ●...
Page 54 Do not attach any accessories other than genuine Lexus parts to the trunk lid. ● Such additional weight on the trunk lid may cause the lid to suddenly shut again...
Page 55: Adjustable Components
1-3. Adjustable components (seats, mirrors, steering wheel) Front seats Type A Type B Seat position switch Seatback angle switch Seat cushion (front) angle switch Vertical height adjustment switch Lumbar support switch Seatback fold lever Entering or exiting the rear seats...
Page 56 1-3. Adjustable components (seats, mirrors, steering wheel) Entering/exiting the rear seats Type A  Switch-operated “Front, Fold & Return” Seat Moving the front seat forward or backward using the switch enables passengers to enter or exit the rear seats smoothly and easily. ■...
Page 57 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Returning the front seats to the original position (auto return func- tion) Press the return switch once. The seatback of the front seat will return to the upright position and the seat will move backward. For safety reasons, if the front seat was originally positioned close to the rear seat, the seat will be...
Page 58 1-3. Adjustable components (seats, mirrors, steering wheel) Type B  Seat slide switches (passenger’ s seat only) Press and hold the switch to move STEP the seat forward. Fold the seatback using either of STEP the seatback fold levers.
Page 59 1-3. Adjustable components (seats, mirrors, steering wheel) Switch-operated “Front, Fold & Return” Seat ■ When the auto return function is on, a buzzer will sound intermittently while the ● switch-operated “Front, Fold & Return” seat is in motion. If any seat adjustment switch or driving position memory switch is operated ●...
Page 60 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION Seat adjustment ■ Do not recline the seat more than necessary when the vehicle is in motion to reduce the risk of sliding under the lap belt. If the seat is too reclined, the lap belt may slide past the hips and apply restraint forces directly to the abdomen or your neck may contact the shoulder belt, increas- ing the risk of death or serious injury in the event of an accident.
Page 61: Driving Position Memory
1-3. Adjustable components (seats, mirrors, steering wheel)  Driving position memory (driver’s seat) Your preferred driving position (the position of the driver's seat, steering wheel and outside rear view mirrors) can be memorized and recalled with the touch of a button. It is also possible to set this function to activate auto- matically when the doors are unlocked.
Page 62 1-3. Adjustable components (seats, mirrors, steering wheel) Linking driving position memory with door unlock operation Record your driving position to button “1”, “2” or “3” before performing the following. Using the wireless remote control Close the driver's door and turn the “ENGINE START STOP” STEP switch OFF.
Page 63 1-3. Adjustable components (seats, mirrors, steering wheel) Using the door lock switch  Carry only the key (including the card key ) to which you want to link the driving position. If 2 or more keys are in the vehicle, the driving position cannot be linked properly.
Page 64 1-3. Adjustable components (seats, mirrors, steering wheel) Canceling the linked door unlock operation ■ Close the driver's door and turn the “ENGINE START STOP” switch STEP OFF. Using the wireless remote control: While pushing the “SET” button, press STEP on the wireless remote control until the signal beeps. Using the door lock switch: While pressing the “SET”...
Page 65: Seat Position Memory
1-3. Adjustable components (seats, mirrors, steering wheel)  Seat position memory (front passenger’s seat) Your preferred front passenger seat position can be memorized and recalled with the touch of a button. Three different seat positions can be entered into memory. ■...
Page 66 1-3. Adjustable components (seats, mirrors, steering wheel) Operating the seat position memory after turning the “ENGINE START STOP” ■ switch OFF Memorized position can be activated up to 180 seconds after the front passenger door is opened, even after turning the “ENGINE START STOP” switch OFF. To cancel seat position recall ■...
Page 67: Head Restraints
1-3. Adjustable components (seats, mirrors, steering wheel) Head restraints Head restraints are provided for all seats. Vertical adjustment (front seats) Pull the head restraints up. Down Push the head restraint down while pushing the lock release Lock release button button. Folding operation (rear seats) Pull the lever.
Page 68 1-3. Adjustable components (seats, mirrors, steering wheel) Removing the head restraints (front seats) ■ Pull the head restraint up while pressing the lock release button. Installing the head restraints (front seats) ■ Align the head restraint with the installation holes and push it down to the lock position. Press and hold the lock release button when lowering the head restraint.
Page 69 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION Observe the following precautions when the head restraints are in use. Failure to do so may result in death or serious injury. Front head restraints ■ Use the head restraints designed for each respective seat. ●...
Page 70: Seat Belts
1-3. Adjustable components (seats, mirrors, steering wheel) Seat belts Make sure that all occupants are wearing their seat belts before driving the vehicle. ■ Correct use of the seat belts ● Extend the shoulder belt so that it comes fully over the shoulder, but does not come into contact with the neck or slide off the shoulder.
Page 71 1-3. Adjustable components (seats, mirrors, steering wheel) Front seat belt guide When fastening a front seat belt, always ensure that it passes through the seat belt guide. When entering or exiting the rear seats, release the seat belt from the guide. Rear seat belt holder &...
Page 72 1-3. Adjustable components (seats, mirrors, steering wheel) Seat belt pretensioners (front seats) The pretensioner helps the seat belt to quickly restrain the occu- pant by retracting the seat belt when the vehicle is subjected to certain types of severe frontal colli- sion.
Page 73 Seat belt extender ■ If your seat belts cannot be fastened securely because they are not long enough, a person- alized seat belt extender is available from your Lexus dealer free of charge.
Page 74 Each seat belt should be used by one person only. Do not use a seat belt for more ● than one person at once, including children. Lexus recommends that children be seated in the rear seat and always use a seat ● belt and/or an appropriate child restraint system.
Page 75 Ensure that the belt and tab are locked and the belt is not twisted. ● If the seat belt does not function correctly, immediately contact your Lexus dealer. Replace the seat assembly, including the belts, if your vehicle has been involved in ●...
Page 76: Steering Wheel
1-3. Adjustable components (seats, mirrors, steering wheel) Steering wheel The steering wheel can be adjusted to a comfortable position. Down Away from the driver Toward the driver Auto tilt away When the “ENGINE START STOP” switch is turned OFF, the steering wheel returns to its stowed position by moving up and away to enable easier driver entry...
Page 77 A desired steering position can be entered to memory and recalled automatically by the driving position memory. (P. 61) Customization that can be configured at Lexus dealer ■ It is possible to deactivate the auto tilt-away function. (Customizable features P. 586)
Page 78: Anti-Glare Inside Rear View Mirror
1-3. Adjustable components (seats, mirrors, steering wheel) Anti-glare inside rear view mirror In automatic mode, sensors are used to detect the headlights of vehicles behind and automatically reduce the reflected light. Turns automatic mode on/off The indicator comes on when automatic mode is turned on.
Page 79: Outside Rear View Mirrors
1-3. Adjustable components (seats, mirrors, steering wheel) Outside rear view mirrors Mirror angle can be adjusted using the switch. Select a mirror to adjust (“L”: left or “R”: right) Adjust the mirror up, down, in, or out using the switch The mirrors can be adjusted when ■...
Page 80 1-3. Adjustable components (seats, mirrors, steering wheel) Linked mirror function when reversing (vehicles with driving position memory) ■ The outside rear view mirrors will automatically angle downwards when the vehicle is reversing in order to give a better view of the ground. However, this function will not operate when the mirror select switch is in the neutral position (between “L”...
Page 81 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION When driving the vehicle ■ Observe the following precautions while driving. Failing to do so may result in loss of control of the vehicle and cause an accident, resulting in death or serious injury. Do not adjust the mirrors while driving.
Page 82: Opening And Closing The Windows And Retractable Hardtop Power Windows
1-4. Opening and closing the windows and retractable hardtop Power windows The power windows can be opened and closed using the following switches. Using the individual window switches Closing One-touch closing (front windows) Opening One-touch opening : To stop the window partway, operate the switch in the oppo- site direction.
Page 83 1-4. Opening and closing the windows and retractable hardtop Lock switch Press the switch down to lock the passenger window switches. Use this switch to prevent children from accidentally opening or clos- ing a passenger window. The power windows can be operated when ■...
Page 84 If you release the switch while the window is moving, start again from the beginning. If the window continues to close but then re-open slightly even after performing the above procedure correctly, have the vehicle inspected by your Lexus dealer. Window operation during retractable hardtop operation ■...
Page 85 1-4. Opening and closing the windows and retractable hardtop CAUTION Closing the windows ■ Observe the following precautions. Failing to do so may result in death or serious injury. Check to make sure that all passengers do not have any part of their body in a ●...
Page 86: Retractable Hardtop
1-4. Opening and closing the windows and retractable hardtop Retractable hardtop The retractable hardtop can be opened and closed using a switch. Opening the retractable hardtop Press and hold the switch until “COMPLETE” is shown on the dis- play. The side windows will open as retractable hardtop operation is performed. A buzzer will sound when operation is complete.
Page 87 1-4. Opening and closing the windows and retractable hardtop Luggage cover The luggage cover is used to ensure that there is enough space for the retractable hardtop to be stored. Proper installation of the luggage cover enables retractable hardtop operation. Pull the board of the luggage STEP cover toward you to unhook the...
Page 88 1-4. Opening and closing the windows and retractable hardtop Retractable hardtop status display Information regarding the retractable hardtop is shown on the multi- information display. ■ Roof Function Status Indicator This indicator shows the operation status of the retractable hardtop. Operation without interruption During operation The bar display shows the progress of the operation of the retractable...
Page 89 1-4. Opening and closing the windows and retractable hardtop Operation with interruption During operation The bar display shows the progress of the operation of the retractable hardtop. Interruption of operation Operation of the retractable hardtop will be suspended if the switch is released, the operating conditions are no longer met or there is a mal- function.
Page 90 1-4. Opening and closing the windows and retractable hardtop Retractable hardtop operation control linked to the intuitive parking assist (vehicles with an intuitive parking assist) This function detects if there is an obstruction behind the vehicle and reg- ulates retractable hardtop operation according to the vehicle’ s distance from that obstruction.
Page 91 1-4. Opening and closing the windows and retractable hardtop ● If an obstruction is detected in area when the switch is oper- ated A buzzer will sound twice and a message will be shown in the multi- information display. Retractable hardtop operation will not activate. If the switch is released and then operated again within 2 seconds, the buzzer will sound again and a message will be shown in the multi-information display to alert the driver.
Page 92 6 seconds or more. In this case, retractable hardtop operation control linked to the intuitive parking assist-sensor will not function. Customization that can be configured at a Lexus dealer ■ Setting of the intuitive parking assist linked function can be changed.
Page 93 1-4. Opening and closing the windows and retractable hardtop CAUTION When opening or closing the retractable hardtop ■ Observe the following precautions. Failure to do so may result in death or serious injury. Check to make sure that all passengers do ●...
Page 94 1-4. Opening and closing the windows and retractable hardtop NOTICE Precautions for opening/closing the retractable hardtop ■ Before operating the retractable hardtop, make sure that the areas 2.3 ft. (70 ● cm) above the roof and 1.2 ft. (35 cm) behind the rear bumper is clear of obstruc- tions.
Page 95: 1-5. Refueling
1-5. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap. ■ Before refueling the vehicle Turn the “ENGINE START STOP” switch OFF and ensure that both side doors and windows are closed. ■ Opening the fuel tank cap Press the opener switch.
Page 96 1-5. Refueling Closing the fuel tank cap When replacing the fuel tank cap, turn it until a clicking sound is heard. After releasing your hand, the cap will turn slightly to the opposite direction. Fuel types ■ Use unleaded gasoline. (Octane rating 91 [Research Octane Number 96] or higher) Fuel tank capacity (reference) ■...
Page 97 When replacing the fuel cap ■ Do not use anything but a genuine Lexus fuel tank cap designed for your vehicle. Failure to do so may cause a fire or other incident which may result in death or seri- ous injury.
Page 98: Theft Deterrent System Engine Immobilizer System
1-6. Theft deterrent system Engine immobilizer system The vehicle's keys have built-in transponder chips that prevent the engine from starting if the key has not been previously registered in the vehicle's on-board computer. Never leave the keys inside the vehicle when you leave the vehicle. The indicator light flashes after the “ENGINE START STOP”...
Page 99 1-6. Theft deterrent system Certifications for the engine immobilizer system ■ For vehicles sold in the U.S.A. FCC ID: NI4TMIMB-1 This device complies with part 15 of the FCC Rules. Operation is subject to the fol- lowing two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 100: Alarm
1-6. Theft deterrent system Alarm The system sounds the alarm and flashes the lights when forcible entry is detected. ■ Triggering of the alarm The alarm is triggered in the following situations when the alarm is set. ● A locked door or trunk is unlocked or opened in any way other than using the entry function, wireless remote door lock function or mechanical key.
Page 101 1-6. Theft deterrent system System maintenance ■ The vehicle has a maintenance-free type alarm system. Items to check before locking the vehicle ■ To prevent unexpected triggering of the alarm and vehicle theft, make sure of the following. Nobody is in the vehicle. ●...
Page 102 1-6. Theft deterrent system When the battery is disconnected ■ Be sure to deactivate the alarm system. If the battery is disconnected before deactivating the alarm system, the alarm may be triggered when the battery is reconnected. Alarm-operated door lock ■...
Page 103: Theft Prevention Labels
1-6. Theft deterrent system Theft prevention labels (U.S.A.) These labels are attached to the vehicle to reduce vehicle theft by facilitating the tracing and recovery of parts from stolen vehicles. Do not remove under penalty of law.
Page 104: 1-7. Safety Information
1-7. Safety information Correct driving posture Drive in a good posture as follows: Sit upright and well back in the seat. (P. 55) Adjust the position of the seat forward or backward to ensure the pedals can be reached easily depressed to the extent required.
Page 105 1-7. Safety information CAUTION While driving ■ Do not adjust the position of the driver’ s seat while driving. ● Doing so could cause the driver to lose control of the vehicle. Do not place a cushion between the driver or passenger and the seatback. ●...
Page 106: Srs Airbags
1-7. Safety information SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury.
Page 107 1-7. Safety information Airbag system components Knee airbags Driver's seat belt buckle switch Front passenger airbag Driver's seat position sensor “AIR BAG ON” and “AIR BAG Front passenger’ s seat belt OFF” indicator lights buckle switch Side airbags Airbag sensor assembly Side airbag sensors Front passenger...
Page 108 1-7. Safety information SRS warning light ■ This warning light system monitors the airbag sensor assembly, front airbag sensors, side airbag sensor assemblies, driver's seat position sensor, driver's seat belt buckle switch, front passenger occupant classification system (ECU and sensors), “AIR BAG ON”...
Page 109 1-7. Safety information Depending on the type of collision, it is possible that only the seat belt preten- ● sioners will activate. The SRS front airbags for the front passenger will not activate if there is no pas- ● senger sitting in the front passenger seat. However, the SRS front airbags for the front passenger may deploy if luggage is put in the seat, even if the seat is unoc- cupied.
Page 110 1-7. Safety information Types of collisions that may not deploy the SRS airbag (SRS front airbags) ■ The SRS front airbags are generally not designed to inflate if the vehicle is involved in a side or rear collision, if it rolls over, or if it is involved in a low-speed frontal colli- sion.
Page 111 1-7. Safety information When to contact your Lexus dealer ■ In the following cases, contact your Lexus dealer as soon as possible. Any of the SRS airbags have been inflated. ● The front of the vehicle is damaged or ●...
Page 112 1-7. Safety information CAUTION SRS airbag precautions ■ Observe the following precautions regarding the airbags. Failure to do so may cause death or serious injury. The driver and all passengers in the vehicle must wear their seat belts properly. ● The SRS airbags are supplemental devices to be used with the seat belts.
Page 113 An infant or child who is too small to use a seat belt should be properly secured using a child restraint system. Lexus strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained.
Page 114 1-7. Safety information CAUTION SRS airbag precautions ■ Do not sit on the edge of the seat or lean ● against the dashboard. Do not allow a child to stand in front of the ● SRS front passenger airbag unit or sit on the knees of a front passenger.
Page 115 Wash off any residue as soon as possible to prevent skin irritation. If the areas where the SRS airbags are stored, such as the steering wheel pad, are ● damaged or cracked, have them replaced by your Lexus dealer.
Page 116 Modification and disposal of SRS airbag system components ■ Do not dispose of your vehicle or perform any of the following modifications with- out consulting your Lexus dealer. The SRS airbag may malfunction or deploy (inflate) accidentally, causing death or serious injury.
Page 117: Front Passenger Occupant Classification System
1-7. Safety information Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classification sys- tem. This system detects the conditions of the front passenger seat and activates or deactivates the devices for front passenger. SRS warning light “AIR BAG OFF”...
Page 118 1-7. Safety information Condition and operation in the front passenger occupant classification system ■ Adult “AIR BAG ON” and “AIR BAG OFF” “AIR BAG indicator lights ON” Indicator/ SRS warning light warning light Front passenger’ s seat belt reminder light Flashing Front passenger airbag Side airbag on the front...
Page 119 1-7. Safety information ■ Unoccupied “AIR BAG ON” and “AIR BAG OFF” Not illuminated indicator lights Indicator/ warning light SRS warning light Front passenger’ s seat belt reminder light Front passenger airbag Deactivated Side airbag on the front Activated passenger seat Devices Front passenger knee airbag Deactivated...
Page 120 1-7. Safety information : Never install a rear facing child restraint system on the front passen- ger seat. A forward facing child restraint system should only be installed on the front passenger seat when it is unavoidable. (P. 122) : In case the indicator is not illuminated, consult this manual as for installing the child restraint system properly.
Page 121 ● the SRS warning light may come on to indicate a malfunction of the detection sys- tem. In this case, contact your Lexus dealer immediately. Child restraint systems installed on the rear seat should not contact the front seat- ●...
Page 122: Child Restraint Systems
1-7. Safety information Child restraint systems A child restraint system for a small child or baby must itself be properly restrained on the seat with the lap portion of the lap/shoulder belt. The laws of all 50 states of the U.S.A. and Canada now require the use of child restraint systems.
Page 123 1-7. Safety information Forward facing  Convertible seat Booster seat Selecting an appropriate child restraint system ■ Use a child restraint system appropriate for the child until the child becomes ● large enough to properly wear the vehicle’ s seat belt. If a child is too large for a child restraint system, sit the child on a rear seat and ●...
Page 124 CAUTION Child restraint precautions ■ Lexus strongly urges the use of a proper child restraint system that conforms to ● the size of the child, installed on the rear seat. According to accident statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Page 125 1-7. Safety information CAUTION When children are in the vehicle ■ Do not allow children to play with the seat belt. If the seat belt becomes twisted around a child’ s neck, it may lead to choking or other serious injuries that could result in death.
Page 126: Installing Child Restraints
1-7. Safety information Installing child restraints Follow the child restraint system manufacturer's instructions. Firmly secure child restraints to the rear seats using the LATCH anchors or a seat belt. Attach the top tether strap when installing a child restraint. The lap/shoulder belt can be used if your child restraint system is not com- patible with the LATCH (Lower Anchors and Tethers for Children) system.
Page 127 1-7. Safety information Installation with LATCH system Type A Latch the hooks of the STEP lower straps onto the LATCH anchors. If the child restraint has a STEP top tether strap, the top tether strap should be latched onto the top tether strap anchors.
Page 128 1-7. Safety information Type B Latch the buckles onto the STEP LATCH anchors. If the child restraint has a STEP top tether strap, the top tether strap should be latched onto the top tether strap anchors. For owners in Canada: The symbol on a child restraint sys- tem indicates the presence of a lower connector system.
Page 129 1-7. Safety information Installing child restraints using a seat belt (child restraint lock function belt) Rear facing Infant seat/convertible seat ■ Place the child seat on the rear STEP seat facing the rear of the vehicle. Run the seat belt through the child STEP seat and insert the plate into the buckle.
Page 130 1-7. Safety information While pushing the child seat down STEP into the rear seat, allow the shoul- der belt to retract until the child seat is securely in place. After the shoulder belt has retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
Page 131 1-7. Safety information While pushing the child seat into STEP the rear seat, allow the shoulder belt to retract until the child seat is securely in place. After the shoulder belt has retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
Page 132 1-7. Safety information Removing a child restraint installed with a seat belt Push the buckle release button and fully retract the seat belt. Child restraint systems with a top tether strap Secure the child restraint using a STEP seat belt or the lower anchors.
Page 133 1-7. Safety information Pass the end of the top tether strap STEP through the gap between the seat and the head restraint. Fold the head restraint forward into the stowed position. (P. 67) Open the anchor bracket cover, latch the hook onto the anchor bracket and tighten the top tether strap.
Page 134 1-7. Safety information CAUTION When installing a booster seat ■ Do not fully extend the shoulder belt to prevent the belt from going to ALR lock mode: (P. 72) ALR mode causes the belt to tighten only which could cause injury or discomfort to the child.
Page 135 1-7. Safety information CAUTION When installing a child restraint system ■ When a booster seat is installed, always ensure that the shoulder belt is posi- ● tioned across the center of the child's shoulder. The belt should be kept away from the child's neck, but not so that it could fall off the child's shoulder.
Page 136 1-7. Safety information...
Page 137: When Driving
When driving 2-1. Driving procedures 2-4. Using other driving systems Driving the vehicle....138 Cruise control......190 Engine (ignition) switch..147 Dynamic radar cruise Automatic transmission ..151 control ........194 Turn signal lever....... 158 Intuitive parking assist..208 Parking brake......159 Driving assist systems....
Page 138: Driving The Vehicle
2-1. Driving procedures Driving the vehicle The following procedures should be observed to ensure safe driving. ■ Starting the engine (P. 147) ■ Driving With the brake pedal depressed, shift the shift lever to D. STEP (P. 151) Release the parking brake. (P.
Page 139 Your vehicle has a drum-in-disc type parking brake system. This type of brake sys- tem needs bedding-down of the brake shoes periodically or whenever the parking brake shoes and/or drum are replaced. Have your Lexus dealer perform the bed- ding down.
Page 140 Large amounts of exhaust in the vehicle can cause driver drowsiness and an accident, resulting in death or a serious health hazard. Have the vehicle inspected by your Lexus dealer immediately. Do not shift the shift lever to P while the vehicle is moving.
Page 141 2-1. Driving procedures CAUTION Do not shift the shift lever to R while the vehicle is moving forward. ● Doing so can damage the transmission and may result in a loss of vehicle control. Do not shift the shift lever to D while the vehicle is moving backward. ●...
Page 142 If you hear a squealing or scraping noise (brake pad wear limit indicators) ■ Have your Lexus dealer check and replace the brake pads as soon as possible. The rotor damage can result if the pads are not replaced when needed.
Page 143 2-1. Driving procedures CAUTION If the vehicle is stopped on an incline, in order to prevent accidents caused by the ● vehicle rolling forward or backward, always depress the brake pedal and securely apply the parking brake as needed. Avoid revving or racing the engine. ●...
Page 144 Lexus dealer. Failure to do so may allow exhaust gases to enter the vehicle, resulting in death or a serious health hazard.
Page 145 2-1. Driving procedures NOTICE When driving the vehicle ■ Do not depress the accelerator and brake pedals at the same time during driving, ● as this may restrain driving torque. Do not use the accelerator pedal or depress the accelerator and brake pedals ●...
Page 146 Engine damage caused by water immersion ● In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Lexus dealer check the following. Brake function ● Changes in quantity and quality of oil and fluid used for the engine, transmission, ●...
Page 147: Engine (Ignition) Switch
2-1. Driving procedures Engine (ignition) switch Performing the following operations when carrying the electronic key on your person starts the engine or changes “ENGINE START STOP” switch modes. ■ Starting the engine Check that the parking brake is set. STEP Check that the shift lever is set in P.
Page 148 2-1. Driving procedures ■ Changing “ENGINE START STOP” switch mode Modes can be changed by pressing the “ENGINE START STOP” switch with the brake pedal released. (The mode changes each time the switch is pressed.) OFF* Emergency flashers can be used.
Page 149 “ENGINE START STOP” switch again while turning the steering wheel left and right. When the “ENGINE START STOP” switch indicator flashes in amber ■ The system may be malfunctioning. Have the vehicle inspected by your Lexus dealer immediately. Auto power off function ■...
Page 150 2-1. Driving procedures CAUTION When starting the engine ■ Always start the engine while sitting in the driver’ s seat. Do not press the accelera- tor while starting the engine under any circumstances. Doing so may cause an accident resulting in death or serious injury. Stopping the engine in an emergency ■...
Page 151: Automatic Transmission
2-1. Driving procedures Automatic transmission Select a shift position appropriate for the driving conditions. ■ Shifting the shift lever While the “ENGINE START STOP” switch is in IGNITION ON mode, depress the brake pedal and move the shift lever. ■ Shift position uses Shift position Function...
Page 152 2-1. Driving procedures ■ Selecting a driving mode The following patterns can be selected to suit current driving and operating conditions. Power mode For powerful acceleration and driving in mountainous regions. Normal mode Snow mode For accelerating and driving on slippery road surfaces, such as on snow.
Page 153 2-1. Driving procedures Selecting shift ranges in the D position To drive using temporary shift range selection, operate the “-” shift paddle switch. The shift range can then be selected by operating the “-” and “+” shift paddle switches. Changing the shift range allows restriction of the upper limit of the gears to be used, preventing unnecessary upshifting and enabling the level of engine braking force to be selected.
Page 154 2-1. Driving procedures ■ Shift ranges and their functions Shift range Function Automatically selecting gears between 1 and 6 according to vehicle speed and driving conditions. Automatically selecting gears between 1 and 5 according to vehicle speed and driving conditions. Automatically selecting gears between 1 and 4 according to vehicle speed and driving conditions.
Page 155 2-1. Driving procedures Changing shift ranges in S mode To enter S mode, shift the shift lever to the S position. The shift range can then be selected by operating the “-” and “+” shift paddle switches or the shift lever. Changing the shift range allows restriction of the upper limit of the gears to be used, preventing unnecessary upshifting and enabling the level of engine braking force to be selected.
Page 156 2-1. Driving procedures When the “-” shift paddle switch is operated in the D position ■ When the “-” shift paddle switch is operated in the D position, a shift range will be automatically selected. The highest gear of the first shift range will be one gear lower than the gear in use during normal D position driving.
Page 157 S ■ This may indicate a malfunction in the automatic transmission system. Have the vehicle inspected by your Lexus dealer immediately. (In this situation, the vehicle will operate as if the shift lever is in D.) AI-SHIFT ■...
Page 158: Turn Signal Lever
2-1. Driving procedures Turn signal lever Right turn Left turn Move and hold the lever part- way to signal a lane change The right hand signal will flash until you release the lever. Move and hold the lever part- way to signal a lane change The left hand signal will flash until you release the lever.
Page 159: Parking Brake
2-1. Driving procedures Parking brake Sets the parking brake (Depressing the pedal again releases the parking brake.) U.S.A. Canada : Fully depress the parking brake pedal with your left foot while depressing the brake pedal with your right foot. Usage in winter time ■...
Page 160: Horn
2-1. Driving procedures Horn To sound the horn, press on or close to the mark.
Page 161: Instrument Cluster Gauges And Meters
2-2. Instrument cluster Gauges and meters The units used on the speedometer and the tachometer gauge display may differ depending on the model/type. The following gauges, meters and display illuminate when the “ENGINE START STOP” switch is in IGNITION ON mode. Speedometer Displays the vehicle speed.
Page 162 2-2. Instrument cluster Odometer and trip meter Odometer: Displays the total distance the vehicle has been driven. Trip meter: Displays the distance the vehicle has been driven since the meter was last reset. Trip meters “A” and “B” can be used to record and display different distances indepen- dently.
Page 163 2-2. Instrument cluster Speed and tacho indicators ■ Turning the indicator on/off Bring up the satellite switch mode STEP on the multi-information display.   Press “ ”, “ ” or the “ON/OFF” button. Select the item whose setting is to STEP be changed.
Page 164 2-2. Instrument cluster ■ Changing the indicator setting The satellite switch can be used to change the set speed at which the yellow speed or tacho indicator ring comes on. The setting can be made only when the “ENGINE START STOP” switch is in IGNITION ON mode and the vehicle is stopped.
Page 165 2-2. Instrument cluster STEP   Push “ ” or “ ” within 6 seconds of the speedometer or tachometer nee- dle moving to change the setting of the desired speed, then turn the indi- cator mode to “ON” by pushing the “ON/OFF” button. Pushing and holding the button changes values at a faster rate.
Page 166 2-2. Instrument cluster Speed indicator display conditions and vehicle speed setting range ■ Vehicle speed setting range: Approximately 30 to 100 mph (approximately 50 to 160 km/h) When the maximum speed is selected, the speed indicator comes on only in red. Tacho indicator display conditions and engine speed setting range ■...
Page 167: Indicators And Warning Lights
2-2. Instrument cluster Indicators and warning lights The indicator and warning lights on the instrument cluster and center panel inform the driver of the status of the vehicle’s various systems. Instrument cluster The units used on the speedometer and the tachometer gauge display may differ depending on the model/type.
Page 168 2-2. Instrument cluster ■ Indicators The indicators inform the driver of the operating state of the vehi- cle’ s various systems. Turn signal indicator “ECT SNOW” indicator (P. 158) (P. 152) Headlight high beam indi- “ECT PWR” indicator cator (P. 178) (P.
Page 169 There may be a malfunction in a system if a light does not come on, or if the lights do not turn off. Have the vehicle inspected by your Lexus dealer. : The light flashes to indicate that the system is operating.
Page 170 Have the vehicle inspected by your Lexus dealer immediately if this occurs.
Page 171: Multi-Information Display
2-2. Instrument cluster Multi-information display The multi-information display presents the driver with a variety of driving- related data, including the current outside air temperature. ● Trip information (P. 172) Displays driving range, fuel con- sumption and other cruising related information. ●...
Page 172: Outside Temperature
2-2. Instrument cluster Trip information Display items can be switched by pushing the “DISP” switch. ■ Outside temperature Displays the outside air temperature. The temperature range that can be displayed is from -40F (-40C) to 122F (50C). When the temperature drops to 37 ...
Page 173 2-2. Instrument cluster ■ Average fuel consumption Displays the average fuel consumption since the function was reset. • The function can be reset by pushing the “DISP” switch for longer than one second when the average fuel consumption is displayed. •...
Page 174 2-2. Instrument cluster ■ Gear position display Indicates the current gear, and the range of gears that is available when the shift lever is in the D or S position. The gear range is shown by the number of dots () and the current gear is shown as a number. The transmission automatically selects the gears within the driver selected gear range.
Page 175 2-2. Instrument cluster CAUTION The information display at low temperatures ■ Allow the interior of the vehicle to warm up before using the liquid crystal informa- tion display. At extremely low temperatures, the information display monitor may respond slowly, and display changes may be delayed. For example, there is a lag between the driver's shifting and the new gear number appearing on the display.
Page 176: 2-3. Operating The Lights And Windshield Wipers
2-3. Operating the lights and windshield wipers Headlight switch The headlights can be operated manually or automatically. Type A The daytime running lights turn on. The side marker, park- (vehicles with halogen headlights), daytime running lights, tail, license plate and instrument panel lights turn on.
Page 177 2-3. Operating the lights and windshield wipers Type B The daytime running lights turn on. The side marker, park- (vehicles with halogen headlights), daytime running lights, tail, license plate and instrument panel lights turn on. The headlights and all the lights listed above (except daytime run- ning lights) turn on.
Page 178 2-3. Operating the lights and windshield wipers Turning on the high beam headlights With the headlights on, push the lever forward to turn on the high beams. Pull the lever back to the center position to turn the high beams off. Pull the lever toward you to turn on the high beams.
Page 179 The level of the headlights is automatically adjusted according to the number of passengers and the loading condition of the vehicle to ensure that the headlights do not interfere with other road users. Customization that can be configured at Lexus dealer ■ Settings (e.g. light sensor sensitivity) can be changed.
Page 180: Fog Light Switch
2-3. Operating the lights and windshield wipers Fog light switch The fog lights improve visibility in difficult driving conditions, such as in rain or fog. They can be turned on only when the headlights are on low beam. Type A Front fog lights off Front fog lights on...
Page 181 2-3. Operating the lights and windshield wipers Type B Front fog lights off Front fog lights on...
Page 182: Windshield Wipers And Washer
2-3. Operating the lights and windshield wipers Windshield wipers and washer ■ Intermittent windshield wiper with interval adjuster (if equipped) Wiper intervals can be adjusted for intermittent operation. Type A Intermittent wind- shield wiper operation Low speed windshield wiper operation High speed wind- shield wiper operation Temporary operation...
Page 183 2-3. Operating the lights and windshield wipers Type B Intermittent wind- shield wiper operation Low speed windshield wiper operation High speed wind- shield wiper operation Temporary operation Increases the intermittent windshield wiper frequency Decreases the intermittent windshield wiper frequency...
Page 184 2-3. Operating the lights and windshield wipers Washer/wiper dual operation Wipers operate automatically. (After operating several times, the wipers operate one more time after a short delay to pre- vent dripping.) ■ Rain-sensing windshield wipers (if equipped) When is selected, the wipers will operate automatically when the sensor detects falling rain.
Page 185 2-3. Operating the lights and windshield wipers Type B Rain-sensing wind- shield wiper operation Low speed windshield wiper operation High speed wind- shield wiper operation Temporary operation...
Page 186 2-3. Operating the lights and windshield wipers Sensor sensitivity (high) Sensor sensitivity (low) Washer/wiper dual operation Wipers operate automatically. (After operating several times, the wipers operate one more time after a short delay to pre- vent dripping.) The windshield wipers and washer can be operated when ■...
Page 187 ■ Check that the washer nozzles are not blocked if there is washer fluid in the wind- shield washer fluid reservoir. Customization that can be configured at Lexus dealer ■ Settings (e.g. drip prevention function) can be changed. (Customizable features P. 586) CAUTION Caution regarding the use of windshield wipers in “AUTO”...
Page 188 2-3. Operating the lights and windshield wipers NOTICE When the windshield is dry ■ Do not use the wipers, as they may damage the windshield. When a nozzle becomes blocked ■ Do not try to clear it with a pin or other object. The nozzle will be damaged. When there is no washer fluid spray from the nozzle ■...
Page 189: Headlight Cleaner Switch
2-3. Operating the lights and windshield wipers  Headlight cleaner switch Washer fluid can be sprayed on the headlights. Press the switch to clean the headlights. The headlight cleaner can be operated when ■ When the “ENGINE START STOP” switch is in IGNITION ON mode and the headlight switch is turned on.
Page 190: 2-4. Using Other Driving Systems
2-4. Using other driving systems  Cruise control Use the cruise control to maintain a set speed without depressing the accelerator pedal. Indicator Cruise control switch ■ Setting the vehicle speed Press the “ON-OFF” button to STEP activate the cruise control. Cruise control indicator will come on.
Page 191 2-4. Using other driving systems ■ Adjusting the set speed To change the set speed, operate the lever until the desired set speed is obtained. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direction.
Page 192 If the cruise control speed cannot be set or if the cruise control cancels immediately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by your Lexus dealer.
Page 193 2-4. Using other driving systems CAUTION To avoid operating the cruise control by mistake ■ Switch the cruise control off using the “ON-OFF” button when not in use. Situations unsuitable for cruise control ■ Do not use cruise control in any of the following situations. Doing so may result in loss of control and could cause an accident resulting in death or serious injury.
Page 194: Dynamic Radar Cruise Control
2-4. Using other driving systems  Dynamic radar cruise control Dynamic radar cruise control supplements conventional cruise control with a vehicle-to-vehicle distance control. In vehicle-to-vehicle distance control mode, the vehicle automatically accelerates or decelerates in order to maintain a set following distance from vehicles ahead. Indicator Display Set speed...
Page 195 2-4. Using other driving systems ■ Setting the vehicle speed (vehicle-to-vehicle distance control mode) Press the “ON-OFF” button to STEP activate the cruise control. Cruise control indicator will come on. Press the button again to deacti- vate the cruise control. Accelerate or decelerate the STEP vehicle to the desired speed,...
Page 196 2-4. Using other driving systems ■ Adjusting the set speed To change the set speed, operate the lever until the desired set speed is displayed. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direction.
Page 197 2-4. Using other driving systems ■ Changing the vehicle-to-vehicle distance Pressing the button changes the Preceding vehicle-to-vehicle distance as vehicle mark follows: Long Medium Short The vehicle-to-vehicle distance is set automatically to long mode when the “ENGINE START STOP” switch is turned to IGNITION ON mode.
Page 198 2-4. Using other driving systems ■ Canceling and resuming the speed setting Pulling the lever toward you cancels the cruise control. The speed setting is also can- celed when the brakes are applied. Pushing the lever up resumes the cruise control and returns vehicle speed to the set speed.
Page 199 2-4. Using other driving systems Driving in vehicle-to-vehicle distance control mode This mode employs a radar sensor to detect the presence of vehicles up to approximately 400 ft. (120 m) ahead, determines the current vehicle- to-vehicle following distance, and operates to maintain a suitable follow- ing distance from the vehicle ahead.
Page 200 2-4. Using other driving systems Example of follow-up cruising When following a vehicle driving slower than the set speed The system continues follow-up cruising while adjusting for changes in the speed of the vehicle ahead in order to maintain the vehicle-to-vehicle dis- tance set by the driver.
Page 201 2-4. Using other driving systems Selecting conventional constant speed control mode Constant speed control mode differs from vehicle-to-vehicle distance control mode. When constant speed control mode is selected, your vehi- cle will maintain a set speed regardless of whether or not there are other vehicles in the lane ahead.
Page 202 When snow mode is set. ● If vehicle-to-vehicle distance control driving is automatically canceled for any other reason, there may be a malfunction in the system. Contact your Lexus dealer. Automatic cancelation of constant speed control ■ The cruise control will stop maintaining the vehicle speed in the following situations: Actual vehicle speed is more than approximately 10 mph (16 km/h) below the ●...
Page 203 2-4. Using other driving systems Radar sensor and grille cover ■ Always keep the sensor and grille cover clean to ensure that the vehicle-to-vehicle distance control operates properly. (Some obstructions, such as snow, ice or plastic objects, cannot be detected by the obstruction sensor.) Dynamic radar cruise control is canceled if an obstruction is detected.
Page 204 2-4. Using other driving systems Certification ■ For vehicles sold in U.S.A. FCC ID: HYQDNMWR005 This device complies with part 15 of the FCC Rules. Operation is subject to the fol- lowing two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 205 2-4. Using other driving systems CAUTION Before using dynamic radar cruise control ■ Do not overly rely on vehicle-to-vehicle distance control. Be aware of the set speed. If automatic deceleration/acceleration is not appropri- ate, adjust the vehicle speed, as well as the distance between your vehicle and vehi- cles ahead by applying the brakes etc.
Page 206 2-4. Using other driving systems CAUTION To avoid inadvertent cruise control activation ■ Switch the cruise control off using the “ON-OFF” button when not in use. Situations unsuitable for dynamic radar cruise control ■ Do not use dynamic radar cruise control in any of the following situations. Doing so may result in inappropriate speed control and could cause an accident resulting in death or serious injury.
Page 207 If the sensor moves even slightly off position, the system may malfunction. If the sensor or surrounding area is subject to a strong impact, always have the area inspected and adjusted by a Lexus dealer. Do not disassemble the sensor.
Page 208: Intuitive Parking Assist
2-4. Using other driving systems  Intuitive parking assist The distance to obstacles measured by the sensors is communicated via the multi-information display and a buzzer when parallel parking or maneuvering into a garage. Always check the surrounding area when using this system.
Page 209 2-4. Using other driving systems ■ Intuitive parking assist switch (P. 365) When on, an indicator is dis- played to inform the driver that the function is operational. The display and buzzer system ■ Corner sensor operation display and distance to an obstacle The system operates when the vehicle approaches within approxi- mately 1.6 ft.
Page 210 2-4. Using other driving systems ■ Back sensor operation display and distance to an obstacle The system operates when the vehicle approaches within approxi- mately 4. 9 ft. (150 cm) of an obstacle. Approximately 2.0 ft. (60 cm) to 4. 9 ft. (150 cm) from the obstacle Approximately 1.5 ft.
Page 211 2-4. Using other driving systems Detection range of the sensors Approximately 1.6 ft. (50 cm) Approximately 4. 9 ft. (150 cm) Approximately 1.6 ft. (50 cm) The diagram shows the detection range of the sensors. Note that the sensors cannot detect obstacles that are extremely close to the vehicle.
Page 212 2-4. Using other driving systems Sensor detection information ■ Certain vehicle conditions and the surrounding environment may affect the ● ability of the sensor to correctly detect obstacles. Particular instances where this may occur are listed below. • There is dirt, snow or ice on the sensor. •...
Page 213 For vehicles sold in Canada This ISM device complies with Canadian ICES-001. Cet appareil ISM est conforme à la norme NMB-001 du Canada. Customization that can be configured at Lexus dealer ■ Settings (e.g. buzzer volume) can be changed. (Customizable features P. 586)
Page 214: Driving Assist Systems
2-4. Using other driving systems Driving assist systems To help enhance driving safety and performance, the following systems operate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehicle. ■...
Page 215 2-4. Using other driving systems ■ VDIM (Vehicle Dynamics Integrated Management) Provides integrated control of the ABS, brake assist, TRAC, VSC, and EPS systems. Helps to maintain vehicle stability when swerving on slippery road sur- faces by controlling the brakes, engine output and steering assist. ■...
Page 216 2-4. Using other driving systems To disable TRAC/VSC If the vehicle gets stuck in fresh snow or mud, TRAC and VSC may reduce power from the engine to the wheels. You may need to turn the system off to enable you to rock the vehicle in order to free it. ■...
Page 217 When the message is displayed on the multi-information display showing that ■ TRAC has been disabled even if the VSC off switch has not been pressed TRAC and hill-start assist control cannot be operated. Contact your Lexus dealer. Automatic reactivation of the TRAC/VSC systems ■...
Page 218 10 minutes. If the slip indicator comes on ■ It may indicate a malfunction in the VSC or TRAC function. Contact your Lexus dealer. CAUTION The ABS does not operate effectively when ■ The limits of tire gripping performance have been exceeded (such as excessively ●...
Page 219 The ABS, VSC and TRAC systems will not function correctly if different tires are fit- ted on the vehicle. Contact your Lexus dealer for further information when replacing tires or wheels. Handling of tires and suspension ■ Using tires with any kind of problem or modifying the suspension will affect the driv-...
Page 220: Hill-Start Assist Control
2-4. Using other driving systems Hill-start assist control Hill-start assist control helps to prevent the vehicle from rolling backwards when starting on an incline or slippery slope. To engage hill-start assist con- trol, further depress the brake pedal when the vehicle is stopped completely.
Page 221 • The brake pedal is depressed again. • The brake pedal has been depressed for more than approximately 3 minutes. If the slip indicator comes on ■ It may indicate a malfunction in the system. Contact your Lexus dealer. CAUTION Hill-start assist control ■...
Page 222: (Pre-Collision System)
2-4. Using other driving systems  PCS (Pre-Collision System) When the radar sensor detects possibility of a frontal collision, the pre-col- lision systems such as the brakes and seat belts are automatically engaged in an attempt to lessen damage. ■ Pre-collision seat belts If the pre-collision sensor detects that a collision is unavoidable, the pre- collision system will retract the seat belt before the collision occurs.
Page 223 2-4. Using other driving systems Disabling the pre-collision braking The pre-collision braking function can be turned on and off using the satellite switch. (P. 365) Press “”or “” to display the PCS brake setting ( ). Then, press the “ON/OFF” button in the middle of the switch to select either “ON”...
Page 224 2-4. Using other driving systems The pre-collision system is operational when ■ Pre-collision seat belt (type A) ● • Vehicle speed is above 4 mph (5 km/h). • The speed at which your vehicle is approaching the obstacle or the vehicle is greater than 19 to 25 mph (30 to 40 km/h).
Page 225 2-4. Using other driving systems Conditions that may trigger the system even if there is no possibility of collision ■ When there is an object by the roadside at the entrance to a curve ● When passing an oncoming vehicle on a curve ●...
Page 226 2-4. Using other driving systems Certification ■ For vehicles sold in U.S.A. FCC ID: HYQDNMWR005 This device complies with part 15 of the FCC Rules. Operation is subject to the fol- lowing two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 227 2-4. Using other driving systems CAUTION Limitations of the pre-collision system ■ Do not rely on the pre-collision system. Always drive safely, taking care to observe your surroundings and checking for any obstacles or other road hazards. Failure to do so may cause an accident resulting in death or serious injury. Cautions regarding the assist contents of the system ■...
Page 228 If the sensor moves even slightly off position, the system may become inaccurate or malfunction. If the sensor or surrounding area are subject to a strong impact, always have the area inspected and adjusted by a Lexus dealer. Do not disassemble the sensor.
Page 229: 2-5. Driving Information
2-5. Driving information Cargo and luggage Take notice of the following information about storage precautions, cargo capacity and load. ● Stow cargo and luggage in the trunk whenever possible. Be sure all items are secured in place. ● Be careful to keep the vehicle level. Placing the weight as far for- ward as possible helps maintain vehicle balance.
Page 230 Consult this manual to determine how this reduces the available cargo and luggage load capacity of your vehi- cle. Lexus does not recommend towing a trailer with your vehicle. Your vehicle is not designed for trailer towing. Calculation formula for your vehicle...
Page 231 2-5. Driving information As shown in the above example, if the number of occupants increases, the cargo and luggage load equaling the combined weight of the occu- pants who got on later, by an amount. In other words, if an increase in the number of occupants causes an excess of the total load capacity (com- bined weight of occupants plus cargo and luggage load), you must reduce the cargo and luggage on your vehicle.
Page 232: Vehicle Load Limits
Seating capacity means the maximum number of occupants whose esti- mated average weight is 150 lb. (68 kg) per person. ■ Towing capacity Lexus does not recommend towing a trailer with your vehicle. ■ Cargo capacity Cargo capacity may increase or decrease depending on the weight and the number of occupants.
Page 233: Winter Driving Tips
2-5. Driving information Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a manner appropriate to the prevailing weather conditions. ■ Pre-winter preparations ● Use fluids that are appropriate to the prevailing outside tempera- tures.
Page 234 2-5. Driving information ■ When driving the vehicle Accelerate the vehicle slowly and drive at a reduced speed suitable to road conditions. ■ When parking the vehicle (in the winter time or in the cold lati- tudes) Park the vehicle and move the shift lever to P and block the wheel under the vehicle without setting the parking brake.
Page 235 2-5. Driving information Tire chain installation (17-inch tires only) ■ Observe the following precautions when installing and removing chains. Install and remove tire chains in a safe location. ● Install tire chains on the rear tires only. Do not install tire chains on front tires. ●...
Page 236 NOTICE Repairing or replacing snow tires ■ Request repairs of and obtain replacement snow tires from Lexus dealers or legiti- mate tire retailers. This is because the removal and attachment of snow tires affects the operation of the tire air pressure sensor.
Page 237: Trailer Towing
2-5. Driving information Trailer towing Lexus does not recommend towing a trailer with your vehicle. Lexus also does not recommend the installation of a tow hitch or the use of a tow hitch carrier for a wheelchair, scooter, bicycle, etc. Your Lexus is not designed...
Page 238: Dinghy Towing
2-5. Driving information Dinghy towing Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. NOTICE To avoid serious damage to your vehicle ■ Do not tow your vehicle with four wheels on the ground.
Page 239 2-5. Driving information...
Page 240: Interior Features
Interior features 3-1. Using the air conditioning system and defogger Automatic air conditioning system........242 Rear window and outside rear view mirror defoggers....251 Windshield wiper de-icer..252 3-2. Using the audio system Audio system type ....253 Using the radio ....... 256 Using the CD player.....
Page 241 Interior features ® 3-3. Using the Bluetooth 3-5. Using the interior lights audio system Interior lights list ....353 ® Bluetooth audio system ... 303 • Interior light......354 ® • Personal lights ..... 354 Using the Bluetooth audio system ......306 ®...
Page 242: Automatic Air Conditioning System
3-1. Using the air conditioning system and defogger Automatic air conditioning system Air outlets and fan speed are automatically adjusted according to the tem- perature setting. With navigation system Owners of models equipped with a navigation system should refer to the “Navigation System Owner's Manual”.
Page 243 3-1. Using the air conditioning system and defogger  to increase the temperature and “” to Press “” on STEP decrease the temperature. The temperature for the driver and passenger seats can be set sepa- rately. Adjusting the settings ■ Adjusting the temperature setting Press “”...
Page 244 3-1. Using the air conditioning system and defogger ■ Changing the air outlets Press The air outlets switch each time the is pressed. The air flow shown on the display indicates the following. Upper body : Automatic air flow mode only Upper body and feet Feet...
Page 245 3-1. Using the air conditioning system and defogger Feet and windshield ■ Switching between outside air and recirculated air modes IS250C Press The mode switches between (recycles air inside the vehicle) and (introduces air from outside the vehicle) modes each time is pressed.
Page 246 3-1. Using the air conditioning system and defogger Micro dust and pollen filter Press Outside air mode switches to (recirculated air) mode. Pol- len is removed from the air and the air flows to the upper part of the body. Usually the system will turn off automatically after 1 or 3 minutes.
Page 247 3-1. Using the air conditioning system and defogger Adjusting the position of and opening and closing the air outlets Front outlets (center) Direct air flow to the left or right, up or down Turn the knob to open or close the vent Front outlets (right and left side) Direct air flow to the left or right,...
Page 248 3-1. Using the air conditioning system and defogger Rear outlets Direct air flow to the left or right, up or down Turn the knob fully to the outside of the vehicle to close the vent Using the automatic mode ■ Fan speed is adjusted automatically in accordance with the temperature setting and ambient conditions.
Page 249 There may be a problem in the air conditioning system if the indicator light continues to flash. Turn the air conditioning system off and have it inspected by your Lexus dealer. Automatic mode for air intake control (IS350C only) ■...
Page 250 3-1. Using the air conditioning system and defogger NOTICE To prevent battery discharge ■ Do not leave the air conditioning system on longer than necessary when the engine is off.
Page 251: Rear Window And Outside Rear View Mirror Defoggers
3-1. Using the air conditioning system and defogger Rear window and outside rear view mirror defoggers These features are used to defog the rear window, and to remove rain- drops, dew and frost from the outside rear view mirrors. With navigation system Owners of models equipped with a navigation system should refer to the “Navigation System Owner's Manual”.
Page 252: Windshield Wiper De-Icer
3-1. Using the air conditioning system and defogger  Windshield wiper de-icer This feature is used to prevent ice from building up on the windshield and wiper blades. On/off The windshield wiper de-icer will automatically turn off after approximately 15 minutes. The windshield wiper de-icer can be operated when ■...
Page 253: 3-2. Using The Audio System
3-2. Using the audio system Audio system type With navigation system Owners of models equipped with a navigation system should refer to the “Navigation System Owner's Manual”. Without navigation system (type A) CD player with changer and AM/FM radio Without navigation system (type B) CD player with changer and AM/FM radio...
Page 254 3-2. Using the audio system Title Page Using the radio P. 256 Using the CD player P. 264 Playing back MP3 and WMA discs P. 271 Operating an iPod P. 279 Operating a USB memory P. 287 Optimal use of the audio system P.
Page 255 3-2. Using the audio system Using cellular phones ■ Interference may be heard through the audio system’ s speakers if a cellular phone is being used inside or close to the vehicle while the audio system is operating. CAUTION For vehicles sold in U.S.A. and Canada ■...
Page 256: Using The Radio
3-2. Using the audio system Using the radio Type A Station Seeking any traffic program station selector Displays radio text messages Silencing a sound Adjusting the frequency Power Volume (AM, FM mode) or channel (SAT mode) Seeking the Changing the program types frequency AMFM/SAT Scans for receivable stations...
Page 257 3-2. Using the audio system ® Setting station presets (excluding XM Satellite Radio) Search for desired stations by turning or pressing “” or STEP “” on Press and hold the button (from ) the station is to STEP be set to until you hear a beep. ®...
Page 258 3-2. Using the audio system RDS (Radio Data System) (type A) This feature allows your radio to receive station identification information and program information (classical, jazz, etc.) from radio stations which broadcast this information. ■ Receiving RDS broadcasts Press “” or “” on during FM reception.
Page 259 3-2. Using the audio system ■ Displaying radio station names Press ■ Displaying radio text messages Press twice. If “MSG” shows in the display, a text message will be displayed. If the text continues past the end of the display, is displayed.
Page 260 3-2. Using the audio system ® ■ Scanning XM Satellite Radio channels ● Scanning channels in the current category Press STEP When the desired channel is reached, press again. STEP ● Scanning preset channels Press and hold until you hear a beep. STEP When the desired channel is reached, press again.
Page 261 3-2. Using the audio system When the battery is disconnected ■ Stations presets are erased. Radio antenna type ■ Detachable antenna ● To remove a detachable antenna, carefully turn it counterclockwise. Wire antenna ● The radio antenna is mounted inside the windshield. Reception sensitivity ■...
Page 262 XM antenna cable is attached securely. “ANTENNA” There is a short-circuit in the antenna or the surround- ing antenna cable. See a Lexus certified dealer. ® You have not subscribed to the XM Satellite Radio. The radio is being updated with the latest encryption ®...
Page 263 3-2. Using the audio system The channel you selected is no longer available. Wait for about 2 seconds until the radio returns to the previ- “CH UNAVL” ous channel or “CH001”. If it does not change auto- matically, select another channel. ®...
Page 264: Using The Cd Player
3-2. Using the audio system Using the CD player Type A Playback/Pause Repeat play Displays text Random playback message Silencing a sound Power Volume CD selection CD eject Playback CD load Track selection Search playback Type B Playback/Pause Repeat play Displays text Random playback message...
Page 265 3-2. Using the audio system Loading CDs ■ Loading a CD Push STEP “WAIT” is shown on the display. Insert a CD when the indicator on the slot turns from amber to STEP green. The display changes from “WAIT” to “LOAD”. ■...
Page 266 3-2. Using the audio system Ejecting CDs ■ Ejecting a CD To select the CD to be ejected, STEP press “” or “” on The number of the CD selected is shown on the display. Press and remove the CD. STEP ■...
Page 267 3-2. Using the audio system Selecting a CD ■ To select a CD to play To select the desired CD, press “” or “” on ■ To scan loaded CDs (type A) Press and hold until you hear a beep. STEP The first ten seconds of the first track on each CD will be played.
Page 268 “WAIT”: Operation is stopped due to a high temperature inside the player. Wait for a while and then press . Contact your Lexus dealer if the CD still cannot be played back. Discs that can be used ■...
Page 269 3-2. Using the audio system CD player protection feature ■ To protect the internal components, playback is automatically stopped when a problem is detected. If CDs are left inside the CD player or in the ejected position for extended peri- ■...
Page 270 3-2. Using the audio system NOTICE CDs with a transparent or translucent ● recording area. CDs that have had tape, stickers or CD-R ● labels attached to them, or that have had the label peeled off. CD player precautions ■ Failure to follow the precautions below may result in serious damage to the CDs or the player itself.
Page 271: Playing Back Mp3 And Wma Discs
3-2. Using the audio system Playing back MP3 and WMA discs Type A Playback/Pause Folder selection Repeat play Displays text message Random playback Silencing a sound File selection Power Volume CD selection File Playback CD load selection Search playback CD eject Type B Playback/Pause Folder selection...
Page 272 3-2. Using the audio system Loading and ejecting MP3 and WMA discs P. 265, 266 Selecting MP3 and WMA discs P. 267 Selecting a folder ■ Selecting folders one at a time Press () or () to select the desired folder. ■...
Page 273 3-2. Using the audio system Selecting and scanning files ■ Selecting one file at a time Turn or press “” or “” on to select the desired file. ■ Selecting the desired file by cueing the files in the folder (type A) Press When the desired file is reached, press once again.
Page 274 “WAIT”: Operation is stopped due to a high temperature inside the player. Wait for a while and then press . Contact your Lexus dealer if the CD still cannot be played back. “NO MUSIC”: This indicates that the MP3/WMA file is not included in the CD.
Page 275 3-2. Using the audio system Discs that can be used ■ Discs with the marks shown below can be used. Playback may not be possible depending on recording format or disc features, or due to scratches, dirt or deterioration. CD player protection feature ■...
Page 276 3-2. Using the audio system WMA file compatibility ● • Compatible standards WMA Ver. 7, 8, 9 • Compatible sampling frequencies 32, 44.1, 48 (kHz) • Compatible bit rates (only compatible with 2-channel playback) Ver. 7, 8: CBR 48, 64, 80, 96, 128, 160, 192 (kbps) Ver.
Page 277 3-2. Using the audio system ID3 and WMA tags ● ID3 tags can be added to MP3 files, making it possible to record the track title, artist name, etc. The system is compatible with ID3 Ver. 1.0, 1.1, and Ver. 2.2, 2.3 ID3 tags. (The number of characters is based on ID3 Ver.
Page 278 3-2. Using the audio system NOTICE CDs and adapters that cannot be used ■ P. 269 CD player precautions ■ P. 270...
Page 279: Operating An Ipod
3-2. Using the audio system Operating an iPod Connecting an iPod enables you to enjoy music from the vehicle speakers. ■ Connecting an iPod Open the cover and connect STEP the portable audio device. Turn on the power of the iPod if it is not turned on.
Page 280 3-2. Using the audio system ■ Control panel Type A Repeat play Playback/Pause Go back Shuffle playback Displays text message Silencing a sound iPod menu/ Song selection Song selection Power Volume Song selection Playback...
Page 281 3-2. Using the audio system Type B Repeat play Playback/Pause Go back Shuffle playback Displays text message Silencing a sound iPod menu/ Song selection Song selection Power Volume Song selection Playback Selecting a play mode Press to select iPod menu mode. STEP Pressing changes the play mode in the following...
Page 282 3-2. Using the audio system ■ Play mode list First Second Third Fourth Play mode selection selection selection selection “PLAYLISTS” Playlists select Songs select “ARTISTS” Artists select Albums select Songs select “ALBUMS” Albums select Songs select “SONGS” Songs select “PODCASTS” Albums select Songs select “GENRES”...
Page 283 3-2. Using the audio system Selecting songs Turn or press “” or “” on to select the desired song. Playing and pausing songs To play or pause a song, press Fast-forwarding and rewinding songs To fast-forward or rewind, press and hold “” or “” on until you hear a beep.
Page 284 3-2. Using the audio system Adjusting sound quality and volume balance Press to enter iPod menu mode. STEP Pressing changes sound modes. (P. 297) STEP About iPod ■ Apple is not responsible for the operation of this device or its compliance with ●...
Page 285 3-2. Using the audio system Display ■ Up to 12 characters can be displayed at a time. If there are 13 characters or more, pressing and holding until you hear a beep will display the remaining characters. A maximum of 24 characters can be displayed. is pressed until you hear a beep again or has not been pressed for 6 sec- onds or more, the display will return to the first 12 characters.
Page 286 3-2. Using the audio system Compatible models ■ Model Generation Software version iPod 5th generation Ver. 1.2.0 or higher 1st generation Ver. 1.3.0 or higher iPod nano 2nd generation Ver. 1.1.2 or higher 3rd generation Ver. 1.0.0 or higher iPod touch 1st generation Ver.
Page 287: Operating A Usb Memory
3-2. Using the audio system Operating a USB memory Connecting a USB memory enables you to enjoy music from the vehicle speakers. ■ Connecting a USB memory Open the cover and connect STEP the portable audio device. Turn on the power of the USB memory if it is not turned on.
Page 288 3-2. Using the audio system ■ Control panel Type A Playback/Pause Folder selection Repeat play Displays text message Random playback Silencing a sound File selection Power Volume Search playback File selection Playback...
Page 289 3-2. Using the audio system Type B Playback/Pause Folder selection Repeat play Displays text message Random playback Silencing a sound File selection Power Volume Playback File selection Selecting a folder ■ Selecting folders one at a time Press () or () to select the desired folder.
Page 290 3-2. Using the audio system Selecting files ■ Selecting one file at a time Turn or press “” or “” on to select the desired file. ■ Selecting the desired file by cueing the files in the folder (type A) Press When the desired file is reached, press once again.
Page 291 3-2. Using the audio system Switching the display Press Each time is pressed, the display changes in the order of Elapsed time  Folder name  File name  Album title (MP3 only) Track title  Artist name. USB memory functions ■...
Page 292 3-2. Using the audio system USB memory ■ Compatible devices ● USB memory that can be used for MP3 and WMA playback Compatible device formats ● The following device formats can be used: • USB communication formats: USB2.0 FS (12 mbps) •...
Page 293 3-2. Using the audio system MP3 file compatibility ● • Compatible standards MP3 (MPEG1 AUDIO LAYERII, III, MPEG2 AUDIO LAYERII, III, MPEG2.5) • Compatible sampling frequencies MPEG1 AUDIO LAYERII, III: 32, 44.1, 48 (kHz) MPEG2 AUDIO LAYERII, III: 16, 22.05, 24 (kHz) MPEG2.5: 8, 11.025, 12 (kHz) •...
Page 294 3-2. Using the audio system MP3 and WMA playback ● • When a device containing MP3 or WMA files is connected, all files in the USB memory are checked. Once the file check is finished, the first MP3 or WMA file is played. To make the file check finish more quickly, we recom- mend that you do not include any files other than MP3 or WMA files or cre- ate any unnecessary folders.
Page 295 3-2. Using the audio system NOTICE To prevent damage to USB memory ■ Do not leave USB memory in the vehicle. The temperature inside the vehicle may ● become high, resulting in damage to the player. Do not push down on or apply unnecessary pressure to the USB memory while it ●...
Page 296: Optimal Use Of The Audio System
3-2. Using the audio system Optimal use of the audio system Adjusting the sound quality Adjusting the ASL Changing the sound quality modes...
Page 297 3-2. Using the audio system Adjusting the Automatic Sound Levelizer (ASL) Press The ASL switches between on and off modes each time pressed. ASL automatically adjusts the volume and tone quality according to the noise level as you drive your vehicle. Adjusting sound quality and volume balance ■...
Page 298: Using The Aux Port
3-2. Using the audio system Using the AUX port This port can be used to connect a portable audio device and listen to it through the vehicle’s speakers. Open the cover and connect STEP the portable audio device. Type A Press STEP Type B...
Page 299 3-2. Using the audio system Operating portable audio devices connected to the audio system ■ The volume can be adjusted using the vehicle's audio controls. All other adjust- ments must be made on the portable audio device itself. When using a portable audio device connected to the power outlet ■...
Page 300: Using The Steering Wheel Audio Switches
3-2. Using the audio system Using the steering wheel audio switches Some audio features can be controlled using the switches on the steering wheel. Operation may differ depending on the type of audio system or navi- gation system. For details, refer to the manual provided with the audio system or navigation system.
Page 301: Using The Bluetooth ® Audio System
3-2. Using the audio system Changing the audio source Press when the audio system is turned on. The audio source changes as follows each time is pressed. If no discs are inserted in the player, or if the external device is not connected, that mode will be skipped.
Page 302 3-2. Using the audio system Selecting an album ® Press to select Bluetooth audio mode. STEP Press and hold “” or “” on until you hear a beep. STEP Selecting a folder Press to select USB memory mode. STEP Press and hold “” or “” on until you hear a beep.
Page 303: Bluetooth ® Audio System
® 3-3. Using the Bluetooth audio system ® Bluetooth audio system ® The Bluetooth audio system enables you to enjoy music played on a por- table digital audio player (portable player) from the vehicle speakers via wireless communication. ® This audio system supports Bluetooth , a wireless data system capable of playing portable audio music without cables.
Page 304 ® 3-3. Using the Bluetooth audio system When transferring ownership of the vehicle ■ Be sure to initialize the system to prevent personal data from being improperly accessed. (P. 345) ® About Bluetooth ■ Bluetooth is a registered trademark of Bluetooth SIG.
Page 305 ® 3-3. Using the Bluetooth audio system CAUTION FCC WARNING ■ Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Radio Frequency Radiation Exposure. This equipment complies with FCC radiation exposure limits set forth for uncontrolled equipment and meets the FCC radio fre- quency (RF) Exposure Guidelines in Supplement C to OET65.
Page 306: Using The Bluetooth Audio System
® 3-3. Using the Bluetooth audio system ® Using the Bluetooth audio system ■ Audio unit Display A message, name, number, etc. is displayed. Lower-case characters and special characters cannot be displayed. Displays information that is too long to be displayed at one time on the display (press and hold) Selects items such as menu...
Page 307 ® 3-3. Using the Bluetooth audio system Operating the system using voice commands By following voice guidance instructions output from the speaker, voice ® commands enable the operation of the Bluetooth audio system without the need to check the display or operate ■...
Page 308: Using The Bluetooth
® 3-3. Using the Bluetooth audio system ® Using the Bluetooth audio system for the first time ® Before using the Bluetooth audio system, it is necessary to register a ® Bluetooth enabled portable player in the system. Follow the procedure below to register (pair) a portable player: Press and select “BT•A MENU”...
Page 309: Audio System
® 3-3. Using the Bluetooth audio system Guidance for registration completion is heard. ® If the portable player has a Bluetooth phone, the phone can be regis- tered at the same time. A voice guidance instruction to register a Blue- ®...
Page 310 ® 3-3. Using the Bluetooth audio system When using a voice command ■ For numbers, say a combination of single digits from zero to nine. Say the command correctly and clearly. Situations in which the system may not recognize your voice ■...
Page 311: Operating A Bluetooth
® 3-3. Using the Bluetooth audio system ® Operating a Bluetooth enabled portable player Type A Playback/Pause Album selection Repeat play Displays text message Random playback BT•A menu Power Volume Search playback Track selection Playback...
Page 312: Selecting Tracks
® 3-3. Using the Bluetooth audio system Type B Playback/Pause Album selection Repeat play Displays text message Random playback BT•A menu Power Volume Playback Track selection Selecting an album To select the desired album, press () or (). Selecting tracks Press “”...
Page 313 ® 3-3. Using the Bluetooth audio system Fast-forwarding and rewinding tracks To fast-forward or rewind, press and hold “” or “” on until you hear a beep. Random playback Press (RAND). Repeat play Press (RPT). Scanning tracks (type A) Press Switching the display Press Each time...
Page 314 ® 3-3. Using the Bluetooth audio system ® Bluetooth audio system functions ■ Depending on the portable player that is connected to the system, certain functions may not be available. Display ■ Up to 12 characters can be displayed at a time. If there are 13 characters or more, pressing and holding until you hear a beep will display the remaining characters.
Page 315: Setting Up A Bluetooth ® Enabled Portable Player
® 3-3. Using the Bluetooth audio system ® Setting up a Bluetooth enabled portable player ® Registering a portable player in the Bluetooth audio system allows the system to function. The following functions can be used for registered por- table players: ■...
Page 316 ® 3-3. Using the Bluetooth audio system Pattern B Press to select “BT•A MENU”. STEP Press the talk switch or select “BT•A Setup” using STEP Select one of the following functions using a voice command STEP ● Registering a portable player “Pair Audio Player (Pair Audio)”...
Page 317 ® 3-3. Using the Bluetooth audio system Selecting a portable player to be used Select “Connect Audio Player (Connect)” using a voice com- STEP mand or Pattern A Select the portable player to be used by either of the following STEP methods, and select “Confirm”...
Page 318 ® 3-3. Using the Bluetooth audio system Changing the registered name of a portable player Select “Change Name” using a voice command or STEP Pattern A Select the name of the portable player to be changed by either of STEP the following methods, and select “Confirm”...
Page 319 ® 3-3. Using the Bluetooth audio system Listing the registered portable players Select “List Audio Players (List Audios)” using a voice command or . The list of registered portable players will be read aloud. When listing is complete, the system returns to “BT•A Setup”. Pressing the talk switch while the name of a portable player is being read aloud selects the portable player, and the following functions will become available:...
Page 320 ® 3-3. Using the Bluetooth audio system Deleting a registered portable player Select “Delete Audio Player (Delete Audio)” using a voice com- STEP mand or Pattern A Select the portable player to be deleted by either of the following STEP methods and select “Confirm”...
Page 321: Bluetooth Audio System Setup
® 3-3. Using the Bluetooth audio system ® Bluetooth audio system setup ■ System setup items and operation procedures Pattern A To enter the menu for each function, follow the steps below using a voice command or (P. 343) Pattern B Press to select “BT•A MENU”.
Page 322: Using The Hands-Free Phone System (For Mobile Phones)
3-4. Using the hands-free phone system (for mobile phones) Hands-free system for mobile phones The hands-free system is a function that allows you to use your mobile phone without touching it. ® ® This system supports Bluetooth mobile phones. Bluetooth is a wireless data system that allows the mobile phone to wirelessly connect to the hands-free system and make/receive calls.
Page 323 3-4. Using the hands-free phone system (for mobile phones) Conditions under which the system will not operate ■ ® If using a mobile phone that does not support Bluetooth ● If the mobile phone is switched off ● If you are outside service range ●...
Page 324 3-4. Using the hands-free phone system (for mobile phones) Compatible models ■ Compatible with HFP (Hands Free Profile) Ver. 1.0 or higher (Conformed: Ver. 1.5) and OPP (Object Push Profile) Ver. 1.1. ® If your mobile phone does not support HFP, you cannot enter the Bluetooth ®...
Page 325 3-4. Using the hands-free phone system (for mobile phones) NOTICE To prevent damage to mobile phones ■ Do not leave mobile phones in the vehicle. The temperature inside the vehicle may become high, resulting in damage to the phone.
Page 326: Using The Hands-Free System (For Mobile Phones)
3-4. Using the hands-free phone system (for mobile phones) Using the hands-free system (for mobile phones) ■ Audio unit Display A message, name, phone number, etc. is displayed. Lower-case characters and special characters cannot be displayed. Displays information that is too long to be displayed at one time on the display (press and hold)
Page 327 3-4. Using the hands-free phone system (for mobile phones) ■ Steering wheel switches Volume During an incoming call: Adjusts the ring tone volume During an ongoing call: Adjusts the receiver volume The voice guidance volume can- not be adjusted using this but- ton.
Page 328 3-4. Using the hands-free phone system (for mobile phones) Operating the system using voice commands By following voice guidance instructions output from the speaker, voice commands enable the operation of the hands-free phone system without the need to check the display or operate ■...
Page 329 3-4. Using the hands-free phone system (for mobile phones) Using the hands-free phone system for the first time Before using the hands-free phone system, it is necessary to register a mobile phone in the system. The system will enter phone registration mode automatically when starting the system with no mobile phone reg- istered.
Page 330 3-4. Using the hands-free phone system (for mobile phones) Menu list of the hands-free phone system ■ Normal operation Second First menu Third menu Operation detail menu Dialing a number stored in the “Callback” incoming call history memory Dialing a number stored in the “Redial”...
Page 331 3-4. Using the hands-free phone system (for mobile phones) Second First menu Third menu Operation detail menu “Set PIN” Setting a PIN code “Security” “Phbk Lock” Locking the phone book “Phbk Unlock” Unlocking the phone book Registering the mobile phone “Pair Phone”...
Page 332 3-4. Using the hands-free phone system (for mobile phones) ■ Short cut key operation First menu Second menu Operation detail Dialing a name registered in the “Dial XXX (name)” phone book “Phone book add Adding a new phone number Entry” “Phone book Change Changing a registered name in name”...
Page 333 3-4. Using the hands-free phone system (for mobile phones) Automatic volume adjustment ■ When vehicle speed reaches 50 mph (80 km/h) or more, the volume automati- cally increases. The volume returns to the previous volume setting when vehicle speed drops to 43 mph (70 km/h) or less. When using a voice command ■...
Page 334: Making A Phone Call
3-4. Using the hands-free phone system (for mobile phones) Making a phone call ■ Making a phone call ● Dialing by inputting a number “Dial by number” ● Dialing by inputting a name “Dial by name” ● Speed dialing ● Dialing a number stored in the outgoing history memory “Redial”...
Page 335 3-4. Using the hands-free phone system (for mobile phones) Dialing by inputting a number Press the talk switch and say “Dial by number”. STEP Press the talk switch and say the phone number. STEP Dial by one of the following methods: STEP a.
Page 336 3-4. Using the hands-free phone system (for mobile phones) When receiving a phone call ■ Answering a phone call Press the off-hook switch. ■ Refusing a phone call Press the on-hook switch. Transferring a phone call A call can be transferred between the mobile phone and system while dialing, receiving a call, or during a call.
Page 337 3-4. Using the hands-free phone system (for mobile phones) Using the call history memory Follow the procedure below to use a number stored in the call history memory: Press the talk switch and say “Redial” (when using a number STEP stored in the outgoing call history memory) or “Call back”...
Page 338: Setting A Mobile Phone
3-4. Using the hands-free phone system (for mobile phones) Setting a mobile phone Registering a mobile phone in the hands-free phone system allows the sys- tem to function. The following functions can be used for registered mobile phones: ■ Functions and operation procedures To enter the menu for each function, follow the steps below using a voice command or ●...
Page 339 3-4. Using the hands-free phone system (for mobile phones) Selecting a mobile phone to be used Select “Connect Phone (Connect)” using a voice command or STEP Pattern A Select the mobile phone to be used by either of the following STEP methods, and select “Confirm”...
Page 340 3-4. Using the hands-free phone system (for mobile phones) Changing the registered name of a mobile phone Select “Change Name” using a voice command or STEP Pattern A Select the name of the mobile phone to be changed by either of STEP the following methods, and select “Confirm”...
Page 341 3-4. Using the hands-free phone system (for mobile phones) Listing the registered mobile phones Select “List Phones” using a voice command or The list of registered mobile phones will be read aloud. When listing is complete, the system returns to “Phone Setup”. Pressing the talk switch while the name of a mobile phone is being read aloud selects the mobile phone, and the following functions will become available:...
Page 342 3-4. Using the hands-free phone system (for mobile phones) Deleting a registered mobile phone Select “Delete Phone” using a voice command or STEP Pattern A Select the mobile phone to be deleted by either of the following STEP methods and select “Confirm” using a voice command or a.
Page 343: Security And System Setup
3-4. Using the hands-free phone system (for mobile phones) Security and system setup ■ Security setting items and operation procedures To enter the menu for each function, follow the steps below using a voice command or ● Setting or changing the PIN (Personal Identification Number) 1.
Page 344 3-4. Using the hands-free phone system (for mobile phones) Setting or changing the PIN ■ Setting a PIN Select “Set PIN” using a voice command or STEP Enter a PIN using a voice command or STEP When using , input the code 1 digit at a time. ■...
Page 345 3-4. Using the hands-free phone system (for mobile phones) Setting voice guidance volume Select “Guidance Vol” using STEP Change the voice guidance volume using STEP ® Displaying the Bluetooth device address and name Select “Device Name” using STEP ® Press to display the Bluetooth device address STEP...
Page 346 3-4. Using the hands-free phone system (for mobile phones) Initialization ■ The following data in the system can be initialized: ● • Phone book • Outgoing and incoming call history • Speed dials • Registered mobile phone data • Security code ®...
Page 347: Using The Phone Book
3-4. Using the hands-free phone system (for mobile phones) Using the phone book To enter the menu for each function, follow the steps below using a voice command or ● Adding a new phone number 1. “Phonebook”  2. “Add Entry” ●...
Page 348 3-4. Using the hands-free phone system (for mobile phones) ■ Adding procedure Select “Add Entry” using a voice command or STEP Use one of the following methods to input a telephone number: STEP Inputting a telephone number using a voice command: STEP2-1 Select “By Voice”...
Page 349 3-4. Using the hands-free phone system (for mobile phones) Inputting a phone number using STEP2-1 Select “Manual Input” using STEP2-2 Input a phone number using and press again. Input the phone number 1 digit at a time. Selecting a phone number from the outgoing or incoming call history: STEP2-1 Select “Call History”...
Page 350 3-4. Using the hands-free phone system (for mobile phones) Changing the registered name in the phone book Select “Change Name” using a voice command or STEP Pattern A Select the name to be changed by either of the following meth- STEP ods, and select “Confirm”...
Page 351 3-4. Using the hands-free phone system (for mobile phones) Setting speed dials Select “Set Speed Dial (Speed Dial)” using a voice command or STEP Pattern A Select the data to be registered as a speed dial by either of the STEP following methods and select “Confirm”...
Page 352 3-4. Using the hands-free phone system (for mobile phones) Deleting the registered data Select “Delete Entry” using a voice command or STEP Pattern A Select the data to be deleted by either of the following methods STEP and select “Confirm” using a voice command or a.
Page 353: 3-5. Using The Interior Lights
3-5. Using the interior lights Interior lights list Your Lexus is equipped with the illuminated entry system to assist in enter- ing the vehicle. Owing to the function of the system, the lights shown in the following illustration automatically turn on/off according to the presence of the electronic key, whether the doors are locked/unlocked, whether the doors are opened/closed, and the “ENGINE START STOP”...
Page 354: Interior Light
If the interior light remain on when the door is not fully closed and the interior light switch (door position on/off) is on, the lights will go off automatically after 20 min- utes. Customization that can be configured at Lexus dealer ■ Setting (e.g. The time elapsed before lights turn off) can be changed.
Page 355: Using The Storage Features List Of Storage Features
3-6. Using the storage features List of storage features Glove box Auxiliary box (if equipped) Cup holders Console box CAUTION Items that should not be left in the storage spaces ■ Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause the following when cabin temperature becomes high: Glasses may be deformed by heat or cracked if they come into contact with ●...
Page 356: Glove Box
3-6. Using the storage features Glove box Glove box Open (push button) Lock with the mechanical key Unlock with the mechanical key Glove box light ■ The glove box light turns on when the “ENGINE START STOP” switch is in IGNI- TION ON mode.
Page 357: Console Box
3-6. Using the storage features Console box Console box Pull up the knob to release the lock. Slide the armrest. Pull up the knob to release the lock. Lift the armrest to open. Console box light ■ The console box light turn on when the “ENGINE START STOP” switch is in IGNI- TION ON mode.
Page 358: Cup Holders
3-6. Using the storage features Cup holders Cup holders Front (press-in type) To open, press down and release the front of the cup holder lid. Front (slide type) Press the knob to release the lock. Slide the armrest.
Page 359 3-6. Using the storage features Cup holders Rear Open the front lid. Open the rear lid. Cup holder insert ■ Front (slide type) Remove the cup holder insert holding the base part. Rear Cup holder insert may be removed for clean- ing.
Page 360 3-6. Using the storage features Cup holders CAUTION Items unsuitable for the cup holder (front press-in type, rear) ■ Do not place anything other than cups or beverage cans in the cup holders. Even when the lid is closed, items must not be stored in the cup holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.
Page 361: Auxiliary Box
3-6. Using the storage features Auxiliary box Auxiliary box (if equipped) Push the back part of the lid to open. Push the lid again to close. CAUTION Caution while driving ■ Do not leave open while driving. Items stored in the auxiliary box may fall out and cause death or serious injury in case of an accident or sudden stop.
Page 362: 3-7. Other Interior Features
3-7. Other interior features Sun visors Forward position: Flip down. Side position: Flip down, unhook, and swing to the side.
Page 363: Vanity Mirror
3-7. Other interior features Vanity mirror Open the cover to use. The light turns on when the cover is opened.
Page 364: Clock
3-7. Other interior features Clock Adjusts the hour. Adjusts the minutes. Rounds to the nearest hour. : e.g. 1:00 to 1:29  1:00 1:30 to 1:59  2:00 The clock is displayed when ■ The “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode.
Page 365: Satellite Switches
3-7. Other interior features Satellite switches The satellite switches can be used to change the settings of various fea- tures. Settings are shown on the multi-information display. ■ Operating the satellite switches Bring up the satellite switch STEP mode on the multi-information display.
Page 366 3-7. Other interior features Change the settings. STEP STEP Press the “ON/OFF” button to change the settings (e.g. on/off). ■ Items that can be set using the satellite switches Intuitive parking assist on/off (if equipped) (P. 208) Tire pressure warning system initialization (P.
Page 367 3-7. Other interior features Front seat auto return function on/off (P. 57) Changing the settings ■ Each item is displayed and its setting can be changed only in the following condi- tions: Intuitive parking assist: When the “ENGINE START STOP” switch is in IGNI- ●...
Page 368: Ashtrays
3-7. Other interior features  Ashtrays Front Push the back part of the lid to open. Push the lid again to close. Push the lever to remove the ashtray. Rear Pull the ashtray lid to open. Hold the plate down and pull the ashtray upwards to remove.
Page 369: Cigarette Lighter
3-7. Other interior features  Cigarette lighter Push the back part of the lid to open, and push the cigarette lighter down. The cigarette lighter will pop up when it is ready for use. The cigarette lighter can be used when ■...
Page 370: Power Outlet
3-7. Other interior features Power outlet The power outlet can be used for 12 V accessories that run on less than 10 The power outlet can be used when ■ The “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode. NOTICE To avoid damaging the power outlet ■...
Page 371: Seat Heaters And Ventilators
3-7. Other interior features  Seat heaters and ventilators The seat heaters and ventilators heat the seats and maintain good airflow by blowing air from the seats. Heats the seats The indicator light (amber) Front comes on. Driver’ s passenger’ s The higher the number, the seat seat...
Page 372 3-7. Other interior features CAUTION Burns ■ Use caution when seating the following persons in a seat with the seat heater on ● to avoid the possibility of burns: • Babies, small children, the elderly, the sick and the disabled •...
Page 373: Floor Mat
■ Do not use floor mats designed for other models or different model year vehicles, ● even if they are Lexus Genuine floor mats. Only use floor mats designed for the driver's seat. ● Always install the floor mat securely using the retaining hooks (clips) provided.
Page 374: Trunk Features
3-7. Other interior features Trunk features ■ Cargo hooks Cargo hooks are provided for securing loose items. ■ Shopping bag hooks...
Page 375 3-7. Other interior features ■ Auxiliary box (vehicles with run-flat tires) Pull the lever upward to lift up STEP the luggage mat. The lever can be hooked on the STEP edge of the trunk.
Page 376 3-7. Other interior features Using the auxiliary box when the retractable hardtop is open ■ By attaching the lever of the luggage mat to the luggage cover, the auxiliary box can be accessed. Auxiliary box partition ■ The auxiliary box partition also serves as the luggage mat support can be removed.
Page 377: Garage Door Opener
3-7. Other interior features Garage door opener The garage door opener can be programmed to operate garage doors, gates, entry doors, door locks, home lighting systems, and security systems, and other devices.  The garage door opener (HomeLink Universal Transceiver) is manufactured ...
Page 378 3-7. Other interior features Press and hold one of the STEP  HomeLink buttons and the trans- mitter button. When  HomeLink indicator light changes from a slow to a rapid flash, you can release both buttons.  If the HomeLink indicator light comes on but does not flash, flashes rapidly for 2 seconds and...
Page 379 3-7. Other interior features ■ Programming a Rolling Code system (for U.S.A. owners) If your device is Rolling Code equipped, follow the steps under the  heading “Programming the HomeLink ” before proceeding with the steps listed below. Locate the learn button on the ceiling mounted garage door STEP opener motor.
Page 380 HomeLink buttons. ■ Programming other devices To program other devices such as home security systems, home door locks or lighting, contact your authorized Lexus dealer for assistance. ■ Reprogramming a button  The individual HomeLink buttons cannot be erased but can be reprogrammed.
Page 381 3-7. Other interior features  Erasing the entire HomeLink memory (all three programs) Press and hold the 2 outside but- tons for 10 seconds until the indi- cator light flashes. If you sell your vehicle, be sure to erase the programs stored in the ...
Page 382 3-7. Other interior features CAUTION When programming a garage door or other remote control device ■ The garage door on other devices may operate, so ensure people and objects are out of danger to prevent potential harm. Conforming to federal safety standards ■...
Page 383: Compass
3-7. Other interior features  Compass The compass on the inside rear view mirror indicates the direction in which the vehicle is heading. ■ Operation To turn the compass on or off, push “AUTO” for 3 seconds. ■ Displays and directions Display Direction “N”...
Page 384 3-7. Other interior features Calibrating the compass The direction display deviates from the true direction determined by the earth’ s magnetic field. The amount of deviation varies according to the geographic position of the vehicle. If you cross over a map boundary shown in illustration, the compass will devi- ate.
Page 385 3-7. Other interior features Press “AUTO” again. STEP If the direction is displayed several seconds after adjustment, the cali- bration is complete. ■ Circling calibration If “CAL” appears on the display, drive the vehicle at 5 mph (8 km/h) or less in a circle until a direction is displayed.
Page 386 3-7. Other interior features CAUTION While driving the vehicle ■ Do not adjust the display. Be sure to adjust the display only when the vehicle is stopped. When doing the circling calibration ■ Be sure to secure a wide space, and watch out for people and vehicles in the neigh- borhood.
Page 387: Safety Connect
Telematics Subscription Service Agreement and its Terms and Conditions, as in effect and amended from time to time, a current copy of which is avail- able at Lexus.com. All use of the Safety Connect service is subject to such then-applicable Terms and Conditions.
Page 388 After you have signed the Telematics Subscription Service Agree- ment and are enrolled, you can begin receiving services. A variety of subscription terms is available for purchase. Contact your Lexus dealer, call 1-800-25-LEXUS (1-800-255-3987) or push the “SOS” button in your vehicle for further subscription details.
Page 389 ● ing Safety Connect. Safety Connect is available beginning Fall 2009 on select Lexus models. Con- ● tact with the Safety Connect response center is dependent upon the telematics device being in operative condition, cellular connection availability, and GPS satellite signal reception, which can limit the ability to reach the response center or receive emergency service support.
Page 390 ● Green indicator light flashing = Safety Connect call in process ● Red indicator light (except at vehicle start-up) = System malfunction (contact your Lexus dealer) ● No indicator light (off) = Safety Connect service not active Safety Connect services ■...
Page 391 After filing a police report, call the Safety Connect response center at 1-800-25- LEXUS (1-800-255-3987) and follow the prompts for Safety Con- nect to initiate this service. In addition to assisting law enforcement with recovery of a stolen vehi- cle, Safety-Connect-equipped vehicle location data may, under cer- tain circumstances, be shared with third parties to locate your vehicle.
Page 392 3-7. Other interior features Safety information for Safety Connect Important! Read this information before using Safety Connect. ■ Exposure to radio frequency signals The Safety Connect system installed in your vehicle is a low-power radio transmitter and receiver. It receives and also sends out radio fre- quency (RF) signals.
Page 393 3-7. Other interior features Certification for Lexus Enform with Safety Connect ■ FCC ID: O9EGTM1 FCC ID: O6Y-CDMRF101 FCC ID: N7NGTM2 NOTE: This device complies with part 15 of the FCC Rules. Operation is subject to the fol- lowing two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 394 3-7. Other interior features...
Page 395: Maintenance And Care
Maintenance and care 4-1. Maintenance and care 4-3. Do-it-yourself maintenance Cleaning and protecting the vehicle exterior..... 396 Do-it-yourself service precautions......410 Cleaning and protecting the vehicle interior....401 Hood........... 413 Positioning a floor jack ..414 4-2. Maintenance Engine compartment .... 416 Maintenance Tires..........
Page 396: Cleaning And Protecting The Vehicle Exterior
4-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condi- tion. ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 397 • Do not use any metallic objects to remove condensation build up. When the water-repellent performance has become insufficient, the coating ● can be repaired. Contact your Lexus dealer. Outside rear view mirror rain-clearing coating (if equipped) ■ Observe the following precautions in order to retain the rain-clearing properties of the mirror.
Page 398 4-1. Maintenance and care CAUTION When cleaning the windshield (vehicles with the rain-sensing windshield wipers) ■ Set the wiper switch to off. If the wiper switch is in “AUTO”, the wipers may operate unexpectedly in the following situations, and may result in hands being caught or other serious injuries and cause damage to the wiper blades.
Page 399 4-1. Maintenance and care NOTICE To prevent paint deterioration and corrosion on the body and components (alu- ■ minum wheels etc.) Wash the vehicle immediately in the following cases: ● • After driving near the sea coast • After driving on salted roads •...
Page 400 4-1. Maintenance and care NOTICE To prevent damage to the windshield wiper arms ■ When lifting the wiper arms away from the windshield, pull the driver side wiper arm upward first, and repeat for the passenger side. When returning the wipers to their original position, do so from the passenger side first.
Page 401: Cleaning And Protecting The Vehicle Interior
4-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle's interior and keep it in top condition: ■ Protecting the vehicle interior Remove dirt and dust using a vacuum cleaner. Wipe dirty surfaces with a cloth dampened with lukewarm water.
Page 402 4-1. Maintenance and care Caring for leather areas ■ Lexus recommends cleaning the interior of the vehicle at least twice a year to main- tain the quality of the vehicle’ s interior. Shampooing the carpets ■ There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
Page 403 4-1. Maintenance and care NOTICE Cleaning detergents ■ Do not use organic substances such as benzene or gasoline, acidic or alkaline ● solutions, dye, bleach or other detergent. Doing so may discolor the vehicle inte- rior or cause streaks or damage to painted surfaces. Do not use polish wax or polish cleaner.
Page 404: Maintenance Maintenance Requirements
It is recommended that genuine Lexus parts be used for repair to ensure perfor- mance of each system. If non-Lexus parts are used in replacement or if a repair shop other than a Lexus dealer performs repairs, confirm the warranty coverage.
Page 405 “000000”. Allow inspection and repairs to be performed by a Lexus dealer ■ Lexus technicians are well-trained specialists and are kept up to date with the ● latest service information. They are well informed about the operations of all systems on your vehicle.
Page 406: General Maintenance
“Warranty and Services Guide” or “Owners Manual Supplement”. It is recommended that any problem you notice should be brought to the attention of your Lexus dealer or qualified service shop for advice. Engine compartment...
Page 407: Vehicle Interior
4-2. Maintenance Vehicle interior Items Check points • Moves smoothly (without uneven Accelerator pedal pedal effort or catching)? • Can the vehicle be held securely Automatic transmission “Park” on an incline with the shift lever in mechanism • Moves smoothly? Brake pedal •...
Page 408: Vehicle Exterior
4-2. Maintenance Items Check points • Moves smoothly? Steering wheel • Has correct free play? • No strange noises? Vehicle exterior Items Check points Door/trunk • Operate smoothly? Engine hood • The lock system works properly? Fluid leaks • Is there any leakage after parking? •...
Page 409: Emission Inspection And Maintenance (I/M) Programs
If the malfunction indicator lamp comes on The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/M test and may need to be repaired. Contact your Lexus dealer to service the vehicle. ■...
Page 410: Do-It-Yourself Maintenance Do-It-Yourself Service Precautions
4-3. Do-it-yourself maintenance Do-it-yourself service precautions If you perform maintenance yourself, be sure to follow the correct proce- dure given in these sections. Items Parts and tools • Warm water • Baking soda Battery condition ( P. 427 ) • Grease •...
Page 411 4-3. Do-it-yourself maintenance Items Parts and tools • “Toyota Genuine Motor Oil” or equivalent Engine oil level (P. 420) • Rag or paper towel, funnel (used only for adding engine oil) • Fuse with same amperage rating as Fuses (P. 451) original •...
Page 412 4-3. Do-it-yourself maintenance CAUTION When working near the electric cooling fan or radiator grille ■ Be sure the “ENGINE START STOP” switch is OFF. With the “ENGINE START STOP” switch in IGNITION ON mode, the electric cooling fan may automatically start to run if the air conditioning is on and/or the coolant temperature is high.
Page 413: Hood
4-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood release lever. STEP The hood will pop up slightly. Lift the auxiliary catch lever and STEP lift the hood. CAUTION Pre-driving check ■...
Page 414: Positioning A Floor Jack
4-3. Do-it-yourself maintenance Positioning a floor jack When raising your vehicle with a floor jack, position the jack correctly. Improper placement may damage your vehicle or cause injury. ■ Front ■ Rear Position the floor jack diagonally in the direction of the arrow marked on the underbody cover.
Page 415 4-3. Do-it-yourself maintenance CAUTION When raising your vehicle ■ Make sure to observe the following to reduce the possibility of death or serious injury. Lift up the vehicle using a floor jack such as ● the one shown in the illustration. When using a floor jack, follow the instructions of the manual provided with the ●...
Page 416: Engine Compartment
4-3. Do-it-yourself maintenance Engine compartment IS350C Battery (P. 427) Washer fluid tank (P. 430) Engine oil level dipstick (P. 420) Electric cooling fans Engine oil filler cap Condenser (P. 425) (P. 420) Radiator (P. 425) Brake fluid reservoir Engine coolant reservoir (P.
Page 417 4-3. Do-it-yourself maintenance IS250C Battery (P. 427) Washer fluid tank (P. 430) Engine oil level dipstick (P. 420) Electric cooling fans Engine oil filler cap Condenser (P. 425) (P. 420) Radiator (P. 425) Brake fluid reservoir Engine coolant reservoir (P. 425) (P.
Page 418 4-3. Do-it-yourself maintenance Engine compartment cover ■ Removing the engine compartment cover Front Outside...
Page 419 4-3. Do-it-yourself maintenance ■ Installing the clips Press the tip of the clip against a hard surface, such as a desk, to allow the center part of the clip to be pushed up. Insert Press NOTICE After installing an engine compartment cover ■...
Page 420 4-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. ■ Checking the engine oil Park the vehicle on level ground. After warming up the engine STEP and turning it off, wait more than five minutes for the oil to drain back into the bottom of the engine.
Page 421 4-3. Do-it-yourself maintenance ■ Adding engine oil If the oil level is below or near the low level mark, add engine oil of the same type as already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
Page 422 ● pose of used oil and filters in household trash, in sewers or onto the ground. Call your Lexus dealer, service station or auto parts store for information con- cerning recycling or disposal. Do not leave used engine oil within the reach of children.
Page 423 4-3. Do-it-yourself maintenance NOTICE To prevent serious engine damage ■ Check the oil level on a regular basis. When replacing the engine oil ■ Be careful not to spill engine oil on the vehicle components. ● Avoid overfilling, or the engine could be damaged. ●...
Page 424 Visually check the radiator, hoses, engine coolant filler cap, radiator cap, drain cock and water pump. If you cannot find a leak, have your Lexus dealer pressure test the cap and check for leaks in the cooling system. Coolant selection ■...
Page 425 Check the radiator and condenser and clear any foreign objects. If either of the above parts are extremely dirty or you are not sure of their condition, have your vehicle checked by your Lexus dealer. CAUTION When the engine is hot ■...
Page 426 4-3. Do-it-yourself maintenance CAUTION When filling the reservoir ■ Take care because brake fluid can harm your hands or eyes and damage painted surfaces. If fluid gets in your eyes, flush your eyes with clean water immediately. If you still experience discomfort, see a doctor. NOTICE If the fluid level is low or high ■...
Page 427 4-3. Do-it-yourself maintenance Battery Check the battery as follows. ■ Battery exterior Make sure that the battery terminals are not corroded and that there are no loose connections, cracks, or loose clamps. Terminals Hold-down clamp ■ Checking battery fluid Check that the level is between “UPPER LEVEL”...
Page 428 Open and close any of the doors. STEP Start the engine. (If the engine does not start first time, repeat the proce- STEP dure.) If the engine will not start even after multiple attempts at the above method, contact your Lexus dealer.
Page 429 4-3. Do-it-yourself maintenance CAUTION Chemicals in the battery ■ A battery contains poisonous and corrosive sulfuric acid and may produce hydro- gen gas which is flammable and explosive. To reduce the risk of death or serious injury, take the following precautions while working on or near the battery: Do not cause sparks by touching the battery terminals with tools.
Page 430 4-3. Do-it-yourself maintenance NOTICE When recharging the battery ■ Never recharge the battery while the engine is running. Also, be sure all accesso- ries are turned off. Washer fluid If any washer does not work or the warning message appears on the multi-information display, washer tank may be empty.
Page 431: Tires
Tires cannot be rotated. ■ The tire pressure warning system Your Lexus is equipped with a tire pressure warning system that uses tire pressure warning valves and transmitters to detect low tire infla- tion pressure before serious problems arise. (P. 493)
Page 432 ID codes must be regis- tered in the tire pressure warning computer and tire pressure warning system must be initialized. Have tire pressure warning valve and transmit- ter ID codes registered by your Lexus dealer. (P. 434) Initializing the tire pressure warning system ■...
Page 433 4-3. Do-it-yourself maintenance ■ How to initialize the tire pressure warning system To initialize the system, use the satellite switch. (P. 365) Park the vehicle in safe place and turn the “ENGINE START STEP STOP” switch OFF. While the vehicle is moving, initialization is not performed. Adjust the tire inflation pressure to the specified cold tire inflation STEP pressure level.
Page 434 “2ND” position: The ID code is not registered. When you replace a new set of tires, purchase tire pressure warning valves and transmitters from your Lexus dealer and have the new ID code registered by your Lexus dealer.
Page 435 4-3. Do-it-yourself maintenance ■ Selecting ID codes When replacing tires, make sure to select the ID code set that matches the new tire set. If the tire pressure warning select switch is set to the wrong tire setting, the tire pressure warning system will not operate properly.
Page 436 A tire goes flat repeatedly or cannot be properly repaired due to the size or ● location of a cut or other damage If you are not sure, consult with your Lexus dealer. Replacing tires and wheels ■ If the ID code of the tire pressure warning valve and transmitter is not registered, the tire pressure warning system will not work properly.
Page 437 4-3. Do-it-yourself maintenance Maximum load of tire ■ Check that the maximum load of the replacement tire is greater than 1/2 of the Gross Axle Weight Ratings (GAWR) of either the front axle or the rear axle, which- ever is greater. For the GAWR, see the Certification Label.
Page 438 If repeated attempts to record tire inflation pressure settings are unsuccessful, have the vehicle inspected by your Lexus dealer. When operating the satellite switch, the tire pressure warning light does not ●...
Page 439 When removing or fitting the wheels, tires or the tire pressure warning valves and ● transmitters, contact your Lexus dealer as the tire pressure warning valves and transmitters may be damaged if not handled correctly. When replacing tire valve caps, do not use tire valve caps other than those speci- ●...
Page 440 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Lexus dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when replacing the tire.
Page 441: Tire Inflation Pressure
4-3. Do-it-yourself maintenance Tire inflation pressure ■ Tire inflation pressure The recommended cold tire inflation pressure and tire size is dis- played on the tire and loading information label. (P. 563)
Page 442 4-3. Do-it-yourself maintenance ■ Inspection and adjustment procedure Tire valve Tire pressure gauge Remove the tire valve cap. STEP Press the tip of the tire pressure gauge onto the tire valve. STEP Read the pressure using the graduations of the gauge. STEP If the tire inflation pressure is not within the recommended lev- STEP...
Page 443 Reduced safety ● Damage to the drive train ● If a tire needs frequent refilling, have it checked by your Lexus dealer. Instructions for checking tire inflation pressure ■ When checking tire inflation pressure, observe the following: Check only when the tires are cold.
Page 444 4-3. Do-it-yourself maintenance CAUTION Proper inflation is critical to save tire performance ■ Keep your tires properly inflated. Otherwise, the following conditions may occur and result in an accident causing death or serious injury. Excessive wear ● Uneven wear ● Poor handling ●...
Page 445: Wheels
When replacing wheels ■ The wheels of your Lexus are equipped with tire pressure warning valves and trans- mitters that allow the tire pressure warning system to provide advanced warning in the event of a loss in tire inflation pressure. Whenever wheels are replaced, the tire...
Page 446 Because tire repair or replacement may affect the tire pressure warning valves ● and transmitters, make sure to have tires serviced by your Lexus dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valves and transmitters at your Lexus dealer.
Page 447: Air Conditioning Filter
4-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be changed regularly to maintain air condi- tioning efficiency. ■ Removal method Set the air conditioning system to recirculated mode. STEP (P. 242) The air conditioning filter case cannot be removed with the system in the outside air mode.
Page 448 4-3. Do-it-yourself maintenance ■ Replacement method Remove the air conditioning fil- ter from the filter case and replace it with a new one. The “UP” marks shown on the filter and the filter case should be pointing up. Checking interval ■...
Page 449: Electronic Key Battery
4-3. Do-it-yourself maintenance Electronic key battery Replace the battery with a new one if it is discharged. ■ You will need the following items: ● Flathead screwdriver ● Small Phillips-head screwdriver ● Lithium battery (CR1632) ■ Replacing the battery Take out the mechanical key. STEP Remove the cover.
Page 450 ● When the card key battery needs to be replaced (if equipped) ■ The battery for the card key is available only at Lexus dealers. Your Lexus dealer can replace the battery for you. CAUTION Removed battery and other parts ■...
Page 451: Checking And Replacing Fuses
4-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as necessary. Turn the “ENGINE START STOP” switch OFF. STEP Engine compartment (type B fuse box): Remove the engine STEP compartment cover.
Page 452 4-3. Do-it-yourself maintenance Driver's side instrument panel Remove the lid. Passenger's side instrument panel Remove the lid. Trunk Remove the lid. After a system failure, see “Fuse layout and amperage ratings” STEP (P. 455) for details about which fuse to check.
Page 453 4-3. Do-it-yourself maintenance Remove the fuse with the pull- STEP out tool. Check if the fuse has blown. STEP Type A Normal fuse Blown fuse Replace it with one of an appro- priate amperage rating. The amperage rating can be found on the fuse box lid.
Page 454 4-3. Do-it-yourself maintenance Type C Normal fuse Blown fuse Contact your Lexus dealer. Type D Normal fuse Blown fuse Contact your Lexus dealer. Removing the front controller (engine compartment: type B fuse box) Lift the lid off while pushing the...
Page 455 4-3. Do-it-yourself maintenance Fuse layout and amperage ratings ■ Engine compartment (type A fuse box) Fuse Ampere Circuit TURN-HAZ 15 A Emergency flashers, turn signals IG2 MAIN 20 A IG2, IGN, GAUGE RAD NO.2 30 A Audio D/C CUT 20 A DOME, MPX-B RAD NO.1 30 A...
Page 456 4-3. Do-it-yourself maintenance Fuse Ampere Circuit FR CTRL-B, ETCS, ALT-S, A/F, TEL, E/G-B 60 A STR LOCK ABS1 50 A VDIM RH J/B-B 30 A FR DOOR RH, AM2 MAIN 30 A H-LP R LWR, H-LP L LWR Smart access system with push-button STARTER 30 A start...
Page 457 4-3. Do-it-yourself maintenance Fuse Ampere Circuit H-LP CLN, FR CTRL-AM, DEICER, E/G-AM 60 A A/C COMP FR P/SEAT LH, TV NO.1, A/C, FUEL OPN, FR WIP, LH-IG, ECU-IG LH, LH J/B-AM 80 A PANEL, TAIL, MIR HTR, FR S/HTR LH, TV NO. 2, RR FOG...
Page 458 Exhaust system Multiport fuel injection system/ ETCS 10 A sequential multiport fuel injection sys- ALT-S 7.5 A Charging system 10 A Lexus Enform STR LOCK 25 A Steering lock system H-LP CLN 30 A Headlight cleaner A/C COMP 7.5 A...
Page 459 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Ignition system, multiport fuel injec- 10 A tion system/sequential multiport fuel injection system EFI NO.2 10 A Fuel system, exhaust system H-LP R LWR 15 A Headlight low beam (right) H-LP L LWR 15 A Headlight low beam (left) F/PMP 25 A...
Page 460 4-3. Do-it-yourself maintenance ■ Driver’s side instrument panel Fuse Ampere Circuit FR P/SEAT LH 30 A Power seat 7.5 A Air conditioning system MIR HTR 15 A Outside rear view mirror defoggers TV NO.1 10 A Display FUEL OPN 10 A Fuel filler door opener TV NO.2 7.5 A...
Page 461 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Cruise control, air conditioning sys- tem, power steering, rain sensor, anti- ECU-IG LH 10 A glare inside rear view mirror, shift lock system, tire inflation pressure warning system, vehicle stability control Seat heaters and ventilators, air condi- FR S/HTR LH 15 A tioning system...
Page 462 4-3. Do-it-yourself maintenance ■ Passenger’s side instrument panel Fuse Ampere Circuit FR P/SEAT RH 30 A Power seat DOOR DL 15 A 7.5 A On-board diagnosis system Stop lights, multiport fuel injection sys- STOP SW 7.5 A tem/sequential multiport fuel injection system, VDIM, shift lock system Electric tilt and telescopic steering TI &...
Page 463 4-3. Do-it-yourself maintenance Fuse Ampere Circuit 15 A Cigarette lighter PWR OUTLET 15 A Power outlet Power windows, outside rear view FR DOOR RH 20 A mirrors 7.5 A Starting system Seat belt pretensioner, intuitive park- RH-IG 7.5 A ing assist, automatic transmission, seat heater and ventilator Seat heaters and ventilators, air condi- FR S/HTR RH...
Page 464 If the lights do not turn on even after the fuse has been replaced, a bulb may ● need replacement. (P. 468) If the replaced fuse blows again, have the vehicle inspected by your Lexus ● dealer. If there is an overload in the circuits ■...
Page 465 ● Never replace a fuse with a wire, even as a temporary fix. Do not modify fuses or the fuse box. ● NOTICE Before replacing fuses ■ Have the cause of electrical overload determined and repaired by your Lexus dealer.
Page 466: Headlight Aim
4-3. Do-it-yourself maintenance Headlight aim ■ Removing the engine compartment cover P. 418 ■ Vertical movement adjusting bolts Adjustment bolt A Adjustment bolt B ■ Before checking the headlight aim Make sure the vehicle has a full tank of gas and the area around STEP the headlight is not deformed.
Page 467 Turn bolt B the same number of STEP turns and in the same direction as step 1 using a Phillips-head screwdriver. If the error is over the value specified above, take the vehicle to your Lexus dealer to adjust the headlight aim.
Page 468: Light Bulbs
4-3. Do-it-yourself maintenance Light bulbs You may replace the following bulbs yourself. For more information about replacing other light bulbs, contact your Lexus dealer. ■ Preparing a replacement light bulb Check the wattage of the light bulb being replaced. (P. 568) ■...
Page 469 4-3. Do-it-yourself maintenance ■ Rear bulb locations Rear turn signal lights Back-up lights...
Page 470 4-3. Do-it-yourself maintenance Replacing light bulbs ■ Headlight high beams and daytime running lights (vehicles with halo- gen headlights) Release the lock and remove the STEP cover. Turn the bulb base counterclock- STEP wise. Unplug the connector while STEP depressing the lock release.
Page 471 4-3. Do-it-yourself maintenance Replace the light bulb, and install STEP the bulb base. Align the 3 tabs on the light bulb with the mounting, and insert. Turn and secure the bulb base. STEP Shake the bulb base gently to check that it is not loose, turn the headlight high beams and daytime running lights on once and visually confirm that no light is leaking...
Page 472 4-3. Do-it-yourself maintenance ■ Headlight high beams (vehicles with discharge headlights) Turn the cover counterclockwise STEP and remove it. Turn the bulb base counterclock- STEP wise. Unplug the connector while pull- STEP ing the lock release.
Page 473 4-3. Do-it-yourself maintenance Replace the light bulb, and install STEP the bulb base. Align the 3 tabs on the light bulb with the mounting, and insert. Turn and secure the bulb base. STEP Shake the bulb base gently to check that it is not loose, turn the headlight high beams on once and visually confirm that no light is leak- ing through the mounting.
Page 474 4-3. Do-it-yourself maintenance ■ Parking lights (vehicles with halogen headlights) Release the lock and remove the STEP cover. Turn the bulb base counterclock- STEP wise. Remove the light bulb. STEP...
Page 475 4-3. Do-it-yourself maintenance ■ Back-up light Open the trunk lid and remove the STEP trunk panel cover clips. Partly remove the trunk panel STEP cover and turn bulb bases coun- terclockwise. Remove the light bulb. STEP...
Page 476 4-3. Do-it-yourself maintenance ■ Rear turn signal lights Open the trunk lid and remove the STEP covers. Remove the bolts and unit. STEP Turn the bulb base counterclock- STEP wise. Remove the light bulb. STEP...
Page 477 4-3. Do-it-yourself maintenance ■ Bulbs other than the above If any of the bulbs listed below has burnt out, have your Lexus dealer replace it. ● Headlight low beams (vehicles with halogen bulbs) ● Headlight high and low beams (vehicles with discharge bulbs) ●...
Page 478 LEDs. If any of the LEDs burn out, take your vehicle to your Lexus dealer to have the light replaced. CAUTION Replacing light bulbs ■...
Page 479 4-3. Do-it-yourself maintenance CAUTION Discharge headlights (if equipped) ■ Contact your Lexus dealer before replacing discharge headlights (including light ● bulbs). Do not touch the high-intensity discharge headlight’ s high voltage socket when ● the headlights are turned on. An extremely high voltage of 20000 V will be discharged and could result in serious injury or death by electric shock.
Page 480 4-3. Do-it-yourself maintenance...
Page 481: When Trouble Arises
When trouble arises 5-1. Essential information 5-2. Steps to take in an emergency Emergency flashers....482 If a warning light turns If your vehicle needs to on or a warning buzzer be towed........ 483 sounds........491 If you think something is If a warning message is wrong ........
Page 482: 5-1. Essential Information
5-1. Essential information Emergency flashers Use the emergency flashers if the vehicle malfunctions or is involved in an accident. Press the switch to flash all the turn signal lights. To turn them off, press the switch once again. NOTICE To prevent battery discharge ■...
Page 483: If Your Vehicle Needs To Be Towed
If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Lexus dealer or a commercial towing service, using a lift-type truck or a flat bed truck. Use a safety chain system for all towing, and abide by all state/provincial and local laws.
Page 484 5-1. Essential information Emergency towing procedure ■ Release the parking brake. STEP Shift the shift lever to N. STEP Put the “ENGINE START STOP” switch in ACCESSORY mode or IGNI- STEP TION ON mode. CAUTION Caution while towing ■ Use extreme caution when towing the vehicle. ●...
Page 485 5-1. Essential information Installing towing eyelets Remove the eyelet cover using a STEP flathead screwdriver. To protect the bodywork, place a rag between the screwdriver and the vehicle body, as shown in the illustration. Insert the towing eyelet into the STEP hole and tighten partially by hand.
Page 486 5-1. Essential information CAUTION Installing towing eyelets to the vehicle ■ Make sure that towing eyelets are installed securely. If not securely installed, towing eyelets may come loose during towing. This may lead to accidents that cause serious injury or even death. Towing with a sling-type truck NOTICE To prevent body damage...
Page 487 5-1. Essential information Towing with a wheel lift-type truck From the front Use a towing dolly under the rear wheels. From the rear Switch to ACCESSORY mode so that steering wheel unlocked.
Page 488 Without adequate clearance, the vehicle could be damaged while being towed from the rear. Using a flat bed truck If your Lexus is transported by a flat bed truck, it should be tied down at the locations shown in the illustration.
Page 489: If You Think Something Is Wrong
5-1. Essential information If you think something is wrong If you notice any of the following symptoms, your vehicle probably needs adjustment or repair. Contact your Lexus dealer as soon as possible. ■ Visible symptoms ● Fluid leaks under the vehicle (Water dripping from the air conditioning after use is normal.)
Page 490: Fuel Pump Shut Off System
5-1. Essential information Fuel pump shut off system To minimize the risk of fuel leakage when the engine stalls or an airbag inflates upon collision, the fuel pump shut off system stops supplying fuel to the engine. Follow the procedure below to restart the engine after the system is activated.
Page 491: 5-2. Steps To Take In An Emergency
Stop the vehicle immediately. Continuing to drive the vehicle may be dangerous. The following warning indicates a possible problem in the brake system. Immediately stop the vehicle in a safe place and contact your Lexus dealer. Warning light...
Page 492 5-2. Steps to take in an emergency Have the vehicle inspected by your Lexus dealer immediately. Failing to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident. Have the vehicle inspected by your Lexus dealer immediately.
Page 493 5-2. Steps to take in an emergency Warning light Warning light/Details Slip indicator Indicates a malfunction in: • The VSC system; • The TRAC system; or • The hill-start assist control system Follow the correction procedures. After taking the specified steps to correct the suspected problem, check that the warning light turns off.
Page 494 • Natural causes (P. 496) tire inflation pressure is • Flat tire (P. 513, 522) adjusted, have the system checked by your Lexus dealer. When the light comes on after blinking for 1 minute: Have the system checked by Malfunction in the tire pres- your Lexus dealer.
Page 495 If it is, tighten it securely. The lamp will go off after taking several driving trips. If the lamp does not go off even after several trips, contact your Lexus dealer as soon as possible. Electric power steering system warning light ■...
Page 496 If there is a lot of snow or ice on the vehicle, in particular around the wheels or ● wheel housings If non-genuine Lexus wheels are used (Even if you use Lexus wheels, the tire ● pressure warning system may not work properly with some types of tires.) If tire chains are used ●...
Page 497 • If the tire pressure warning light comes on even after tire inflation pressure adjustment, it is probable that you have a flat tire. Have the tire replaced by the nearest Lexus dealer. • Avoid abrupt maneuvering and braking. If the vehicle tires deteriorate, you could lose control of the steering wheel or the brakes.
Page 498 5-2. Steps to take in an emergency CAUTION Maintenance of the tires ■ Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label (tire and load information label). (If your vehicle has tires of a different size than the size indicated on the vehicle placard or tire inflation pressure label [tire and load information label], you should determine the proper tire inflation pressure for those tires.)
Page 499 5-2. Steps to take in an emergency NOTICE Precaution when installing a different tire ■ When a tire of a different specification or maker is installed, the tire pressure warn- ing system may not operate properly.
Page 500: If A Warning Message Is Displayed
A buzzer sounds and a warning message is shown on the multi-informa- tion display. The following warnings indicate the possibility of damage to the vehicle that may lead to an accident. Immediately stop the vehicle in a safe place and contact your Lexus dealer. Message Details (U.S.A)
Page 501 5-2. Steps to take in an emergency Have the vehicle inspected by your Lexus dealer immediately. A buzzer sounds and a message is shown. Failure to investigate the cause of the following messages may lead to the system operating abnormally and possibly cause an accident.
Page 502 5-2. Steps to take in an emergency Message Details Indicates intuitive parking assist malfunction. The malfunctioning assist-sensor is shown flashing on the display. (If equipped) Indicates a malfunction in the radar cruise control system. Press the “ON-OFF” button once to deactivate the (Flashing) system, and then press the button again to reactivate the system.
Page 503 5-2. Steps to take in an emergency Follow the correction procedures. A buzzer sounds and a message is shown. After taking the specified steps to correct the suspected problem, check that the message goes off. Message Details Correction procedure Indicates that one or more of the doors is not fully closed.
Page 504 5-2. Steps to take in an emergency Message Details Correction procedure Indicates that the trunk is not fully closed. flashes and a buzzer sounds to indi- Close the trunk. cate that trunk is not fully closed (with the vehicle having reached a speed of 3 mph [5 km/h]).
Page 505 5-2. Steps to take in an emergency Message Details Correction procedure • The roof switch was operated when there was an obstacle behind the vehicle. • Operation of the retractable hardtop was suspended due to an (P. 86) obstacle being detected behind the vehicle.
Page 506 5-2. Steps to take in an emergency Message Details Correction procedure The roof switch was pressed while the lug- (P. 86) gage cover was not in the correct position. Indicates that the parking brake is still engaged. flashes and a buzzer sounds to indi- Release the parking cate that the parking...
Page 507 5-2. Steps to take in an emergency Message Details Correction procedure Indicates that all mainte- nance according to the driven distance on the maintenance schedule* should be performed If necessary, perform soon. maintenance. Comes on approximately 4500 miles (7200 km) (U.S.A.
Page 508 5-2. Steps to take in an emergency Message Details Correction procedure Indicates that intuitive parking assist is dirty or Clean the sensor. covered with ice. (If equipped) Indicates that the radar cruise control sensor is Clean the sensor. (Flashing) dirty or covered with ice. (If equipped) •...
Page 509 5-2. Steps to take in an emergency Message Details Correction procedure Indicates that there is a high possibility of a fron- Slow the vehicle by apply- tal collision, or that the ing the brakes. (Flashing pre-collision braking quickly) function is operating. (If equipped) *: Refer to the separate “Scheduled Maintenance”...
Page 510 5-2. Steps to take in an emergency Follow the correction procedures. After taking the specified steps to correct the suspected problem, check that the warning light turns off. Interior Correction Exterior Message Details buzzer buzzer procedure Indicates that an attempt was made to start the engine Start the engine without the elec-...
Page 511 5-2. Steps to take in an emergency Interior Correction Exterior Message Details buzzer buzzer procedure Indicates that the driver’ s door has been opened or closed with the Turn the shift lever in P, the “ENGINE START “ENGINE START STOP” switch Once 3 times STOP”...
Page 512 5-2. Steps to take in an emergency Interior Correction Exterior Message Details buzzer buzzer procedure Indicates that a door has been opened or closed Press the and the “ENGINE “ENGINE START  Once START STOP” STOP” switch switch has been while applying the switched twice to brakes.
Page 513: If You Have A Flat Tire (Vehicles With Standard Tires)
5-2. Steps to take in an emergency If you have a flat tire (vehicles with standard tires) Remove the flat tire and replace it with the spare provided. ■ Before jacking up the vehicle ● Stop the vehicle on a hard, flat surface. ●...
Page 514 5-2. Steps to take in an emergency Taking out the spare tire Lift up the hook of the panel on the STEP trunk floor. Secure the panel using the hook STEP provided. Loosen the center fastener that STEP secures the spare tire.
Page 515 5-2. Steps to take in an emergency Replacing a flat tire Chock the tires. STEP Wheel chock Flat tire positions Behind the Left-hand rear right- side hand side tire Front Behind the Right- rear left- hand side hand side tire In front of the Left-hand front right-...
Page 516 5-2. Steps to take in an emergency Raise the vehicle until the tire is STEP slightly raised off the ground. Remove all the wheel nuts and the STEP tire. When resting the tire on the ground, place the tire so that the wheel design faces up to avoid scratching the wheel surface.
Page 517 5-2. Steps to take in an emergency Install the spare tire and loosely Tapered portion STEP tighten each nut by hand to approximately the same amount. Tighten the wheel nuts until the tapered portion comes into loose Disc wheel contact with the disc wheel seat. seat Lower the vehicle.
Page 518 5-2. Steps to take in an emergency The compact spare tire ■ The compact spare tire is identified by the label “TEMPORARY USE ONLY” ● on the tire sidewall. Use the compact spare tire temporarily only in an emergency. Make sure to check the tire pressure of the compact spare tire. (P. 563) ●...
Page 519 5-2. Steps to take in an emergency CAUTION Using the tire jack ■ Improper use of the tire jack may lead to death or serious injuries due to the vehicle suddenly falling off the jack. Do not use the tire jack for any purpose other than replacing tires or installing and ●...
Page 520 5-2. Steps to take in an emergency CAUTION When using the compact spare tire ■ Remember that your compact spare tire is specifically designed for use with your ● vehicle. Do not use your compact spare tire on another vehicle. Do not use two compact spare tires simultaneously.
Page 521 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Lexus dealer or other qualified service shop as soon as possible. Make sure to replace the...
Page 522: If You Have A Flat Tire (Vehicles With Run-Flat Tires)
5-2. Steps to take in an emergency If you have a flat tire (vehicles with run-flat tires) Take your vehicle to the nearest Lexus dealer or authorized tire dealer as soon as possible. ■ Run-flat tires (A “RFT” or “DSST” mark is molded on the sidewall)
Page 523 ■ When removing or fitting the wheels, tires or the tire pressure warning valve and transmitter, contact your Lexus dealer as the tire pressure warning valve and trans- mitter may be damaged if not handled correctly. To avoid damaging the tire pressure warning valves and transmitters ■...
Page 524: If The Engine Will Not Start
5-2. Steps to take in an emergency If the engine will not start If the engine will not start even though correct starting procedures are  being followed ( P. 147), consider each of the following points. ■ The engine will not start even when the starter motor operates normally.
Page 525 ● One or both of the battery terminals may be disconnected. ● The battery may be discharged. (P. 532) ● There may be a malfunction in the steering lock system. Contact your Lexus dealer if the problem cannot be repaired, or if repair procedures are unknown.
Page 526: If The Shift Lever Cannot Be Shifted From P
If the shift lever cannot be shifted with your foot on the brake, there may be a problem with the shift lock system (a system to prevent accidental opera- tion of the shift lever). Have the vehicle inspected by your Lexus dealer immediately.
Page 527: If You Lose Your Keys
5-2. Steps to take in an emergency If you lose your keys New genuine Lexus keys can be made by your Lexus dealer using the other key and the key number stamped on your key number plate.
Page 528: If The Electronic Key Does Not Operate Properly
5-2. Steps to take in an emergency If the electronic key does not operate properly If communication between the electronic key and vehicle is interrupted (P. 36) or the electronic key cannot be used because the battery is depleted, the smart access system with push-button start and wireless remote control cannot be used.
Page 529 5-2. Steps to take in an emergency After the operation is completed, STEP reinstall the cover. Hook the upper claw of the cover onto the upper catch on the vehi- cle side, and then push on the lower side of the cover. Make sure that the lower claw of the cover is securely fastened to the lower catch on the vehicle side.
Page 530 Press the “ENGINE START STOP” switch within 10 seconds STEP after the buzzer sounds, keeping the brake pedal depressed. In the event that the engine still cannot be started, contact your Lexus dealer.
Page 531 5-2. Steps to take in an emergency Stopping the engine ■ Shift the shift lever to P and press the “ENGINE START STOP” switch as you nor- mally do when stopping the engine. Replacing the key battery ■ As the above procedure is a temporary measure, it is recommended that the elec- tronic key battery be replaced immediately when the battery depletes.
Page 532: If The Vehicle Battery Is Discharged
You can call your Lexus dealer, or qualified repair shop. If you have a set of jumper (or booster) cables and a second vehicle with a 12-volt battery, you can jump start your Lexus following the steps below. Remove the engine compartment covers. (P. 418) STEP Connecting the jumper cables.
Page 533 Once the vehicle’ s engine has started, remove the jumper STEP cables in the exact reverse order in which they were con- nected. Once the engine starts, have the vehicle checked at your Lexus dealer as soon as possible. Avoiding a discharged battery ■...
Page 534 5-2. Steps to take in an emergency CAUTION Avoiding battery fires or explosions ■ Observe the following precautions to prevent accidentally igniting the flammable gas that may be emitted from the battery. Make sure the jumper cable is connected to the correct terminal and that it is not ●...
Page 535 5-2. Steps to take in an emergency NOTICE To prevent damaging the vehicle ■ Do not pull- or push-start the vehicle, because the three-way catalytic converter may overheat and become a fire hazard. When handling jumper cables ■ Be careful that the jumper cables do not become tangled in the cooling fan or any of the belts when connecting or disconnecting them.
Page 536: If Your Vehicle Overheats
Wait until the temperature of the engine (shown on the instrument cluster) begins to fall and then stop the engine. If the fan is not operating: Stop the engine immediately and call your local Lexus dealer. After the engine has cooled...
Page 537 STEP Water can be used in an emer- gency measure if engine coolant is unavailable. (P. 559) Have the vehicle checked at your nearest Lexus dealer as soon as pos- sible. Overheating ■ If you observe the following, your vehicle may be overheating.
Page 538 5-2. Steps to take in an emergency NOTICE When adding engine coolant ■ Wait until the engine has cooled down before adding engine coolant. When adding coolant, do so slowly. Adding cool coolant to a hot engine too quickly can cause damage to the engine.
Page 539: If The Vehicle Becomes Stuck
5-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt, or snow. Stop the engine. Set the parking brake and shift the shift lever STEP in P.
Page 540: If The Retractable Hardtop Does Not Close
If the retractable hardtop will not close even though all operating condi- tions have been met, there may be a malfunction. Immediately have the vehicle inspected by your Lexus dealer. As a temporary measure, the following procedure can be performed to manually close the retractable hardtop.
Page 541 5-2. Steps to take in an emergency Pulling the yellow rings attached to STEP the left and right sides of the trunk, raise the front end of the trunk lid. Holding the parts in the same STEP places as those shown in the illus- trations, lift the trunk lid and move it as far as possible toward the rear of the vehicle.
Page 542 5-2. Steps to take in an emergency Remove the 2 screws and cover STEP from each trunk lid hinge. Remove the bolts and brackets. STEP...
Page 543 5-2. Steps to take in an emergency Detach the connector on each STEP trunk lid hinge. Remove the bolts and connector STEP brackets. Remove the 2 bolts and side pack- STEP age tray from each trunk lid hinge. Support each side package tray by hand to prevent it from falling down.
Page 544 5-2. Steps to take in an emergency Remove the board on the rear STEP side. Remove the board on the front STEP side. Remove the 6 bolts and rear plate. STEP Remove the 4 bolts and front plate. STEP...
Page 545 5-2. Steps to take in an emergency Using an open-end wrench, turn STEP the six-sided part of the silver rod as far as possible. The plate brackets will rise up. Using a hexagon wrench, remove STEP the 2 bolts and lock on the left and right sides of the vehicle.
Page 546 5-2. Steps to take in an emergency Remove the forward lock cover STEP located on the ceiling. Insert the end of the hexagon STEP wrench and turn it counterclock- wise as far as possible to release the forward lock. The roof panel will be fully lowered. Be careful not to catch your hands or fingers between the roof panel and vehicle body when releasing...
Page 547 5-2. Steps to take in an emergency Holding the parts in the same STEP places as those shown in the illus- trations, carefully raise the rear window panel until it comes into contact with the roof panel. Performing this procedure by hold- ing parts other than those indi- cated may result in damage to the vehicle or serious injury.
Page 548 5-2. Steps to take in an emergency Holding the parts in the same STEP places as those shown in the illus- trations, push the trunk lid down toward the front of the vehicle until it locks. Performing this procedure by hold- ing parts other than those indi- cated may result in damage to the vehicle or serious injury.
Page 549 Drive as slowly as possible. The trunk lid may not be closed securely, causing it to ● open due to wind pressure while driving. After the procedure is performed, take the vehicle to your Lexus dealer as soon ● as possible.
Page 550: If Your Vehicle Has To Be Stopped In An Emergency
5-2. Steps to take in an emergency If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the following procedure: Steadily step on the brake pedal with both feet and firmly STEP depress it.
Page 551: Vehicle Specifications
Vehicle specifications 6-1. Specifications Maintenance data (fuel, oil level, etc.) ....552 Fuel information..... 569 Tire information...... 573 6-2. Customization Customizable features ..586 6-3. Initialization Items to initialize ....590...
Page 552: Specifications Maintenance Data (Fuel, Oil Level, Etc.)
6-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions and weight Overall length 182.5 in. (4635 mm) Overall width 70. 9 in. (1800 mm) Overall height 55.7 in. (1415 mm) Wheelbase 107.4 in. (2730 mm) Front 60.4 in. (1535 mm) Tread 60.4 in.
Page 553 Vehicle identification number The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Lexus. It is used in registering the ownership of your vehicle. This number is stamped on the top left of the instrument panel and in the engine compartment.
Page 554 6-1. Specifications ■ Engine number The engine number is stamped on the engine block as shown.
Page 555 6-1. Specifications Engine IS250C IS350C Model 4GR-FSE 2GR-FSE 6-cylinder V type, 6-cylinder V type, Type 4-cycle, gasoline 4-cycle, gasoline 3.70  3.27 in. 3.27 3.03 in. Bore and stroke (83.0  77.0 mm) (94.0  83.0 mm) 152.5 cu.in. 210. 9 cu.in. Displacement (2500 cm (3456 cm...
Page 556 ■ Engine oil selection IS250C “Toyota Genuine Motor Oil” is used in your Lexus vehicle. Use Lexus approved “Toyota Genuine Motor Oil” or equivalent to satisfy the follow- ing grade and viscosity. Oil grade: ILSAC GF-5 multigrade engine oil...
Page 557 6-1. Specifications Oil viscosity (0W-20 is explained here as an example): • The 0W in 0W-20 indicates the characteristic of the oil which allows cold startability. Oils with a lower value before the W allow for easier starting of the engine in cold weather. •...
Page 558 6-1. Specifications IS350C “Toyota Genuine Motor Oil” is used in your Lexus vehicle. Use Lexus approved “Toyota Genuine Motor Oil” or equivalent to satisfy the follow- ing grade and viscosity. Oil grade: ILSAC GF-5 multigrade engine oil Recommended viscosity: SAE 5W-30...
Page 559 6-1. Specifications How to read oil container label: The ILSAC (International Lubricant Standardization and Approval Com- mittee) Certification Mark is added to some oil containers to help you select the oil you should use. Cooling system IS350C 9.6 qt. (9.1 L, 8.0 Imp. qt.) Capacity IS250C 10.
Page 560: Electrical System
6-1. Specifications Ignition system Spark plug Make DENSO FK20HBR11 0.043 in. (1.1 mm) NOTICE Iridium-tipped spark plugs ■ Use only iridium-tipped spark plugs. Do not adjust gap when tuning engine. Electrical system Battery 12.6  Open voltage* at 12.8 V Fully charged ...
Page 561 Oil type and viscosity* GL-5 or equivalent : Your Lexus vehicle is filled with “Toyota Genuine Differential Gear Oil” at the factory. Use Lexus approved “Toyota Genuine Differential Gear Oil” or an equivalent oil of matching quality that satisfies the above specifications. Please contact your Lexus dealer for further details.
Page 562 6-1. Specifications Brakes Pedal clearance IS 350C 4.13 in. (105 mm) Min. IS 250C 4.3 in. (108 mm) Min. Pedal free play 0.04 0.08 in. (1.0 2.0 mm)   Brake pad wear limit 0.04 in. (1.0 mm) Parking brake lining wear limit 0.04 in.
Page 563 6-1. Specifications Steering Free play Less than 1.2 in. (30 mm) Tires and wheels Type A Front tires: 225/45R17 90W Tire size Rear tires: 245/45R17 95W Spare tire: T125/70D17 98M Driving under normal conditions Front: 35 psi (240 kPa, 2.4 kgf/cm or bar)* Rear: 38 psi (260 kPa, 2.6 kgf/cm...
Page 564 6-1. Specifications Type B Front tires: 225/45R17 91V Tire size Rear tires: 245/45R17 95V Spare tire: T125/70D17 98M Driving under normal conditions Front: 35 psi (240 kPa, 2.4 kgf/cm or bar)* Rear: 38 psi (260 kPa, 2.6 kgf/cm or bar)* Front and rear tire inflation pres- Spare: sure...
Page 565 6-1. Specifications Type C Front tires: 225/40R18 88Y Tire size Rear tires: 255/40R18 95Y Spare tire: T145/70D17 106M Driving under normal conditions Front: 35 psi (240 kPa, 2.4 kgf/cm or bar)* Rear: 38 psi (260 kPa, 2.6 kgf/cm or bar)* Front and rear tire inflation pres- Spare: sure...
Page 566 6-1. Specifications Type D Front tires: 225/40R18 88W Tire size Rear tires: 255/40R18 95W Spare tire: T145/70D17 106M Driving under normal conditions Front: 35 psi (240 kPa, 2.4 kgf/cm or bar)* Rear: 38 psi (260 kPa, 2.6 kgf/cm or bar)* Front and rear tire inflation pres- Spare: sure...
Page 567 6-1. Specifications Type E Front tires: 225/40RF18 88V Tire size Rear tires: 255/40RF18 95V Driving under normal conditions Front: 35 psi (240 kPa, 2.4 kgf/cm or bar)* Rear: Front and rear tire inflation pres- 38 psi (260 kPa, 2.6 kgf/cm or bar)* sure *: When driving at high speeds above 100 mph...
Page 568 6-1. Specifications Light bulbs Light Bulbs Bulb No. Type Headlights High beam 9005 Low/high beam (discharge bulbs) Low beam (halogen bulbs) Front turn signal lights WY21W Exterior Parking lights (vehicles with halogen headlights) Front fog lights Rear turn signal lights WY21W Back-up lights ...
Page 569: Fuel Information
ASTM D4814 in the U.S.A. and CGSB3.5-M93 in Canada. Fuel tank opening for unleaded gasoline ■ To help prevent incorrect fueling, your Lexus has a fuel tank opening that only accommodates the special nozzle on unleaded fuel pumps. If your engine knocks ■...
Page 570 EPA’ s lowest additives concentration pro- gram. Lexus strongly recommends the use of Top Tier Detergent Gasoline. For more ● information on Top Tier Detergent Gasoline and a list of marketers, please go to the official website www.toptiergas.com.
Page 571 10% ethanol). (85% ethanol) If you use gasohol in your Lexus, be sure that it has an octane rating no lower ● than 87. Lexus DOES NOT recommend the use of gasoline containing methanol.
Page 572 6-1. Specifications NOTICE Notice on fuel quality ■ Do not use improper fuels. If improper fuels are used the engine will be damaged. ● Do not use leaded gasoline. ● Leaded gasoline can cause damage to your vehicle’ s three-way catalytic convert- ers causing the emission control system to malfunction.
Page 573: Tire Information
6-1. Specifications Tire information Typical tire symbols Standard tire Compact spare tire Tire size (P. 576) DOT and Tire Identification Number (TIN) (P. 575) Location of treadwear indicators (P. 431) Tire ply composition and materials Plies are layers of rubber-coated parallel cords. Cords are the strands which form the plies in a tire.
Page 574 6-1. Specifications Radial tires or bias-ply tires A radial tire has “RADIAL” on the sidewall. A tire not marked “RADIAL” is a bias-ply tire. TUBELESS or TUBE TYPE A tubeless tire does not have a tube and air is directly filled in the tire. A tube type tire has a tube inside the tire and the tube maintains the air pres- sure.
Page 575 6-1. Specifications Typical DOT and tire identification number (TIN) DOT symbol Tire Identification Number (TIN) Tire manufacturer's identifica- tion mark Tire size code Manufacturer's optional tire type code (3 or 4 letters) Manufacturing week Manufacturing year : The DOT symbol certifies that the tire conforms to applicable Federal Motor Vehicle Safety Standards.
Page 576 6-1. Specifications Tire size ■ Typical tire size information The illustration indicates typical tire size. Tire use (P = Passenger car, T = Temporary use) Section width (millimeters) Aspect ratio (tire height to section width) Tire construction code (R = Radial, D = Diagonal) Wheel diameter (inches) Load index (2 or 3 digits) Speed symbol...
Page 577 National Highway Traffic Safety Administration of the U.S. Department of Transportation. It provides the purchasers and/or prospective purchasers of Lexus vehi- cles with information on uniform tire quality grading. Your Lexus dealer will help answer any questions you may have as you read this information.
Page 578 6-1. Specifications ■ DOT quality grades All passenger vehicle tires must conform to Federal Safety Require- ments in addition to these grades. Quality grades can be found where applicable on the tire sidewall between tread shoulder and maximum section width. For example: Treadwear 200 Traction AA Temperature A ■...
Page 579 6-1. Specifications ■ Temperature A, B, C The temperature grades are A (the highest), B, and C, representing the tire's resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 580 6-1. Specifications Tire related term Meaning Maximum inflation pres- The maximum cold inflated pressure to which a tire sure may be inflated, shown on the sidewall of the tire The sum of: (a) Curb weight Maximum loaded vehicle (b) Accessory weight weight (c) Vehicle capacity weight (d) Production options weight...
Page 581 6-1. Specifications Tire related term Meaning Rim width Nominal distance between rim flanges The load on an individual tire that is determined by Vehicle maximum load on distributing to each axle its share of the maximum the tire loaded vehicle weight, and dividing by two The load on an individual tire that is determined by distributing to each axle its share of curb weight, Vehicle normal load on...
Page 582 6-1. Specifications Tire related term Meaning The part of the tire that is made of steel wires, Bead wrapped or reinforced by ply cords and that is shaped to fit the rim A breakdown of the bond between components in Bead separation the bead A pneumatic tire in which the ply cords that extend to...
Page 583 6-1. Specifications Tire related term Meaning (a) The sidewall that contains a whitewall, bears white lettering, or bears manufacturer, brand, and/or model name molding that is higher or Intended outboard side- deeper than the same molding on the other side- wall wall of the tire, or (b) The outward facing sidewall of an asymmetrical...
Page 584 6-1. Specifications Tire related term Meaning A parting of rubber compound between adjacent Ply separation plies A mechanical device made of rubber, chemicals, fab- ric and steel or other materials, that, when mounted Pneumatic tire on an automotive wheel, provides the traction and contains the gas or fluid that sustains the load A pneumatic tire in which the ply cords that extend to Radial ply tire...
Page 585 6-1. Specifications Tire related term Meaning That portion of a tire that comes into contact with the Tread road A tread section running circumferentially around a Tread rib tire Tread separation Pulling away of the tread from the tire carcass The projections within the principal grooves Treadwear indicators designed to give a visual indication of the degrees of...
Page 586: Customization Customizable Features
Your vehicle includes a variety of electronic features that can be personal- ized to your preferences. Programming these preferences requires spe- cialized equipment and may be performed by an authorized Lexus dealership. Some function settings are changed simultaneously with other functions being customized.
Page 587 6-2. Customization Customized Item Function Default setting setting Time elapsed before auto- 30 seconds matic door lock function is activated if door is not 60 seconds opened after being 120 seconds unlocked Operation signal Wireless (Emergency flashers) remote con- Operation signal trol (Buzzer) ...
Page 588 6-2. Customization Customized Item Function Default setting setting Steering wheel Auto tilt-away function P. 76)  Power win- Wireless remote control dows linked operation P. 82)  Retractable hardtop Retractable operation control linked hardtop to the intuitive parking  P. 90) assist Light sensor sensitivity Level 3...
Page 589 6-2. Customization Customized Item Function Default setting setting Back sensor operation display and buzzer Intuitive park- ing assist Buzzer volume Level 3 Level 1 to 5  P. 208) Distance which a sensor 4. 9 ft. (150 cm) 2.0 ft. (60 cm) detects 7.5 seconds Time elapsed before lights...
Page 590: 6-3. Initialization
6-3. Initialization Items to initialize The following item must be initialized for normal system operation in cases such as after the battery is reconnected, or maintenance is performed on the vehicle. Item When to initialize Reference Maintenance data After the maintenance is performed P.
Page 591: For Owners
For owners Reporting safety defects for U.S. owners..... 592 Seat belt instructions for Canadian owners (in French) ......593 SRS airbag instructions for Canadian owners (in French) ......596 Headlight aim instructions for Canadian owners (in French) ......604...
Page 592: Reporting Safety Defects For U.s. Owners
National Highway Traffic Safety Administration (NHTSA) in addition to notifying the Lexus Division of Toyota Motor Sales, U.S.A., Inc. (Toll- free: 1-800-25-LEXUS). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 593: Seat Belt Instructions For Canadian Owners (In French)
Seat belt instructions for Canadian owners (in French) The following is a French explanation of seat belt instructions extracted from the seat belt section in this manual. See the seat belt section for more detailed seat belt instructions in English. Utilisation correcte des ceintures de sécurité...
Page 594 Guide de ceinture de sécurité avant Lorsque vous attachez ceinture sécurité avant, assurez-vous toujours qu'elle passe dans le guide. Lorsque vous accédez aux sièges arrière ou en descendez, sortez la ceinture de sécurité de son guide. Guide de ceinture de sécurité arrière Si la sangle diagonale gêne au niveau du cou de l'occupant, attachez la ceinture de sécurité...
Page 595 Entretien et soin ■ Ceintures de sécurité Nettoyez avec un chiffon ou une éponge humectée d'eau savonneuse tiède. Profitez de l'occasion pour vérifier régulièrement que les ceintures ne sont pas effilochées, entaillées, ou ne paraissent pas exagérément usées. ATTENTION ■ Détérioration et usure des ceintures de sécurité...
Page 596: Srs Airbag Instructions For Canadian Owners (In French)
SRS airbag instructions for Canadian owners (in French) The following is a French explanation of SRS airbag instructions extracted from the SRS airbag section in this manual. See the SRS airbag section for more detailed SRS airbag instructions in English. Sacs de sécurité...
Page 597 Composition du système de sacs de sécurité gonflables Sacs de sécurité gonflables de Contacteur de boucle de genoux ceinture sécurité conducteur Sac de sécurité gonflable passager avant Capteur de position du siège conducteur Témoins indicateurs “AIR BAG ON” et “AIR BAG OFF” Contacteur de boucle de ceinture de sécurité...
Page 598 Votre véhicule est équipé de SACS DE SÉCURITÉ GONFLABLES INTELLIGENTS (ADVANCED AIRBAGS) conçus selon les normes de sécurité américaines applicables aux véhicules à moteur (FMVSS208). Le boîtier électronique (ECU) des sacs de sécurité gonflables régule le déploiement de ces derniers sur la base des informations qu'il reçoit des capteurs, etc., indiqués ci-dessus dans le schéma illustrant les composants du système.
Page 599 ATTENTION ■ Précautions à observer avec les sacs de sécurité gonflables SRS Respectez les précautions suivantes avec les sacs de sécurité gonflables. À défaut, des blessures graves, voire mortelles, pourraient s'ensuivre. ● Le conducteur et tous les passagers à bord du véhicule doivent porter leur ceinture de sécurité...
Page 600 être grièvement blessés ou tués par le déploiement d'un sac de sécurité gonflable. Installez dans un siège de sécurité enfant les enfants trop jeunes pour pouvoir utiliser la ceinture de sécurité. Lexus recommande vivement d'installer tous les nourrissons et enfants aux sièges arrière du véhicule et de prévoir pour eux des systèmes de retenue adaptés.
Page 601 ATTENTION ■ Précautions à observer avec les sacs de sécurité gonflables SRS ● Ne pas s'asseoir sur le bord du siège et ne pas s'appuyer contre la planche de bord. ● Ne laissez pas un enfant rester debout devant le sac de sécurité gonflable SRS passager avant ou bien s'asseoir sur les genoux du passager avant.
Page 602 ATTENTION ■ Précautions à observer avec les sacs de sécurité gonflables SRS ● Ne fixez ni ne posez aucun objet sur la planche de bord, la garniture centrale du moyeu de volant de direction et la partie inférieure du tableau de bord. Au déploiement des sacs de sécurité...
Page 603 Modification et mise au rebut des éléments du système de sacs de sécurité gonflables SRS Consultez impérativement votre concessionnaire Lexus si vous avez besoin d'intervenir sur votre véhicule ou de procéder à l'une des modifications suivantes. Le sac de sécurité gonflable SRS risque de ne pas fonctionner correctement ou de se déclencher (déployer) accidentellement, ce qui pourrait risquer de vous tuer ou...
Page 604: Headlight Aim Instructions For Canadian Owners (In French)
Headlight aim instructions for Canadian owners (in French) The following is a French explanation of headlight aim instructions from the headlight aim section in this manual. ■ Dépose de l'habillage du compartiment moteur Avant Extérieur ■ Vis de réglage dans l'axe vertical Vis de réglage A Vis de réglage B...
Page 605 étape 1 au moyen d'un tournevis cruciforme (empreinte Phillips). Si l'erreur est supérieure à la valeur précédemment indiquée, confiez votre véhicule à votre concessionnaire Lexus pour qu'il règle le faisceau des phares.
Page 607 Index Abbreviation list ....608 Alphabetical index....610 What to do if......622 For vehicles with a navigation system, refer to the “Naviga- tion System Owner’ s Manual” for information regarding the equipment listed below. • Navigation system • Audio/video system •...
Page 608: Abbreviation List
Abbreviation list Abbreviation/Acronym list ABBREVIATIONS MEANING Anti-lock Brake System AI-SHIFT Artificial Intelligence Shift Automatic Locking Retractor Child Restraint System DISP Display Electronic Controlled Transmission Electronic Control Unit Event Data Recorder Emergency Locking Retractor Electric Power Steering ETCS Electronic Throttle Control System GAWR Gross Axle Weight Rating Emission inspection and maintenance...
Page 609 Abbreviation list ABBREVIATIONS MEANING Vehicle Identification Number Vehicle Stability Control...
Page 610: Alphabetical Index
Alphabetical index Alphabetical index A/C* ............242 Audio system* ABS.............. 214 Antenna............ 261 Air conditioning filter ......447 AUX port..........298 ® Bluetooth audio ......303 Air conditioning system Air conditioning filter ....... 447 CD player/changer......264 Automatic air conditioning iPod ............279 system..........242 MP3/WMA disc........271 Airbags Optimal use .........
Page 611 Alphabetical index Back-up lights Child restraint system Wattage ..........568 Booster seats, definition ....122 Battery Booster seats, installation ....129 Checking..........427 Convertible seats, definition...122 If the vehicle has a discharged Convertible seats, installation..129 battery..........532 Front passenger occupant Preparing and checking classification system......117 before winter........
Page 612 Alphabetical index Cigarette lighter........369 Daytime running light system....178 Cleaning Defogger* Exterior ...........396 Rear window ......... 251 Interior............401 Side mirror..........251 Seat belts..........402 Dimension ..........552 Clock ............364 Dinghy towing........238 Compass ..........383 Display Condenser ..........425 Dynamic radar cruise control..194 Console box ...........357 Satellite switch mode.......
Page 613 Alphabetical index Electric power steering ....... 214 Engine Electronic key Compartment........416 If the electronic key does not Engine switch.........147 operate properly......528 Hood............413 Emergency, in case of How to start the engine ....147 If a warning message is Identification number ...... 553 displayed...........
Page 614 Alphabetical index Floor mat ..........373 Fuel Fluid Capacity ..........555 Brake............425 Fuel gauge..........161 Washer...........430 Fuel pump shut off system....490 Fog lights Information ...........569 Switch ............180 Refueling........... 95 Wattage..........568 Fuel door............. 95 Foot well lights ........353 Fuel filler door........... 95 Front fog lights Fuel pump shut off system....490 Switch ............
Page 615 Alphabetical index Headlights I/M test............409 Discharge headlight Identification precautions ........479 Engine............. 553 Replacing light bulbs .......468 Vehicle ........... 553 Switch............176 Ignition switch...........147 Wattage ..........568 Illuminated entry system ....353 Heaters Indicator lights..........167 Seat heaters..........371 Initialization Side mirror..........251 Items to initialize ........590 Hill-start assist control .......
Page 616 Alphabetical index Keyless entry..........44 Maintenance Keys Do-it-yourself maintenance...410 Electronic key......... 28 General maintenance.....406 Engine switch.........147 Maintenance data ......552 If the electronic key does not Maintenance requirements..404 operate properly ......528 Meter If you lose your keys......527 Instrument panel light control..162 Key number..........
Page 617 Alphabetical index Odometer..........161 Parking assist sensors*...... 208 Parking brake.......... 159 Engine oil..........420 Parking lights Opener Replacing light bulbs....... 468 Fuel filler door ........95 Switch............176 Hood ............413 Wattage..........568 Trunk............. 51 PCS ............222 Outer foot lights Personal lights Outer foot lights.........353 Switch............354 Wattage ..........568...
Page 618 Alphabetical index Safety connect ........387 Seats Scuff lights..........353 Adjustment ..........55 Seat belts Adjustment precautions ....60 Adjusting the seat belt......70 Child seats/child restraint Automatic locking retractor.....72 system installation......126 Child restraint system Cleaning ..........401 installation ..........126 Driver’s seat position memory ..61 Cleaning and maintaining Front passenger seat position the seat belts........402...
Page 619 Alphabetical index Side mirror Stuck Adjusting and folding ......79 If your vehicle becomes stuck..539 Mirror position memory ..... 61 Sun visors ..........362 Smart access system with Switch push-button start All window control switch....82 Entry function ..........32 ECT switch..........152 Starting the engine......
Page 620 Alphabetical index Tachometer Towing Tacho indicator........161 Dinghy towing ........238 Tachometer ..........161 Emergency towing......483 Tail lights Trailer towing ........237 Switch ............176 TRAC ............214 Talk switch* ..........326 Traction control........214 Telephone switch*........326 Transmission shift switches..153, 155 Theft deterrent system Trip meter ...........
Page 621 Alphabetical index Warning buzzers Smart access system with Brake system.........491 push-button start ......510 Open door .......... 493 Steering lock..........501 Seat belt reminder ......493 Trunk ............503 Warning lights Washer fluid ........503 Anti-lock brake system ....492 Washer Brake assist system ......492 Checking ..........
Page 622 What to do if... What to do if... P. 513 A tire punctures If you have a flat tire P. 522 If the engine will not start P. 524 The engine does not start Engine immobilizer system P. 98 If the vehicle battery is discharged P.
Page 623 What to do if... A warning light or indicator If a warning light turns on or a warning P. 491 light comes on buzzer sounds... ■Warning lights Brake system warning light Malfunction indicator lamp P. 491 P. 492 Driver’s seat belt reminder “ABS”...
Page 624: Gas Station Information
GAS STATION INFORMATION Auxiliary catch lever Trunk opener Fuel filler door P. 413 P. 51 P. 95 Hood lock release lever Fuel filler door opener Tire inflation pressure P. 413 P. 95 P. 563 Fuel tank capacity 17.2 gal. (65 L, 14.3 Imp. gal.) (Reference) Fuel type Unleaded gasoline only...
