Accessing the Extender's GUI

The Extender features an onboard graphical user interface (GUI) that
includes user-configurable settings. Some of these settings should be
accessed by experienced network technicians only.
To configure the network settings of the Extender:
1. Ensure that the Extender is connected to a gateway/modem, and that
both devices are powered on.
2. On a computer connected to the same network as the gateway/
modem and Extender, log in to the gateway/modem by entering
192.168.99.254
into the address bar of a web browser.
3. The gateway/modem's GUI appears. The IP address of the Extender
should be displayed on the Main or Home screen of an Actiontec
gateway/modem, as indicated below.
4. Write down the IP address of the Extender.
5. Enter the IP address written down in step 4 in the address box of the
web browser.
6
