Transceiver menu system
)
1.3.4 Total reading *
Select sensor ID to read data from with the key.
Start the reading by pressing
Before the transmission begins, the operating voltage
must be given. (see 1.3.3.1)
Each reading is made in turn automatically.
A successful transmission is marked with
A failed transmission is marked with
If the transmission was unsuccessful, an error code
will be displayed
If any reading is unsuccessfull press
key again to repeat the reading.
Back to total reading menu
* ) Not available in all versions.
1.4 Set clock and date
The cursor highlights which digit to adjust. The cursor
is moved to the next digit by pressing the key.
Each digit is changed by using the and
keys.
After changing any digit the status symbol is changed
to X .
When the correct date and clock is set move the
cursor to the X and enter the value by
pressing
This changes the status symbol to
